Citizen HYPER AQUALAND User manual

CITIZEN.
HYPER AQUALAND
Model No.MA9***/Cal.No.D20*
INSTRUCTION P.
BETRIEBSANLEI
MANUEL DESTRUCTION
• MANUAL DE INSTRUCCION
• MANUALE Dl FUNZIONAMENTO
•mmm
• MANUAL DE INSTRUQOES

Thank you for purchasing this CITIZEN
QUARTZ WATCH.
To ensure correct use, read these
instructions carefully.
Please verify at the time of purchase that the
CITIZEN International Limited Warranty
Card has been included with your watch to
ensure any and all claims for service under the
terms of the limited warranty.

Before use
Depending on the model the specifications differ at one place.
Please confirm the specifications of your watch beforehand by the following method.
• Confirm the Caliber No. of your watch. Caliber No.
Confirrp the Caliber No. of. your watch by the .
stamp on its case back.
,<Caseback> .
• The operation and specifications ofCaliber No. D203 are the same as
those of Caliber No. D202. Inthis manual, please refer to the
explanation of Caliber No. D202.

Index
Introduction ; 5
A. Special functionsof this watch 6
B. For safe diving 7
A WARNING:
C. Usage points that should be avoided while diving[Make sure you read this warning.] 8
ACAUTION:
D. For safe usage [Make sure you read this caution] 11
1. Items to check for safe usage 11
2.Things to check before diving 15
3. Points to notice while diving
16
4. What to do after diving 17
E.Various warning functions 18
F. Name of each part [The dot display symbols and their meaning] 21
G.How to change the mode 24
H.Time and calendar mode 26
J. How to set the time and calendar 28
J. The alarm mode 30
K.The diving mode 32
L.Valid and invalid diving used in this watch 36
3

M. The surface mode [Measurement of reset time on surface] 39
N.The logmode 42
O. The transfer mode 45
P. How toperformall reset..... :...:.......;..... ..48
Q. No decompression limits -50
R. Specifications . 52
S.The batterywarning function andthebattery.. .. : '. ......54
T. For long usage ....!..57

Introduction
Ifyou follow the right rules of scuba diving and skin diving, you can enjoy safe water
sports. But on the other hand, there is an element of danger from the bends and other
possible accidents. So after receiving proper training, please check forsafety and enjoy
your diving.
When you use this product, please understand the instructions and warnings well, so that
you may use it properly.
In a case where this product is used in a way that is not mentioned in the USER'S
manual, the watch might not function properly
Further more all repairs including battery replacement should be carried out by a Citizen
Service Center.
Please arrange for a Citizen Service Center to look after your watch
through the shop from which it was purchased.
Please keep this USER'S manual in a safe place, for reference when you need it.

A. Special functions of this watch
This is a full-scale divers watch with digital display andan electronic depthgauge.
1) This watch measures and displays depth as soon as you start'diving; duetothe
water sensor. ' ' ' <,vv' ^ '":"'^ •.!•-•):.,•....,.:•.<::••
2) This watch measures the water temperaturewhile diving; and when not diving,the
airtemperature. ' '"'- ..',-.'
3) While you are diving, various log data is recorded.
4) After completing a divei by using a communication unit', you can transfer data to a
personalcomputer and also confirmi the datawitha personaicomputer.
* Compatible computers: IBM PC7ATor any other compatible computer with key^
board and monitor.(There aresome computers thatare not compatible)? '
Formore details, please read the "Communications AQUALAND;GRAPH USER'S'
manual". •• " • •••' ': '•;' " ' • ••' " ;M- " '' ' ' ''"•'
5) The elapsed time after a valid dive is completed (maximum of 24 hours) is meas
ured automatically. This watch can be used as a safety guide line for resting time
on the surface, [surface mode]
6) To ensure safe diving, various warning functions are included.

B. For safe diving=
• Basic knowledge and techniques are requiredto dive safely so please take the neces
sary training to acquire them.
• In orderto use thiswatch safely, C. [Usage points thatshouldbe avoidedwhile diving]
and D. [For safe usage] need to be understoodsufficiently when using thiswatch for
diving.

C. Usage points that should be avoided while
diving [Make sure you read this warning]=
When you use this watch fordiving,please heed the following points. [Do not use under
these conditions.]
AWARNING:
1. Do not use under these conditions:
a. Ifyou have not taken a course on safe diving, please do not use the watch.
b. Please do not use the watch outside the temperature limits.
The temperature limits for this watch are 10°C~40oC(50oF~104°F). Ifyou use the
watch outside of this range, it will not display accurate depth.
c. Never use the watch while diving with helium gas [saturated diving]. Ifyou use the
watch with helium
gas, it is likelyto cause problems, or failure.
d. Do not use the watch for determining your actions in dangerous situations.This
watch is not designed as equipment for the prevention of emergencies or acci
dents.
e. Do not use this watch as asubstitute for pressure equipment in applications other
than diving or instead of a buddy systems.
This watch is not a gauge or meter which is authorized by any public organization,
it should be used as a guide line for auxiliary equipment.
8

f. Do not use this watch at altitudes over 4000m (13120 ft) since.
Water depth cannot be measured at higher altitudes.
g. Do not use the watch outside of the water depth measurement range.
h. In case the safe diving warning function activates, immediately check the watch,
and stop using it.
Look up "various warning functions" to find out how to deal with each one.
(Before diving)
1) When the water sensor check warning function operates, -^ the dot display alter
nates between dot display and "CHEK"(D201/D207)/"ERR"(D202/D208) display as a
warning.
2) When the battery warning function operates — the dot display alternates between dot
display and "BAT."(D201/D207)/"BT"(D202/D208)display as a warning.
3) When the unusual air pressure error warning function operates
—The dot display alternates between dot display and "ERR"
display as awarning.
4) When the watch stops or something goes wrong with it,
please do not use it. ;
5)
When the water depth meter display on the watch shows a
big difference with other Water depth meters, please re
frain from using the watch.
Dot display

(While diving)
1) When the depth chart error warning function operates—* the;dot display alternates
between dot display and "ERR" display as awarning.
2) When the battery warningfunctionoperates —the dot display alternates between dot
displayand "BAT." (D201/D207)/"BT"(D202/D208) display, as a warning. Once1he bat
tery warningdisplayappears, please realizewe can't guarantee the accuracy,ofthe
depth measurement. -
3) When the watch stops or something goes wrong with it, pleasedo not use it
4) When the Water depth meter has a big difference with other water depth meters,
please do not use the watch.
10

D. For safe usage
[Make sure you read this caution]=
A CAUTION:
1. Items to check for safe usage
a. The depth display of this watch is up to 80m(260ft).
Although this watch has water resistance up to 200m(656ft), the depth display only
goes up to 80m(260ft). For safe diving we recommend that you stay shallower than 30
meters( 100ft) [sports diving].
We recommend that yqu stay within these
limitsof sports diving,(no decompression)
m^-
0m
30m
<The limit of the
depth displays
<The limit of water
200m resistance. >

b. The water depth meter in this watch is set according to the sea water standard
(1.025 gravity).
In case you use the watch infresh water, i.e. lake water etc., you need to make a con
version.
[Example]
When the watch is 80m(260ft) deep, in the case of sea water itdisplays 80m(260ft), but
when in fresh water, it displays 78m(253ft); Shallower than what it really is.
(Caution)
12
Actual depth «|T>
80m(260ft)------
: Sea water>
<Fresh water>
; Actual depth
-^^80m(260ft)

c. Avoid descending too rapidly.
Inorderto get an accurate depth readings, slow down
the descent, or stop.
d. Avoid ascending too rapidly.
Ifyou ascend at a speed greater than 1 5m(5ft) per 5secs
(D201/D207). /0.9m(3ft) per 6 sees (D202/D208).
18m(60ft) per minute (D201/D207)/9m(30ft) per minute
(D202/D208) according to the U.S. navy diving manual),
then the ascending speed warning function willoperate.
The dot display changes to "SLOW display and an alarm
will sound.
Please maintain a safe ascending speed.
Slow down your ascent or stop in order to get an accurate
depth reading.
As rapid ascending is hazardous to the human body,
sometimes causing the bends, always avoid it
*The new regulation of the U.S. Navy diving manual is executed on t993, changing the
Surface Speed Warning at the rate of 9m/min. from 18m/min.
13

e. Do not use the watch in places where it is exposed to large changes of air
pressure or temperature. ~n . •
The watch willautomatically check for unusual air pressure, while in various normal
modes (time and calendar mode / surface mode / log,mode / alarm mode).If any .
abnormality is detected, the dot display will alternate between dot display and '•
"ERR"display. When this happens, the v/ater depth cannot be measured. Ifthe
"ERR" display disappears, the watch canbeused normally. Or,
ftWhen boarding a plane. . )' —i. ; •
When exposed to sudden pressure phange (pressurization) as:in the inside of an
aeroplane, ifthe water sensor is touched with a finger ormoistened, the watch may
change to dive mode. Ifit changes to dive mode, dry the water sensor, and cancel
dive mode by holdingdown button (M)for more than 2-seconds;
f. We recommend that you change the battery as early as possible.
The life of the battery in thjs«.watch is about «3 years after a new battery is installed.
( Please look upS. [Battery]for the conditions^ usage). Howevefrthe'Mife of the
battery changes a lot depending on the frequency of use of various functions.
In order to;eniQy-:$afe diving, we recommend'thatyou change the battery ahead of
time. • •<• .'• • •••'-•': '''••' ] '* ' '••''••' ;' '
14

2. Things to check before diving—
When you dive please check the following points.
a. Check your watch
Dot display
1) Check that there are no problems like scratches,
cracks or chipson the strap or glass.
2) Check that the band and watch body are at
tached correctly.
3) Check that the timeand calendar is set correctly.
4) Check ifthe dot display is alternating between
dot display ana* "BAT.°(D2ai/Q207)/"BT"(D202/
208) display. Ifso, then it is time to change the
battery. ••.
-♦Consult various other warning functions for
counteraction needed.
5) Check that the dot display is not alternating
between dot display and "ERR". If so then it ,
indicates
mat there has been unusual air pres
sure detected.
^Consult various other warning functions for
counteraction needed, t
15

6) Check that the dot display is not alternating between dot display and
"CHEK"(D201/D207)/ "ERR"(D202/D208) display. Ifso, then you should check
the water sensor.
-•Consult various other warning functions for counteraction needed.
7) Comfirmthe alarm sound byoperationg the alarm monitor.
• Change tothe alarm mode by pressing (jvj) button.
• Alarm monitor is activated while pressing (A) button.
At the same time the alarm will be switched ON/OFF.
3. Points to notice while diving
a. There are times when the alarm sound is not easily
heard: when underwater, when being carry, and in othe
outside environment.
b. Accurate water temperature is most likely to be indicate
after 1 to 3 minutes from the start of your dive.
c.
When various warning functions are operating, please
heed the warning.
d. Be careful not to
knock the watch against hard objects
like diving equipment or rocks, etc.
16

4. What to do after-diving - -— — ——
a. Wash and rinse off any sea water, mud, sand, and such like, present on the watch,
- with fresh water. Then dry any moisture completely, with a dry cloth, etc.
b. Treat the sensor carefully. Do not remove the cover or use sharp objects to clean dirt
ordust fromjt. Ifany dirtgets intothe sensor,wash itwith clean water;ifthat doesn't
remove the dirt, please take the watch to the nearest Citizen Service Center.
Also when washing, if a strong jet of water hits the sensor; or if it is pressed with a
hand, it
may change to the diving mode. So take care.
c. Do not expose the watch to chemicals.
d. For information about basic care for this watch, please look atT. [Forlong usage].
17

E. Various warning functions=
This watch has5 warning functionsto help you ayqjd ahytrouble or, danger while diving.
Use these warning functions, as much as possible, as safety guidelines for diving.
The level of danger is often complex depending on your body condition or diving
situation, etc. Even if there is no warning, it may not mean there is no danger.
18
Function
Ascending speed
warning
Water depth display
error warning
Battery warning
Warning
method
The dot display will
alternate between
dot display and
"SLOW" display.
• The alarm will
continue to beep for
5
seconds (D201/
D207)/ 6
seconds
(D202/D208) until
ascent is slowed.
The dot display will
alternate between dot
display and "ERR"
display.
• While displaying
"ERR" we do not
guarantee water
depth accuracy.
When the dot display will
alternate between dot
display and UBAT."(D201/
D207)/ "BT"(D202/D208)
display.
• You cannot change to
diving mode.
• The alarm doesn't sound.
• The lamp doesn't work.

Function
Ascending speed
warning
Water depth.display
error warning
Battery warning
Conditions
of
operation
[While in diving mode,
the waterdepth
measurement display]
•When the ascending
speed is too fast,
continuous speed of
0.3m (1ft) per second
for more than 5
seconds. (D201/D207)
/0.3m (1ft) per 2
second for more than
6 secourids. (D202/
D208)
[While in diving mode,
the water depth
measurement display]
•When the ascending
or descending speed
is too fast, more than
4m (15ft) per second.
[While in diving mode,
the water depth measurement
display or each normal mode]
•When it is dose to the time
to change the battery.
•When changing the battery
all the diving data willbe lost.
In the case where there is
needed diving data, transfer
the data to a personal com
puteror recorditina log
book beforehand.
•Various tests are made in
order to maintain the special
properties of the watch, so
avoid any place other than a
Citizen Service Center for
any after service care, such
as changing the battery, etc.
Counter
action
needed
•Please slow down
your ascent.
•After the diving mode
is complete, ifyou
can change back to
normal mode, there
is no problem,
19
