HDMI 1x2 Splitter User Guide
Model CM-SP1210-HD

Copyright
© 18DEC13 Clare Controls, Inc. All rights reserved.
This document may not be copied in whole or in part or otherwise
reproduced without prior written consent from Clare Controls, Inc.,
except where specifically permitted under US and international
copyright law.
Trademarks and
patents
The HDMI 1x2 Splitter User Guide, Model CM-SP1210-HD name is
a trademark of Clare Controls, Inc.
Other trade names used in this document may be trademarks or
registered trademarks of the manufacturers or vendors of the
respective products.
Manufacturer
Clare Controls, Inc., 7519 Pennsylvania Ave., Suite 104, Sarasota,
FL 34243, USA
Version
This document applies to HDMI 1x2 Splitter User Guide,
Model CM-SP1210-HD version 1.
Contact information
For contact information, see www.clarecontrols.com.

HDMI 1x2 Splitter User Guide i
Content
Important information...ii!
Limitation of liability...ii!
Introduction...1!
Features...1!
Packagecontents...1!
Product appearance...2!
System connection...2!
Usage precautions...3!
Connection procedure...3!
Application solution...3!
Specifications...4!
Panel drawing...5!
Troubleshooting and maintenance...5!
Safety operation guide...6!
After-sales service...7!

ii HDMI 1x2 Splitter User Guide
Important information
Limitation of liability
To the maximum extent permitted by applicable law, in no event will Clare
Controls, Inc. be liable for any lost profits or business opportunities, loss of use,
business interruption, loss of data, or any other indirect, special, incidental, or
consequential damages under any theory of liability, whether based in contract,
tort, negligence, product liability, or otherwise. Because some jurisdictions do not
allow the exclusion or limitation of liability for consequential or incidental damages
the preceding limitation may not apply to you. In any event the total liability of
Clare Controls, Inc. shall not exceed the purchase price of the product. The
foregoing limitation will apply to the maximum extent permitted by applicable law,
regardless of whether Clare Controls, Inc. has been advised of the possibility of
such damages and regardless of whether any remedy fails of its essential
purpose.
Installation in accordance with this manual, applicable codes, and the instructions
of the authority having jurisdiction is mandatory.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, Clare Controls, Inc. assumes no responsibility
for errors or omissions.

HDMI 1x2 Splitter User Guide 1
Introduction
The CM-SP1210-HD 1x2 HDMI splitter is equipped with a high-quality one input, two
output distribution chip. Its anti-static function gives it the advantage over others when
distributing HDMI signals. It is equipped with HDMI 1.4a connectors. It is HDCP
compliant, and HDTV compatible, with resolution up to 1920 x 1200 at 60 Hz, and
1080p.
Features
•HDCP compliant
•HDMI1.4a, supports 3D
•Supports Extended Display Identification Data (EDID) and Display Data Channel
(DDC)
•HDTV compatible with high definition transmission resolution up to 1920 x 1200 at
60 Hz (maximum), supports 1080P
•LED indicators to show working status
•Antistatic case design to providing good performance protection
•Built-in gain compensation technology
Package contents
•1 x CM-SP1210-HD 1x2 HDMI splitter
•2 x removable mounting brackets
•4 x screws
•1 x power adapter (5 VDC)
•1 x user manual
Notes: Please verify that the product and all the accessories are included. If not,
contact your dealer.

2 HDMI 1x2 Splitter User Guide
Product appearance
The CM-SP210-HD has one HDMI input port and two HDMI output ports, as shown
below.
Figure 1: CM-SP1210-HD 1x2 HDMI splitter
(1) HDMI output ports connect with HDMI displays devices, such as HDTVs, or projectors.
(2) Power indicator remains red when power is on.
(3) Power port connects with a 5 VDC power adapter (included).
(4) HDMI input port connects with an HDMI video source device, such as DVD player.
System connection
Figure 2: System diagram

HDMI 1x2 Splitter User Guide 3
Usage precautions
•The system should be installed in a clean environment and have proper
temperature and humidity controls.
•All of the power switches, plugs, sockets, and power cords should be insulated for
safety.
•All devices should be connected before powering on.
Connection procedure
To connect the splitter:
1. Connect HDMI from the source (such as Blue-ray DVD) to the HDMI input port on
the HDMI 1x2 splitter using an HDMI cable.
2. Connect HDMI from either or both of the output ports on the splitter to display
devices, a surround receiver, or an HDBaseT transmitter.
3. Connect the 5 VDC power adapter to the power input on the splitter.
Application solution
Figure 3: Solution diagram

4 HDMI 1x2 Splitter User Guide
Specifications
Video Input
Video Output
Input type
HDMI
Output
HDMI
Input connector
1 HDMI female
Output connector
2 HDMI female
Input level
T.M.D.S. 2.9 V / 3.3 V
Output level
T.M.D.S. 2.9 V / 3.3 V
Input impedance
50Ω
Output impedance
50Ω
Video general
Gain
0 dB
Bandwidth
6.75 Gbit/s
Video signal
HDMI (or DVI-D)
Maximum pixel
clock
165 MHz
Resolution range
Up to 1920 ×1200, or
1080p at 60 Hz
Switching speed
200 ns (max.)
Consumer Electronics
Control (CEC)
Supports CEC wired infrared data pass-through using the HDMI 1.4a
standard
EDID and DDC
Management
Supports Extended Display Identification Data (EDID) and Display
Data Channel (DDC) data using DVI and HDMI standards, EDID and
DDC signals are actively buffered.
HDCP Management
Compliant with High-bandwidth Digital Content Protection (HDCP)
using DVI and HDMI 1.4a standards.
General
Power supply
5 VDC adapter
Power
consumption
10 W
Temperature
-4 to 158°F
(-20 to 70°C)
Humidity
10% to 90%
Case dimension
(W ×H ×D)
2.7 ×1.0 ×2.3 in
(6.8 ×2.6 ×5.9 cm)
Product weight
.22 lb.
(0.1 Kg)

HDMI 1x2 Splitter User Guide 5
Panel drawing
Figure 4: Panel drawing of the HDMI 1x2 splitter
Troubleshooting and maintenance
•If the POWER indicator does not work, ensure the power supply is connected
properly. Check to be sure that a circuit breaker has not tripped and that power is
available. If power is available and the splitter will not power on, contact Customer
Service for assistance.
•No image on display.
•Ensure that the display device is set to the correct input.
•Ensure that the HDMI cables used for both the input source and the output
displays are properly connected and are working. Test the HDMI cables
directly from a source to display and ensure their operation.
•Ensure the power supply is properly grounded.

6 HDMI 1x2 Splitter User Guide
Safety operation guide
To guarantee the reliable operation of the equipment and personal safety, please
follow the procedures listed below.
•The system must be grounded properly. Do not use two blades plugs. Ensure the
supply voltage is in the correct range of 100~240 V and from 50~60 Hz.
•Do not locate the device in a place that is abnormally hot or cold or does not have
proper temperature control and ventilation.
•The device generates heat when running. Its environment should be well
ventilated to prevent damage caused by overheating.
•Disconnect power in humid weather, or when left unused for long periods.
•Before making or removing any connections to the device, ensure that the power
supply has been disconnected.
•Do not attempt to open the enclosure of the equipment. DO NOT attempt any
repairs. There are no user-serviceable parts inside. Any attempt to open the
equipment will result in a complete void of any warranty and may result in serious
injury or death.
•Do not splash any chemical substances or liquids on or around the equipment.

HDMI 1x2 Splitter User Guide 7
After-sales service
•If there appears to be problems when running the device, refer to the
“Troubleshooting and maintenance” section in this manual. Return shipping costs
are not covered by this warranty.
•You can contact Customer Support at http://support.clarecontrols.com. Please be
ready to provide the following information.
•Product model number, version and serial number.
•Detailed description of the trouble issues.
•Description of all connections and third-party equipment being used.
•We offer this product with a three-year warranty, which starts from the first day
you purchase this product.
•If, during the warranty period, the unit cannot be repaired, a suitable replacement
will be issued. Replacement units will be comparable to the original. However, due
to potential design changes over time, replacement units may not be identical to
the unit replaced.
•Items not covered by this warranty.
•Damage caused due to incorrect usage and/or connections.
•Damage caused due to installation by person(s) not adequately trained in the
installation of this equipment.
•Any attempt to open this unit and access internal components shall
immediately void this warranty.
•Damage caused by any physical force (dropping the unit or dropping an
object upon the unit, etc.).
•Damage caused by voltage/cycle fluctuations outside acceptable range.
•Damage caused by over-current, voltage spikes or lightning damage due to
inadequate surge protection.
•A valid invoice of purchase via an authorized dealer shall be required for any
warranty coverage.
