CKO DF-515151 User manual

Car Rear View Security System
User Guide
Before using the products, please read the
manual and preserve it well.
Warning
Specifications and manual content are subject to
change without any notice.

Five inch high resolution color TFT LCD.
Free power input: DC11V-32V.
Three-channel CVBS input,one-channel video input.
Normal/mirror image setup.
Automatic/manual selection,when sutomatic,monitor in sleeping mode.
Compulsory signal switch:The images from CAM1 or CAM2 will be
activated automatically,when backing up the car or opening the
door of car.Reversing image priority.
Power supply of camera:while CAM1/CAM2 is in operation,power of CAM2/CAM1
will be cut off automatically.Effectively prolong the life of the cameras and fulfill
the objective of saving car power.
Jacks of AV input and output.
Automatic induction of LED indicator.It will be activated
automatically while the environment is dark,so that the user
still can see the key of the monitor clearly.
Double PCB,effectively heighten the ability of shock resistance.(8G)
Remote control or manual operation.
Shell of the monitor is made from ABS resisting hight temperature and blast.
Blue light indicates startup,and red light indicates sleeping mode.
★
★
★
★
★
★
★
★
★
★
★
★
★
KIT CHARACTERISTICS Before you request for repair
1
Phenomena below are not necessary mean failure with Display.
Please check off per following methods before you request for repair.
18
Phenomena
Possible Causes
No picture, no sound
Improper connection with Automobile adapter. Use of
unauthorized power supply.Power Switch is on OFF
position.
No picture
Check whether AV line is plugged well.
No sound
Whether audio wire is connected well, or the sound volume is
turned off or till minimum.
Dark picture
Whether bright and contrast adjust correctly;Whether
environment temperature too low.
No color
Whether color is well-adjusted
Upside down or lateral
inverted picture
Maybe improperly adjusted Horizonal,Vertical on the remote
controller.
No backing function
(i.e. Picture)
Whether the single blown/blue AV wire connecting to the
positive power cord of reversing light is loose or not. Whether
the connection head of red CAM socket is of poor contact.

PRECAUTIONS
17 2
This manual is just for reference. Any changes with the information, we will not
give notice to yu. Any wrongor un-detailed thing, the explaination right belongs to
the manufacturer.
There is not any reparable parts in the system, so please do not take apart the
CCD camera or the monitor. It is dangerous with the high voltage in the products.
Itmust be the special worker to repair and regulate the products.
Warning
Notice
★Before using our products,please read this manual first.
★Before connection to power,please check the connection of cables,
if improper connection occurs,it may damage the picture。
★The monitor is not waterproof,please don not place the monitor
outdoor.
★In order to avoid damaging the components,please do not use the
products,while welding in your car.
★Please make sure all the cables are connected tightly,or else the
system will not work well.
★Please do not put the cables together with high temperature and
rotary objects.。
★In order to evacuate the hight temperature inside the monitor,
please do not jam the holes in the shell.
★Please do not use caustic chemicals to wipe the camera and
monitor.
★High voltage inside the monitor,non-specialist do not open the
back shell.。
★Do not open the housing of the camera,otherwise the waterproof
device and chipset inside it will be demaged.
★While driving,please do not watch DVD,etc.
Accessories
Ⅴ、 railer backup camera system connectionT
pri ority o f rever se came ra
Truck
LCD Color Monitor
P
P
Tra ile r con nec tor
Rear Vi ew Camera
Waterproof Joint Cable
To Camera 2
C
M
C
Field of View:115°
Field of View:95°
To Camera 1
CAM 1
CAM 2
Auto cigarette lighter Input:DC11~32V
CAM1 To start reversing wire
CAM2To start reversing wire
Camera
extension cable
Remote control
Cigarette lighter
adaptor
4pin screw AV Cable
switching cable
U-shape Mount
Trailer extensionTrailer extension Trailer connector
SYSTEM CONNECTION
M

Ⅰ、Technical parameters
316
MONITOR
Bright spots or dark spots may appear on the screen. This is a normal phenomenon
associated with the active matrix display technology and is not a sign of malfunction. Do
not attempt to maintain. For any failures, please turn off the unit immediately and contact
us or local dealer. This device integrates a great deal of fine electronic components.
Disassembly or alternation may result in
damages or breaks.
Special Notice
LCD Color Monitor
FUSE
CAM2
CAM1
11 - 32V v olt age i nput
Power input
CAM3
To start reversing wire(Brown)CAM1
To start reversing wire(Blue)CAM2
Field of View:115°
C
M
C
C
LCD Color Monitor
FUSE
CAM2
CAM1
11 - 32V v olt age i nput
Power input
CAM3
To start reversing wire(Brown)CAM1
To start reversing wire(Blue)CAM2
Field of View:115°
C
M
C
C
YELLOW VIDEO
WHITE AUDIO
AV inp ut
M
M
SYSTEM CONNECTION
Ⅲ、System connection diagram 3
Ⅵ、System connection diagram 4
Display Device
Color TFT-LCD
Size
5.0 inch(Diagonal)
Interface
Digital TTL
Analog
Resolution
640×RGB×480
320×RGB×234
Dot Pitch(mm)
0.0529(W)X0.1587(H)
0.107(W)X0.319(H)
Luminance (nits)
300
300
Contrast Ratio
500:1
500:1
Response Time (ms)
25
25
View Angle (LR/UD)
130 / 140
110 / 50
Audio output
≤1W
Loudspeaker
φ4.0cm,16Ω/1W
Connect plug
9/13pinsS-VIDEO
Application Power
Supply
1.AC power supply-AC Adapter(DC11V-32V)
2.Automobile storage battery (12V/24V) Automobile adapter
Power Consumption
5W Max
Outer Dimension
W152mm×H109mm×T50mm
Weight
350g
Rear view Camera
Camera
Rear view Camera
Camera
Camera

Ⅱ、Appearance and accessories
15 4
MONITOR
Ⅰ、System connection diagram 1
Ⅱ、System connection diagram 2
LCD Color Monitor
To Camera 2
Waterproof connector
Auto cigarette lighter Input:DC11~32V
Reversing s cable ignal CAM2 (blue)
Rear View Camera
Reversing s cable CAM1ignal (brown)
connect follo w the j ack m ark “ ”
extension cable
4pin screw AV cable
CAM2
CAM1
yellow Video
white ( audio)
AV input
Waterproof connector
To Camera 1
Field of View:115°
C
M
LCD Color Monitor
To Camera 2
Waterproof connector
Auto cigarette lighter Input:DC11~32V
Reversing s cable ignal CAM2 (blue)
Reversing s cable CAM1ignal (brown)
connect follo w the j ack m ark “ ”
extension cable
CAM2
CAM1
Field of View:115°
C
M
C
extension cab le
Rear View Camera
Camera
M
M
SYSTEM CONNECTION
Color LCD Screen
Sunshade
Remote receiving window
Volume-
Volume+
Menu
Down
Cam1/Cam2 Shift
Bracket
nameplate
Londspeaker
Audio/video singal output
CDS indicator
Brightness inductive component is
embedded, please do not block the hole.
Power on/off
Radiation Hole
Bracket Aid Steel Plate
Insert the AV connector into the output jack,
the video will be transferred to the other
monitor, and at this moment the monitor
has no audio input.
Bottom Clip-buckle Top Clip-buckle
M

veise
veise
veise
veise
veise
veise
veise
veise
Ⅲ、 recautionsP
Storage and Keeping
Keep this machine
away from too hot
or too cold places.
The storage
temperature of this
machine is-20~60 ,
the application
temperature of this
machine is 0~40 .
Avoid t h i s
machine f r o m
dropping o r
i m p a c t i n g .
Never make the
TV set under
affection of
moisture, dust or
oil smoke etc.
Environment.
Never put this
machine within
certain box at
your will or
place it at toooscillating
place and under
further severe
collision.
Please wipe the
machine cover,
display screen
and buttons with
soft cloth dipped
with little soft
abluent.
514
Never use this
machine near
bathtub, wash
basin, kitchen, etc
places with water
or at damp
basement,
swimming pool or
similar places.
Never extrude or
frictionize this
machine with
sharp objects.
Maintenance
Please plug off all connection wires before you start cleaning this
machine.
Alcoho l
Never wipe this
machine with
abrasion cloth,
abstergent powder,
alcohol and
benzene etc. various
propellants or
chemical cleaning
media.
MONITOR CAMERA
5.78mm×4.19mm
1/3"CMOS
Image Pick-up Device
TV System
Image Size
Picture Elements
Scanning Frequency
Horizontal Resolution
Electronic Shutter Time
S/N Ratio
Minimum illumination
Gain control
Lens furnished
Sync system
Horizontal:15.625KHz Horizontal: 15.7343KHz
Vertical: 50Hz Vertical: 60Hz
PAL
330 TV Lines
NTSC
330 TV Lines
500(H) 582(V)×510(H) 492(V)×
White Balance
Electronic Shutter Control
γcharacteris
Video Out
Horizontal:15.625KHz Horizontal: 15.7343KHz
Vertical: 50Hz Vertical: 60Hz
Board lens 2.9~8mm/F2.0(optional)
1/50(1/60)-1/100,000(sec)
420 TV Lines
500(H) 582(V)×
1.0Lux(F:2.0) / 0 Lux At Night ( IR LED ON)
Automatic(2500K to 9500K)
CCIR
Internal synchronization
More than 48db
Automatic
Automatic
4.9mm×3.7mm
1/3"B/W CCD
1.0Vp-p 75Ω
0.45
EIA
510(H) 492(V)×
380 TV Lines
COLOR CAMERACMOS
CAMERA B/W CCD CAMERA

Ⅳ、MENU OPERATION
Press to display options as following:
PICTURE CHANNEL OPTION SYS TEM
Note: Only when displaying the picture of NTSC system,it will show
the character of TINT in the picture menu
13 6
1、Picture
bright,Contrast,color and TINT displays on the screen as illustrated below
Down key Left or Right
Down key Left or Right
Press to select bright,press adjust the analog quantity of bright
from 0 to 100.
Press in turn to select contract color and TINT and press adjust the
analog quantity of contract, Color and TINT.
BRIGHTNESS 50
CONTRAST 50
SATURATION 50
SELECT ADJUST
CHANNEL OPTION
CAM1 NORMAL
CH PRIOITY CAM1
CH DELAY CAM1
DELAY TIME 0S
CAM2 MIRROR
SELECT ADJUST
2、channel choose
Cam1,Cam2,CH prioity,CH delay,Delay time display on the screen as
illustrated below:
MONITOR
Press Down key to select Cam1 or Cam2, press Left or Right to change image Mirror to
Normal or normal to mirror.
Press Down key to select CH prioity,press Left or Right to change Cam1 to Cam2 or Cam2
to Cams.
Press Down key to select CH delay,press Left or Right to choose Cam1 or Cam2 or both
Came1 and Cam2 with delay function.
Press Down key to select delay time,press Left or Right to adjust the delay time from 0s
to 30s
Ⅳ、Technical Parameters
CAMERA
1/4"SHARP CCD
3.6mm×2.7mm
Horizontal:15.625KHz Horizontal: 15.7343KHz
Vertical: 50Hz Vertical: 60Hz
PAL
420 TV Lines
NTSC
380 TV Lines
500(H) 582(V)×510(H) 492(V)×
Image Pick-up Device
TV System
Image Size
Picture Elements
Scanning Frequency
Horizontal Resolution
Electronic Shutter Time
S/N Ratio
White Balance
Electronic Shutter Control
Video Out
Minimum illumination
Gain control
Lens furnished
Sync system
γcharacteris
Horizontal:15.625KHz Horizontal: 15.7343KHz
Vertical: 50Hz Vertical: 60Hz
Board lens 2.9~8mm/F2.0(optional)
1/50(1/60)-1/100,000(sec)
Automatic(2500K to 9500K)
PAL
Internal synchronization
1.0Lux(F:2.0) / 0 Lux At Night ( IR LED ON)
More than 48db
420 TV Lines
1.0Vp-p 75Ω
Automatic
Automatic
0.45
NTSC
380 TV Lines
4.9mm×3.7mm
1/3"SHARP CCD
COLOR CCD CAMERA
500(H) 582(V)×510(H) 492(V)×
CAMERA
0.8Lux(F:2.0) / 0 Lux At Night ( IR LED ON)
3.6mm×2.7mm
500(H) 582(V)×
Horizontal:15.625KHz Horizontal: 15.7343KHz
Vertical: 50Hz Vertical: 60Hz
PAL
1/4"SONY CCD
420 TV Lines
510(H) 492(V)×
NTSC
380 TV Lines
Picture Elements
Scanning Frequency
Horizontal Resolution
Electronic Shutter Time
S/N Ratio
White Balance
Electronic Shutter Control
Video Out
Minimum illumination
Gain control
Lens furnished
Sync system
γcharacteris
500(H) 582(V)×
Horizontal:15.625KHz Horizontal: 15.7343KHz
Vertical: 50Hz Vertical: 60Hz
Board lens 2.9~8mm/F2.0(optional)
1/50(1/60)-1/100,000(sec)
Automatic(2500K to 9500K)
Internal synchronization
More than 48db
420 TV Lines
1.0Vp-p 75Ω
Automatic
Automatic
0.45
510(H) 492(V)×
380 TV Lines
0.8Lux(F:2.0) / 0 Lux At Night ( IR LED ON)
Image Pick-up Device
TV System
Image Size
PAL
1/3"SONY CCD
4.9mm×3.7mm
NTSC
COLOR CCD CAMERA
CAMERA

712
MONITOR
3、SYSTEM
Attention:CH prioity,CH delay and delay time only operate when backing the car.for
example,Cam1 for CH prioity,if both reversing signal cales with power in,the screen just
displays picture from Cam1,otherwise it displays picture of Cam2. it can select Cam1 or
Cam2 or both with delay function,if Cam1 for CH delay and the delay time is 10s,when
backing the car(reversing cable of Cam1 power input)the screen will displays picture of
Cam1,but when you stop backing car,the screen still displays the picture of Cam1,it will
back to orginal picture after 10s.
Press Down key to select language,press Left or Right to select language to Chinese or
English.
Down key Left or Right Press to select blue screen,press to select blue screen on or off
SYSTEM
LAGUAGE ENGLISH
BLUE SCREEN ON
SELECT ADJUST
CAMERA APPEARANCE CAMERA APPEARANCE
CAMERA
2.Automatic clamshell rear view camera
IR LED
12 IR LED
IR project distance
15 meters
Power supply
DC12/24V/500/250mA
Dimension(mm)
89(W) x 53(H) x 48(D)
Weight
450g

8
11
Ⅰ、Remote control appearence
Ⅱ、Battery of the Remote Controller
Puller Enter
Using the push button(CR2025)
MONITOR REMOTE CONTROL
CAMERA
Ⅲ、camera appearance and dimension
1、Car Backup Camera
Mute
Up
vol-
Picture Mode
Language
Flip horizontal
Power switch
VOL+
Menu
Down
Call
Timer
CAM1/CAM2 shift
Calendar
FLIP virtical
IR LED
9 IR LED
IR project distance
5 meters
Power supply
DC12V/120mA
Dimension(mm)
Φ28mm×42.5mm
Weight
88g
IR LED
NC
IR project distance
NC
Power supply
DC12V/60mA
Dimension(mm)
260mm×32mm
Weight
75g
IR LED
18 IR LED
IR project distance
15 meters
Power supply
DC12V/250mA
Dimension(mm)
76mm×70mm×84mm
Weight
350g
IR LED
18 IR LED
IR project distance
15 meters
Power supply
DC12V/250mA
Dimension(mm)
80mm×63mm×70mm
Weight
350g
IR LED
NC
IR project distance
NC
Power supply
DC12V/60mA
Dimension(mm)
Φ24mm×78mm
Weight
180g
IR LED
NC
IR project distance
NC
Power supply
DC12V/60mA
Dimension(mm)
Φ26mm×31.5mm
Weight
65g
IR LED
NC
IR project distance
NC
Power supply
DC12V/60mA
Dimension(mm)
68.5mm×45mm×41mm
Weight
80g
IR LED
NC
IR project distance
NC
Power supply
DC12V/50mA
Dimension(mm)
Φ14mm×42mm
Weight
100g
IR LED
6 IR LED
IR project distance
5 meters
Power supply
DC12V/150mA
Dimension(mm)
60mm×55mm×60mm
Weight
330g
IR LED
8 IR LED
IR project distance
5 meters
Power supply
DC12V/120mA
Dimension(mm)
48mm×45mm×54mm
Weight
300g
IR LED
8 IR LED
IR project distance
5 meters
Power supply
DC12V/120mA
Dimension(mm)
Φ35mm×74mm
Weight
240g
IR LED
NC
IR project distance
NC
Power supply
DC12V/50mA
Dimension(mm)
Φ25mm×41mm
Weight
80g
IR LED
NC
IR project distance
NC
Power supply
DC12V/50mA
Dimension(mm)
190mm×28mm×23mm
Weight
120g
IR LED
12 IR LED
IR project distance
15 meters
Power supply
DC12V/150mA
Dimension(mm)
62mm×95mm×100mm
Weight
120g

109
MUTE :
Press this button, sound disappears, press it again or
VOL+/ VOL- is to resume normal sound.
POWER :
Press this button is to turn off the monitor, press it again is to
turn on the machine.
CH button(up/down)
press this button to select MENU mode.
VOL - / + (Volume adjust/analog quantity):
Press VOL -,the volume of Display -/analog quantity-.
Press VOL +,the volume of Display +/analog quantity+.
Menu
Press this button to select MENU mode.
MODE:
Press this button, users can realize the five picture statuses of
Standard,Soft, Vivid and light .
CALL:
Press this button is to display AV character currently watching
Press this button is to flip the picture vertically.
Ⅲ、Remote Control operation
Press this button is to flip the picture horizontally.
AV1 / AV2 shift:
Press this button is to realize switch between Cam1 and Cam2
pictures.
Language:
Press this button can realize the switch of Chinese, English,
TIMER
Time setup of sleep off, it is used to set the time off within 120
minutes.
MONITOR REMOTE CONTROL
COLOR
Ground (B LACK)
Power IN (R ED)
Video (YELLOW)
Audio(G reen)
1
2
3
4
2
1
3
4
Ⅰ、Characteristics of Rear View Camera
Ⅱ、Sketch Map for 4-Pin Connector of Camer
1 Alloy shell and 6.8G-force rated shock resistant.
2 High resolution and low power consumption.
3 Audio/Video signal outpur.
4 4pin aircraft grade weatherproof connector.
5 Wide angle and adjustable bracket.
6 Water resistance: IP66.
7 High intensity infrared night vision illuminator.
CAMERA
This manual suits for next models
1
Table of contents
