MR30H Installation Guide
The Cisco Meraki MR30H is a dual-band 802.11ac cloud-managed access point with integrated Ethernet switch.
Designed for room wireless and wired connectivity, the MR30H is easy to install on the wall on a single gang box, and is
the first cloud managed hospitality AP.
Package Contents
The MR30H package contains the following:
MR30H Cloud-Managed Access Point
1

Mount cradle
Mount Kit
• Wall screws, wall screw anchors, and security screws
• Eject/Security Screw tool
2

Security Features
The MR30H features multiple options for physically securing the access point after installation:
1. Security screw – The accessory kit includes screws that can be used to secure the access point to the mount
cradle. Engaging the security screw prevents accidental dislodging and theft.
Ethernet Ports
Uplink
The MR30H features a Gigabit Ethernet RJ45 port that accepts 802.3at and 802.3af power on the rear of the unit.
This port should be used for uplink to your WAN connection.
LAN Access Ports
The MR30H features 4x LAN ports labeled 1 through 4. Port 1 may provide 802.3af out to a end device if the
MR30H is powered via a 802.3at power source. Configuration details can be found in the AP port profiles article.
3

Power Source Options
The MR30H access point can be powered via PoE using either the Meraki PoE Injector (sold separately), or a PoE
switch.
Factory Reset Button
If the button is pressed and held for at least five seconds and then released, the MR30H will reboot and be restored to
its original factory settings by deleting all configuration information stored on the unit.
The MR30H will function in low power mode when powered by a 802.3af power source. While in low power
mode, the MR30H will disable 802.3af out on the LAN1 port. Despite being in low power mode, the device can
still supply full wireless capabilities.
The factory reset button is located on the rear of the unit and must be ejected from the mount plate in order to
be activated.
4

LED Indicators
System Status
The MR30H is equipped with a multi-color LED light on the front of the unit on the top right to convey information
about system functionality and performance. The LED shines through the faceplate of the AP and is not visible
when either disabled via Run Dark mode or powered off.
• Orange - AP is booting (permanent Orange suggests hardware issue)
• Blinking Orange - AP can't find uplink
• Rainbow - AP is initializing/scanning
• Blue - AP in Gateway mode with clients
• Blinking Blue - AP is upgrading
• Green - AP in Gateway mode with no clients
Ethernet Status
The MR30H features four green Ethernet status LEDs near the bottom of the faceplate. When an Ethernet client
is connected, the LED will shine through the faceplate if Run Dark mode is not enabled.
Run Dark Mode
The MR30H may be operated in “Run Dark” mode for additional security and to reduce the visibility of the access
point. In this mode, the LED will not be illuminated. This mode may be configured through Meraki dashboard.
5

Pre-Install Preparation
You should complete the following steps before going on-site to perform an installation.
Configure Your Network in Dashboard
The following is a brief overview only of the steps required to add an MR30H to your network. For detailed instructions
about creating, configuring and managing Meraki wireless networks, refer to the online documentation
(documentation.meraki.com).
1. Login to http://dashboard.meraki.com. If this is your first time, create a new account.
2. Find the network to which you plan to add your APs or create a new network.
3. Add your APs to your network. You will need your Meraki order number (found on your invoice) or the serial
number of each AP, which looks like Qxxx-xxxx-xxxx, and is found on the bottom of the unit. You will also need
your Enterprise license key, which you should have received via email.
4. Go to the map / floor plan view and place each AP on the map by clicking and dragging it to the location where you
plan to mount it.
Check and Upgrade Firmware
To ensure your MR30H performs optimally immediately following installation, it is recommended that you facilitate a
firmware upgrade prior to mounting your MR30H.
1. Attach your MR30H to power and a wired Internet connection. See the "Power the MR30H" section for details.
2. The MR30H will turn on and the LED will glow solid orange. If the unit does not require a firmware upgrade, the
LED will turn either green (no clients associated) or blue (clients associated) within thirty seconds.
* If the unit requires an upgrade, the LED will begin blinking orange until the upgrade is complete, at which point the LED
will turn solid green or blue. You should allow at least a few minutes for the firmware upgrade to complete, depending on
the speed of your internet connection.
Check and Configure Firewall Settings
If a firewall is in place, it must allow outgoing connections on particular ports to particular IP addresses. Check the
Meraki Dashboard under the help section for Firewall inforamtion.
Assigning an IP Address to the MR30H
All gateway MR30Hs (MR30Hs with Ethernet connections to the LAN) must be assigned routable IP addresses. These
IP addresses can be dynamically assigned via DHCP or statically assigned.
When a MR30H is rebooted with rundark mode enabled, a orange LED will illuminate during boot then all lights
will be turned off after boot.
6

Dynamic Assignment
When using DHCP, the DHCP server should be configured to assign a static IP address for each MAC address
belonging to a Meraki AP. Other features of the wireless network, such as 802.1X authentication, may rely on the
property that the APs have static IP addresses.
Static Assignment
Static IPs are assigned using the local web server on each AP. The following procedure describes how to set the
static IP:
1. Using a client machine (e.g., a laptop), connect to the AP wirelessly (by associating to any SSID
broadcast by the AP) or over a wired connection.
2. If using a wired connection, connect the client machine to the MR30H either through a PoE switch or a
PoE Injector. If using a PoE switch, plug an Ethernet cable into the MR30H’s Ethernet jack, and the
other end into a PoE switch. Then connect the client machine over Ethernet cable to the PoE switch. If
using a PoE Injector, connect the MR30H to the “PoE” port of the Injector, and the client machine to the
“LAN” port.
3. Using a web browser on the client machine, access the AP’s built-in web server by browsing
to http://my.meraki.com. Alternatively, browse to http://10.128.128.128.
4. Click on the “Uplink Configuration” tab. Log in. The default login is the serial number (e.g. Qxxx-xxxx-
xxxx), with no password (e.g., Q2DD-551C-ZYW3).
5. Configure the static IP address, net mask, gateway IP address and DNS servers that this AP will use on
its wired connection.
6. If necessary, reconnect the AP to the LAN.
Static IP via DHCP Reservations
Instead of associating to each Meraki AP individually to configure static IP addresses, an administrator can
assign static IP addresses on the upstream DHCP server. Through “DHCP reservations,” IP addresses are
“reserved” for the MAC addresses of the Meraki APs. Please consult the documentation for the DHCP server to
configure DHCP reservations.
Installation Instructions
Choose Your Mounting Location
A good mounting location is important to getting the best performance out of your MR30H access point. Keep the
following in mind:
1. The device should have unobstructed line of sight to most coverage areas for highest performance.
2. Power over Ethernet supports a maximum cable length of 300 ft (100 m).
7

Install the MR30H
For most mounting scenarios, the MR30H mount cradle provides a quick, simple, and flexible means of mounting your
device. The installation should be done in two steps. First, install the mount cradle to your selected location. Then,
attach the MR30H to the mount cradle.
Attach the mount cradle
The MR30H can be mounted to a 4” square cable junction box and European outlet boxes (mounting screws are
not included).
Using appropriate mounting hardware for your specific type of junction box, attach the mount cradle to the
junction box.
Attach the MR30H to the Mount Cradle
To attach the MR30H to the mount cradle properly, line up the top edge of the AP with the top tab of the mount
cradle. Since the cradle is already mounted to the wall, guide the MR30H towards the top tab and insert the top
tabs into the MR30H’s slot.
8

Then adjust the MR30H to guide the MR30H’s bottom slot into the cradle’s bottom tab until it clicks into place.
Once in place, the MR30H should be secured to the cradle by using one of the included screws in the cradle’s
bottom tab.
9

Secure the MR30H
Depending on your mounting environment, you may want to secure the MR30H to its mount location. Your
MR30H can be secured via security screw (Torx security screws are included).
10

Ejecting MR30H from mount plate
To release the MR30H from the mount cradle, first remove the security screw that secures the MR30H to the cradle’s
bottom tab. While holding the MR30H with one hand, use the eject tool to trigger the release mechnisim. Then remove
the MR30H from the cradle’s top tab.
11

Verify Device Functionality and Test Network Coverage
1. Check LEDs
a. The Power LED should be solid green (or blue, if clients are connected). If it is flashing blue, the firmware is
automatically upgrading and the LED should turn green when the upgrade is completed (normally within a
few minutes). See the "LED Indicators" section for more details. .
b. Note: Your MR30H must have an active route to the Internet to check and upgrade its firmware.
2. Verify access point connectivity
a. Use any 802.11 client device to connect to the MR30H and verify proper connectivity using the client’s web
browser.
3. Check network coverage
4. Confirm that you have good signal strength throughout your coverage area. You can use the signal strength meter
on a laptop, smart phone, or other wireless device.
12

Troubleshooting
Reference the MR Product Page for additional information and troubleshooting tips.
