Clarion PS-2375D User manual

- 1 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
SUZUKI Automobile Genuine
AM/FM Stereo CD Deck
PS-2375D
Published by Service Dept.
Printed in Japan
Clarion Co., Ltd.
Export Division - 22-3, Shibuya 2-chome, Shibuyaku, Tokyo, 150-8335 Japan Tel: [phone]
Service Dept.- 50 kamitoda,Toda-shi,Saitama,335-8511 Japan Tel: [phone] FAX:[phone]
298-5854-00 Aug.2000 B
Service Manual
Model
Model
Model
Model
Model
Model
PS-2375D
(Genuine No.39101-65D80-000)
PS-2375I
(Genuine No.39101-69G80-000)
PS-2376D
(Genuine No.39101-65D70-000)
PS-2376I
(Genuine No.39101-69G70-000)
PS-2377D
(Genuine No.39101-65D60-000)
PS-2377I
(Genuine No.39101-69G60-000)
■SPECIFICATIONS
Radio section
Tuning system: PLL Frequency synthesizer system
Receive range: PS-2375D,I
AM 530kHz to 1,710kHz
FM 87.75MHz to 107.9MHz
PS-2376D,I
AM 531kHz to 1,602kHz
FM 87.5MHz to 108.0MHz
PS-2377D,I
AM 531kHz to 1,629kHz
FM 87.5MHz to 108.0MHz
Intermediate frequency:
AM 450±3kHz
FM 10.7±0.2MHz
Quieting sensitivity: AM Less than 34dBμ
(at 20dB S/N)
FM Less than 15dBμ
(at 30dB S/N)
Auto tuning stop sensitivity:
AM 32±6dBμ
FM 26±6dBμ
Separation: FM More than 20dB(at 1kHz)
CD section
Disc: Compact disc(8cm/12cm)
Separation: More than 55dB
S/N ratio: More than 70dB
Distortion: Less than 1.0%(at 20kHz LPF)
General
Load impedance: 4Ω
Power output: 16W×4(MAX)
Power supply voltage: DC13.2V(10.8V to 15.6V)
Negative ground
Back-up consumption: Less than 4mA
Dimensions(mm): 186(W)×106(H)×156.5(D)
Weight: PS-2375D/2376D/2377D:
2.13kg
PS-2375I/2376I/2377I:
2.15kg
※Specifications and design are subject to change without
notice for further improvement.
CONTROLSYSTEM
COMPACTDISCAUTOCHANGER

- 2 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
■NOTE
1. We cannot supply PWB with component parts in prin-
ciple. When a circuit on PWB has failure, please repair
it by component parts base. Parts which are not men-
tioned in service manual are not supplied.
2. Prevent damage caused by static electricity when re-
pairing the pick-up.
The pattern of the pick-up is short-circuiting for preven-
tion. Remove the soldering with a solder iron whose in-
sulation resistance is larger than 10MΩ(DC 500V) after
complete connection to the main PWB.
For repair table shall use copper or conductive sheet
(with impedance is to 100MΩfrom 1MΩ) such as a
sheet.
Be sure to put on a wrist-strap for prevent electric static's.
(with impedance to 100MΩfrom 1MΩ) The strap works
to drain away the static electricity build-up on the human
body.
And as static electricity build-up on clothes is not drained
away, be careful and not your clothes to touch the pick-
up.
Position of short soldering for pick-up protection posi-
tion is different by model.
Some units have two short soldering points.
Always short LD circuit to open the short circuit and re-
moves by soldering iron.
■COMPONENTS
PS-2375D-A,I-A/PS-2376D-A,I-A
/PS-2377D-A,I-A
Main unit −−−−− 1
■To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow
the instructions so that customers and Engineers
in charge of repair or inspection can avoid suf-
fering any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent charac-
teristics when replacing them.
The use of unspecified parts shall be regarded as re-
modeling for which we shall not be liable. The onus of
product liability (PL) shall not be our responsibility in cases
where an accident or failure is as a result of unspecified
parts being used.
2. Place the parts and wiring back in their original positions
after replacement or re-wiring.
For proper circuit construction, use of insulation tubes,
bonding, gaps to PWB, etc, is involved. The wiring con-
nection and routing to the PWB are specially planned
using clamps to keep away from heated and high voltage
parts. Ensure that they are placed back in their original
positions after repair or inspection.
If extended damage is caused due to negligence during
repair, the legal responsibility shall be with the repairing
company.
3. Check for safety after repair.
Check that the screws, parts and wires are put back se-
curely in their original position after repair. Ensure for
safety reasons there is no possibility of secondary
ploblems around the repaired spots.
If extended damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
4. Caution in removal and making wiring connection to the
parts for the automobile.
Disconnect the battery terminal after turning the ignition
key off. If wrong wiring connections are made with the
battery connected, a short circuit and/or fire may occur.
If extensive damage is caused due to negligence of re-
pair, the legal responsibility shall be with the repairing
company.
5. Cautions regarding chips.
Do not reuse removed chips even when no abnormality
is observed in their appearance. Always replace them
with new ones. (The chip parts include resistors, capaci-
tors, diodes, transistors, etc). The negative pole of tanta-
lum capacitors is highly susceptible to heat, so use spe-
cial care when replacing them and check the operation
afterwards.
6. Cautions in handling flexible PWB
Before working with a soldering iron, make sure that the
iron tip temperature is around 270℃. Take care not to
apply the iron tip repeatedly(more than three times)to the
same patterns. Also take care not to apply the tip with
force.
7. Turn the unit OFF during disassembly and parts replace-
ment. Recheck all work before you apply power to the
unit.
8. Cautions in checking that the optical pickup lights up.
The laser is focused on the disc reflection surface through
the lens of the optical pickup. When checking that the
laser optical diode lights up, keep your eyes more than
30cms away from the lens. Prolonged viewing of the la-
ser within 30cms may damage your eyesight.
9. Cautions in handling the optical pickup
The laser diode of the optical pickup can be damaged by
electrostatic charge caused by your clothes and body.
Make sure to avoid electrostatic charges on your clothes
or body, or discharge static electricity before handling the
optical pickup.
9-1. Laser diode
The laser diode terminals are shorted for transpor-
tation in order to prevent electrostatic damage.
After replacement, open the shorted circuit. When
removing the pickup from the mechanism, short
the terminals by soldering them to prevent this
damage.
9-2. Actuator
The actuator has a powerful magnetic circuit. If a
magnetic material is put close to it. its characteris-
tics will change. Ensure that no foreign substances
enter through the ventilation slots in the cover.
9-3. Cleaning the lens
Dust on the optical lens affects performance. To
clean the lens, apply a small amount of isopropylalcohol
to lens paper and wipe the lens gently.

- 3 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
■ADJUSTMENT
Item Procedure Measuring
instrument
FM noise
convergence
1. Input the 98.1MHz/55dBμ(400Hz, 30% MOD, 22.5kHz Div.) SSG signal.
2. Set the output to 0dBm(0.775V) by main volume.
3. Adjust VR101 so that the output level is −20dB when the output of SSG is set
to −20dBμ.
SSG
Milli-volt meter
FM SD 1. Turn off the power switch and on the FM/AM button, while holding the buttons
of CH1 and CH3 to make the unit the test mode. ("FM SD" indicator of LCD
display appears.)
2. Input the 98.1MHz, 26dBμ(400Hz, 30% MOD, 22.5kHz Div.) SSG signal.
3. Adjust the "FM SD" indicator of LCD display to appear at the 25dBμand to
blink at the 24dBμby VR103.
SSG
AM SD 1. After FM SD adjustment, turn on the FM/AM button. ("AM SD" indicator of LCD
display appears.)
2. Input the 1000kHz, 31dBμ(400Hz, 30% MOD) SSG signal.
3. Adjust the "AM SD" indicator of LCD display to appear at the 30dBμand to
blink at the 29dBμby VR105.
SSG
Clock accuracy 1. Set a universal timer to TP101(BEEP), adjust TC101 so that a reading of the
meter is ＋0.5±0.5 sec./day.
Chronometer
■EXPLANATION OF IC
052-3143-20 M30622MAA-D86FP
Radio/TAPE/CD System Controller
1. Terminal Description
pin 1 : PLL CLK : O : PLL clock pulse output
pin 2 : PLL DO : O : PLL serial data output.
pin 3 : PLL CE : O : Chip enable signal output to PLL.
pin 4 : FM ST DET_ : IN : FM stereo detection flag input. "L"=
stereo.
pin 5 : E VOL CLK : O : Clock pulse output to the E VOL IC.
pin 6 : E VOL DATA : O : Serial data output to the E VOL IC.
pin 7 : TIME BASE : IN : 8Hz time base signal input.
pin 8 : BYTE : IN : External data bus setting. "L"= 16bit.
pin 8 : BYTE : IN : Input "L" at single mode operation.
pin 9 : CN VSS : IN : Input "L" at single mode operation.
pin 10 : XC IN : IN : Sub system clock.
pin 11 : XC OUT : O : Sub system clock.
pin 12 : RESET_ : IN : Reset signal input. Negative logic.
pin 13 : X OUT : O : Crystal connection.
pin 14 : GND : - : Ground.
pin 15 : X IN : IN : Crystal connection.
pin 16 : VCC : - : Positive supply voltage.
pin 17 : NU : - : Not in use.
pin 18 : B/U DET : IN : Backup voltage ON signal input. "H"=
Backup ON.
pin 19 : ACC DET_ : IN : ACC detection terminal. "L"= ACC ON.
pin 20 : SBSY : IN : CD IC Sub Q data request signal in-
put.
pin 21 : NU : - : Not in use.
pin 22 : ILL ON_ : IN : "L"= Illumination ON.
pin 23 : AMP ON : O : Audio power amplifier ON signal out-
put.
pin 24 : LINE MUTE_ : O : Mute signal output for Audio signal.
Negative logic.
pin 25 : STD/Mcintosh_ : IN : H= standard, "L"= Mcintosh.
pin 26 : CLOCK TP : O : 8Hz output for adjusting the clock.
pin 27 : NU : - : Not in use.
pin 28 : NU : - : Not in use.
pin 29 : RX : IN : Serial data input from IE BUS driver
IC.
pin 30 : TX : O : Serial data output to IE BUS driver IC.
pin 31 : CD SEL : IN : "H"= builtin CD player, "L"= external
CD player.
pin 32 : CLOCK SEL : IN : "L"= without a clock.
pin 33 : AREA 2 : IN : Destination setting input.
pin 34 : AREA 1 : IN : Destination setting input.
pin 35 : DOLBY : O : Dolby ON signal output.
pin 36 : FWD / REV_ : O : "H"= Forward, "L"= Reverse.
pin 37 : APC SENCE : O : Sensitivity select signal output to APC
circuit. "H"= play, "L"= FF/REW.
pin 38 : APC DET : IN : "H"= Non recorded part.
pin 39 : TAPE IN : IN : Tape loading start signal input.
pin 40 : Mechanism ON : O : "H"= Mechanism power ON.
pin 41 : MAIN MOTOR : O : H= Tape main motor ON.
pin 42 : P MOTOR 2(-) : O : Power motor control signal output.
pin 43 : P MOTOR 1(+) : O : Power motor control signal output.
pin 44 : MODE BIT 2 : IN : Mode switch signal input from the
mechanism.
pin 45 : MODE BIT 1 : IN : Mode switch signal input from the
mechanism.
pin 46 : MODE BIT 3 : IN : Mode switch signal input from the
mechanism.
pin 47 : REEL PULSE : IN : Reel pulse input.
pin 48 : NAVI MUTE : O : Mute signal output for the audio signal
of Navigation.
pin 49 : G ANT ON : O : Power supply circuit control signal out-
put for the glass antenna.
pin 50 : MASTER ON : O : Master ON signal output of C-BUS.
pin 51 : SLAVE ON_ : IN : "L"= External input ON.
pin 51 : SLAVE ON_ : IN : Slave ON signal input of C-BUS. Neg-
ative logic.
pin 52 : AUDIO OUT : O : "L"= Audio signal of IE-BUS is ON.
"H"= OFF.
pin 53 : SYS ACC : O : Power supply circuit control signal out-
put.
pin 54 : REM +5V : O : Power supply circuit control signal.
"H"= ON.
pin 55 : CD +5V : O : Power supply control signal output for
the CD mechanism. "H"= ON.
pin 56 : CD +8V : O : Power supply ON signal output for the
Loading motor and the Photo sensors.
pin 57 : VFD ON : O : VFD power supply circuit control signal.
"H"= ON.
pin 58 : AMP MUTE_ : O : Muting signal output the internal Power
Amplifier. Negative logic.
pin 59 : NU : - : Not in use.
pin 60 : MCCW : O : Loading motor control output.
pin 61 : MCW : O : Loading motor control output.
pin 62 : VDD : - : Positive supply voltage for the digital
part.
pin 63 : NU : - : Not in use.
pin 64 : GND : - : Ground.
pin 65 : NU : - : Not in use.
pin 66 : TR C : IN : Photo sensor signal input from the CD
mechanism.

- 4 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
pin 67 : TR B : IN : Photo sensor signal input from the CD
mechanism.
pin 68 : TR A : IN : Photo sensor signal input from the CD
mechanism.
pin 69 : CHU SW_ : IN : L= Disc chucked.
pin 70 : RESET CD_ : O : Reset signal output to the CD mecha-
nism. Negative logic.
pin 71 : CCE_ : O : Chip enable signal output to CD IC.
Negative logic.
pin 72 : BUC CLOCK : O : CD IC clock pulse output.
pin 73 : BUC 3 : I/O : CD IC Data input / output.
pin 74 : BUC 2 : I/O : CD IC Data input / output.
pin 75 : BUC 1 : I/O : CD IC Data input / output.
pin 76 : BUC 0 : I/O : CD IC Data input / output.
pin 77 : NU : - : Not in use.
pin 78 : NU : - : Not in use.
pin 79 : NU : - : Not in use.
pin 80 : VFD DO : O : Serial data output to the VFD driver.
pin 81 : VFD DI : IN : Serial data input from the VFD driver.
pin 82 : VFD CLK : O : Clock pulse output to the VFD driver.
pin 83 : VFD CE : O : Chip enable signal output to the VFD
driver.
pin 84 : VFD BLK : O : BLK output to the VFD driver.
pin 85 : NU : - : Not in use.
pin 86 : POWER SW_ : IN : Power switch pulse input. Negative log-
ic.
pin 87 : E VOL 1 : IN : Volume control pulse input.
pin 88 : E VOL 2 : IN : Volume control pulse input.
pin 89 : TAPE EJ_ : IN : Tape-eject-signal input. Negative logic.
pin 90 : CD EJ_ : IN : CD-eject-signal input. Negative logic.
pin 91 : NU : - : Not in use.
pin 92 : NU : - : Not in use.
pin 93 : CS SEL : IN : "L"= Without builtin cassette tape
player.
pin 94 : E VOL CE : O : Chip enable signal output to the E
VOL IC.
pin 95 : CD TEMP : IN : CD temperature voltage input.
pin 96 : A VSS : - : Analog ground.
pin 97 : ILL CONT A : IN : VFD power supply voltage sensor in-
put.
pin 98 : Vref : - : Reference voltage,
pin 98 : Vref : O : Reference voltage output.
pin 99 : A VCC : IN : Positive supply voltage for the internal
analog section.
pin100 : PLL DI : IN : PLL serial data input.
■BLOCK DIAGRAM

- 5 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
7 017-0420-09 PILOT LAMP(14V 40mA) 6
8 016-0010-05 VR W/SHAFT 1
9 074-1151-18 OUTLET SOCKET(18P) 1
10 379-4018-24 INDICATOR 1
11 716-0778-00 WAVE SCREW(φ2×6) 8
12 345-8090-00 INSULATOR 1
13 383-0616-21 FACE PANEL 1
■EXPLODED VIEW・PARTS LIST
Escutcheon section
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 940-7928-22 ESCUTCHEON ASSY 1
1-1 716-0778-00 WAVE SCREW(φ2×6) 3
2 373-0939-20 DIAL COVER 1
3 380-5494-00 KNOB 1
4 371-3938-00 TRIM PLATE 1
5 039-1731-01 SWITCH PWB 1
(WITHOUT COMPONENT)
6 013-6302-01 SWITCH 18
1‑1
2
4
3
12
7
9
11
5
68
10
13
7
6
6
61‑1
1

- 6 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
Main section
38 2
20
19 11 33 22 18
21
16
6
17
25
23
10
24
9
30 27
27
27 37
28
28
28
731 13
28
8
26
27
12
27
36
27
38
1
15
32
40
27
27
3
34
5
27
427
22
R
Ea
35
A
A
B
C
D
J
K
N
C
G
e
e
G
H
O
F
E
L
M
S1
H
b
B
L
M
S2
cdJK
S1
S2
D
O
U
P
N
R
cd
U
P
29
39
F
41
V
b
16
a
f
f
14
V

- 7 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 310-1639-00 UPPER CASE 1
2 311-1727-02 LOWER CASE 1
3 305-0266-00 SIDE PLATE(LEFT) 1
4 305-0265-00 SIDE PLATE(RIGHT) 1
5 309-0698-00 FRONT PLATE 1
6 331-2275-01 MECHANISM BRACKET 1
7 331-2281-01 MECHANISM BRACKET 1
(FRONT)
8 331-2282-00 MECHANISM BRACKET(REAR) 1
9 307-0597-20 REAR PLATE 1
10 331-2276-00 OUTLET HOLDER 1
11 331-0567-00 TRANSISTOR HOLDER 1
12 313-1709-00 HEAT SINK 1
13 816-2451-00 FLAT CABLE 1
14 060-0108-00 JUMPER WIRE 1
15 929-0069-04 CD MECHANISM 1
16 039-1730-01 MAIN PWB 1
(WITHOUT COMPONENT)
17 074-1010-00 OUTLET SOCKET 1
18 074-1194-00 OUTLET SOCKET 1
19 074-1186-26 OUTLET SOCKET 1
20 076-0540-18 PLUG(18P) 1
21 076-0368-12 PLUG(12P) 2
22 074-0898-12 OUTLET SOCKET 2
23 009-0666-62 CHOKE 1
24 331-2277-00 IC HOLDER 1
25 051-2013-00 IC(TDA7385) 1
26 714-2612-81 MACHINE SCREW(M2.6×12) 2
27 714-2606-81 MACHINE SCREW(M2.6×6) 19
28 714-2303-81 MACHINE SCREW(M2.3×3) 6
29 345-8455-01 CUSHION RUBBER 1
30 092-0702-00 ANTENNA RECEPT 1
31 347-2022-02 PAPER PART 1
32 347-5679-02 DOUBLE FACE 1
33 076-0312-03 PLUG(3P) 1
34 854-4376-00 EXTENSION LEAD 1
35 880-2079G TUNER PACK (AM/FM) 1
36 286-9431-00 SETPLATE(PS-2375D) 1
286-9431-10 SETPLATE(PS-2375I)
286-9431-20 SETPLATE(PS-2376D)
286-9431-30 SETPLATE(PS-2376I)
286-9431-40 SETPLATE(PS-2377D)
286-9431-50 SETPLATE(PS-2377I)
37 347-5206-00 SHADE 1
38 353-0531-00 SHADE 2
39 093-0778-01 ANTENNA JUMPER 1
(USE PS-2375I/2376I/2377I)
40 347-6036-00 DOUBLE FACE 1
41 854-8213-00 EXTENSION LEAD 1

- 8 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
CD mechanism section
※The parts list is on page 10.
A 7
L 1
K
A 1 1
L 1
N
A 5
D 1
A 1 0
PD 2
D 5 D 6
D 7
D 4
D 3
L 2
D 4
D 7
H 2
H 1
M
D 5
D 6
J
I 2
H 2
H 1
C 2
C 1 I 1
I 2
I 3
I 1
P
N

- 9 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
BF 2
F 1
E 3
M
A 4
I 3
D 2
D 3
A 1 1
A 7 K
A 4
A 6
F 1
A 5
A 8
G
A 9
A 1 A 1 0
D 1
G
A 9
E 4
E 4
A 1
A 3
B
E 1
E 2 E 3
A 2
A 6
F 2
A 8
C 2
E 1
E 2
A 3
A 2
C 1

- 10 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
CD mechanism section
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
1 HBS-463-100 DRIVE UNIT 1
1-1 966-0314-21 STOP LINK ASSY 1
1-2 966-0447-23 DR-PLATE ASSY 1
1-3 966-0448-21 SIDE PLATE ASSY 1
1-4 966-0449-23 CLAMP LINK ASSY 1
1-5 969-0050-04 PICK UP UNIT 1
1-6 013-7100-00 LIMIT SWITCH 1
1-7 620-0198-03 CLAMPER PLATE 1
1-8 620-0491-03 SPRING PLATE 1
1-9 620-0690-01 RATTLE PLATE 1
1-10 621-0205-02 CLAMPER RING 1
1-11 621-0251-03 LOCK LINK 1
1-12 621-0252-03 DISC STOPPER 1
1-13 621-0253-02 MOTOR HOLDER 1
1-14 621-0255-02 SECOUND GEAR 1
1-15 621-0375-00 SH-BASE 1
1-16 621-0357-03 PICK UP GUIDE 1
1-17 621-0358-02 LS-HOLDER-F 1
1-18 621-0359-02 LS-HOLDER-R 1
1-19 622-1073-02 CLAMPER ROLLER 1
1-20 714-2003-81 MACHINE SCREW(M2X3) 10
1-21 716-0675-00 SCREW 2
1-22 716-1468-00 SCREW 2
1-23 716-1555-00 WAVE SCREW 1
1-24 716-1733-00 SCREW 2
1-25 732-2004-11 SEMS SCREW 2
1-26 739-1735-17 PRECISION SCREW 2
1-27 746-0761-00 SCREW 2
1-28 750-3097-03 CLAMPER SPRING 1
1-29 750-3098-00 L-LINK SPRING 1
1-30 750-3099-00 ES-SPRING 1
1-31 816-2372-00 VINYL COAT WIRE(BLU) 1
1-32 816-2373-00 VINYL COAT WIRE(WHT) 1
1-33 966-0454-00 SH-RACK ASSY 1
1-34 HBS-432-100 LS-GEAR ASSY 1
1-35 SMA-146-100 SLED MOTOR ASSY 1
1-36 SMA-151-100 SPINDLE MOTOR ASSY 1
2 966-0308-24 CHASSIS ASSY 1
3 966-0309-22 L-DISC-G-ASSY 1
4 966-0310-21 SFT-P-CH-ASSY 1
5 966-0312-21 SHIFT-P-ASSY 1
6 966-0358-21 DRIVE-L-PL-ASSY 1
7 966-0359-21 SIDE-L-PL-ASSY 1
8 013-3879-01 CHUCKING SWITCH 1
9 039-0586-01 CHUCKING SWTICH PWB 1
(WITHOUT COMPONENT)
10 039-0588-01 SENSOR PWB 1
(WITHOUT COMPONENT)
11 060-0252-01 PHOTO TR (PT4850F) 3
12 345-7513-01 CLAMPER SHEET 1
13 345-7514-00 S-PWB-SHEET 1
14 620-0485-20 FRONT PLATE 1
15 620-0488-20 S-L-LINK PLATE 1
16 620-0489-02 MOTOR PLATE 1
17 620-0492-20 MOTOR BRACKET 1
18 620-0773-01 MECHANISM BRACKET 1
19 621-0402-02 U-DISC GUIDE-F 1
20 621-0243-02 ROLLER SLEEVE 2
21 621-0248-07 RACK GEAR 1
22 621-0249-02 ROLLER GEAR 1
23 621-0250-01 DAMPER HOLDER 4
24 621-0258-03 LOADING ROLLER 2
25 622-1072-05 ROLLER SHAFT 1
26 622-1219-01 SHIFT ROLLER 1
27 629-0058-00 DAMPER-VA 4
28 714-2003-81 MACHINE SCREW(M2×3) 8
29 714-2603-81 MACHINE SCREW(M2.6×3) 5
30 716-1468-00 SCREW(M2×2.5) 2
31 716-1507-00 SCREW(M2×3) 2
32 716-1670-00 SCREW(M2×4) 5
33 716-1677-00 SCREW(M2×5) 1
34 716-1704-00 SCREW(M2×7) 1
35 716-1742-00 SCREW((M2×5) 1
36 743-1500-20 E-RING 3
37 746-0712-03 WASHER 1
38 746-0762-00 WASHER 1
39 746-0877-02 WASHER 2
40 750-3090-02 RO-SPRING-L 1
41 750-3091-03 RO-SPRING-R 1
42 750-3092-03 SHIFT SPRING 1
43 750-3094-00 S-ARM SPRING 1
44 750-3096-01 DR-SPRING-R 1
45 750-3098-00 L-LINK SPRING 1
46 750-3164-00 DR-SPRING-LR 1
47 750-3188-00 DR-SPRING-F-B 1
48 750-3189-00 SIDE-L-SPRING 1
49 750-3201-00 DR-SPRING-F-R 1
50 750-3202-00 CENTER SPRING-B 1
51 800-4904-60 VINYL COAT WIRE(BLK) 1
52 800-4910-60 VINYL COAT WIRE(BLK) 1
53 801-4910-60 VINYL COAT WIRE(BRN) 1
54 802-4904-60 VINYL COAT WIRE(RED) 1
55 802-4910-60 VINYL COAT WIRE(RED) 1
56 804-4910-60 VINYL COAT WIRE(YEL) 1
57 716-1819-00 MECHANISM PWB SCREW 1
58 HBS-430-100 GEAR-PLATE ASSY 1
59 HBS-482-100 MECHANISM PWB ASSY 1
60 SMA-147-100 LOADING MOTOR ASSY 1
61 001-0563-00 DIODE 3

- 11 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
■ELECTRICAL PARTS LIST
Main PWB section(B1)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
ANT1 092-0702-00 ANT RECEPT
BL101 880-2079G AM/FM TUNER
C101 176-1801-00 18pF CH
C104 178-1032-78 0.01μF
C105 178-1032-78 0.01μF
C109 183-1063-31 16V10μF
C110 183-1073-21 10V100μF
C112 178-3322-78 3300pF
C115 178-1042-78 0.1μF
C118 178-2232-78 0.022μF
C119 178-1032-78 0.01μF
C120 117-0000-00 1/10W 0ΩJW
C121 042-0458-05 35V4.7μF
C122 178-1042-78 0.1μF
C123 176-1011-00 100pF CH
C124 176-1011-00 100pF CH
C125 176-1011-00 100pF CH
C126 178-2212-78 220pF
C127 176-1801-00 18pF CH
C128 176-2201-00 22pF CH
C130 183-1073-21 10V100μF
C133 178-2232-78 0.022μF
C147 178-1032-78 0.01μF
C152 184-4773-22 10V470μF
C158 178-2232-78 0.022μF
C159 178-2232-78 0.022μF
C160 178-1832-78 0.018μF
C161 183-1046-67 50V0.1μF NP
C162 183-1046-67 50V0.1μF NP
C163 172-1831-11 0.018μF
C164 183-2263-31 16V22μF
C165 183-2253-62 50V2.2μF
C166 183-2253-62 50V2.2μF
C168 183-2253-62 50V2.2μF
C170 178-1042-78 0.1μF
C171 183-4763-31 16V47μF
C174 183-2253-62 50V2.2μF
C176 183-2253-62 50V2.2μF
C177 183-2253-62 50V2.2μF
C181 183-1053-61 50V1μF
C182 183-1053-61 50V1μF
C184 178-1542-78 0.15μF
C185 178-1542-78 0.15μF
C186 183-1063-31 16V10μF
C187 183-1063-31 16V10μF
C188 183-1063-31 16V10μF
C189 183-1063-31 16V10μF
C190 043-0309-90 10V 1μF
C191 043-0309-90 10V 1μF
C192 178-6832-78 0.068μF
C193 178-6832-78 0.068μF
C194 178-1042-78 0.1μF
C195 178-1042-78 0.1μF
C196 178-4722-78 4700pF
C197 178-4722-78 4700pF
C198 178-1032-78 0.01μF
C199 178-1032-78 0.01μF
C200 178-1032-78 0.01μF
C201 178-4712-78 470pF
C202 178-4712-78 470pF
C205 176-1201-00 12pF CH
C206 176-1201-00 12pF CH
C209 183-1063-31 16V10μF
C210 176-1011-00 100pF CH
C211 172-1041-11 0.1μF
C212 178-2212-78 220pF
C213 178-2212-78 220pF
C214 183-4763-31 16V47μF
C215 178-4732-78 0.047μF
C216 184-4773-22 10V470μF
C217 183-1063-31 16V10μF
C221 178-3332-78 0.033μF
C222 043-0309-90 10V 1μF
C223 183-4763-31 16V47μF
C227 178-1042-78 0.1μF
C228 043-0309-90 10V 1μF
C229 178-4732-78 0.047μF
C230 183-1063-31 16V10μF
C232 178-1032-78 0.01μF
C237 042-0563-15 10V220μF
C239 183-4763-31 16V47μF
C243 042-0565-00 16V22μF
C246 184-4773-22 10V470μF
C247 183-1053-61 50V1μF
C248 184-4773-22 10V470μF
C249 183-2263-31 16V22μF
C250 178-2232-78 0.022μF
C251 178-4742-78 0.47μF
C254 178-1032-78 0.01μF
C255 176-2201-00 22pF CH
C256 176-1511-00 150pF CH
C259 184-1073-52 35V100μF
C267 178-2212-78 220pF
C268 178-2212-78 220pF
C269 042-0565-00 16V22μF
C278 178-2232-78 0.022μF
C279 183-1063-31 16V10μF
C281 176-1011-00 100pF CH
C282 178-1022-78 1000pF
C290 176-2201-00 22pF CH
C291 176-1801-00 18pF CH
C304 176-2201-00 22pF CH
C305 176-2201-00 22pF CH
C306 117-0000-00 1/10W 0ΩJW
C307 117-0000-00 1/10W 0ΩJW
C309 117-0000-00 1/10W 0ΩJW
C310 117-0000-00 1/10W 0ΩJW
C311 176-2201-00 22pF CH
C312 176-2201-00 22pF CH
C330 117-0000-00 1/10W 0ΩJW
C331 117-0000-00 1/10W 0ΩJW
C332 117-0000-00 1/10W 0ΩJW
C333 117-0000-00 1/10W 0ΩJW
C338 163-1063-30 16V10μF
C339 163-1063-30 16V10μF
C340 183-6853-59 35V6.8μF
C341 163-1063-30 16V10μF
C342 163-1063-30 16V10μF
C344 043-0499-51 0.1μF
C345 043-0499-51 0.1μF
C346 043-0499-51 0.1μF
C348 043-0499-51 0.1μF
C349 178-4712-78 470pF
C350 178-4712-78 470pF
C351 178-4712-78 470pF
C352 178-4712-78 470pF
C353 172-1041-11 0.1μF
C354 183-2263-31 16V22μF
C355 042-0447-00 16V2200μF
C356 042-0280-01 16V1000μF
C357 183-1063-32 16V10μF
C358 183-1053-62 50V1μF
C360 183-1063-31 16V10μF
C361 183-4763-32 16V47μF
C362 172-1041-11 0.1μF
C363 183-4753-52 35V4.7μF
C369 178-2232-78 0.022μF
C370 178-2232-78 0.022μF
C500 178-2732-78 0.027μF
C501 178-2732-78 0.027μF
C502 042-0563-71 16V100μF
C503 042-0563-71 16V100μF
C504 184-1073-52 35V100μF
C505 183-1063-51 35V10μF
C506 042-0563-71 16V100μF
C507 183-2263-31 16V22μF
D108 001-0377-21 MA4039H
D109 001-0377-32 MA4056M
D110 001-0377-45 MA4082H
D111 001-0377-68 MA4180L
D114 001-0377-68 MA4180L
D115 001-0377-68 MA4180L
D116 001-0377-40 MA4075L
D117 001-0503-47 HZS9B3L
D118 001-0503-32 HZS6A3L
D120 001-0516-00 MA111
D122 001-0516-00 MA111
D301 001-0376-34 MTZJ6.2A
D302 001-2015-00 RL253
D304 001-2015-00 RL253
D305 001-0466-00 S5688B
D306 001-0516-00 MA111
D500 001-0330-00 1SS119
D501 001-0330-00 1SS119
D502 001-0330-00 1SS119
D503 001-0330-00 1SS119
D504 001-0377-68 MA4180L
D505 001-0516-00 MA111
IC103 051-6212-08 LC72191JM-TLM
IC105 051-5013-00 LC75384E
IC106 051-6600-38 CA0008AM
IC107 052-3143-20 M30622MAA-D86FP
IC109 051-0869-05 MB3771PF(-G)
IC113 051-3019-90 NJM2060V
IC114 051-1700-00 TA7806S
IC305 051-2013-00 TDA7385
IC500 051-0172-05 TC4011BF
IC501 051-3237-00 NJM78L18A
J101 074-1186-26 26P
J102 074-1194-00 13P CE-NET
J104 074-0898-12 12P
J105 074-0898-12 12P
J303 074-1010-00 OUTLET SOCKET
JW101 117-0000-00 1/10W 0ΩJW
JW102 117-0000-00 1/10W 0ΩJW
JW103 117-0000-00 1/10W 0ΩJW
JW104 117-0000-00 1/10W 0ΩJW
L101 010-2330-12 2.2μH J
L102 010-2230-88 220μH
L103 010-2330-17 5.6μH J
L107 010-2230-84 100μH
L108 010-2230-84 100μH
P103 076-0540-18 18P
P106 076-0368-12 12P
P107 076-0368-12 12P
P108 076-0312-03 3P
Q105 102-2712-51 2SC2712G,L
Q107 102-2712-51 2SC2712G,L
Q112 101-1240-00 2SB1240
Q113 101-1240-00 2SB1240
Q115 125-0002-02 RN2402
Q116 125-2004-03 RN1403
Q118 102-2712-00 2SC2712
Q119 103-1858-00 2SD1858
Q120 103-1858-00 2SD1858
Q121 125-0002-03 RN2403
Q123 125-0002-02 RN2402

- 12 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Q124 125-2004-02 RN1402
Q125 103-2012-00 2SD2012
Q128 125-0002-02 RN2402
Q129 125-2004-03 RN1403
Q130 102-2712-00 2SC2712
Q132 100-1431-00 2SA1431
Q133 103-1858-00 2SD1858
Q134 103-1858-00 2SD1858
Q135 102-2712-51 2SC2712G,L
Q137 100-1162-00 2SA1162
Q138 125-2004-06 RN1406
Q140 108-0161-50 2SK161Y.G
Q142 101-1240-00 2SB1240
Q143 125-2004-03 RN1403
Q144 103-1858-00 2SD1858
Q145 102-2458-51 2SC2458Y.GR.BL
Q300 125-4001-00 XN1504
Q301 125-4001-00 XN1504
Q302 125-2003-03 RN1203
Q303 125-2004-02 RN1402
Q304 100-1431-00 2SA1431
Q305 125-2003-01 RN1201
Q306 125-0002-03 RN2403
Q500 100-1048-50 2SA1048Y,GR
Q501 102-2458-49 2SC2458Y,GR
Q502 100-1048-50 2SA1048Y,GR
Q503 102-2458-49 2SC2458Y,GR
Q504 103-1858-00 2SD1858
R103 117-2221-10 1/10W 2.2kΩ
R105 117-2221-10 1/10W 2.2kΩ
R110 117-4721-10 1/10W 4.7kΩ
R116 117-4721-10 1/10W 4.7kΩ
R117 117-2221-10 1/10W 2.2kΩ
R121 117-1021-10 1/10W 1kΩ
R128 117-4721-10 1/10W 4.7kΩ
R129 117-2221-10 1/10W 2.2kΩ
R130 117-2221-10 1/10W 2.2kΩ
R131 117-2221-10 1/10W 2.2kΩ
R132 117-1031-10 1/10W 10kΩ
R134 117-1221-10 1/10W 1.2kΩ
R135 117-1221-10 1/10W 1.2kΩ
R136 117-1031-10 1/10W 10kΩ
R137 117-1031-10 1/10W 10kΩ
R138 117-1031-10 1/10W 10kΩ
R140 117-2231-10 1/10W 22kΩ
R141 117-1021-10 1/10W 1kΩ
R143 117-1031-10 1/10W 10kΩ
R144 117-1021-10 1/10W 1kΩ
R147 117-1021-10 1/10W 1kΩ
R148 117-2241-10 1/10W 220kΩ
R149 117-2241-10 1/10W 220kΩ
R150 117-3341-10 1/10W 330kΩ
R151 117-1031-10 1/10W 10kΩ
R156 117-3341-10 1/10W 330kΩ
R157 111-2291-91 1/4WS 2.2Ω
R158 117-4721-10 1/10W 4.7kΩ
R161 117-2231-10 1/10W 22kΩ
R164 117-2231-10 1/10W 22kΩ
R166 117-1241-10 1/10W 120kΩ
R167 117-1241-10 1/10W 120kΩ
R168 117-1241-10 1/10W 120kΩ
R169 117-1241-10 1/10W 120kΩ
R170 117-2231-10 1/10W 22kΩ
R171 117-4721-10 1/10W 4.7kΩ
R172 117-4721-10 1/10W 4.7kΩ
R173 117-4731-10 1/10W 47kΩ
R176 117-4731-10 1/10W 47kΩ
R177 117-4721-10 1/10W 4.7kΩ
R178 117-4721-10 1/10W 4.7kΩ
R182 117-4731-10 1/10W 47kΩ
R185 117-6811-10 1/10W 680Ω
R187 117-2221-10 1/10W 2.2kΩ
R188 117-2221-10 1/10W 2.2kΩ
R189 117-2221-10 1/10W 2.2kΩ
R190 111-3311-91 1/4WS 330Ω
R191 117-6821-10 1/10W 6.8kΩ
R193 117-2231-10 1/10W 22kΩ
R194 117-3621-10 1/10W 3.6kΩ
R195 117-3621-10 1/10W 3.6kΩ
R196 117-3321-10 1/10W 3.3kΩ
R197 117-3331-10 1/10W 33kΩ
R198 117-2231-10 1/10W 22kΩ
R200 117-1041-10 1/10W 100kΩ
R201 117-2231-10 1/10W 22kΩ
R205 117-2231-10 1/10W 22kΩ
R207 117-2231-10 1/10W 22kΩ
R209 111-2291-91 1/4WS 2.2Ω
R210 111-2291-91 1/4WS 2.2Ω
R214 117-1041-10 1/10W 100kΩ
R215 117-5611-10 1/10W 560Ω
R224 117-1031-10 1/10W 10kΩ
R225 117-5631-10 1/10W 56kΩ
R227 111-4711-91 1/4WS 470Ω
R229 117-1241-10 1/10W 120kΩ
R230 117-1041-10 1/10W 100kΩ
R241 117-5621-10 1/10W 5.6kΩ
R243 117-1021-10 1/10W 1kΩ
R244 111-2291-91 1/4WS 2.2Ω
R245 111-2291-91 1/4WS 2.2Ω
R246 117-4721-10 1/10W 4.7kΩ
R247 111-6801-91 1/4WS 68Ω
R248 117-1031-10 1/10W 10kΩ
R249 111-1211-91 1/4WS 120Ω
R250 111-2221-91 1/4WS 2.2kΩ
R251 117-1031-10 1/10W 10kΩ
R252 111-2221-91 1/4WS 2.2kΩ
R253 117-1011-10 1/10W 100Ω
R258 111-2221-91 1/4WS 2.2kΩ
R261 114-8291-11 1W 8.2Ω
R262 117-1031-10 1/10W 10kΩ
R263 111-2221-91 1/4WS 2.2kΩ
R266 117-4721-10 1/10W 4.7kΩ
R267 117-1031-10 1/10W 10kΩ
R269 111-4791-91 1/4WS 4.7Ω
R270 111-4791-91 1/4WS 4.7Ω
R272 117-6821-10 1/10W 6.8kΩ
R273 114-3391-11 1W 3.3Ω
R274 117-1041-10 1/10W 100kΩ
R275 117-1041-10 1/10W 100kΩ
R276 117-1041-10 1/10W 100kΩ
R277 117-4731-10 1/10W 47kΩ
R278 117-1031-10 1/10W 10kΩ
R287 117-4741-10 1/10W 470kΩ
R288 117-4731-10 1/10W 47kΩ
R292 117-1041-10 1/10W 100kΩ
R296 117-1021-10 1/10W 1kΩ
R297 117-1021-10 1/10W 1kΩ
R298 111-4711-91 1/4WS 470Ω
R300 117-1031-10 1/10W 10kΩ
R301 117-1031-10 1/10W 10kΩ
R302 117-1031-10 1/10W 10kΩ
R303 117-1031-10 1/10W 10kΩ
R304 117-6821-10 1/10W 6.8kΩ
R305 117-1031-10 1/10W 10kΩ
R306 117-1031-10 1/10W 10kΩ
R307 117-6821-10 1/10W 6.8kΩ
R308 117-2241-10 1/10W 220kΩ
R309 117-2241-10 1/10W 220kΩ
R310 117-2241-10 1/10W 220kΩ
R311 117-2241-10 1/10W 220kΩ
R312 117-6821-10 1/10W 6.8kΩ
R313 117-1031-10 1/10W 10kΩ
R314 117-1031-10 1/10W 10kΩ
R315 117-6821-10 1/10W 6.8kΩ
R321 117-0000-00 1/10W 0ΩJW
R322 117-0000-00 1/10W 0ΩJW
R326 117-0000-00 1/10W 0ΩJW
R330 117-0000-00 1/10W 0ΩJW
R358 117-0000-00 1/10W 0ΩJW
R359 117-0000-00 1/10W 0ΩJW
R360 117-0000-00 1/10W 0ΩJW
R361 117-0000-00 1/10W 0ΩJW
R362 117-2221-10 1/10W 2.2kΩ
R363 117-2221-10 1/10W 2.2kΩ
R365 117-2221-10 1/10W 2.2kΩ
R366 117-2221-10 1/10W 2.2kΩ
R369 117-4731-10 1/10W 47kΩ
R370 117-2221-10 1/10W 2.2kΩ
R373 117-4731-10 1/10W 47kΩ
R374 117-4731-10 1/10W 47kΩ
R375 117-4731-10 1/10W 47kΩ
R376 117-4721-10 1/10W 4.7kΩ
R377 117-4721-10 1/10W 4.7kΩ
R378 117-4721-10 1/10W 4.7kΩ
R380 117-4721-10 1/10W 4.7kΩ
R381 111-1021-91 1/4WS 1kΩ
R383 117-1031-10 1/10W 10kΩ
R384 117-2231-10 1/10W 22kΩ
R385 111-4721-91 1/4WS 4.7kΩ
R386 111-2701-91 1/4WS 27Ω
R387 111-2221-91 1/4WS 2.2kΩ
R388 111-8201-91 1/4WS 82Ω
R389 111-8221-91 1/4WS 8.2kΩ
R390 117-2221-10 1/10W 2.2kΩ
R391 117-2221-10 1/10W 2.2kΩ
R393 111-2701-91 1/4WS 27Ω
R406 111-2701-91 1/4WS 27Ω
R407 111-8201-91 1/4WS 82Ω
R408 117-1031-10 1/10W 10kΩ
R409 111-1521-91 1/4WS 1.5kΩ
R410 111-1031-91 1/4WS 10kΩ
R500 117-4731-10 1/10W 47kΩ
R501 117-4731-10 1/10W 47kΩ
R502 117-1531-10 1/10W 15kΩ
R503 117-1531-10 1/10W 15kΩ
R504 117-1531-10 1/10W 15kΩ
R505 117-1531-10 1/10W 15kΩ
R506 117-3331-10 1/10W 33kΩ
R507 111-1001-91 1/4WS 10Ω
R508 111-1021-91 1/4WS 1kΩ
R900 117-1011-10 1/10W 100Ω
R902 117-4721-10 1/10W 4.7kΩ
SUP1 060-0122-10 DSP-201M-S00B
T301 009-0666-62 0.4mH
TC101 004-1580-10 30pF GRN
VR101 012-5203-57 22kΩ
VR103 012-5203-57 22kΩ
VR105 012-5203-63 470kΩ
X101 061-1066-00 7.2MHz
X103 061-3504-90 CX-5F 10MHz
X104 061-3506-90 10MHz

- 13 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
Switch PWB section(B2)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C401 178-1032-78 0.01μF
C402 178-1032-78 0.01μF
C403 178-1042-78 0.1μF
C404 176-3301-00 33pF CH
C405 178-1042-78 0.1μF
D401 001-2403-90 M1F60
D402 001-2403-90 M1F60
IC401 051-6028-10 LC75757W
J401 074-1151-18 18P
PL401 017-0420-09 14V40mA
PL402 017-0420-09 14V40mA
PL403 017-0420-09 14V40mA
PL404 017-0420-09 14V40mA
PL405 017-0420-09 14V40mA
PL406 017-0420-09 14V40mA
R401 117-1231-10 1/10W 12kΩ
R402 117-1021-10 1/10W 1kΩ
R403 117-1021-10 1/10W 1kΩ
R404 117-1021-10 1/10W 1kΩ
R405 117-1021-10 1/10W 1kΩ
S401 013-6302-01 SKQMAL
S402 013-6302-01 SKQMAL
S403 013-6302-01 SKQMAL
S404 013-6302-01 SKQMAL
S405 013-6302-01 SKQMAL
S406 013-6302-01 SKQMAL
S407 013-6302-01 SKQMAL
S408 013-6302-01 SKQMAL
S409 013-6302-01 SKQMAL
S410 013-6302-01 SKQMAL
S411 013-6302-01 SKQMAL
S412 013-6302-01 SKQMAL
S413 013-6302-01 SKQMAL
S414 013-6302-01 SKQMAL
S415 013-6302-01 SKQMAL
S416 013-6302-01 SKQMAL
S417 013-6302-01 SKQMAL
S418 013-6302-01 SKQMAL
VR401 016-0010-05
Mechanism PWB section(B3) : CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C1 183-1073-12 6.3V100μF
C2 183-4763-11 6.3V47μF
C3 178-1042-78 0.1μF
C4 176-2201-00 22pF CH
C5 176-1801-00 18pF CH
C6 176-1801-00 18pF CH
C7 176-8201-00 82pF CH
C8 178-1042-78 0.1μF
C9 178-2242-78 0.22μF
C10 178-2242-78 0.22μF
C11 176-4701-00 47pF CH
C12 178-1532-78 0.015μF
C13 178-1032-78 0.01μF
C14 178-2722-78 2700pF
C15 178-4722-78 4700pF
C16 176-1201-00 12pF CH
C17 178-4712-78 470pF
C18 178-4712-78 470pF
C19 178-4732-78 0.047μF
C20 178-4732-78 0.047μF
C21 178-4732-78 0.047μF
C22 178-4732-78 0.047μF
C23 178-1032-78 0.01μF
C25 183-1073-21 10V100μF
C26 178-1042-78 0.1μF
C27 178-1042-78 0.1μF
C29 178-1042-78 0.1μF
C30 178-1042-78 0.1μF
C31 178-1032-78 0.01μF
C32 178-1032-78 0.01μF
C33 178-1042-78 0.1μF
C34 176-1501-00 15pF CH
C35 176-1501-00 15pF CH
C39 178-1042-78 0.1μF
C40 178-1042-78 0.1μF
C41 183-1073-12 6.3V100μF
C43 183-1073-12 6.3V100μF
C44 183-4763-11 6.3V47μF
C45 183-1073-12 6.3V100μF
C46 178-1032-78 0.01μF
C47 178-1042-78 0.1μF
C48 178-1032-78 0.01μF
C49 176-6801-00 68pF CH
C51 178-1032-78 0.01μF
C52 178-1032-78 0.01μF
C54 183-4763-11 6.3V47μF
C55 178-1042-78 0.1μF
C56 178-1042-78 0.1μF
C58 178-1042-78 0.1μF
C59 178-2222-78 2200pF
D1 001-0563-00 GL380
D2 001-0563-00 GL380
D3 001-0563-00 GL380
D4 001-0330-00 1SS119
IC1 051-5704-00 TA2096FN
IC2 051-6330-00 TC9432AF
IC3 051-6026-08 TA2058F
IC4 051-6027-00 BA6283N
J1 074-1138-17 17P
J2 074-1143-06 6P
L1 010-2155-03 10μH
L3 010-2199-24 10μH J
Q1 101-1237-50 2SB1237QR
Q2 102-2712-00 2SC2712
R1 117-1011-10 1/10W 100Ω
R2 117-1841-10 1/10W 180kΩ
R3 117-1841-10 1/10W 180kΩ
R4 117-2201-10 1/10W 22Ω
R5 117-8231-10 1/10W 82kΩ
R6 117-1041-10 1/10W 100kΩ
R7 117-1041-10 1/10W 100kΩ
R8 117-1031-10 1/10W 10kΩ
R9 117-2221-10 1/10W 2.2kΩ
R10 117-1031-10 1/10W 10kΩ
R12 117-1031-10 1/10W 10kΩ
R13 117-4731-10 1/10W 47kΩ
R15 117-4741-10 1/10W 470kΩ
R17 117-3331-10 1/10W 33kΩ
R18 117-3311-10 1/10W 330Ω
R19 117-3321-10 1/10W 3.3kΩ
R20 117-1031-10 1/10W 10kΩ
R21 117-3321-10 1/10W 3.3kΩ
R22 117-3321-10 1/10W 3.3kΩ
R23 117-3321-10 1/10W 3.3kΩ
R24 117-3321-10 1/10W 3.3kΩ
R26 117-1041-10 1/10W 100kΩ
R27 117-4711-10 1/10W 470Ω
R28 117-2211-10 1/10W 220Ω
R29 117-2211-10 1/10W 220Ω
R30 117-4721-10 1/10W 4.7kΩ
R34 111-2711-91 1/4WS 270Ω
R40 117-3321-10 1/10W 3.3kΩ
X1 061-3051-00 HC49/US 16.92MHz
Sensor PWB section(B4) : CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Q101 060-0252-01 PT4850F Q102 060-0252-01 PT4850F Q103 060-0252-01 PT4850F
Chucking switch PWB section(B5) : CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
S2 013-3879-01 CHUCKING SWITCH M3 SMA-147-100 LOADING MOTOR
Limit switch PWB section(B6) : CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
S1 013-7100-00 LIMIT SWITCH M1 SMA-151-100 SPINDLE MOTOR M2 SMA-146-100 SLED MOTOR

- 14 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
■CIRCUIT DIAGRAM
Switcch PWB(B2) section

- 17 -
PS-2375D,I
PS-2376D,I
PS-2377D,I
No. Description
A BACK-UP
B REAR SP L-CH(＋)
C REAR SP R-CH(＋)
D FRONT SP L-CH(＋)
E FRONT SP R-CH(＋)
F ILLUMI
G−
H REAR SP L-CH(−)
I REAR SP R-CH(−)
J GND
K ACC
L FRONT SP L-CH(−)
M FRONT SP R-CH(−)
N−
■CIRCUIT DIAGRAM
Main PWB-B section(B1)
