RHINO RCA User manual

OPERATION INSTRUCTIONS FOR
ROLLING CODE ALARM RCA
HIGH SECURITY SWITCH
Located in the rear of the siren is a master switch. This can be used to turn the system on and off.
Bear in mind that if you plug the alarm while it is armed, the build in backup battery will continue
to power the system. In this case, you must use the keyswitch to disable the alarm.
BACK UP BATTERY TEST
•Insert key, switch to “ON”position.
•Switch to “TEST” position, the siren will sound on the
internal back up battery, if the battery is fully charged.
•
If no siren sound is heard, this indicates a faulty
internal battery.
NOTE: Back up battery requires a minimum of 24 hours
to charge fully after installation.
KEYSWITCH POSITIONS
SYSTEM OFF
SYSTEM ON
BATTERY BACKUP TEST
EMERGENCY PANIC BUTTON OPERATED VIA REMOTE
The panic is activated by pressing the button on the remote control transmitter for 3 seconds. This
sets off the siren. To cancel panic, press the button on the transmitter for 1 second.
TO ARM/DISARM ALARM
Alarm is activated by pressing the button on remote control transmitter. The blinkers will flash once,
and siren will beep, dash LED-light will stay on for 20 seconds then flash, ALARM IS NOW ON. To
deactivate alarm, press the button again. Blinkers will flash 3 times. ALARM IS OFF.
LEARNING NEW TRANSMITTERS
To add a new transmitter to your alarm, simply follow the
procedure below:
RHINO
1. Turn the keyswitch on the rear of the alarm to battery back (test ) position. The siren will sound,
this is OK.
2. Press and hold the button on the new remote control and immediately;
3. Turn the keyswitch on the rear of the alarm to the SYSTEM ON position.
4. Now release the button on the new remote control.
5. The new remote control is now programmed into the alarm.

FEATURES:
•ROLLING CODE ( ANTI SCANNING )
•PREWARN FROM THE SHOCK SENSOR WITH AN EXTERNAL OUTPUT
•LEARNING CODE RECEIVER FOR OPTIONAL TRANSMITTER PROGRAMMING
•CRYSTAL LOCKED TRANSMITTERS ( SAW )
•LONG LIFE LITHIUM TRANSMITTER BATTERIES
•PANIC DISTRESS
•HIGH INTENSITY FLASHING RED LED LIGHT
•AUTO RESET / AUTO REVALUATION
•POWERFUL SIX TONE SIREN
•ONE WIRE INPUT FOR NEGATIVE OR POSITIVE SWITCHING DOORS
•SECURITY CIRCUIT PREVENTS ACCIDENTAL ARMING WHILE DRIVING
•TWO NORMALLY OPEN SECTORS
•IGNITION SENSING INPUT
•FLASHES BLINKERS ONCE TO ARM AND BEEPS SIREN / FLASHES BLINKERS THREE
TIMES TO DISARM
•FLASHES BLINKERS WHEN ALARM TRIGGERS
•2 STAGE PULSE COUNT -SHOCK SENSOR
•EXIT DELAY -20 SECONDS
•EXCEPTIONALLY LOW POWER CONSUMPTION
•RESET PERIOD -60 SECONDS
•POWER OUT -FOR ACCESSORY 150mA RATED
•ALARM MEMORY HISTORY REPORTING MODE
•OPTIONAL QUARTZ LOCKED ULTRASONIC MOTION SENSOR
•INTERNAL ENGINE IMMOBILISATION 30AMPS
•INSTALLER MODE

FEATURES USED BY INSTALLERS / SERVICEMEN
1. INSTALLER / SERVICE MODE TEST
Installer and alarm service mode and test mode is accessed by on powering of
alarm. It is used to check each sector input when door, hood, aux or voltage drop is
triggered. A signal is given via the blinkers and the dash LED light.
Shock sensor adjustment: If a hard shock is received by the shock piezo sensor, one
second flash will be seen from blinkers. If a light shock is received by piezo sensor, a
half second flash will be seen from blinkers.
For proper adjustment of shock sensor go to the rear of vehicle and bump vehicle
until a half second flash is seen from blinkers. When the desired force is applied.
On completion of shock sensor adjustment, you can exit installer mode. This is
accomplished by pushing the button on remote control or turn ignition to on
position.
2. ALARM HISTORY MEMORY READ OUT VIA SIREN AND LED
To access alarm memory turn ignition on and hood opened i.e. bonnet switch
grounded. By pressing the remote control, alarm history is accessed via siren and
LED.
1 Beep, 1 Flash -Voltage Drop Alarm
2 Beep, 2 Flashes -Not Used On This Model
3 Beep, 3 Flashes -Shock Sensor Alarm
4 Beep, 4 Flashes -Power Fail Alarm
5 Beep, 5 Flashes -Ignition Alarm
6 Beep, 6 Flashes -Not Used
7 Beep, 7 Flashes -Door Alarms
8 Beep, 8 Flashes -Bonnet / Boot Alarm
If two previous alarms were caused by i.e. voltage drop and shock sensor the LED
will flash and siren will beep once for voltage drop, no noise for 1 second then beep
three times for shock sensor. The memory will hold ten alarm memories. The last
memory heard is the most recent alarm sector triggered.
To exit memory mode turn ignition off and close bonnet.

WIRING INSTRUCTIONS
RED -
CONNECT TO A CONSTANT +12 VOLTS TO THE BATTERY
BLACK -
CONNECT TO A SUITABLE EARTH ON THE CAR BODY
ORANGE
(x2) -
CONNECT TO THE LEFT AND RIGHT INDICATOR CIRCUITS
OF THE VEHICLE TO FLASH THE INDICATORS
YELLOW - CONNECT TO A +12 VOLTS IGNITION SWITCHED LEAD,
WHICH DOES NOT FALL TO 0 VOLT WHEN THE ENGINE IS
CRANKED
DARK BLUE -
-
CONNECT TO PIN SWITCHES FOR BONNET
CONNECT TO PIN SWITCHES FOR BOOT
WHITE - CONNECT TO EXISTING DOOR SWITCHES, IF SWITCH
SENSING IS REQUIRED
GREEN (X2) - LOCATE THE POSITIVE FEED WIRE TO THE STARTER, CUT
THAT WIRE AND JOIN THE TWO GREEN WIRES TO EITHER
END OF THE STARTER FEED WIRE WHICH YOU HAVE JUST
CUT
YELLOW/ BLACK - THIS IS A SWITCHED NEGATIVE OUTPUT (-VE 150mA).
CONNECT TO THE NEGATIVE WIRE (USUALLY BLACK) ON
ANY ACCESSORY USED i.e. ULTRASONIC / GLASS BREAKAGE
/ MICROWAVE DETECTORS OR ETC
LIGHT BLUE - THIS IS A POSITIVE OR NEGATIVE TRIGGER, AND SHOULD BE
CONNECTED TO THE OUTPUT CIRCUIT WIRE ON ANY
ACCESSORY TO BE USED. (ie ULTRASONIC, MICROWAVE, OR
GLASS BREAK DETECTORS, ETC.)
PINK - THIS IS THE NEGATIVE OUTPUT (150mA MAXIMUM) FOR THE
SHOCK SENSOR PREWARN. CONNECT THIS WIRE TO A PIEZO
SIREN OR THE NEGATIVE TRIGGER OF A LARGER SIREN.
VIOLET/BLACK - NEGATIVE TRIGGER ON ALARM TO BE USED TO INTERFACE
TO PAGER OR OPTIONAL SIREN (100mA MAXIMUM)
ORANGE/BLACK -
NEGATIVE PULSE LOCK SIGNAL
YELLOW/BLACK -
NEGATIVE PULSE UNLOCK SIGNAL

WARNING TO ALL ALARM
INSTALLERS
The RCA alarm is equipped with Low
Current Negative Pulse Central Lock
outputs. This must not be used unless a
complete understanding of the car’s
central locking system is known. Failure
to do this can damage electronics and
this damage WILL NOT BE
COVERED UNDER WARRANTY! If
unsure, please connect relays as shown
on wiring instructions.

RCA WIRING DIAGRAM
15A FUSE RED +12 VOLTS
5A FUSE ORANGE RIGHT INDICATORS
5A FUSE ORANGE LEFT INDICATORS
SHOCK SENSOR ADJUSTMENT
YELLOW
CUT
GREEN HERE STARTER
MOTOR
C
O
N
N DARK BLUE
E
C ORANGE BLACK LOCK (NEG PULSE 150mA)
T
O YELLOW PINK UNLOCK (NEG PULSE 150mA)
R
WHITE DOOR SWITCH (+/- TYPES)
LIGHT BLUE AUX. INPUT (NEG. TRIGGER)
VIOLET BLACK NEGATIVE OUT ON ALARM
CONNECT THE BLACK (100mA MAX)
RING TO THE PINK SHOCK SENSOR PREWARN
MOUNTING BOLT EARTH WIRE OUTPUT (NEG. 150mA)
YELLOW BLACK NEG. OUT ON ARM 150mA
ORIGINAL WIRE TO FUEL PUMP
IGN 87
CONNECT FUEL PUMP DISABLE AS 86 87a 85 CUT DASHED LINE
SHOWN
30 FUEL PUMP
CURRENT SENSING
The RCA alarm is fitted standard with current sensing. This feature with the Rhino
Australian made alarms has been proven to be very reliable, so on the RCA model it
is a standard feature, not removable.

If removing this feature is a necessity, this can be achieved by connecting both the
positive and negative power feed directly on to the car battery, this will override the
current sensing feature in most cases.
LOCK (ORANGE WIRE ON RCA)
15A FUSE +12V
(YELLOW PINK) 87 87
UNLOCK 87a 87a
86 85 86 85
30 30
LOCK OUTPUT
UNLOCK OUTPUT
INSTALL NEW DOOR LOCK MOTORS
LOCK (ORANGE WIRE ON RCA)
15A FUSE +12V
(YELLOW PINK) 87 87
UNLOCK 87a 87a
86 85 86 85 MASTER LOCK SWITCH
30 30
LOCK OUTPUT
UNLOVK OUTPUT
TO EXISTING LOCK RELAY +12V
5-WIRE “POLARITY REVERSING” POWER LOCK SYSTEM
LOCK (ORANGE / BLACK FROM RCA)
TO EXISTING DOOR
RELAYS
UNLOCK (YELLOW / PINK FROM RCA)
”NEGATIVE TRIGGER” ORIGINAL POWER LOCK SYSTEM

LOCK (ORANGE WIRE ON RCA) +12V OR GROUND
DENPENDING ON
+12V SYSTEM REQUIREMENTS
(YELLOW PINK) 87 87
UNLOCK 87a 87a
86 85 86 85
30 30
LOCK TO DRIVER
SIDE LOCKING
UNLOCK SWITCH
LOCK
TO PASSENGER
UNLOCK SIDE LOCKING
SWITCH
3 WIRE “POSITVE TRIGGER” POWER LOCK SYSTEM
