CK WORLDWIDE CK9 FLEX Series User manual

HEAD STYLE CABLE STYLE CABLE LENGTH STANDARD # SUPERFLEX #
Flex Head
w/o Valve
1 Piece 12-1/2 ft. (3.8 m) CK9-12-R FX CK9-12-RSF FX
25 ft (7.6 m) CK9-25-R FX CK9-25-RSF FX
2 Piece 12-1/2 ft. (3.8 m) CK9-12-2 FX CK9-12-2SF FX
25 ft (7.6 m) CK9-25-2 FX CK9-25-2SF FX
Flex Head
w/Valve
1 Piece 12-1/2 ft. (3.8 m) CK9V-12-R FX CK9V-12-RSF FX
25 ft (7.6 m) CK9V-25-R FX CK9V-25-RSF FX
2 Piece 12-1/2 ft. (3.8 m) CK9V-12-2 FX CK9V-12-2SF FX
25 ft (7.6 m) CK9V-25-2 FX CK9V-25-2SF FX
CK WORLDWIDE INC.
WARRANTY:
CK Worldwide, Inc. warrants products manufactured by CK Worldwide, Inc. to
be free of defects in materials and workmanship. CK Worldwide, Inc. limits this
warranty to replacement of the product or parts thereof and excludes liability for
injury, property damage or economic loss attributable to product use or misuse.
In any event, CK Worldwide, Inc. will only be responsible for its products when
used with accessory items manufactured by CK Worldwide, Inc.
INSTALLATION:
Before using this torch, - tighten regulator, hose and power cable fittings with
proper wrenches. Using small pliers, securely tighten all knurled hose fittings
(Slide the torch handle back for access to the torch connections). Purge the
regulator and TIG torch with inert gas at 20 cubic feet per hour. Following these
steps will ensure contamination free welds. Repeat this procedure whenever
torch or regulator fittings have been detached.
CONNECTION
DIAGRAM:
CAUTION:
Personal harm will result from touching the hot parts of a TIG torch without
insulative protection, or from looking directly or indirectly at an arc or reflected
arc. At no time should bare skin be exposed to a welding arc.
TUNGSTEN
PREPARATION:
GRINDING PREPARATION:
Use a 60 Grit or finer aluminum
oxide wheel
EXTENSION INSTRUCTION:
STANDARD PARTS
General Purpose:
Flat:
1/4 to 1/2 x Diameter
Taper:
2 to 3 x Diameter
3 x Diameter from end of cup.
END PREPARATION:
DCSP (EN)
General Purpose:
Ball tip by arcing on clean metal
at low current DCRP (EP) then
slowly increase current to form
the desired ball diameter.
The included angle determines weld
bead shape and size. Generally,
as the included angle increases,
penetration increases and bead
width decreases.
Maximum extension:
6 x Diameter from end of cup.
(In draft - free areas)
Ball:
Maximum 1 x Diameter
Remove sharp point to leave a
truncated point with a flat spot.
Diameter of flat spot determines
amperage.
3 x Diameter from end of cup.
Shape tungsten by grinding
logitudinally, never radially.
ACHF
General Purpose:
GAS LENS PARTS
General Purpose:
INFORMATION
CHART:
ARGON FLOW
- ALUMINUM
ARGON FLOW
- FERROUS METALS
WELDING CURRENT (AMPS)
- TUNGSTEN TYPE
Gas Lens
Body
(Liters)
Standard
Body
(Liters)
Gas Lens
Body
(Liters)
Standard
Body
(Liters)
DCSP
Thoriated
DCSP
Pure
AC
Thoriated
AC
Pure
.020 (0.50)
.040 (1.00)
1/16 (1.60)
3/32 (2.40)
1/8 (3.20)
5/32 (4.00)
3/16 (4.80)
1/4 (6.40)
Cup
Size
Electrode
Diameter
in inches
(mm)
5-8 (3-4)
5-10 (3-5)
7-12 (4-6)
10-15 (5-7)
10-20 (5-10)
12-25 (6-12)
15-30 (7-14)
25-45 (12-21)
5-8 (3-4)
5-12 (3-6)
8-15 (4-7)
10-20 (5-10)
12-25 (6-12)
15-30 (7-14)
25-40 (12-19)
30-55 (14-26)
5-8 (3-4)
5-8 (3-4)
5-10 (3-5)
8-10 (4-5)
8-12 (4-6)
12-25 (6-12)
20-35 (10-17)
10-15 (5-7)
5-8 (3-4)
5-10 (3-5)
7-12 (4-6)
10-15 (5-7)
10-18 (5-9)
15-25 (7-12)
20-35 (10-17)
25-50 (12-24)
5 - 20
20 - 80
80 - 150
150 - 250
240 - 350
400 - 500
475-800
700 - 1100
5 - 15
15 - 70
70 - 130
150 - 220
220 - 330
375 - 475
475-800
5 - 20
15-80
70 - 150
140 - 235
220 - 325
300 - 425
400 - 525
500 - 700
5 - 15
10 - 60
50 - 100
100 - 160
150 - 210
200 - 275
250 - 350
325 - 700
4 or 5
4 or 5
4, 5 or 6
6, 7 or 8
7, 8 or 10
8 or 10
8 or 10
10 750 - 1000
1 PIECE
CABLE ASSEMBLY
2 PIECE
CABLE ASSEMBLY
CK WORLDWIDE INC. PHONE: [phone] www.ckworldwide.com
3501 “C” ST. N.E. PHONE: [phone] [e-mail]
AUBURN, WA. 98002 FAX: [phone]
USA
IMPORTANT !!
READ AND UNDERSTAND THE
INFORMATION CONTAINED IN THIS
MANUAL BEFORE OPERATING THE EQUIPMENT !
TECHNICAL INFORMATION
TIG TORCH MANUAL
RATING @ 100% DUTY CYCLE:
COOLING METHOD:
HEAD ACCESSORIES:
POWER CABLE ADAPTOR:
125 AMP ACHF OR DCSP
GAS COOLED
2 SERIES HEAD ACCESSORIES
105Z57 (15PCA)
CK9 & CK9V FLEX
CK9F
ACCESSORY ITEMS REQUIRED FOR COMPLETE INSTALLATION:
MODEL SELECTOR - TORCH PACKAGES

PARTS:
PARTS LIST: ACCESSORIES:
CK9 FLEX ...............
CK9V FLEX ............
VKS .................
9HR ........................
1512CN ....................
1525CN ....................
57Y01-R ...............
57Y01-RSF ...............
57Y03-R ................
57Y03-RSF ................
57Y01-2 ..................
57Y01-2SF ..................
57Y03-2 ..................
57Y03-2SF ..................
200R .........................
45V09 ......................
45V09SF ......................
45V10 ......................
45V10SF ......................
2GHS .......................
200R .........................
41V35 .........................
PART NUMBERDESCRIPTION
TORCH BODY, FLEX, 70 DEGREE, 125 AMP
TORCH BODY WITH VALVE, FLEX, 70 DEGREE, 125 AMP
GAS VALVE, TOP MOUNTED
HANDLE
POWER CABLE WITH FITTINGS, 12-1/2 FT.
POWER CABLE WITH FITTINGS, 25 FT.
POWER CABLE ASSEMBLY, HI-FLEX 1 PIECE, 12-1/2 FT.
POWER CABLE ASSEMBLY, SUPER FLEX 1 PIECE, 12-1/2 FT.
POWER CABLE ASSEMBLY, HI-FLEX 1 PIECE, 25 FT.
POWER CABLE ASSEMBLY, SUPER FLEX 1 PIECE, 25 FT.
POWER CABLE ASSEMBLY, HI-PERFORMANCE 2 PIECE, 12-1/2 FT.
POWER CABLE ASSEMBLY, SUPER FLEX 2 PIECE, 12-1/2 FT.
POWER CABLE ASSEMBLY, HI-PERFORMANCE 2 PIECE, 25 FT.
POWER CABLE ASSEMBLY, SUPER FLEX 2 PIECE, 25 FT.
O-RING
GAS HOSE WITH FITTINGS, 12-1/2 FT.
GAS HOSE WITH FITTINGS, 12-1/2 FT., SUPER FLEX
GAS HOSE WITH FITTINGS, 25 FT.
GAS HOSE WITH FITTINGS, 25 FT., SUPER FLEX
HEAT SHIELD, STANDARD
O-RING
BACKCAP, MEDIUM
PART NUMBERDESCRIPTION
15PCA (105Z57)...........
SL2.............................
SL2-25............................
SL2-35......................
SL2-35M...................
2AN.......................
3HF.........................
15PFN........................
5PF....................
15PF..........................
POWER CABLE ADAPTER
ONE PIECE POWER CABLE ONLY
TWECO POWER CABLE ADAPTER
DINSE-25 POWER CABLE ADAPTER
DINSE-35 POWER CABLE ADAPTER
DINSE 35 FLOW-THRU GAS
POWER CABLE ADAPTER
ARGON NUT
HOSE FITTING
POWER CABLE FITTTING AND NUT
POWER CABLE FITTING
POWER CABLE FITTING
CK9 FLEX
200R
41V35
2GHS
VKS
200R
2GHS
57Y01RSF (12-1/2 ft.) 57Y03RSF (25 ft.)
1512CN (12-1/2 ft.) 1525CN (25 ft.)
45V09SF (12-1/2 ft.) 45V10SF (25 ft.)
57Y01-2SF (12-1/2 ft.) 57Y03-2SF (25 ft.)
57Y01R (12-1/2 ft.) 57Y03R (25 ft.)
45V09 (12-1/2 ft.) 45V10 (25 ft.)
57Y01-2 (12-1/2 ft.) 57Y03-2 (25 ft.)
2AN 3HF
15PFN 5PF
15PF 15PF
CK9V FLEX 9HR
CUPCOLLET BODY COLLETHEATSHIELDTORCH BACKCAP
ALUMINASTANDARD
2A4GS
2A5GS
2A6GS
2CBGS 2HSGS
WEDGE
2C040GS
2C116GS
2C332GS
2C418GS
STANDARD
ADAPTER
WITH SCREEN LONG
200L (41V24)
MEDIUM
200M (41V35)
SHORT
200S (41V33)
2A7GS
2A8GS
CLEAR
2P8GS
WITHOUT SCREEN
TORCHES
USED ON:
CK100
CK110
CK130
CK200
CK230
FL2L
CKM230
CWH230
CLEARLARGE DIAMETER
2P18GSLD 2CBGSLD 2HSGSLD
WEDGE
See Above
LARGE DIAMETER
TAS040GSLD
TAS116GSLD
TAS332GSLD
TAS418GSLD
LARGE DIAMETER
WITH SCREEN
TAS040GS
TAS116GS
TAS332GS
TAS418GS
TA040GS
TA116GS
TA332GS
TA418GS
CWM230
CK9
CK20
2 SERIES HEAD ACCESSORIES GAS SAVER
CUP COLLET BODY COLLET HEATSHIELDTORCHBACKCAP
ALUMINA
STANDARDSTANDARDSTANDARD
2A7 (13N11)
2A8 (13N12)
2A10 (13N13)
2C20 (13N20)
2C40 (13N21)
2C116 (13N22)
2C332 (13N23)
2C418 (13N24)
2GHS
2CB20 (13N25)
2CB40 (13N26)
2CB116 (13N27)
2CB332 (13N28)
2CB418 (13N29)
CERAMIC
2C4 (13N14)
2C5 (13N15)
2C6 (13N16)
2C7 (13N17)
2C8 (13N18)
2C10 (13N19)
CERAMIC - LONG
2A3L (A796F70)
2A4L (A796F71)
2A5L (A796F72)
2A6L (A796F73)
WEDGE
2C040GS
2C116GS
2C332GS
2C418GS
6C20
6C40
6C116
6C332
6C418
REVERSE
LONG
200L (41V24)
MEDIUM
200M (41V35)
SHORT
200S (41V33)
ALUMINA - GAS LENS GAS LENS STANDARD STANDARD
2AG4 (53N58)
2AG5 (53N59)
2AG6 (53N60)
2AG7 (53N61)
2AG8 (53N61S)
2GL20 (45V41)
2GL40 (45V42)
2GL116 (45V43)
2GL332 (45V44)
2GL418 (45V45)
See Above See Above
WEDGE
See Above
REVERSE
See Above
ALUMINA - LARGE DIAMETERLARGE DIAMETER
LARGE DIAMETER
LARGE DIAMETER
2C020LD(13N20L)
2C040LD(13N21L)
2C116LD (13N22L)
2C332LD (13N23L)
2C418LD (13N24L)
2GHSLD
CERAMIC
SHORT STANDARD
8C6 (53N27)
6CB20
6CB40
6CB116
6CB332
6CB418
See Above
REVERSE
See Above
CERAMIC - LONG
8C4L (53N28)8C6L (53N26)
3AG6LD(57N75)
3AG8LD(57N74)
3AG10LD(53N88)
2GL0204LD(45V0204S)
2GL116LD (45V116S)
2GL332LD (45V64S)
2GL418LD (995795S)
TORCHES
USED ON:
CK100
CK110
CK130
CK200
CK230
FL2L
CKM230
CWH230
CWM230
CK9
CK20
2C3L (796F70)
2C4L (796F71)
2C5L (796F72)
2C6L (796F73)
2A4 (13N08)
2A5 (13N09)
2A6 (13N10)
ALUMINA - LONG
8C4 (53N24)
8C5 (53N25)
Size Suffix Inches Millimeters
020.020".5mm
040.040"1.0mm
1161/16"1.6mm
3323/32"2.4mm
4181/8"3.2mm
5325/32"4.0mm
TUNGSTEN ELECTRODE CONVERSION CHART
3AG11LD(53N89)
3AG12LD(53N87)
ALUMINA
8A4 (A53N24)
8A5 (A53N25)
8A6 (A53N27)
2 SERIES HEAD ACCESSORIES
2
CK WORLDWIDE INC.
APPLICATIONS OF:
STANDARD PARTS:
ARE FOR GENERAL PURPOSE USE.
WEDGE COLLETS:
IMPROVE ARC STARTING.
IMPROVE ARC STABILITY.
IMPROVE ARC CONTROL.
CERAMIC (LAVA) CUPS:
ARE USED WHEN REFLECTED HEAT IS
HIGH.
ALUMINA CUPS:
ARE USED FOR GENERAL PURPOSE,
AND WHEN IMPACT RESISTANT CUPS
ARE REQUIRED.
GAS LENS PARTS:
ARE USED TO REDUCE TURBULENCE
AND IMPROVE SHIELD GAS COVERAGE
PATTERNS,
INCREASES DUTY CYCLE OF TORCH
AND INCREASES TUNGSTEN STICK
OUT.
SHORT (STUBBY) PARTS:
ARE USED TO SHORTEN THE OVERALL
LENGTH OF THE TORCH HEAD.
REDUCES DUTY CYCLE OF TORCH
GAS SAVER
®
PARTS:
ARE USED TO SAVE UP TO 40% ON GAS
CONSUMPTION.
ARE USED TO SAVE UP TO 60% ON
CONSUMABLE PARTS.
ARE USED TO CLEARLY SEE THE WELD
PUDDLE.
ARE USED TO ACHIEVE GAS LENS 3
CK WORLDWIDE INC.
