CITROEN C3 User manual

1
5
2
3 4
1
2
34 5
REMOTE CONTROL KEY
A. Unfolding/Folding the key.
B . Unlocking the vehicle.
C . Normal locking of the vehicle.
Vehicle location.
STEERING WHEEL ADJUSTMENT
1. Release the adjustment mechanism.
2. Adjust for height and reach.
3. Lock the adjustment mechanism.
DOOR MIRRORS
Move control Ato the right or to the left to select the corresponding
mirror.
Move control Bin all four directions to adjust.
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
Bonnet
1. Driver's electric window control switch.
2. Passenger's electric window control switch.
3. Rear right electric window control switch.
4. Rear left electric window control switch.
5. Deactivating the rear electric window and door controls.
ELECTRIC WINDOWS
PARKING BRAKE
Applying
Pull the parking brake lever fully up to immobilise your vehicle.
Releasing
Pull the parking brake lever gently, press the release button
then lower the lever fully.
FUEL TANK
1. Opening the fuel ller ap.
2. Opening and hooking the fuel ller cap.
Capacity of the tank: approximately 50 litres (petrol) or 48 litres
(Diesel).
GEAR SHIFT INDICATOR
System which reduces fuel consumption by advising the driver to
change up on vehicles tted with a manual gearbox.
1. Engine not running
- Short press: on/off.
- Long press: CD pause, mute for the radio.
Engine running
- Short press: CD pause, mute for the radio.
- Long press: reinitialisation of the system.
2. Volume adjustment (each source is independent, including also
navigation messages and alerts).
3. Access to the "Radio" Menu. Display the list of stations.
4. Access to the "Music" Menu. Display the tracks.
5. Access to the "SETUP" menu.
Long press: access to the GPS coverage and the demonstration
mode.
1 . On/Off and volume adjustment.
2. CD eject.
3 . Selection of the display on the screen from the following modes:
Audio (AUDIO), Trip Computer (TRIP) and Telephone (TEL)
functions.
4 . Selection of source: radio, audio CD/MP3 CD, USB, Jack
connection, Streaming.
5. Selection of FM1, FM2, FMast and AM.
AUDIO AND TELEMATICS
MAIN MENU
Press the "MENU" button to gain access to the
main menu.
MISFUEL PREVENTION
Mechanical device which prevents lling the tank of a Diesel vehicle
with petrol. It avoids the risk of engine damage that can result from
lling with the wrong fuel.
Located in the ller neck, the misfuel prevention device appears
when the ller cap is removed.
When a petrol ller nozzle is introduced into the fuel ller neck of
your Diesel vehicle, it comes into contact with the ap. The system
remains closed and prevents lling.
Do not persist but introduce a Diesel type ller nozzle.
EMERGENCY CALL
ASSISTANCE CALL
PANORAMIC GLASS SUNROOF
Lift the handle of the blind concerned and release.
READY TO GO
CITROËN C3 PICASSO
FL - C3 - PICASSO - ED 01-2010 - AN
Fiche_loueur_C3_Picasso_en_01-201 1Fiche_loueur_C3_Picasso_en_01-201 1 26/07/2010 13:09:3126/07/2010 13:09:31

–
LIGHTING CONTROLS
Ring A
Ring B
Lighting off.
Automatic illumination of headlamps.
Sidelamps.
Dipped/main beam headlamps.
Rear foglamp.
or
Front and rear foglamps.
WIPER CONTROLS
Control stalk A: windscreen wipers
Park.
Intermittent wipe.
Wash-wipe.
Ring B: rear wiper
Digital air conditioning: we recommend use of the fully automatic mode by pressing the "AUTO" button, after selecting the level of comfort
required.
SPEED LIMITER "LIMIT"
1. Limiter mode Selection/Off.
2 . Decrease the programmed value.
3 . Increase the programmed value.
4. Speed limiter On/Off.
CRUISE CONTROL "CRUISE"
1. Cruise control mode Selection/Off.
2. Programming a speed/Decrease the programmed
value.
3. Programming a speed/Increase the programmed
value.
4. Cruise control Off/Resume.
FRONT SEATS
1. Forwards-backwards adjustment. 2. Driver's seat height adjustment. 3. Seat back angle adjustment.
REAR SCREEN DEMIST/DEFROST
I require...
Heating or Manual air conditioning
Air distribution Air ow Air recirculation/
Exterior air intake Temperature Manual A/C
H E A T
COOL
DEMISTING
DEFROSTING
2ND ROW REAR CENTRE SEAT BELT TABLE POSITION OF THE FRONT PASSENGER
SEAT 2-POSITION ADJUSTABLE BOOT
The seat belt for the rear centre seat of the 2nd row is incorporated
at the rear left of the roof.
Placing the adjustable boot oor in the
low position
Lift the adjustable boot oor by pulling on
the strap.
 Move the adjustable boot oor rearwards
and then down, following the guides on
the sides.
Placing the adjustable boot oor in the
high position
Lift the adjustable boot oor by pulling
the strap.
Move the adjustable boot oor rearwards
then up to its high position.
fast (heavy rain),
normal (moderate rain),
intermittent (proportional to the speed of the
vehicle),
park,
single wipe (press down and release),
automatic, then single wipe.
