Cisco Small Business Pro
Services Ready Platform SRP 500 Series
ADMINISTRATION
GUIDE

© 2010 Cisco Systems, Inc. All rights reserved. OL-20474-03
CCDE, CCENT, CCSI, Cisco Eos, Cisco HealthPresence, Cisco Ironport, the Cisco logo, Cisco Lumin, Cisco Nexus, Cisco Nurse Connect, Cisco Stackpower,
Cisco StadiumVision, Cisco TelePresence, Cisco Unified Computing System, Cisco WebEx, DCE, Flip Channels, Flip for Good, Flip Mino, Flip Video, Flip Video
(Design), Flipshare (Design), Flip Ultra, and Welcome to the Human Network are trademarks; Changing the Way We Work, Live, Play, and Learn, Cisco Store, and
Flip Gift Card are service marks; and Access Registrar, Aironet, AsyncOS, Bringing the Meeting To You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP,
CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity,
Collaboration Without Limitation, EtherFast, EtherSwitch, Event Center, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS,
iPhone, iQuick Study, IronPort, the IronPort logo, LightStream, Linksys, MediaTone, MeetingPlace, MeetingPlace Chime Sound, MGX, Networkers, Networking
Academy, Network Registrar, PCNow, PIX, PowerPanels, ProConnect, ScriptShare, SenderBase, SMARTnet, Spectrum Expert, StackWise, The Fastest Way to
Increase Your Internet Quotient, TransPath, WebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States
and certain other countries.
All other trademarks mentioned in this document or website are the property of their respective owners. The use of the word partner does not imply a
partnership relationship between Cisco and any other company. (0907R)

Services Ready Platform SRP 500 Series Administration Guide 3
Contents
Chapter 1: Introduction to the Services Ready Platform 8
Feature Overview 8
Product Overview 8
SRP 521W Front Panel 9
SRP 526W / SRP 527W Front Panel 9
SRP 521W Back Panel 10
SRP 526W / SRP 527W Back Panel 11
Side Panels 12
Top View 13
Default Settings 14
Chapter 2: Getting Started with the Configuration Utility 15
Logging In to the Configuration Utility 15
Using the Configuration Utility 16
Main Window Areas 16
Configuration Utility Icons 17
Chapter 3: The Quick Setup Menu 19
Basic Configuration Setup 19
WAN Setup (Ethernet) 19
WAN Setup (ADSL) 25
LAN Setup 27
Wireless Setup 30
Remote Provisioning 36
Advanced Configuration 38
Voice 38
Mobile Network Setup 38
Firewall 39
NAT 39
Chapter 4: Setting up the Interfaces of the Services Ready Platform 40
Setting up the WAN Interface 40

Services Ready Platform SRP 500 Series Administration Guide 4
Contents
Internet Setup 40
VC Setting 43
IPOA Settings / Static IP Setting 44
PPPoE Settings 44
PPPoA Settings 46
Mobile Network 46
Failover and Recovery (SRP 521W) 50
Failover and Recovery (SRP 526W, SRP 527W) 53
Setting up the LAN Interface 56
DHCP Server 56
VLAN Setting 60
Port Setting 62
Setting up the Wireless LAN 63
Basic Wireless Settings 63
Wireless Protected Setup 66
WPS Method 1 66
WPS Method 2 66
WPS Method 3 67
Wireless MAC Filter 69
Advanced Wireless Settings 71
WMM Setting 75
Using the Management Interface 76
Chapter 5: Configuring the Network 78
Static Routing 78
RIP 80
Intervlan Routing 81
NAT 81
Setting 81
Port Forwarding 82
Port Range Triggering 84
QoS 86
Bandwidth Control 86

Services Ready Platform SRP 500 Series Administration Guide 5
Contents
QoS Policy 87
QoS Settings 88
CoS To Queue 89
DSCP To Queue 90
Firewall 91
Firewall Filter 91
Internet Access Control 94
PPPoE Relay 96
DDNS 98
DMZ 102
IGMP 103
UPnP 105
CDP Setting 106
Chapter 6: Voice Settings 108
Info 108
System 109
SIP 110
Provisioning 111
Regional 117
Chapter 7: Configuring VPN 118
IKE Policy 118
IPSec Policy 120
GRE Tunnel 123
VPN Passthrough 125
Chapter 8: Administration Settings 128
Web Access Management 128
Settings 128
Remote Management 130

Services Ready Platform SRP 500 Series Administration Guide 6
Contents
TR069 130
SNMP 132
Local TFTP 133
Time Setup 135
Setup Wizard 137
User List 137
User Privilege Control 138
Log 139
Factory Defaults 140
Firmware Upgrade 142
Backup & Restore 142
Backup Configuration 142
Restore Configuration 143
Reboot 144
Status 145
Switch Setting 146
Chapter 9: Using Services Ready Platform Diagnostics 148
Ping Test 148
Traceroute Test 149
Detect Active LAN Clients 150
Chapter 10: Viewing the Services Ready Platform Status 152
Router Settings 152
Firewall Status 154
Interface Information 156
Wireless Network 158
Wireless Client Information 159
Mobile Network 160
DHCP Server Information 163

Services Ready Platform SRP 500 Series Administration Guide 7
Contents
QoS status 164
Routing table 165
ARP Table 166
RIP Status 167
IGMP Status 168
VPN Status 169
CDP Neighbor Information 169
Appendix A: Specifications 172
Appendix B: Where to Go From Here 174

1
Services Ready Platform SRP 500 Series Administration Guide 8
Introduction to the Services Ready Platform
This chapter provides information to familiarize you with the product features and
get started using the web-based Configuration Utility.
•Feature Overview, page 8
•Product Overview, page 8
Feature Overview
Thank you for choosing the Cisco Services Ready Platform SRP 500 Series. The
Services Ready Platform has the features needed for small business.
SRP 500 Series platforms include:
•Intelligence to support voice, data, security, and application services.
•Industry-leading Session Initiation Protocol (SIP) stack to deliver clear, high-
quality voice service.
•Interoperability with popular soft switches and voice gateways.
•Integrated security, VPN capabilities, and an 802.11n wireless access point.
•Standards-based provisioning for streamlined deployments.
Product Overview
The Services Ready Platform, a member of the Cisco Small Business Pro family, is a
unified communications solution for small businesses that provides voice, data,
video, security, and wireless capabilities.
With its web-based interface, the Services Ready Platform is easy to setup and
configure.

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 9
1
SRP 521W Front Panel
SRP 526W / SRP 527W Front Panel
LED Description
Power/Sys Solid green indicates that the SRP is powered on.
Green flash indicates that the SRP is booting.
LAN Ports 1 to 4 Solid green indicates link. Green flash indicates link
traffic.
WAN (SRP 521W only) Solid green indicates link. Green flash indicates link
traffic.
DSL CD (SRP 526W/527W
only)
Solid green indicates carrier detection.
DSL Data (SRP 526W/527W
only)
Green flash indicates DSL activity.
WLAN Solid green indicates the radio is operational. Green
flash indicates wireless traffic.
276377
LANPOWER/SYS PHONE USB WPSWLANWLAN
Cisco Small Business Pro
SRP 521W
12 2143
195210
LANPOWER/SYS PHONE CD Data
DSL
USB WPSWLAN
Cisco Small Business Pro
SRP 526W
12 2143

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 10
1
SRP 521W Back Panel
USB Solid green indicates USB device is operational. Green
flash indicates device failure or unsupported device.
WPS Solid green indicates WiFi Protected Setup success.
Slow green flash indicates setup in progress. Fast
green flash indicates a setup error.
Feature Description
Phone Ports 1 to 2 Use these ports to connect to standard analog telephones.
FXO Line Port Use this port to connect to analog telephone Service
(PSTN) which is the analog telephone service network that
traditional telephone service uses.
WAN Port Use this port to connect the Services Ready Platform to
your WAN Internet connection.
LAN Ports 1 to 4 Use these ports to connect to wired computers and other
network devices.
On/Off Switch Use this switch to power the Services Ready Platform on
or off.
12 V DC Power Use this port to connect the provided power adapter.
276375
12VDC
LAN (10/100)WAN (10/100)
21 1234
LINE (FXO)PHONE (FXS)
WAN
Port
On/Off
Switch
FXO
Line
Port
Phone
Ports
12V DC
Power
LAN
Ports

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 11
1
SRP 526W / SRP 527W Back Panel
Feature Description
DSL Port Use this port to connect the Services Ready Platform to
your DSL connection.
Phone Ports 1 to 2 Use these ports to connect to standard analog telephones.
FXO Line Port Use this port to connect to analog telephone Service
(PSTN) which is the analog telephone service network that
traditional telephone service uses.
LAN Ports 1 to 4 Use these ports to connect to wired computers and other
network devices.
On/Off Switch Use this switch to power the Services Ready Platform on
or off.
12 V DC Power Use this port to connect the provided power adapter.
195211
LAN (10/100)LAN/WAN
21 1234
LINE (FXO)DSL PHONE (FXS)
On/Off
Switch
FXO
Line
Port
Phone
Ports
LAN
Ports

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 12
1
Side Panels
Feature Description
RESET Button Press this button for 10 seconds to reset the Services
Ready Platform.
USB Port Use this port to connect a compatible 3G USB device. For
a list of compatible 3G USB modems please check the
support community at www.cisco.com/go/srp500.
Antenna Services Ready Platform Wi-Fi antenna.
276380
RESET
Reset
Button
USB
Connector
276381
Antenna

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 13
1
Top View
Feature Description
WPS Button To automatically configure wireless security for devices
that support WiFi Protected Setup (WPS), press and hold
this button until the WPS LED flashes.
NOTE The device being configured by WPS should be
located next to the Services Ready Platform during
setup.
276378
WPS Button

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 14
1
Default Settings
Parameter Value
Device IP 192.168.15.1
Username cisco
Password cisco
Admin Username admin
Admin Password admin
DHCP Range 192.168.15.100 to 149
Data VLAN VLAN 1
Voice VLAN VLAN 100, published to the Cisco VOIP phones via CDP

2
Services Ready Platform SRP 500 Series Administration Guide 15
Getting Started with the Configuration Utility
This chapter describes how to login and use the Services Ready Platform
Configuration Utility.
•Logging In to the Configuration Utility, page 15
•Using the Configuration Utility, page 16
Logging In to the Configuration Utility
Before you begin to use the Configuration Utility, make sure that you have a
computer that meets the following requirement:
•• Adobe Flash Player version 9.0.124 or later. Visit http://get.adobe.com/
flashplayer/ to download and install the latest Adobe Flash Player.
STEP 1 Connect a computer to an available LAN port of your Services Ready Platform.
By default, your PC will become a DHCP client of the Cisco SRP 500 Series
Services Ready Platform and will receive an IP address in the 192.168.15.x range.
STEP 2 Start a web browser. In the Address bar, enter the default IP address of the Cisco
SRP 500 Series Services Ready Platform: http://192.168.15.1.
STEP 3 When the login page appears, enter the username and password to login as the
administrator.
The default username is admin.
The default password is admin.
NOTE Passwords are case sensitive.

Getting Started with the Configuration Utility
Using the Configuration Utility
Services Ready Platform SRP 500 Series Administration Guide 16
2
NOTE If you log in as cisco (with password of cisco), the Setup Wizard will automatically
begin. if you log in as admin, you can start the Setup Wizard by clicking the
Administration > Setup Wizard command.
STEP 4 Click Log In. The Services Ready Platform Configuration Utility opens.
Using the Configuration Utility
Main Window Areas
The Configuration Utility is a web-based device manager that is used to provision
the Services Ready Platform. You must have IP connectivity between the PC and
the Services Ready Platform to configure it.

Getting Started with the Configuration Utility
Using the Configuration Utility
17 Services Ready Platform SRP 500 Series Administration Guide
2
Configuration Utility Icons
Various icons are used throughout the Configuration Utility. These icons are
defined below.
Component Description
1Tab The Tab bar contains major function categories. Click a
tab to change to another category.
2Navigation Pane The navigation pane provides easy navigation through
the configurable device features.The main branches
expand to provide the subfeatures. Click on the triangle
next to the main branch title to expand or contract its
contents. Click on the title of a feature or subfeature to
open it.
3Main Content The main content of the feature appears in this area.
Icon Description
Edit Icon The Edit icon lets you edit an existing item from a list.
After making your changes, click the Submit button to
save your changes.
Add Item
Icon
The Add Item icon lets you add an item to a list. After
you have created a new item, click the Submit button to
save the new item.
Delete Item
Icon
The Delete Item icon lets you delete an item from a list.
After you have deleted an item, click the Submit button
to save your changes.
Increment
Decrement
Icons
The Increment and Decrement icons let you change
numeric values. Click the “+” icon to increment a value;
click the “-” icon to decrement a value. Click the Submit
button to save your changes.

Getting Started with the Configuration Utility
Using the Configuration Utility
Services Ready Platform SRP 500 Series Administration Guide 18
2

3
Services Ready Platform SRP 500 Series Administration Guide 19
The Quick Setup Menu
This chapter describes how to use the Quick Setup features to setup your
Services Ready Platform.
•Basic Configuration Setup, page 19
•Advanced Configuration, page 38
Basic Configuration Setup
The features in Basic Configuration Setup lets you setup your WAN, LAN, Wireless,
and Remote Provisioning.
WAN Setup (Ethernet)
The WAN Setup page lets you quickly setup your Ethernet WAN interface.
STEP 1 Click Quick Setup on the tab and then click WAN Setup in the navigation pane. The
WAN Setup page appears.
STEP 2 Enter your Internet connection type and any optional WAN settings as necessary.
STEP 3 Click Submit to save your settings.

The Quick Setup Menu
Basic Configuration Setup
Services Ready Platform SRP 500 Series Administration Guide 20
3
Field Description
WAN The WAN interface.
VLAN ID The VLAN ID.
Connection Type The type of Internet connection your ISP provides from
the drop-down menu.
Automatic Configuration - DHCP
By default, the Router's Internet Connection Type is set
to Automatic Configuration - DHCP, which should be
kept only if your ISP supports DHCP or you are
connecting through a dynamic IP address.
