TECshow BEAMER 17R User manual

BEAMER 17R
ENGLISH VERSION
P. 2
1. Overview
Beamer 17R is a versatile moving head that covers
spot, wash and beam functions. Powered by a 17R
short-arc 350W lamp, achieves 134.000 lux at 30 feet
with its 3.8º beam angle. The unit has a 14 dichroic fil-
ter + open and bidirectional rainbow eect color wheel
and sports CTO and CTB filters. Regarding gobos, this
moving head has a 9 dichroic rotating indexable and
interchangeable gobo wheel and a 14 static gobo
wheel, each of them with gobo shaking. Beamer 17R
comes with frost filter, a linear 6-facet & 16-facet ro-
tating prism and a zoom function that allows the user
to choose between 3.8º and 45º to cover beam, spot &
wash applications with only one moving head.
Specifications
Source & Optics
• Light Source: 17R 350W Short-arc Lamp
• Lamp Life: 1,500 hours
• Color temperature: 7800K
• Zoom: 3.8º-45º
• Photometric Data
• B3.8º Beam angle: 134,000 lux @ 10m (30 .)
• Eects and Functions
• Color wheel: 14 filters
• Open & bidirectional rainbow eect
• 2 CTO filters (2500K & 3200K)
• CTB filter
• Rotatinggobowheel:9HQdichroicinterchange-
able and indexable rotating gobos + open
• Staticgobowheel:14indexablegobos+open&4
beam reducers
• Gobo diameter: outside 4.9 mm., inside 10.5 mm.
• Gobo shake & morph
• Frost filter
• 6 & 16-facet rotating prism
• Motorized focus
• Dimmer: Full range 0-100%
• Strobe eect
• Control
• DMX Channels: 15/20
• Modes: DMX, Sound-active & Auto-run
• Movement
• Pan: 540°
• Tilt: 265°
• 16-bit resolution
• Auto repositioning
• Electrical
• Input voltage range: 100–240V, 50-60Hz
• Power Supply: Automatic range
• Max. power consumption: 450W
• Physical
• 2 XLR connectors (XLR-3 input & output)
• Power supply connectors: PowerCON® In
• Backlit LCD display
• Dimensions: 420x382x673 mm. /16.5x15x26.5 in.
• Weight: 23.8 Kg. / 52 Lbs.

BEAMER 17R
A. Before Using
What is included
• 1pc fixture(lamp installed)
• 1pc User Manual
• 1pc Power Cable
• 1pc Signal Cable
• 2pc Fast-lock Omega Clamp (1/4 turn)
ENGLISH VERSION
P. 3
2. Open Instructions
Carefully unpack the box and check the contents
to ensure that all parts are present and in good
conditions. If anything damaged during transit,
notify the shipper immediately and keep the packing
material for inspection. Again, please save the carton
and all packing materials. If the fixture must be
returned to manufacturer, it is important that the
fixture be returned in the original manufacturer box
and packing.

BEAMER 17R
ENGLISH VERSION
P. 4
3. Safety instructions
Please conserve this manual as operation guidance. If
you sell this product to other user, please make sure
that they also receive this user manual.
1. Always make sure that you are connecting
to the proper voltage and the line voltage not
higher than stated on the decal or rear panel
of the fixture.
2. This lighting is intended to indoor use only.
To prevent risk of fire or shock, do not ex-
pose fixture to rain or moisture. Make sure
therearenoflammable,explosiveorcorrosive
materialin 10metersaroundwhile operating.
3. The unit must be installed in a location with
adequate ventilation, at least 5m away from
adjacent surfaces. Be sure that no ventilation
slots are blocked.
4. Fixture may carry high heat, do not aim at
objective exceeding 2 minutes.
5. Safe wire should be used to install machine.
Bearing of safe wire should be 3 times of the
machine weight.
6. Always disconnect from the power source
before servicing or replacing fuse/lamp and
be sure to replace with same fuse/lamp size
and type. Cut o power before moving, repair-
ing and cleaning the machine.
7. To avoid electric shock, all fixtures must be
connected to circuits with a suitable ground.
8. Always secure fixture using a safety chain and
carrying handles. Never carry the fixture
by its cord.
9. Do not operate at ambient temperatures
higher than 104F(40C).
10. In case of failure or misfunction occurred, stop
using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled
people can lead to damage or malfunction. Please
contactthenearestauthorizedtechnicalassistance
center. Buy the same spare parts/components
from manufacturer directly.
11. Make sure the power cord is never damaged.
12. Avoid direct eye exposure to the light source
while it is on.
13. Do not power on and power o the fixture in a
short time.
14. When use DMX controller, please make sure
that there is no interference sources (e.g. inter-
com, high frequency radio waves and radiation.
Caution
There are no user serviceable parts inside
the unit. Do not open the housing or attempt
any repairs yourself. If exceptional problem
happen, please contact related aer-sale de-
partment or manufacturer. Any damage that
cased by violating this manual is out of insur-
ance, our company will not take the respon-
sibility.

BEAMER 17R
ENGLISH VERSION
P. 5
Installation
Installation Requirements
• This machine should be mounted through the
screw holes of truss. Safety wire is a must to fix
fixture well. Make sure truss and safety wire have
strong load capacity to bear 3 times weight than
fixture at least.
• This machine should be installed by qualified
technician.
Controlling Board
MENU
UP
DOWN
ENTER
SIG
MIC
MENU
UP
DOWN
ENTER
SIG
MIC

BEAMER 17R
ENGLISH VERSION
P. 6

INPUT OUTPUT
DMX -
DMX +
Common
1
231 2
3
Machine Connection
• Cables must have a male XLR connector on one
end and a female XLR connector on the other end
• A word on termination: DMX is a resilient commu-
nication protocol, however errors still occasional-
ly occur. Termination reduces signal errors, and
therefore best practices include use of a ternina-
tor in all circumstances. If you are experiencing
problems with erratic fixture behavior, especially
over long signal cable runs, a terminator may help
improve performance.
• To build your own DMX Terminator: Obtain a 120-
ohm, 1/4-watt resistor, and wire it between pins
2&3 of the last fixture. They are also readily availa-
ble from specialty retailers.
1
2
3120-ohm, 1/4-watt resistor
Complimentary signal cable can transmits sig-
nals to 20 unit fixtures at most. Signal amplifier
is a must to connect more fixtures
4. Troubleshooting
Problem Probable Cause(s) Remedy
No response from fixture
when power is applies
No power to fixture Replace fuse
Primary fuse blown Replace fuse
Secondary fuse blown Connect controller

BEAMER 17R
ENGLISH VERSION
P. 7
Fixture resets but does not
respond correctly to con-
troller(DMX mode opera-
tion)
Controller not connected Connect Controller
Incorrect addressing of the
fixtures
Check address setting on
fixture and controller
Bad data link connection Inspect cables and cor-
rect poor connections
and/or broken cables.
Conflict between tracking
and vector control
Eliminate scene cross-
fade on controller
Data link not terminated Insert termination plug
in output of last fixture
Defective fixture or 2 de-
vices transmitting on link
Bypass fixtures one at a
time until normal oper-
ation is regained:unplug
both connectors and
connect them directly
together
Colors cannot be mixed Random color mixing is on Turn o random color
mixing
Fixure does not reset cor-
rectly
Electronic or mechanical
failure
Contact service techni-
cian
No light, lamp cuts out
intermittently,or burns out
too quickly
Lamp missing or blown Disconnect fixture and
replace lamp
Fixture or lamp is too hot Allow fixture to cool. If
problem persists,contact
service technician

BEAMER 17R
P. 8
ENGLISH VERSION
5.Reference
DMX Protocol 20CH MODE
Channel Function Eect
1 Pan Scan 000~255 0-540°
2 Pan Bit 000~255 2° adjust
3 Tilt Scan 000-255 0°-270°
4 Tilt Bit 000-255 2° adjust
5 Pan/Tilt speed 000-255 from fast to slow
6 Shutter 001~031 Light o
032~063 Light on
064~095 strobe from slow to
fast 096~127 Light on
128~159 free strobe, from slow
to fast
160~191 Light on
192~250 skip strobe, from slow
to fast
251~255 Light on
7 Dimmer 000-255 from dark to bright

BEAMER 17R
ENGLISH VERSION
P. 9
8 Color 000~004 Open
005~009 Red
010~014 Yellow
015~019 Dark Blue
020~024 Green
025~029 Magenta
030~034 Blue
035~039 Dark Yellow
040~044 CTB
045~049 Green
050~054 CTO 3200K
055~059 Red
060~064 Orange
065~069 CTO 2500K
070~189 color linear change
190~219 forward flow, from
fast to slow
220~224 Open
225~255 reverse flow, from
slow to fast
Channel Function Eect

BEAMER 17R
ENGLISH VERSION
P. 10
9 Fixed Gobo 000~003 open
004~009 Gobo 1
010~015 Gobo 2
016~021 Gobo 3
022~027 Gobo 4
028~033 Gobo 5
034~039 Gobo 6
040~045 Gobo 7
046~051 Gobo 8
052~057 Gobo 9
058~063 Gobo 10
064~069 Gobo 11
070~075 Gobo 12
076~081 Gobo 13
082~087 open
shaking from slow to fast
088~095 Gobo 1 shaking
096~103 Gobo 2 shaking
104~111 Gobo 3 shaking
112~119 Gobo 4 shaking
120~127 Gobo 5 shaking
128~135 Gobo 6 shaking
136~143 Gobo 7 shaking
144~151 Gobo 8 shaking
152~167 Gobo 9 shaking
168~175 Gobo 10 shaking
176~183 Gobo 11 shaking
184~191 Gobo 12 shaking
192~199 Gobo 13 shaking
200~201 No Scroll
202~227 forward flow, fast to
slow
228~229 No Scroll
230~255 reverse flow, slow to
fast
Channel Function Eect

BEAMER 17R
ENGLISH VERSION
P. 11
10 Rotating Gobo 000~009 open
010~019 Gobo 1
020~029 Gobo 2
030~039 Gobo 3
040~049 Gobo 4
050~059 Gobo 5
060~069 Gobo 6
070~079 Gobo 7
080~089 Gobo 8
090~099 Gobo 9
shaking from slow to fast
100~110 Gobo 1 shaking
111~121 Gobo 2 shaking
122~132 Gobo 3 shaking
133~143 Gobo 4 shaking
144~154 Gobo 5 shaking
155~165 Gobo 6 shaking
166~176 Gobo 7 shaking
177~187 Gobo 8 shaking
188~199 Gobo 9 shaking
200~201 No Scroll
202~227 forward flow, fast to
slow
228~229 No Scroll
230~255 reverse flow, slow to
fast
11 Gobo Rotating 000~127 0°~400° positioning
128~191 forward flow, fast to
slow
192~255 reverse flow, slow to
fast
12 Prism 1 000-127 prism stop
128-255 prism running
Channel Function Eect

BEAMER 17R
P. 12
ENGLISH VERSION
13 Prism 2 000-127 prism stop
128-255 prism running
14 Prism Rotate 0°~400° positioning
128~191 forward flow, fast to
slow
192~255 reverse flow, slow to
fast
15 Frog 000-255 0~100% frog
16 Focus 000-255 0~100% focus
17 Focus Bit 000-255
18 Zoom 000-255 3.8°-45°
19 Zoom Bit 000-255
20 Function 000~029 no function
030~050 stay above 5 second,
lamp stay on low power
049~059 no function
060~080 stay above 5 second,
lamp stay on full power
081~099 no function
100~105 Lamp o
106~119 no function
120~129 color
130~139 gobo
140~149 prism
150~159 Color, gobo, prism
160~199 no function
200~205 Lamp on
204~139 no function
240~255 Reset
Channel Function Eect

BEAMER 17R
P. 13
ENGLISH VERSION
DMX Protocol 16CH MODE
Channel Function Eect
1 Pan Scan 000~255 0-540°
2 Tilt Scan 000-255 0°-270°
3 Pan/Tilt speed 000-255 from fast to slow
4 Shutter 001~031 Light o
032~063 Light on
064~095 strobe from slow to fast
096~127 Light on
128~159 free strobe, from slow
to fast
160~191 Light on
192~250 skip strobe, from slow
to fast
251~255 Light on
5 Dimmer 000-255 from dark to bright
6 color 000~004 White color
005~009 Color 1
010~014 Color 2
015~019 Color 3
020~024 Color 4
025~029 Color 5
030~034 Color 6
035~039 Color 7
040~044 Color 8
045~049 Color 9
050~054 Color 10
055~059 Color 11
060~064 Color 12
065~069 Color 13
070~189 color liner change
190~219 forward flow, from fast
to slow
220~224 stop
225~255 Reverse flow, from slow
to fast

BEAMER 17R
P. 14
ENGLISH VERSION
7 Fixed Gobo 000~003 open
004~009 Gobo 1
010~015 Gobo 2
016~021 Gobo 3
022~027 Gobo 4
028~033 Gobo 5
034~039 Gobo 6
040~045 Gobo 7
046~051 Gobo 8
052~057 Gobo 9
058~063 Gobo 10
064~069 Gobo 11
070~075 Gobo 12
076~081 Gobo 13
082~087 open
shaking from slow to fast
088~095 Gobo 1 shaking
096~103 Gobo 2 shaking
104~111 Gobo 3 shaking
112~119 Gobo 4 shaking
120~127 Gobo 5 shaking
128~135 Gobo 6 shaking
136~143 Gobo 7 shaking
144~151 Gobo 8 shaking
152~167 Gobo 9 shaking
168~175 Gobo 10 shaking
176~183 Gobo 11 shaking
184~191 Gobo 12 shaking
192~199 Gobo 13 shaking
200~201 open
202~227 forward flow, fast to
slow
228~229 stop
230~255 reverse flow, slow to
fast
Channel Function Eect

BEAMER 17R
P. 15
ENGLISH VERSION
8 Rotating Gobo 000~009 open
010~019 Gobo 1
020~029 Gobo 2
030~039 Gobo 3
040~049 Gobo 4
050~059 Gobo 5
060~069 Gobo 6
070~079 Gobo 7
080~089 Gobo 8
090~099 Gobo 9
shaking from slow to fast
100~110 Gobo 1 shaking
111~121 Gobo 2 shaking
122~132 Gobo 3 shaking
133~143 Gobo 4 shaking
144~154 Gobo 5 shaking
155~165 Gobo 6 shaking
166~176 Gobo 7 shaking
177~187 Gobo 8 shaking
188~199 Gobo 9 shaking
200~201 open
202~227 forward flow, fast to
slow
228~229 stop
230~255 reverse flow, slow to
fast
9 Gobo Rotating 000~127 0°~400° positioning
128~191 forward flow, fast to
slow
192~255 reverse flow, slow to
fast
10 Prism 1 000-127 prism stop
128-255 prism running
Channel Function Eect

BEAMER 17R
P. 16
ENGLISH VERSION
11 Prism 2 000-127 prism stop
128-255 prism running
12 Prism Rotate 0°~400° positioning
128~191 forward flow, fast to
slow
192~255 reverse flow, slow to
fast
13 Frog 000-255 0~100% frog
14 Focus 000-255 0~100% focus
15 Zoom 000-255 3.8°-45°
16 Function 000~029 no function
030~050 stay above 5 second,
lamp stay on low power
049~059 no function
060~080 stay above 5 second,
lamp stay on full power
081~099 no function
100~105 Lamp o
106~119 no function
120~129 color
130~139 gobo
140~149 prism
150~159 Color, gobo, prism
160~199 no function
200~205 Lamp on
204~139 no function
240~255 Reset
Channel Function Eect

BEAMER 17R

BEAMER 17R
P. 28
VERSION ESPAÑOL
1. Descripción
Beamer 17R es un versátil cabezal móvil que cubre
las funciones spot, wash y beam. Potenciado por una
lámpara de arco corto 17R de 350W, el equipo alcanza
una luminosidad de 134.000 lux a 10 metros de distan-
cia. La unidad tiene una rueda de color con 14 filtros +
abierto, con efecto de arcoíris bidireccional, dos filtros
CTO y un filtro CTB. En cuanto a los gobos, el equipo
cuenta con una rueda de 9 gobos rotativos dicroicos,
intercambiables e indexables y una rueda de 14 gobos
estáticos, todos con gobo shaking. Beamer 17R cuen-
ta, además, con filtro frost, un prisma rotativo lineal
de 6 facetas, otro prisma rotativo de 16-facetas y una
función zoom que le permite variar su ángulo entre
3,8º y 45º, condensando 3 funciones en un solo cabezal
móvil.
Especificaciones
Fuente y Optica
• Lámpara 17R de arco corto de 350W
• Vida útil promedio: 1.500 horas
• Temperatura de color: 7800K
• Zoom: 3,8º-45º
• Información Fotométrica
• Flujo Luminoso: 134,000 lux @ 10m (30 .)
• Efectos y Funciones
• Rueda de color: 14 filtros + abierto y efecto ar-
coiris bidireccional
• 2 filtros CTO (2500K & 3200K)
• Rueda de gobo rotativa: 9 gobos dicróicos ro-
tativos intercambiables e indexables + abierto
• Ruedadegoboestática:14gobosindexables&4
reductores de haz
• Diámetro del gobo:diámetro externo 14,9 mm. &
diámetro interno 10,5 mm.
• Efecto gobo shake & gobo morph
• Frost: 0-100%
• Prisma rotativo lineal de 6-facetas & prisma rota-
tivo de 16-facetas
• Foco motorizado
• Dimmer: Rango completo 0-100%
• Efecto estrobo
•
• Control
• Canales DMX: 15/20
• Modos de operación: DMX, Maestro/Esclavo &
automático
• Movimiento
• Pan: 540°
• Tilt: 265°
• Resolución: 16-bit
• Reposicionamiento automático
• Eléctrico
• Rango de voltaje de entrada: 100–240V, 50-60Hz
• Consumo de potencia: 450W
• Físico
• 2 conectores XLR (XLR-3 de entrada & salida)
• Alimentación: PowerCON® de entrada
• Display LCD retroiluminado
• Dimensiones: 420x382x673 mm. / 16,5x15x26,5.

BEAMER 17R
P. 29
VERSION ESPAÑOL
A. Contenido
Que viene Incluido
• 1 Beamer 17R 3-in-1 (lámpara incluida).
• 1 manual del usuario.
• 1 cable de suministro eléctrico.
• 1 cable de señal.
• 2 soportes Omega.
2. Instrucciones
Gracias por haber elegido el producto Beamer 17R
3-in-1. Abra la caja con cuidado y verifique que todas
las piezas se encuentren presentes y en buen estado.
En caso de que encuentre piezas faltantes o dañadas
por el envío, póngase en contacto de inmediato con su
distribuidor. Si el equipo tuviere que ser devuelto a la
fábrica, utilice la caja y el envoltorio originales.

BEAMER 17R
P. 30
VERSION ESPAÑOL
3. Seguridad
Conserve el presente manual para futuras referencias.
En caso de vender la unidad, procure entregar esta
guía al comprador.
1. Utilice el equipo únicamente con la corriente
alterna indicada en las especificaciones téc-
nicas. Compruebe que el voltaje utilizado no
sea superior ni inferior.
2. Esta equipo se diseño para uso profesional
en espacios interiores. No exponga el equipo
al agua o la humedad con el fin de evitar
descargas eléctricas.
3. Instale el equipo en una zona con ventilación,
a una distancia de, al menos, 5 metros de
otros objetos y 10 metros de superficies
inflamables. Asegúrese de no obstruir las
ranuras de ventilación.
4. Laluzproducealtatemperatura,nolaproyecte
sobre objetos durante más de 2 minutos.
5. Utilice un cable de seguridad para fijar el
equipo al punto de instalación. El cable debe
soportar tres veces el peso del equipo.
6. Siempre desconecte el equipo del suministro
eléctrico antes de realizar cualquier tarea de
mantenimiento o de reemplazar el fusible (utilice
siempre un repuesto del mismo tipo y tamaño).
7. Procure la conexión a tierra del equipo para
prevenir descargas eléctricas.
8. Nunca tire del cable de suministro eléctrico para
trasladar el equipo. Utilice las manijas.
9. No utilice el equipo si la temperatura ambiente
supera los 40 °C (104 °F).
10. En caso de que exista un problema serio de
funcionamiento, deje de utilizar la unidad
inmediatamente. Si el equipo precisa reparación,
pónganseencontactoconelserviciotécnicoauto-
rizado. Las reparaciones realizadas por personas
inexpertas pueden causar daños irreparables.
11. Verifique que el cable de suministro eléctrico no
se encuentre cortado o dañado.
12. No mire de forma directa a la fuente de luz
cuando el equipo esté encendido.
13. Evite encender y apagar el equipo de forma
simultánea.
14. Procure que no haya fuentes de interferencia
(radios de alta frecuencia, intercomunicadores,
etc) cuando utilice un controlador DMX.
Precaución
Evite desarmar el equipo. En su interior no
hay piezas que puedan ser reparadas por el
usuario. En caso de que el equipo precise rep-
aración, póngase en contacto con el servicio
técnico autorizado.
La garantía no cubre daños causados por el
uso inapropiado de este producto. El fabri-
cante y el proveedor no aceptarán responsa-
bilidad por el mal uso del equipo.
