Thank you for using our company the CK-102. To optimize the performance of this product,
please read these operating instructions carefully to familiarize yourself with the basic
operations of this unit. The CK-102 is a unique 192 DMX channel. This unit has been tested
at the factory before being shipped to you, there is no assembly required. It features include:
�
192 DMX channels
�
12 Scanners of 16 channels each
�
30 Banks of 8 programmable scenes
�
6 Programmable chases of 240 scenes
�
8 Sliders for manual control of channels
�
Assignable joystick for ease of channels
�
File Dump allows data to be sent or received between two units
�
Auto mode program controlled by speed and fade time sliders
�
Fade time/Assign fade time
�
Reversible DMX channels allows fixture to react in opposition to others in a chase
�
8 CHANNEL or 16 CHANNEL mode
�
Fine adjustment for joystick pan and tilt
�
Blackout master button
�
Manual Override button allows you to grab any fixture on the fly
�
Built in microphone for music triggering
�
MIDI control over banks, chases and blackout
�
DMX Polarity selector
�
Power failure memory
Read the instruction in this manual carefully and throughly, as they give important
information regarding safety during use and maintenance. Please keep this manual with the
unit, in order to consult it in the future.

II
II
II
II
．
WARNINGS
WARNINGS
WARNINGS
WARNINGS
1. To prevent or reduce the risk of electrical shock or fire, do not expose this unit to rain or
moisture.
2. Clearing memory often may cause damage to the memory chip, be careful not to initialize
your unit frequency often to avoid this risk.
3. Only use the recommended AC/DC power adaptor.
4. Be sure to save the packing carton in case you may ever have to return the unit for
service.
5. Do not spill other liquids or water in to or on to your amplifier.
6. Be sure that the local power outlet match that or the required voltage for your amplifier.
7. Do not attempt to operate this unit if the power cord has been frayed or broken. Please
route your power cord out of the way of foot traffic.
8.
8.
8.
8. Do not attempt to remove or break off the ground prong from the electrical cord. This
prong is used to reduce the risk of electrical shock and fire in case of an internal short.
9.
9.
9.
9. Disconnect from main power before making any type of connection.
10.
10.
10.
10. Do not remove the top cover under any conditions. There are no user serviceable parts
inside.
11.
11.
11.
11. Disconnect the unit ’ s main power when left unused for long periods of time.
12.
12.
12.
12. This unit is not intended for home use.
13.
13.
13.
13. Carefully inspect this unit for damage that may have incurred during shipping. If the unit
appears to be damaged, do not attempt any operation, please contact your dealer.
14.
14.
14.
14. This unit should be operated by adults only, never allow small children tamper or play
with this unit.
15.
15.
15.
15. Never operate this unit under the following conditions:
-
-
-
-In places subject to excessive humidity
-
-
-
-In places subject to excessive vibration or bumps
-
-
-
-In area with a temperature over 45
0
C/113
0
F or less than 2
0
C/35.6
0
F
III.
III.
III.
III. CAUTIONS
CAUTIONS
CAUTIONS
CAUTIONS
1. There are no user serviceable parts inside this unit.
2. Do not attempt any repairs yourself, doing so will void your manufactures warranty.
3. In the unlikely event your unit may require service please contact your nearest dealer.

IV
IV
IV
IV
．
CONTROLS
CONTROLS
CONTROLS
CONTROLS AND
AND
AND
AND FUNCTIONS
FUNCTIONS
FUNCTIONS
FUNCTIONS
Front
Front
Front
Front Panel:
Panel:
Panel:
Panel:
Scanner
Scanner
Scanner
Scanner Buttons(1-12)
Buttons(1-12)
Buttons(1-12)
Buttons(1-12) –
–
–
–
1.
1.
1.
1. Scene
Scene
Scene
Scene Buttons
Buttons
Buttons
Buttons –
–
–
–
Press the scene buttons to load or stored your scenes. There are maximum of 240
programmable scenes.
2.
2.
2.
2. Faders
Faders
Faders
Faders –
–
–
–
These faders are used to control the intensity of channel 1-8 or channel 9-16 depending
upon the selected page.
3.
3.
3.
3. Page
Page
Page
Page Select
Select
Select
Select Button
Button
Button
Button –
–
–
–
Used to select page between Page A(1-8) and Page B(9-16).
4.
4.
4.
4. Fog
Fog
Fog
Fog Machine
Machine
Machine
Machine Button
Button
Button
Button –
–
–
–
Activates Fog Machine.
5.
5.
5.
5. Speed
Speed
Speed
Speed Slider
Slider
Slider
Slider –
–
–
–
Used to adjust the chase speed within the range of 0.1 second to 10 minutes.
6.
6.
6.
6. Fade
Fade
Fade
Fade Time
Time
Time
Time Slider
Slider
Slider
Slider –
–
–
–
Used to adjust the fade time. Fade time is the amount of time it takes for a scanner(or
scanner) to move from one position to another, for the dimmer to fade in or fade out.
7.
7.
7.
7. LCD
LCD
LCD
LCD Display
Display
Display
Display –
–
–
–
Shows the current activity or programming state.
8.
8.
8.
8. Pan
Pan
Pan
Pan Joystick
Joystick
Joystick
Joystick –
–
–
–
This joystick is used to control the Pan of the scanner or for programming.
9.
9.
9.
9. Tilt
Tilt
Tilt
Tilt Joystick
Joystick
Joystick
Joystick –
–
–
–
This joystick is used to control the Tilt of the scanner or for programming.
Page A
Music
Manual
Auto
Assign
Reverse
Auto/Del
SPEED FADE TIME
Music/
Bankcopy
1
1 2 3 4 5 6 7 87
2 8
3 9
4 10
5 11
6 12
FOG MACHINE
SCANNERS
READY
SCENES
Page B
Page Select
Midi/Rec
PAN
Override
TILT
Program
BANK TAP/Display
BANK
Chase 1 Chase 2
Chase 3 Chase 4
Chase 5
MODE FINE
Chase 6
Blackout1
0
9
2
0
10
3
0
11
4
0
12
5
0
13
6
0
14
7
0
15
8
0
16
30S
010Min
0.1S
1
311 12 6 7 10 9 204
2 13 14 8 15 16
17
18
19
5

10.
10.
10.
10. Program
Program
Program
Program Button
Button
Button
Button –
–
–
–
Activates program mode.
11.
11.
11.
11. MIDI/Rec
MIDI/Rec
MIDI/Rec
MIDI/Rec –
–
–
–
Used to control MIDI operation or to record programs.
12.
12.
12.
12. Auto/Del
Auto/Del
Auto/Del
Auto/Del –
–
–
–
Activates Music mode or to delect scenes or chases .
.
.
.
13.
13.
13.
13. Music/Bank
Music/Bank
Music/Bank
Music/Bank Copy
Copy
Copy
Copy –
–
–
–
Activates Program mode .
.
.
.
14.
14.
14.
14. Bank
Bank
Bank
Bank Up/Down
Up/Down
Up/Down
Up/Down –
–
–
–
Press the Up/Down button to select from 30 banks .
.
.
.
15.
15.
15.
15. Tap/Display
Tap/Display
Tap/Display
Tap/Display –
–
–
–
Used to create a standard beat or to change the value mode between % and 0-255 .
.
.
.
16.
16.
16.
16. Blackout
Blackout
Blackout
Blackout Button
Button
Button
Button –
–
–
–
Tap to momentarily pause whole output .
.
.
.
17.
17.
17.
17. Chase
Chase
Chase
Chase Button(1-6)
Button(1-6)
Button(1-6)
Button(1-6) –
–
–
–
These buttons are used for activating the chase of programmed scenes .
.
.
.
18.
18.
18.
18. Fine
Fine
Fine
Fine Button
Button
Button
Button –
–
–
–
When Fine is on, the Pan or Tilt joystick will control the scanner in the smallest
increment .
.
.
.
19.
19.
19.
19. Mode
Mode
Mode
Mode Button
Button
Button
Button –
–
–
–
Pressing Fine and Mode buttons allows to activate Assign or Reverse mode .
.
.
.
Rear
Rear
Rear
Rear Panel:
Panel:
Panel:
Panel:
1.
1.
1.
1. MIDI
MIDI
MIDI
MIDI IN
IN
IN
IN –
–
–
–
Receives MIDI data .
.
.
.
DMX POLARITY SELECT
2
2
11
1
2
-
+
+9V~12V,
300mA min. 0.1V~1Vp-p
3
3
3
1=Ground
2=Data -
3=DATA+
1=Ground
2=Data +
3=DATA-
DMX OUTDMX OUTMIDI INAUDIO FOG
CONTROL OUTDMX IN
DC INPUT POWER
ONOFF
8 1 2 3 4 56 7

2.
2.
2.
2. DMX
DMX
DMX
DMX Polarity
Polarity
Polarity
Polarity Select
Select
Select
Select –
–
–
–
Used to select DMX polarity .
.
.
.
3.
3.
3.
3. DMX
DMX
DMX
DMX OUT
OUT
OUT
OUT –
–
–
–
This connector sends your DMX value to the DMX scanner or DMX pack .
.
.
.
4.
4.
4.
4. DMX
DMX
DMX
DMX IN
IN
IN
IN –
–
–
–
This connector accepts your DMX input signals .
.
.
.
5.
5.
5.
5. Fog
Fog
Fog
Fog Machine
Machine
Machine
Machine Connector
Connector
Connector
Connector –
–
–
–
This connector is used to plug in the Fog Machine .
.
.
.
6.
6.
6.
6. DC
DC
DC
DC Input
Input
Input
Input –
–
–
–
DC9-12V , 300Ma min..
7.
7.
7.
7. Power
Power
Power
Power Switch
Switch
Switch
Switch –
–
–
–
This switch turns On/Off the power .
.
.
.
8.
8.
8.
8. AUDIO
AUDIO
AUDIO
AUDIO IN
IN
IN
IN –
–
–
–
0.1V~1Vp-p .
.
.
.
V
V
V
V
．
OPERATION
OPERATION
OPERATION
OPERATION
�
�
�
�
General:
General:
General:
General:
The CK-102 allows you to program 12 scanners with 16 DMX channels each, 30 banks
of 8 programmable scenes, 6 chases of 240 scenes using 8 channel sliders, a joystick, and
other buttons. With the ease of the joystick, you can easily and more accurately control
the movement of a fixture. To further your ability to dazzle the audience, this unit allows
you to assign and revement DMX channels. In addition, two units can set up
communication so that they can send or receive a complete file dump.
�
�
�
�
Display
Display
Display
Display Information:
Information:
Information:
Information:
The LCD Display contains a maximum of 2 lines, each of 8 characters. Below are the
definitions.
LCD
LCD
LCD
LCD Display
Display
Display
Display Message
Message
Message
Message
SN1 Scene 1
BK1 Bank 1
CHASE1 Chase 1 is activated

STEP 009 The ninth step of a chase
DATA 184 DMX Value (000-255)
SP: 1M54s The current speed is 1 minute 54 seconds
TP: 4.25s The time of the last two taps is 4.25 seconds
ASS 04 05 Assign DMX channels 4 and 5
RES 10 13 Reverse DMX channels 10 and 13
SET
SET
SET
SET UP
UP
UP
UP
�
U
U
U
U nit
nit
nit
nit S
S
S
S etup
etup
etup
etup
The unit is preset to allocate 16 channels per fixture. In order to assign your fixtures to
the scanner buttons located on the left side of the unit you will need to space your
fixtures 16 DMX channels apart.
Use
Use
Use
Use the
the
the
the Following
Following
Following
Following chart
chart
chart
chart for
for
for
for DMX
DMX
DMX
DMX Addressing
Addressing
Addressing
Addressing
Fixture
Fixture
Fixture
Fixture #
#
#
# Digital
Digital
Digital
Digital #
#
#
# Dip
Dip
Dip
Dip Switch
Switch
Switch
Switch Setting
Setting
Setting
Setting
1
1
1
1 1
1
1
1 1
1
1
1 “
“
“
“ On
On
On
On ”
”
”
”
2
2
2
2 17
17
17
17 1
1
1
1 and
and
and
and 5
5
5
5 “
“
“
“ On
On
On
On ”
”
”
”
3
3
3
3 33
33
33
33 1
1
1
1 and
and
and
and 6
6
6
6 “
“
“
“ On
On
On
On ”
”
”
”
4
4
4
4 49
49
49
49 1,5
1,5
1,5
1,5 and
and
and
and 6
6
6
6 “
“
“
“ On
On
On
On ”
”
”
”
5
5
5
5 65
65
65
65 1
1
1
1 and
and
and
and 7
7
7
7 “
“
“
“ On
On
On
On ”
”
”
”
6
6
6
6 81
81
81
81 1,5
1,5
1,5
1,5 and
and
and
and 7
7
7
7 “
“
“
“ On
On
On
On ”
”
”
”
7
7
7
7 97
97
97
97 1,6
1,6
1,6
1,6 and
and
and
and 7
7
7
7 “
“
“
“ On
On
On
On ”
”
”
”
8
8
8
8 113
113
113
113 1,5,6
1,5,6
1,5,6
1,5,6 and
and
and
and 7
7
7
7 “
“
“
“ On
On
On
On ”
”
”
”
9
9
9
9 129
129
129
129 1
1
1
1 and
and
and
and 8
8
8
8 “
“
“
“ On
On
On
On ”
”
”
”
10
10
10
10 145
145
145
145 1,5
1,5
1,5
1,5 and
and
and
and 8
8
8
8 “
“
“
“ On
On
On
On ”
”
”
”
11
11
11
11 161
161
161
161 1,6
1,6
1,6
1,6 and
and
and
and 8
8
8
8 “
“
“
“ On
On
On
On ”
”
”
”
12
12
12
12 177
177
177
177 1,5,6
1,5,6
1,5,6
1,5,6 and
and
and
and 8
8
8
8 “
“
“
“ On
On
On
On ”
”
”
”
�
�
�
�Enabling
Enabling
Enabling
Enabling the
the
the
the program
program
program
program mode
mode
mode
mode
To enable program mode, hold the program button for seconds until LED is lit.
�
�
�
�Set-up
Set-up
Set-up
Set-up Joystick
Joystick
Joystick
Joystick
1) Press and hold the “ Program ” button until LED is lit.
2) Press and hold the “ Mode ” and “ Fine ” button at the same time, the assign LED
should light. If the reverse LED lights, press “ Fine ” and “ Mode ” again to enter assign

mode .
3) Use the bank UP and DOWN keys to select the axis you wish to assign (Pan or TILT).
4) Use the “ Tap/Display ” button to select 16 or 8 channel mode.
5) Press the button corresponding to the scanner you wish to assign.
6) While holding the mode button press the scene number corresponding to the slider
which controls the movement. (Example: If pan is controlled by slider number 4,
press and hold the “ Mode ” button while tapping scene button 4#).
7) When finished press the “ Mode ” and “ Fine ” buttons at the same time again to exit
Assign mode.
S
S
S
S CENES
CENES
CENES
CENES
�
�
�
�
Programming
Programming
Programming
Programming A
A
A
A Scene
Scene
Scene
Scene
1) Enter program mode (See Enabling Program Mode)..
2) Check the blackout key and verify that the LED is not lit, if it is, press it once to exit
blackoutmode.
3) Verify that the speed and fade time sliders are positioned at zero.
4) Press the scanner button corresponding to the unit wish to control. You may control
more than one scanner at time by pressing the button corresponding to the scanner(s)
you wish to program.
5) Move the faders and joystick to the desired position. If necessary, you may select
page B to control channels 9-16.
6) Tap the bank Up/Down button to choose the bank you want to store this scene into.
There are a total of 30 banks you can select, you may store up to 8 scenes in each
bank.
7) Once all scanners are programmed into the desired position for the scene, tap the
MIDI/Rec button to program this scene into memory.
8) Tap the scene button you wish to store your scene into. All LEDs will flash three
times signifying this operation. The LCD readout will show the bank and scene.
9) To unselect the scanner(s) you have been programming and switch to another simply
press the button of the scanner you have been programming again, deselecting it, and
select another scanner.
10) Repeat steps 2-7 until all scenes have been programmed.
11) If you don ’ t intend to continue programming at this time, press and hold the program

button for three seconds to exit program mode. The LED will go out indicating this
selection.
�
�
�
�
Example
Example
Example
Example Scene
Scene
Scene
Scene Program
Program
Program
Program
1) Program Enable.
2) Tap the Scanner 1 button to turn on its fader control.
3) Verify that the page select is set on page A, if not press the page select button to select
page A.
4) Move the first and second faders all the way up to their maximum value position.
5) Select bank 1 using the bank Up/Down buttons.
6) Press the MIDI/Rec button.
7) Tap scene 1 to store the first scene.
8) Repeat steps 4-7 until all scenes have been programmed into bank 1.
9) Tap the scanner 1 button to turn off the fader control.
10) When finished, disable program mode. You can now manually tap through you have
just programmed.
�
�
�
�
Editing
Editing
Editing
Editing A
A
A
A Scene
Scene
Scene
Scene
1) Program Enable.
2) Press the Bank Up/Down button to select the bank containing the scene you wish to
edit.
3) Select the scene you wish to edit by tapping it ’ s scene button.
4) Use the faders and/or joystick to make the desired adjustments to the scene.
5) Once you have completed the changes, tap the MIDI/Rec button.
6) Tap the scene button that corresponds to the scene you ’ re editing. This will override
the existing scene.
Be sure to select the same scene in steps 3 and 6, otherwise you may accidentally record
over an existing scene.
�
�
�
�
Copy
Copy
Copy
Copy Scanner
Scanner
Scanner
Scanner Settings
Settings
Settings
Settings –
–
–
–This setting allows you to copy the settings of one scanner to
another
1) Press and hold down the scanner button you wish to copy.
2) While holding down the button, tap the button of the scanner you wish to copy the

settings to.
�
�
�
�
Copy
Copy
Copy
Copy A
A
A
A Scene
Scene
Scene
Scene
1) Enable Program Mode.
2) Tap the Bank Up/Down button to select the bank containing the scene you wish to
copy.
3) Select the scene you wish to copy by pressing it ’ s scene button.
4) Using the BankUp/Down button select the bank you wish to copy the scene to.
5) Tap the MIDI/Rec button.
6) Tap the scene button you wish to copy the scene to.
�
�
�
�
Deleting
Deleting
Deleting
Deleting A
A
A
A Scene
Scene
Scene
Scene
1) Enable Programming Mode.
2) Press the desired Scene button to select the scene you wish to delete.
3) Press and hold down the Auto/Del button. While holding the button, tap the scene
button that corresponds with the scene you wish to delete.
4) When the programmed scene is delete, all DMX channel values will be set to 0.
�
�
�
�
Deleting
Deleting
Deleting
Deleting All
All
All
All Scenes
Scenes
Scenes
Scenes
1) With the power off to the unit, press and hold down the Program and Bank Down
buttons at the same time.
2) Turn the unit back on, and all scenes should be cleared.
�
�
�
�
Copy
Copy
Copy
Copy A
A
A
A Bank
Bank
Bank
Bank of
of
of
of Scenes
Scenes
Scenes
Scenes
1) Enable Programming Mode.
2) Tap the Bank Up/Down button until you reach the bank you wish to copy.
3) Tap the MIDI/Rec button.
4) Tap the Bank Up/Down button to select the bank you wish to copy to.
5) Tap the Music/Bank Copy button, all LEDs will briefly flash three times indicating
the function has been completed.
6) Press the program button for three seconds to exit programming mode.

CHASES
CHASES
CHASES
CHASES
�
�
�
�
Programming
Programming
Programming
Programming a
a
a
a Chase
Chase
Chase
Chase
Note: You must have already programmed scenes in order to program a chase, this
function allows you to cycle through up to 240 scenes in a preselected order. It is
recommended before programming chases for the first time, you delete all chases in the
controller. See Delete All Chases for instructions on how to do so.
1) Enable Programming Mode.
2) Tap the Chase button to select the chase you wish to program.
3) Select a desired scene from the bank that has scenes stored inside it.
4) Tap the MIDI/Rec button.
5) Repeat steps 3-4 until all desired scenes scenes have been entered.
�
�
�
�
Inserting
Inserting
Inserting
Inserting a
a
a
a bank
bank
bank
bank of
of
of
of scenes
scenes
scenes
scenes into
into
into
into a
a
a
a chase
chase
chase
chase
1) Enable Programming Mode.
2) Select the chase you wish to program.
3) Use the Bank Up/Down key to select the bank of scenes you wish to copy.
4) Tap the Music/Bank Copy button.
5) Tap the MIDI/Rec copy button, all LEDs will flash three times indicating that the
requested operation has been performed.
�
�
�
�
Add
Add
Add
Add A
A
A
A Step
Step
Step
Step
1) Enable Programming Mode.
2) Press the corresponding button to the chase you wish to add a step to.
3) Press the Tap/Display button, the LCD will show the current step.
4) Press the Bank Up/Down button and scroll to the step you wish to insert the step
after.
5) Press the MIDI/Rec button, the segment display will read the step one step higher
than before.
6) Tap the Tap/Display buttonagain. The LCD shows the current chase, scene, and bank.
Create a desired scene and record it as a new step or select a previously programmed
scene to add to the chase.
7) Once you have selected the scene you wish to add, press the MIDI/Rec button again.

All LEDs will flash three time indicating the new step has been inserted into the
chase.
�
�
�
�
Deleting
Deleting
Deleting
Deleting A
A
A
A Step
Step
Step
Step
1) Enable Programming Mode.
2) Select the chase that contains the step you wish to delete.
3) Press the Tap/Display button, the LCD shows the current step.
4) Press the Bank Up/Down button and scroll to the step you wish to delect.
5) Press the Auto/Del button to delete the step. All LEDs will flash three times
indicating the requested operation has been performed.
�
�
�
�
Delete
Delete
Delete
Delete A
A
A
A Chase
Chase
Chase
Chase
1) Press the button corresponding to the chase you wish to delete.
2) Press and hold down the Auto/Del button while holding down the chase button. All
LEDs will flash three time indicating that the requested operation has been
performed.
�
�
�
�
Delete
Delete
Delete
Delete A
A
A
A Chase
Chase
Chase
Chase
1) With the power off, press and hold down the Auto/Del and Bank Down buttons at the
same time.
2) Reapply the power, and all chases should be cleared.
JOYSTICK/CHANNEL
JOYSTICK/CHANNEL
JOYSTICK/CHANNEL
JOYSTICK/CHANNEL SELECTION
SELECTION
SELECTION
SELECTION
�
�
�
�
Set-up
Set-up
Set-up
Set-up Joystick
Joystick
Joystick
Joystick
1) Press and hold the “ Program ” button until LED is lit.
2) Press and hold the “ Mode ” and “ Fine ” buttons at the same time, the assign LED
should light. If the reverse LED lights, press “ Fine ” and “ Mode ” again to enter assign
mode.
3) Use the bank Up and Down keys to select the axis you wish to assign (Pan or Tilt).
4) Use the “ Tap/Display ” button to select 16 or 8 channel mode.
5) Press the button corresponding to the scanner you wish to assign.
6) While holding the mode button press the scene number corresponding to the slider

which controls the movement. (Example: If pan is controlled by slider number 4,
press and hold the “ Mode ” button while tapping scene button 4#).
7) When finished press the “ Mode ” and “ Fine ” button at the same time again to exit
Assign mode.
�
�
�
�
Reverse
Reverse
Reverse
Reverse Joystick
Joystick
Joystick
Joystick Movement/DMX
Movement/DMX
Movement/DMX
Movement/DMX Channel
Channel
Channel
Channel
1) Enable Programming Mode.
2) Press the Fine and Mode buttons to enter assign mode, then press Fine and Mode
buttons again to enter reverse mode. The reverse LED lights up indicating reverse
mode is active.
3) Use Bank Up/Down button to change between the Pan and Tilt, the corresponding
LED lights indicating this selection.
4) Press the Tap/Display button to change between 8 CHANNEL and 16 CHANNEL
mode.
5) Press the scanner buttonto select the scanner.
6) While holding the mode button, press the corresponding scene button the channel you
wish to reverse. (For Example: If you are reversing the on one scanner, once you
verify that you are in reverse mode, and the Tilt LED is lit, check to see which slider
the Tilt control is on. Hold the mode button and press the scene button that is same as
the slider number for tilt. (Slider 5/Scene 5).
7) Continue steps 3-7 as needed. You may reverse a maximum of 48 channels for 12
scanners.
�
�
�
�
Delete
Delete
Delete
Delete a
a
a
a scanner
scanner
scanner
scanner of
of
of
of DMX
DMX
DMX
DMX Channels
Channels
Channels
Channels
1) Activate Assign or reverse mode.
2) Tap the scanner button to select the scanner you wish to delete.
3) Press the mode and Auto/Del buttons at the same time. All LEDs will flash three time
indicating the requested operation has been performed.
�
�
�
�
Clear
Clear
Clear
Clear All
All
All
All DMX
DMX
DMX
DMX Channels
Channels
Channels
Channels
1) Turn the power to the unit off.
2) Press the Mode and Auto/Del buttons at the same time.
3) While holding the two buttons, turn the power back on to the unit. All LEDs will

flash briefly indicating the requested operation has been performed.
�
�
�
�
Display
Display
Display
Display DMX
DMX
DMX
DMX Channel
Channel
Channel
Channel
1) Press the Fine and Mode buttons at the same time, putting the controller into assign
mode.
2) Press the Fine and Mode buttons again, lighting the reverse LED.
3) Press the scanner button that is set at the desired Pan and Tilt and the LCD will
display the DMX values for Pan and Tilt.
FADE
FADE
FADE
FADE TIME
TIME
TIME
TIME
�
�
�
�
Fade
Fade
Fade
Fade Time/Assign
Time/Assign
Time/Assign
Time/Assign Fade
Fade
Fade
Fade Time
Time
Time
Time
1) With the power off, press the mode and Tap/Display buttons at the same time.
2) Apply the power again, tap the Tap/Display button to change between Fade Time and
Assign Fade Time, the LCD reads
3) Press the Mode and Tap/Display buttons at the same time to store your setting into
memory. If you do not wish to save your setting, press the blackout key to exit this
operation.
PLAYBACK
PLAYBACK
PLAYBACK
PLAYBACK
�
�
�
�Running
Running
Running
Running Scenes
Scenes
Scenes
Scenes
Threr are three modes in which you can run scenes and chases. They are Manual mode,
Auto mode, and music mode.
�
�
�
�Manual
Manual
Manual
Manual Mode
Mode
Mode
Mode
1) When the power is turned on, the unit enters manual mode automatically.
2) Check and verify that both the Auto and Music LEDs are off.
3) Use the Bank Up/Down button to select the bank with the scenes you wish to run.
4) Press the scene button corresponding to the scene you wish to display.
�
�
�
�Auto
Auto
Auto
Auto Mode
Mode
Mode
Mode
This function allows you to run a bank of programmed scenes in sequence.
ALL ONLY
FD FD
CH X/YORTIME TIME

1) Press the Auto/Del button to enter into Auto mode. The Auto LED will light
indicating the Auto mode is active.
2) Use the bank Up/Down button to select a bank of scenes to run.
3) After selecting the bank of scenes to run, you can use the speed slider and Fade Time
slider to adjust the speed of the scene progression.
4) You can use the Tap Sync/Display button to set the speed instead. The amount of time
between the last two taps will instruct the controller in the length of time between
steps. This setting will stay in effect until the speed slider is moved.
5) Press the Auto/Display button to exit Auto mode.
�
�
�
�
Music
Music
Music
Music Mode
Mode
Mode
Mode
1) Press the Music/Bank Copy button to activate Music mode.
2) Use the bank Up/Down button to select a bank of scenes you wish to run. The scenes
selected will run through sequentially to the beat of the music identified by the
built-in microphone.
3) Tap the Music/Bank Copy button again to exit music mode.
�
�
�
�
Running
Running
Running
Running Chases
Chases
Chases
Chases
�
�
�
�
Manual
Manual
Manual
Manual Mode
Mode
Mode
Mode
1) When the power is turned on, the unit enters manual mode automatically.
2) Select the chase you wish to run by pressing the corresponding chase button. Pressing
this button a second time will unselect the chase.
�
�
�
�
Auto
Auto
Auto
Auto Mode
Mode
Mode
Mode
1) Press the Auto/Del button to activate Auto mode.
2) Select the desired by pressing one of six Chase buttons. Pressing this button a second
time will negate this selection.
3) Use the speed slider and Fand time slider to adjust the chase to your specifications.
�
�
�
�
Music
Music
Music
Music Mode
Mode
Mode
Mode
1) Press the Music/Bank Copy button to activate Music mode.
2) Select the desired chase by pressing one of six Chase buttons, this will activate the
chase and cause it to respond to the rhythms of the music.

FILE
FILE
FILE
FILE TRANSFER
TRANSFER
TRANSFER
TRANSFER
File Transfer allows the user to transfer all information stored in one CK-102 to a second
CK-102 unit. You must connect the units using 3-pin XLR cables. The unit sending the
information will have the cable plugged into the DMX “ Out ” plug, and the receiving the
information will have the cable running into the DMX “ In ” location.
�
�
�
�
To
To
To
To Send
Send
Send
Send A
A
A
A File
File
File
File Dump
Dump
Dump
Dump
1) With the power off to the unit, press and hold down the scanner 2 and 3 buttons and
scene 1 button at the same time.
2) Turn the unit back on while pressing these three buttons, the LCD will read
“ TRANSMIT ” indicating that the unit is ready to send the files.
3) Press scene button 7 and 8 at the same time to send the file dump.
4) If an error occurs during the file dump, the LCD will readout “ ERROR ” .
�
�
�
�
Receive
Receive
Receive
Receive File
File
File
File Dump
Dump
Dump
Dump
1) With the power off, press and hold down the scanner 8, 9 and scene button 2 at a
time.
2) Apply the power again while pressing these three buttons, the LCD shows
“ RECEIVE ” indicating this unit is receiving the file dump.
3) When receiving is over, the unit will automatically return to normal mode.
�
�
�
�
MIDI
MIDI
MIDI
MIDI Channel
Channel
Channel
Channel Setting
Setting
Setting
Setting
1) Press and hold the MIDI/Rec button for three seconds. The LCD shows the MIDI
channel of last time.
2) Use the bank Up/Down button to select the DMX channel 01-16 to assign to the
MIDI channel.
3) Press and hold the MIDI/Rec button to save your settings. The LEDs will flash three
times indicating that the required operation has been performed..
VI
VI
VI
VI
．
TECHNICAL
TECHNICAL
TECHNICAL
TECHNICAL SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Power Input …………………………………
…………………………………
…………………………………
………………………………… DC 9~12V 300mA Min.
DMX In/Out ………………………
………………………
………………………
……………………… 3 pin female/male XLR socket x 1
MIDI IN ………………
………………
………………
……………… …………………………
…………………………
…………………………
………………………… 5 pin multiple socket
Dimensions ……………………………
……………………………
……………………………
…………………………… ..
..
..
.. ……
……
……
…… ..
..
..
.. ……
……
……
…… ..
..
..
.. 482x134x85mm
Weight …………………………………………………………
…………………………………………………………
…………………………………………………………
………………………………………………………… 2.7 Kgs
