Ciao Bella 4 Quattro Guide

Owner’s Manual
& User’s Guide

Explosive View & Parts List
OWNER’S MANUAL & USER’S GUIDE
2CIAOBELLAPIZZAOVENS.COM

3
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE

4
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
• Only use the oven on a hard, level, non-combustible,
stable surface (concrete, stone, etc.) capable of
supporting the weight of the oven. Never use the oven on
wooden or other combustible surfaces.
• Maintain proper clearance of 3 meters (apx. 10’) between
the oven and combustible materials (bushes, trees,
wooden decks, fences, buildings, etc.) at all times when
the oven is in use. BEWARE of flying sparks from the oven
mouth.
• Do not place the oven under a roof covering, awning,
overhang, or other enclosed area.
• FOR OUTDOOR USE ONLY. Do not operate the oven
indoors or in an enclosed area. In windy weather, place
the oven in an outdoor area that is protected from the
wind.
• Do not use petrol, kerosene, or alcohol for lighting wood.
Use of any of these or similar products will cause an
explosion, possibly leading to severe bodily injury.
• Never add charcoal lighting fluid to hot, or even warm
coals, to start or “freshen up” a fire in the oven, as
flashback or an explosion may occur, causing severe
burns.
• Use firewood for burning only. DO NOT use charcoal,
charcoal pre-treated with lighter fluid, pressure-treated
lumber, chipped wood products, sappy wood (such as
pine,) laminated wood, or any material other than dry,
untreated, medium or hard firewood in your oven. Use
extreme caution when adding wood during cooking.
• The oven will be extremely hot during use. Use caution
when reaching into the oven. To protect yourself from
burns, always wear shoes, long oven mitts or gloves,
protective clothing with long sleeves, and the correct
flame-resistant tools while operating this oven. Avoid
touching hot surfaces and be very careful when
removing the oven door.
• Place the oven in an area where children and pets
cannot come into contact with the unit. Close
supervision is necessary when the oven is in use. Do not
leave the oven unattended when it is in use.
• Lock the caster wheels before use. Never move the oven
when it is in use, or when it contains hot coals or ashes.
• Do not store or use the oven near petrol or other
flammable liquids, or where gases or flammable vapors
may be present.
• Improper installation, amendment, service, or
maintenance may cause property damage, personal
injury, or death.
• Use caution when assembling and operating your oven
to avoid scrapes or cuts from any sharp edges on the
metal parts.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory,
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the oven by a person
responsible for their safety.
Warning
PLEASE READ AND FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS
IN THIS MANUAL TO AVOID PERSONAL INJURY OR PROPERTY DAMAGE.
• WE WANT YOU TO ASSEMBLE AND USE YOUR OVEN AS SAFELY AS POSSIBLE.
• THE PURPOSE OF THIS SAFETY ALERT SYMBOL ⚠ IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU
ASSEMBLE AND USE YOUR OVEN.
• WHEN YOU SEE THE SAFETY ALERT SYMBOL, PLEASE PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS.
• READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING & OPERATING YOUR OVEN.

5
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
2. Attach 4x Wheels (Part #20) and
Wheel Covers (Part #14) to legs with
16x M6*12 Screws (Part #15).
1. You must first remove all
protective stainless steel
film from stainless steel
cart when assembling. The
grey film is used to protect
from scratches. Follow the
arrows and peel back.
HINT #1: To speed up the process of
removing the protect film — use a
heat gun or hair dryer to warm up the
material and it will peel off with ease.
HINT #2: RECOMMENDED SETUP OF
YOUR CIAO BELLA PIZZA OVEN
Choose a flat, cleared assembly area.
This oven is best assembled with two
or more people. Unpack the parts and
place them on the cardboard box or a
furniture blanket to prevent scratches.
PLEASE NOTE: 2PCS WHEELS WITH
BRAKE INSTALLED IN THE BACK SIDE
WHICH PLATE HAS 6 HOLES.
5CIAOBELLAPIZZAOVENS.COM

6
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
3. Attach Trolley Bottom Plate
(Part #12) to legs with 8x M6*12
Screws (Part #15).
4. Attach Trolley Rear Plate
(Part #9) to step 2 with 11x M6*12
Screws (Part #15).
5. Attach Trolley Beam (Part #17)
to step 3 with 4x M6*12 Screws
(Part #15).
6. Attach Trolley’s Bar (Part #8)
to step 4 with 8x M6*12 Screws
(Part #15).

7
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
7. Attach handle to Oven Body
(Part #5).
8. Put Oven Body (Part #5) onto Trolley.
NOTE: A CIAO BELLA PIZZA OVEN WEIGHS OVER 300 LBS AND LIFTING IT IS A TWO TO FOUR PERSON
JOB. KEEP THE OVEN UPRIGHT WHEN MOVING IT. TIPPING THE OVEN OR TURNING IT ON ITS SIDE MAY
RESULT IN SIGNIFICANT DAMAGE TO THE UNIT. THIS DAMAGE IS NOT COVERED UNDER THE WARRANTY.
IF NEEDED, REMOVE STONES TO MAKE OVEN LIGHTER TO LIFT BEFORE PLACING IT ON TROLLEY OR
COUNTER TOP. ONCE COMPLETED, THEN YOU MAY REMOVE THE HANDLE.

8
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
9. Attach right Side Table (Part #10) as
shown with 5x M6*12 Screws (Part #15).
9. Attach left Side Table (Part #10) as
shown with 5x M6*12 Screws (Part #15).

9
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
11. Attach Chimney Cover (Part
#1) to top of Chimney (Part #10).
Use 5x M6*12 Screws (Part #15).
12. Attach Chimney (Part #3)
to the top of the oven with 4x
M6*40 Screws (Part #15).
Wipe down with a stainless
steel cleaner and enjoy!.
NOTE: INSTALL CHIMNEY WITH HANDLE FACING
THE BACK INSTEAD OF FRONT.

10
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
Preliminary Safety Messages:
As this oven uses a naked flame, it is advisable to keep a well-maintained fire
extinguisher close by for safety.
Ensure the oven is not overloaded with firewood and that burning logs cannot roll out.
DO NOT OVER-FIRE. The oven temperature should not exceed 800° F. “Over-firing” by
exceeding this temperature, or having flames spill out the front of the oven, may cause
personal injury and/or damage to the pizza oven which is not covered under the warranty.
Due to the intense heat, please use due care when operating this oven. These units have
been designed as ovens for cooking purposes, not as a general wood fire for outdoor
heating.
Recommended maximum cooking temperature is 750° F?
See Page ? of this manual for additional warnings and instructions on using your oven.
Firing Your Oven:
When firing up your oven, it is recommended that you gradually heat the oven to the
desired temperature. Maximum airflow is recommended to get your fire going, so do not
place the door over the mouth of the oven when lighting your fire.
Start your fire in the center of the oven’s cooking floor using dry kindling and a taste-free,
odor-free fireblock or fire starter. Build your fire up slowly, adding wood to the back and
sides as the fire grows. Once the fire is burning consistently, add wood as required (just a
few pieces of wood will be needed.) Let the fire burn for about 15−20 minutes, or until the fire
has settled with minimal smoke output, and the oven is at the desired heat.
To prepare for cooking, move the fire to one side of the oven and brush the oven floor. Only
use a copper or brass brush. Do not use steel wire brushes, natural fiber brushes, or wet
cloths to clean the oven floor.
Cooking should commence when the coals have formed. Additional firewood can be
added as necessary to sustain the required heat. To maintain the most consistent oven

11
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
temperature, use your metal pizza peel to place any new wood inside of the oven away
from the active fire for a few minutes. When the wood has warmed, move it over onto the
coals. Never toss or throw wood into the oven or directly onto the fire.
Always check the temperature gauge or use a point-and-shoot infrared thermometer to
ensure the oven is maintaining the desired temperature. Note: Shooting an infrared
thermometer directly into the flame will give varying readings.
An open oven mouth (i.e. no door covering the opening) allows extra air flow. This is useful
when lighting the fire, or for boosting the fire when adding firewood. Partially blocking the
mouth of the oven with the door will reduce the flame size, intensity, and heat, allowing for a
more controlled cooking temperature. Do not completely cover the mouth of the oven with
the door when there is a live flame inside.
BEWARE of very high temperatures in the oven and use long oven gloves and mitts to
handle pots and tools. DO NOT put unprotected hands or arms inside of the oven while it
is lit.
Firewood and Fuels:
The efficiency of the oven depends on the quality of the firewood used. Only dry wood
should be used, as damp wood produces excessive smoke and will delay the oven reaching
the desired operating temperature. Double-split wood in lengths of 12”−16” and 2”−5”
diameter is preferred.
Visit www.ciaobellapizzaovens.ca to learn more about firewood types, properties, and
recommendations.
Use solid wood fuels only. DO NOT use charcoal, pressure treated lumber, chipped wood
products, sappy wood (such as pine,) laminated wood, or any material other than dry,
medium or hard firewood.
DO NOT use liquid fuel (firelighter fluid, gasoline, lantern oil, kerosene, or similar liquids) to
start, “freshen up,” or maintain the fire.

12
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
Oven Clearances:
The Ciao Bella Pizza Ovens is designed for outdoor use only. BEWARE of flying sparks from
the mouth of the oven. It is essential to maintain clearance space between the oven
components and any combustible material, such as walls, ceilings, awnings, canopies,
foliage, or construction materials. The oven must have a minimum 10 feet (apx. 3 meters)
Oven Door:
When removing the door, use a mitt to avoid contact with the hot surface. Place the door on
the storage tray of the pizza oven for safe keeping. NEVER close the oven door completely
when a fire is burning, as this cuts off oxygen, which can cause the fire to erupt when the
door is removed.
Water:
• Water can damage the inside of your oven. You must ensure that no water enters the
oven chamber, either through the oven door opening, or through the chimney.
• Always place the provided metal door in the oven opening when not in use to stop water
from entering through the opening into the oven chamber.
• Do not install the oven at a backward-leaning angle, where water could enter the oven
and pool, causing damage.
• Do not ice or wet-mop the oven floor.
• Water is not required to clean the cooking floor. The oven operates at very high tem-
peratures. The high heat acts as an automatic “self-cleaning” mode, burning off all
spilled or stuck-on foods. If stuck-on food is a problem during cooking, you can remove
it with a brass oven brush. As a preventative measure, non-dough based foods should
always be placed on appropriate cookware before being placed in the oven.

13
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
Soot:
Over time, the top of the opening to your oven will darken with soot. While your Ciao Bella’s
vent and chimney system do an excellent job of drawing smoke out of the oven chamber,
soot is an unavoidable part of any wood oven. You can occasionally clean the oven
opening with soap and water (with the door firmly in place,) only when the oven is cool and
not in use or you can allow the opening to naturally become black. Ensure there is enough
clearance to combustibles from all sides and top when in use. See Page 4 for specific
details. Failure to maintain these clearances can result in fire.
Maintenance and Cleaning Instructions:
• To prevent a possible burn injury, always allow the oven to cool before cleaning.
• For painted models, use warm soapy water and a soft cloth to clean the exterior of the
oven. Do not use oven cleaner, as it may damage the surface coating. Use a stainless
steel cleaner for stainless steel models.
• Do not dispose of ash residue or unburnt charcoal briquettes until they have completely
cooled. Do clean the ashes out of your oven before you light a new fire. Old, cold ashes
will get in the way of baking food.
• Disposal of Ashes: Ashes should be placed in a metal container with a tight-fitting lid.
Pending disposal, the closed container of ashes should be placed on a non-combusti-
ble floor or on the ground, well away from all combustible materials.

14
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
Roasting:
450°F – 600°F
Fire: Medium-sized bed of coals and a small flame of 2”−4” high.
Type: Used to sear meats, and brown vegetables or casseroles before covering with a lid or
liquid to finish cooking completely.
Tools: Cast iron pan or good cast iron/terracotta pot.
Baking:
The oven door should be used to have heat circulate properly when baking. The door
should be removed when cooking pizza.
Tips: Add your ingredients in layers, sautéing and browning them as needed. Add your
liquid ingredients at the end, and cover your pan to bake. (This not only keeps you out of
the kitchen and reduces the number of pans you have to clean, it also holds all of the
flavors of your ingredients in your food.)
Warming and Melting:
MOUTH OF THE OVEN
Fire: Place the dish at the front of the oven away from the direct heat and let warm.
Type: Warm a sauce or stock, melt butter, or make flavored olive oils for dipping.
Tools: Small heat-safe dish, cup, or pan:
Ways to use Ciao Bella Pizza Ovens

15
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
Sautéing:
450°F – 600°F
Fire: Small to mid-sized fire with coals.
Type: Onions, garlic, carrots, ground beef.
Tools: Metal or cast iron pan.
Tips: Preheat the pan for a minute or two, add your olive oil, and return the pan for a few
seconds. Add chopped vegetables, or anything else you need to sauté, and return the pan
to the oven for a few minutes. You can either slightly sauté vegetables until they are soft
and translucent, or leave them in longer to brown the vegetables and build up the browned
bits that you can reduced into a sauce with a splash of wine. You can leave your pan in
even longer to caramelize your onions.
Combination Cooking:
400°F – 600°F
Fire: Small to mid-sized fire with coals. Hot to start, cooler temps to finish baking.
Type: Coq au Vin, Chicken Fricassee, and baked vegetable dishes.
Tools: Cook in a single oven-safe pan.
Tips: Add your ingredients in layers, sautéing and browning them as needed. Add your
liquid ingredients at the end, and cover your pan to bake. (This not only keeps you out of
the kitchen and reduces the number of pans you have to clean, it also holds all of the
flavors of your ingredients in your pan and in your food.)

16
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
Grilling
Hot Coals
Fire: Fire the oven, then rake a layer of hot coals across the cooking floor.
Type: Meats and vegetables.
Tools: Place a free standing cast iron grill into the oven over the coals (The Tuscan Grill is
available in the online store.) Allow it to heat up before placing food on top.
Tips: Your food will cook faster in a Ciao Bella oven than a traditional grill, leaving it moist
and tender. (It cooks 3 ways – heat of the grill, coals underneath, & hot dome above.)
Be careful not to overcook your food.
Browning:
450°F – 600°F
Fire: Small to mid-sized fire with coals.
Type: Meats and vegetables.
Tools: The reflected heat from the fire acts like a broiler for searing and browning. Cast iron
skillets work well for this style.

17
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
TIP FROM OUR CHEF?: IF YOU ARE COOKING PIZZA SEQUENTIALLY FOR A LARGE GATHERING, AFTER YOU
FINISH EACH PIZZA, PULL SOME COALS OUT ONTO THE COOKING FLOOR TO QUICKLY “RECHARGE IT.”
(MAYBE INSTEAD OF “RECHARGE”) REHEAT THE OVEN FLOOR AGAIN. THIS PROMOTES EVEN COOKING
TO THE UNDERSIDE OF YOUR PIZZA. WHEN YOUR NEXT PIZZA IS PREPARED AND READY TO GO IN, SIMPLY
PUSH THE COALS BACK TO THE SIDE, GIVE THE FLOOR A QUICK BRUSH OFF, AND BEGIN COOKING AGAIN.
BAKEWARE TO AVOID?:WHITE PORCELAIN COOKWARE TENDS TO CRACK IN WOOD FIRED OVENS. BE
CAREFUL WITH CAST IRON/TERRACOTTA-LOOKING PANS MASS-PRODUCED IN ASIA.
THEY MIGHT NOT WITHSTAND THE TEMPERATURE OF YOUR WOOD FIRED OVEN. CAST IRON /TERRACOTTA
PANS THAT ARE GUARANTEED TO WORK WELL IN YOUR OVEN ARE AVAILABLE IN THE CIAO BELLA PIZZA
OVENS ONLINE STORE.
IN GENERAL, BE CAREFUL WITH ANY CERAMIC PAN THAT YOU WOULD BE SAD TO LOSE. BETTER SAFE
THAN SORRY. THE COMBINATION OF HIGH HEAT, FLAME, AND BEING MOVED AROUND WITH A PIZZA PEEL
CAN BE ROUGH ON ANY PAN.

18
OWNER’S MANUAL & USER’S GUIDE
CIAOBELLAPIZZAOVENS.COM
Limited Warranty | Ciao Bella Pizza Ovens
THE WARRANTY
Ciao Bella Pizza Ovens, a producer and importer of quality ovens , warrants its Ciao Bella Pizza Ovens and
their components, including oven body, floor, venting system, factory-installed finishes, stand, door, and
accessories (herein referred to as Product) to be free from defects in materials and workmanship for a
period of two (2) years from the date of shipment. Additionally, Ciao Bella Pizza Ovens warrants the
internal dome welds on the oven to be free from defects for a period of five (5) years. Warranty may be
invalidated if Product is not correctly installed, operated, and maintained according to all supplied
instructions.
QUALIFICATIONS TO THE WARRANTY
The complete Product Warranty outlined above does not apply under the following circumstances:
(1) The Product was not installed in accordance with Ciao Bella Pizza Ovens installation instructions and
local building codes.
(2) This Warranty does not apply to any hairline cracking in the ceramic cooking floor, or any problems
caused by over-firing, as defined in the Owner’s Manual.
(3) The Product has been subjected to non-standard use, including but not limited to, tossing or throwing
firewood into the oven with force, addition of non-approved appliances or burners, use of improper tools,
burning fuels with abnormal burning characteristics, including: driftwood, coal, plywood, and wood
products using a binder that may burn at excessive temperatures and cause damage to the Product.
(4) The Product has been subjected to icing or wet-mopping the oven while it is still heated (which can
cause cracking or damage to the oven floor,) or improper chemicals or liquids have been used to clean
or sanitize the interior of the oven.
(5) This Warranty does not cover damage caused from storing any materials on the top of the oven.
(6) This Warranty does not apply to normal wear and tear of the Product, or on parts that would be worn
or replaced under normal conditions, including:
(a) Normal, minor cracking due to expansion and contraction stress relief in the refractory materials of
the floor tiles.
(b) Scratch marks on the stainless steel or powder coated finishes from normal use.
(c) Discoloration of exterior finishes in areas repeatedly exposed to smoke, as this is considered normal
wear on wood fired pizza ovens.
(7) This Warranty does not cover damage to, or failure of the Product, resulting from natural causes, or
other catastrophe, such as flood, fire, earth movement, wind, or storms.
LIMITATION ON LIABILITY
It is expressly agreed and understood that Ciao Bella Pizza Ovens sole obligation, and Purchaser’s
exclusive remedy under this Warranty, and under any other Warranty, expressed or implied otherwise,
shall be limited to replacement, repair, or refund up to the original purchase price of the Product,

19
CIAOBELLAPIZZAOVENS.COM
OWNER’S MANUAL & USER’S GUIDE
excluding shipping costs, as specified above. Such liability shall not include, and Purchaser or other third
parties, specifically renounce any rights to recover special, incidental, consequential, or other damages of
any kind whatsoever, including, but not limited to, injuries to persons or damage to property, loss of profits
or anticipated profits, damage to business reputation or goodwill, all costs incurred receiving, unloading,
moving at your location, and installing Ciao Bella Pizza Ovens Products, or loss of use of the Product.
In no event shall Ciao Bella Pizza Ovens be responsible for any incidental or consequential damages
caused by defects in its Products, whether such damage occurs, or is discovered before or after
replacement or repair, and whether or not such damage is caused by Ciao Bella Pizza Ovens. The duration
of any Warranty with respect to this Product is limited to legitimate claims received within the duration of
the foregoing Warranty.
Warranty of replacement parts or Product shall only be from the original purchase date of Product, not
date of repair or replacement covered under this Warranty. Parts to be replaced under the Warranty will
be repaired or replaced with new or functionally sound parts at Ciao Bella Pizza Ovens option.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, or the
duration of an implied warranty, so the above exclusion or limitations may not apply to you.
INVESTIGATION OF CLAIMS AGAINST WARRANTY
Ciao Bella Pizza Ovens reserves the right to investigate any and all claims against this Warranty and to
decide upon the method of settlement.
Before any Product is returned,Ciao Bella Pizza Ovens, or its authorized representative, must provide
Purchaser with written return authorization and instructions for preparation of the shipment. Failure to
properly package Product for return may result in Purchaser being billed by Ciao Bella Pizza Ovens. Ciao
Bella Pizza Ovens reserves the right to bill Purchaser for return freight if Product was found to be damaged
through negligence or Warranty was voided, as outlined in this Warranty. Reference your original Terms of
Sale Agreement for additional details.
DEALERS HAVE NO AUTHORITY TO ALTER THIS WARRANTY
Ciao Bella Pizza Ovens employees and dealers have no authority to make any Warranties, nor to authorize
any remedies in addition to, or inconsistent with, those stated above.
HOW TO REGISTER A CLAIM AGAINST WARRANTY
In order for any claim under this Warranty to be valid, Ciao Bella Pizza Ovens must be notified of the
claimed defect by either: (CIAO BELLA INFO)
All claims against this Warranty should include the Product model, original invoice number, date of
installation, a description of the defect, photographs of the area of concern, and a full description of the
circumstances giving rise to the Warranty Claim, if known. Please examine all of the contents of your
delivery as soon as possible after receipt and inform Ciao Bella Pizza Ovens within ten (10) days if any
items are missing, incorrect, or damaged.

ENJOY
YOUR
BRAND
NEW
OVEN.
CIAO.
[email protected]
ciaobellapizzaovens.com
Don’t forget to share posts
and stories on Instagram
and Facebook.
