Chulux JH-C5010 User manual

ESPRESSO
MACHINE
Model: JH-C5010
14
[email protected]
CUSTOMER SERVICE SUPPORT
Be A Better Coee World
Chulux Css@Chulux01

Import Safeguards
Proudct Features
Before First Use
Espresso Making Guide
Milk Frothing Guide
Hot Water Guide
Cleaning & Maintenance
Trouble Shooting
Table of Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
07
High-temperature Alarm Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance & Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Approval information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1 2
Important Safeguards Important Safeguards
CAUTION：When using an electrical appliance, basic safety precautions
should always be followed to reduce the risk of fire, electric shock and/or
injury to persons, including the followings:
1.To ensure safety, please read the instructions carefully and grasp the correct
use method. Save these instructions booklet for future reference.
12.Regularly clean and maintain the coffee machine parts to ensure the
quality of coffee and extend the service life of the coffee machine.
13.Do not move or turn off the power when the coffee machine is working.
14.Do not operate without water.
15.Do not wash the coffee machine or power cord in water or other liquids.
16.Household use only , don’t use outdoors.
17.Before using the coffee machine for the first time, please boil it twice with
clean water to remove the odor.
18.The coffee machine shall not be placed in a cabinet when in working.
19.Cleaning and user maintenance shall not be made by children without
supervision.
20.This appliance can be used by children aged from 18 years and above if
they have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless they
are older than 18 and supervised. Keep the appliance and its cord out of
reach of children aged less than 18 years.
21.Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
22.Children shall not play with the appliance.
23.WARNING: Misuse may cause potential injury. The heating element
surface is subject to residual heat after use.
2.Before using, checks that the voltage of wall outlet corresponds to the rating
label on the bottom of coffee machine.
4.Close supervision is necessary when your appliance is being used near children.
5.To protect against fire, electric shock and injury to persons, do not put the
power cord and plug into water or any other liquid; Do not damage, over bend
or stretch the power cord; Do not place heavy objects on the cord.
6.Do not use the equipment in high temperature, high magnetic field and damp
environment. Do not put the coffee machine on a hot surface, near the fire source
or other electrical appliances, such as refrigerator.
7.Please do not turn on the machine when the wire or plug is damaged, the
coffee machine is out of order or damaged in any way, and return to the nearest
authorized service center for inspection and maintenance, or contact the dealer.
8.Please use original accessories.
9.This machine is only used for making coffee, do not use it for other purposes,
and keep it in a dry environment.
10.Place the coffee machine on a flat surface or on a table. Do not hang the
power cord on the edge of the table or countertop.
11.When operating the coffee machine, do not directly touch the hot parts on
the surface.
3.WARNING: The appliance must be earthed.

3 4
Product Features Product Features
4 5 6 7
No.
1
2
3
4
5
6
7
8
9
10
11
12
Description
Tank Cover
Model: JH-C5010
Voltage: 120V~ 60Hz, 1350W
Removable Water Tank
Steam Control Knob
Power Button
Single Cup Button
Double Cup Button
Steam Button
Pressure Gauge
Steam Wand
Drip Tray
Group Head
Prevent dust or other objects falling
into the tank.
Push back the tank cover & fill with
cold water, or remove the water tank
by opening the cover.
Turn the knob to select steam and
hot water.
The power light is fixdly lighted when it
is warming up and ready.
Pours 1 cup of espresso then
automatically stops.
Pours 2 cup of espresso then
automatically stops.
Steam button is fixdly lighted when it
is steaming.
Monitors espresso extraction pressure
and allows you to make espresso to
better suit your taste.
Ball joint movement with silicone
cover, allows movement of the Steam
Wand to desired position without
burning fingers.
Includes a water level indicator that
floats through the grill to indicate the
tray is full and requires emptying.
For easy positioning of the portafilter.
Portafilter The size for a more even water flow &
improved extraction taste.
Specification
1
2
3
8
11
9
10
12
Coffee Spoon & Tamper
Single Cup Filter
Double Cup Filter

5 6
Before First Use Before First Use
1.Remove Packaging
Ensure all packaging has been removed.
5.Power
6.Insert Portafilter
A. Make sure the steam control knob is in
OFF-position.
B. Insert the Power Plug into a 120V AC power
outlet.
C. Press the Power button to turn on the
machine.
- Both Single cup button and Double cup button
will illuminate & pulse to indicate the machine
is heating up.
- When the Power button, Single cup button
and Double cup button are solid on, the machine is in the READY state.
A. Align the marking dot on the filter with the
portafilter's groove, and then install the filter to
the portafilter, twist and fix the filter.
INSERT
CENTER
2.TURN
1.ALIGN
& INSERT
B. Hold the machine with one hand and the
portafilter with the other hand.
C. Place the portafilter underneath the group
head, so that the handle is aligned with the
INSERT position.
D.Insert the portafilter into the group head and rotate the handle
towards the center until resistance is felt.
Note: Turning the Portafilter to the center position might be tight for
the first few uses.
Note: If the knob is in ON-position, the four
lights will flash together and it will not work.
2.Position Machine
Ensure the espresso machine is always positioned onto a dry, stable, flat
horizontal counter top.
3.Wash & Dry Parts
4.Fill Water Tank
Wash the parts listed below in warm water, rinse & allow thorough air
drying:
A. Extract the water tank by pulling it upwards.
B. Open the lid and fill enough pure
water(recommended) in advance, but not exceed
the MAX line of the water tank, and do not add too
little water, otherwise when the water runs out the
water pump will make a loud noise and affect the coffee effect.
C. Set up the water tank vertically and align the buckles to the hole on
the back of the machine, and then press it down to be parallel to the top
of the machine.
Note: Do not clean or soak the portafilter in any descaling solution,
otherwise, it would be damaged.
Note: More simply, the water tank can also be filled without being
extracted by pouring the water directly from a jug.
- Stainless Steel Single Cup Filter - Portafilter
- Stainless Steel Double Cup Filter - Drip Tray
- Removable Water Tank - Coffee Spoon & Tamper
CENTRE
ON
OFF

7 8
Before First Use
Espresso Making Guide
7.Cleaning
Clean the Group Head
Clean the Steam Wand/Froth Nozzle
A. Put a container under the Group Head.
A. Position the Steam Wand over the Drip Tray,
or place a container with a minimum capacity of
3.4OZ(100ML) under the Forth Nozzle.
B. Turn the Steam Control Knob to the Steam/ Water
icon. Allow water to run through for 20 seconds.
C. Return the Steam Control Knob to OFF-position, and the machine will
return to the READY state.
B. Press the Double cup button, and water should start
flowing from the Group Head. Allow some water to
run through until the machine stops. The machine will
return to the READY state.
Espresso Making Guide
Operation
ON
OFF
ON
OFF
6
1-Check Water
7
Insert the Power Plug.
Press the Power button
to turn the machine on,
the Single cup & Double
cup button will illuminate
& pulse to indicate it's
heating up.
Both Power button,
Single cup & Double cup
button lights are fully
illuminated = Espresso
Machine is ready for use
Place a cup on counter
top and position Steam
Wand. Turn the knob to
Half fill the cup with
hot water to preheat
the cup. Return the
knob to OFF-position
Place a filter into the
portafilter. Select either
the Single-cup filter,or
the Double-cup filter.
Align the marking dot on
the filter with the porta-
filter'sgroove, and then
install the filter to the
portafilter, twist and fix
the filter.
Dose the filter with
coffee grinds.
• One spoon of fine grinds
for the Single cup filter.
• Two spoons of fine grinds
for the Double cup filter.
Evenly tamp(press) the
grinds to level indicated.
Place the portafilter
underneath the group
head so that the handle
is aligned with the
INSERT position.
Extract the water tank by
pulling it upwards.Fill
the water tank with
clean and fresh water
(Do not exceed the
MAX line).
Set up the water tank
vertically and align the
buckles to the hole on
the back of the machine,
and then press it down
to be parallel to the top
of the machine.
Insert the portafilter into
the group head and
rotate the handle
towards the center until
resistance is felt.
Empty the cup. Position the cup on
the drip tray, under the
portafilter. Remove
the drip tray cover if
the cup is too tall.
Around 30S Heat Up
CENTER

9 10
5
Rinse the inner and
outer holes of the
portafilter with clean
water，and be warned
that do not wash the
portafilter with any
descaler.
6
Use a clean cloth to
wipe the filter and
portafilter dry.
3 4
Align the marking dot
on the Filter Basket
with the groove on
the portafilter and
remove it from the
portafilter.
Rinse the front and
back of the filter basket
under the faucet, and
finally rinse the inner
holes and the outer
holes with water.
INSERT
CENTRE
1 2
10 - Remove & Wash
To avoid coffee grinds in
the portafilter splashing
and collapsing, and acc
ompanied by a "bang"
sound, wait 20 seconds
to let the machine relieve
the pressure then twist
the portafilter out of the
machine clockwise.
Discard the coffee puck
in the portafilter.
Re-programming Single-shot Volume Mode
After finishing heating up, to begin re-programming, press & hold the
Single cup button for 3 seconds to enter the user-defined mode.
Espresso Making Guide
Espresso Making Guide
Re-programming Shot Volume
1
9 - Espresso Extraction
Single
cupDouble cup
OR
Press either the Single cup
button or the Double cup
button.
Extraction begins and will
automatically stop,the
machine have five beeps. The
crema of the coffee is golden
brown with a fine mousse
texture. (Around 1.4OZ(40ML)
per cup is recommended.）
2
When you reach your
desired 1 shot volume,
press the Single cup button
again, the espresso pour
will stop.(Shot Volume
Range: 1-2OZ(30-60ML)
2 3
When the machine have a
beep The new ONE CUP esp
resso shot volume has
been saved and the
machine will return to
the READY state.
NOTE: The setting longest time is 60 seconds. If the setting time is
invalid more than 60 seconds, the machine will remain the
default time.
Re-programming Double-shot Volume Mode
Press Single cup button
once, the espresso will
start to pour.
1
1
1
Press Double cup button
once, the espresso will
start to pour.
2
When you reach your
desired 2 shot volume,
press the Double cup
button. The espre sso pour
will stop.(Shot Volume
Range: 2-3OZ(60-90ML)
3
When the machine have a
beepThe new TWO CUP
espresso shot volume has
been saved and the machine
will return to the READY state.

1221
Resetting Default Volumes
11
Espresso Making Guide
High-temperature Alarm Guide
Milk Frothing Guide
Operation
If you accidentally press the steam button or immediately brew coffee
after steaming, the temperature will be too high, and it is not suitable for
brewing coffee, there will be a high-temperature alarm by pressing the
Single cup button or Double cup button, at this point,the Single cup
button and Double cup button are blinking blue light quickly. The
machine needs to be cooled.
Cool the machine for espresso making
A. Place a cup under the froth nozzle.
B. Turn the Steam control knob to the steam/water position to release
water out for making the machine cool down.
C. Turn the Steam control knob to OFF position. It can make coffee when
the Single cup & Double cup button is fixly lighted.
6
7 8 9
12 O CLOCK
,
3 O CLOCK
,
ON
OFF
ON
OFF
1 2
To reset the machine to
the default shot volumes,
turn off the machine ,
press and hold together
Single cup button &
Steam button for 3
seconds. When both
buttons are on and the
machine have a beep.
Then the default settings
of brewing espresso will
be restored and the
machine will be back to
stand by state.
Insert the Power Plug.Press the
Power button to turn the machine
on,the Single cup & Double cup
button will illuminate & pulse to
indicate it's heating up.
Both Power button, Single cup &
Double cup button lights are fully
illuminated = Espresso Machine is
ready for use
Press the steam button and
start to blink blue light slowly
The steam button keeps blue
light fixed. It means the heating
for steam is finished.
Turn the Steam control Knob
to the steam icon.
Release some steam out from
the steam wand before
performing milk frothing.
Pause steam by returning
knob to OFF-position
Hold the position below the tip
of the milk foam cup and the
bottom of the milk foam cup
with your left hand, and hold
the handle of the milk foam
cup with your right hand.
The steam wand arm is at 12
o'clock. The froth nozzle is at 3
o'clock. The milk is just soaked
to the 2mm position of the Froth
Nozzle.
1 2 3
4 5

To make sure coffee machine operating efficiently, internal piping is cleanly
and the peak flavor of coffee, the coffee machine needs to be descaled,
cleaned and maintained periodically.
Descaling warning will be shown when the appliance has cumulatively
worked for 300 cycles. At that time, all indicators will flash and sound for
5 times, which means that the coffee machine needs to be performed
descaling, and then the appliance will go back into normal condition.
Descaling warning will be shown each time when you turn on the appliance
if you do not cancel.
142113
Milk Frothing Guide
10 11 12
15
17
1413
1 - Check Water
2
2 - Start Up
1 2
Around 30S Heat Up READY
3 - Hot Water
1 2 3
Hot Water Guide
Cleaning & Maintenance
ON
OFF
ON
OFF
ON
OFF
ON
OFF
The position of the left hand is
fixed, and the right hand turns
the Steam Control Knob to the
steam icon to start frothing the
milk.
Extract the water tank by
pulling it upwards.
Fill the water tank
with clean and fresh
water(Do not exceed
the MAX line).
Set up the water tank
vertically and align the
buckles to the hole on
the back of the machine,
and then press it down
to be parallel to the top
of the machine.
Place a cup on the counter
top and position the
steam wand. Turn the
knob to " " icon to start
releasing hot water.
Hot water will pour from
the steam wand and can be
used for making
Americanos and pre
heating cups.
To stop the hot water,
return the knob to the
OFF-position
Insert the Power Plug.
Press the Powe button to
turn the machine on,the
Single cup & Double cup
button will illuminate &
pulse to indicate it's
heating up.
Both Power button,
Single cup & Double cup
button lights are fully
illuminated = Espresso
Machine is ready for use
Frothing makes a smooth
hissing sound.
Check that the milk is swirling
As the milk level rises, lower
the milk foam cup to keep the
froth nozzle below the surface.
When the desired micro-foam
is reached, submerge the steam
wand halfway
Milk frothing is complete when
the base of the milk foam cup
is too hot to touch for 3 seconds.
- Press the steam button and
finish to blink blue.
- Now Return to the READY
state.
Use the black Steam Wand
handle on the Steam Wand to
move the steam wand from the
milk foam cup
Turn the Steam Control Knob to
the OFF position.
16
1

162115
Cleaning & Maintenance Cleaning & Maintenance
Descaling Cycle
1.TURN
2.REMOVE
CENTRE
INSERT
1 2 3
5
7 8
Repeat
Step 11-13
for 2-3 times
with clean water
ESPRESSO
MACHINE
CLEANING
TABLETS
PLEASE EMPTY TRAY
REMOVE
STEAM
FILTER
UNSCREW
INSERT
INSERT
D
U
A
L
W
A
L
L
LOCK
10 11 12
14 15
17 18
13
16
Twist the portafilter out of the
machine clockwise to avoid co-
ffee grinds in the portafilter spl
ashing and collapsing, and acc
ompanied by a "bang" sound.
Pour out the remaining water
in the water tank.
Make sure Power button, Single cup
& Double cup button are solid
on(the machine has been
preheated).
Press the Double cup button to pour
the descaling solution. Repeat step
11 for 3 times.
Wait until running out all the de scaling
solution in the tank and take out the
container, pour away the descaling
solution.
Remove the drip tray and pour
away the descaling solution.
Repeat step 11-13 for several times
with clean water until there is no
descaler smell.
Use a clean cloth to wipe off the
coffee grinds and water stains left on
the Group Head.
Remove the drip tray from the
machine and empty it.
Rinse the drip tray and the drip
tray cover with clean water.
Wipe the drip tray with a cloth a nd
install it back
Put a container under the Group
Head.
Wait for the heating of the machine
to complete, that is, the blue lights
of the Power Button, Single Cup
Button, Double Cup Button are
solid on.
Press the Single Cup Button to
dispense some discaling solution.
Put the container back under the
Group Head. Let the descaling
solution soaks the limescale inside
the machine for 30 minutes.
Empty the container. After 30 minutes, press the Power
button to turn the machine on, the
Singles cup & Double cup button
will illuminate and pulse to indicate
it's heating up.
Fill the water tank with water to
the MAX marking that is 40OZ(1200ML)
and then add 30 grams of the
descaling agent into the water tank,
then mix them evenly.
4 6
9
Around 30S Heat Up
