Clarke WS100 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS0309
WIRELESS WEATHER STATION
MODEL NO: WS100
PART NO: 4501002

2
INTRODUCTION
Thank you for purchasing this CLARKE Wireless Weather Station.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you can look forward to your
purchase giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
IN THE BOX
1. 1 x Base station
2. 1 x Remote sensor with mounting bracket
3. 1 x Instruction manual
ENVIRONMENTAL PROTECTION
BATTERY DISPOSAL
Please ensure batteries are disposed of safely. Never dispose of batteries in
the fire or with household waste. Check with your local authority for disposal
regulations.

3
OVERVIEW
1Daylight Saving Time indicator 16 Outdoor humidity display
2Radio Controlled Time indicator 17 Outdoor temperature and humidity low
alarm and high alarm
3Time 18 Temperature display unit (C or F)
4Radio Controlled Time Icon 19 Outdoor temperature display
5Alarm ON indicator 20 General outdoor alarm icon
6Day of week/ time zone 21 Weather forecast icon
7Date 22 Weather tendency indicator
8Indoor humidity display 23 Pressure with 24 hour history graph
9Indoor temperature and Humidity Low
alarm and high alarm
24 Pressure high alarm
10 Indoor temperature display 25 Pressure low alarm
11 Temperature display units 26 Air pressure history graph (past 24 hours)
12 Indoor temperature and humidity
alarm on indicator
27 Barometric air pressure
13 Remote sensor transmit signal indicator 28 Pressure display unit (inHg or hPa)
14 MIN/MAX information 29 Pressure alarm on indicator
15 Dew point temperature display 30 Low Battery Icon

4
SET UP
NOTE: Use good quality alkaline batteries and avoid rechargeable
batteries.
1. Have the indoor weather station and remote temperature sensor close
together during setup.
2. Place the batteries into the remote sensor first then into the weather
station. See below.
INSTALLING THE BATTERIES
REMOTE SENSOR (FIG 1)
1.
Battery compartment retaining screw
Fig 1
Unscrew and remove the battery
compartment retaining screw.
2. Remove the battery
compartment cover.
3. Insert two alkaline AAA batteries
into the remote sensor.
NOTE: Make sure that you follow
the polarity diagram inside
the battery compartment.
4. Replace the battery compartment cover.
INDOOR BASE STATION (FIG 2)
1.
Fig 2
Remove the battery cover.
2. Observing the correct polarity,
install three alkaline AA batteries.
3. Replace the battery cover.
4. Do not press any buttons for at
least ten minutes.This will allow
time for the weather station to
start receiving information from
the sensor,
• If successful the indoor weather station will show the outdoor
temperature and humidity.

5
• If the indoor weather station does not display these values after 1
minute, the signal search will try again every two hours until a signal is
found.
• Once the remote sensor temperature and humidity values are displayed
for 10 minutes you can place the sensor outdoors.
RADIO TIME SIGNAL
After the initial setup period, the weather station will start to search for a radio
time signal.
The time and date signal is sent by a highly accurate government-operated
atomic clock. The weather station will continually scan for the radio controlled
time signal each day.
• If reception is unsuccessful, then the radio time signal icon will not
appear and the manually entered time will be displayed. See page 9 for
instructions on how to enter the time manually.
• If reception has been successful, the radio time signal icon will be
shown and the received time and date will overwrite any manually set
time and date.

6
MOUNTING
BASE STATION
• There is a folding stand at the
rear of the base station, which
allows the unit to be stood onto
any flat surface.
• The base station may also be
wall mounted using the
hanging hole on the rear of the
unit.
NOTE: It is important to check that
the radio signal can be
received at the chosen location before permanently mounting
either of the units.
REMOTE SENSOR
NOTE: To obtain acurate temperature readings, do not mount the
remote sensor in direct sunlight. We recommend that you mount
the sensor on an outside north-facing wall.
NOTE: Obstructions such as walls, concrete, and large metal objects will
reduce the transmitting range.
1. Use 3 screws to fix the wall bracket
to the wall.
2. Clip the sensor into the wall
bracket as shown.
3. The remote sensor will transmit the
outdoor temperature and
humidity back to the weather
station.

7
USING THE WEATHER STATION
WEATHER FORECASTING
Sunny Cloudy
Partly Cloudy Rain
The four weather icons Sunny, Partly Cloudy, Cloudy and Rainy represent the
weather types.
NOTE: Weather forecasting is based upon the change of air
pressure.The pressure threshold can be adjusted from level 2-4
(default level 2). See “General Settings” on page 9. Areas that
experience frequent changes in air pressure require a higher
setting.
WEATHER TENDENCY ARROWS
The weather tendency arrows are located between the weather icons and
provide a forecast of the weather you can expect.
• Arrows pointing to the right - mean that the air pressure is increasing
and the weather is expected to improve.
• Arrows pointing to the left - mean that the air pressure is decreasing
and the weather is expected to deteriorate.
EXAMPLES OF CHANGING WEATHER ICONS:
This is based upon the current pressure and the pressure change over the last
six hours.
• If the weather is changing, the arrows will flash for three hours
indicating changing weather.
• If the weather conditions become stable, then the arrows will not
flash.

8
STORM WARNING
When there is a fall in pressure (above the threshold) over a period of 3 hours,
the storm warning feature will activate.
• The “cloud with rain” icon and tendency arrows will flash for 3 hours
indicating the storm warning feature has been activated.
NOTE: The storm threshold can be adjusted by the user from level 3-9
(default level 4). See page 9.
SETTINGS
• Display Settings
• General Settings
• Alarm Mode
•Min/MaxMode
You can return to normal mode at any time by either pressing the SNOOZE/
LIGHT button located on top of the unit, or waiting for 10-seconds without
pressing any buttons.
DISPLAY SETTINGS
The display settings mode allows you to select what is displayed either outdoor
temperature or dew point and absolute or relative pressure.
1. Press the SET button once.
• Outdoor Temperature / Dew point will start to flash.
2. Press the MIN/MAX button or + button to select between Outdoor
Temperature and Dew Point.
3. Press the SET button again to make the selection.
• Absolute pressure / Relative pressure will start to flash.
4. Press the MIN/MAX button or + button to select between Absolute Pressure
and Relative Pressure.
5. Press the SET button again to make the selection and return to normal
mode.

9
GENERAL SETTINGS
1. Press and hold the SET button for 3 seconds or until the base station beeps
to enter the “general settings” mode.
2. Press the SET key again to cycle through the following settings.
• Time Zone Setting: the default time zone setting value is -1 based on
Germany DCF time (GMT +1)
• 12/24 hour format
• Manual time setting (hours/minutes)
• Calendar setting (year /month /date)
• Temperature display unit (degrees Celsius or Fahrenheit)
• Air pressure display units in hPa (hectopascals) or inHg (inches of
mercury)
• Relative Pressure setting from 27.13inHg - 31.89inHg (default
29.92inHg)
• Pressure Threshold setting (default 2) - The lower level pressure
threshold setting, the higher sensitivity for weather forecasting
• Storm threshold setting (default 4)
3. Press the + button to increase or MIN/MAX button to decrease the value of
the setting.
4. Press the SNOOZE/LIGHT button on top of the weather station to return to
Normal Mode.

10
ALARM MODES
• High alarm mode means that if any of the current weather values
rise above those set then the alarm will sound.
• Low alarm mode means that if any of the current weather values fall
below those set then the alarm will sound.
SELECTING HIGH/LOW ALARM MODE
1. Press the ALM key once to select HIGH alarm mode or twice to select LOW
alarm mode
• Alarm values will be displayed for those already activated, all other
values will be shown as “—”.
SETTING THE ALARM
1. Press the SET key to select the following alarm options:
• Time alarm (hour/minute)
•Indoor humidity
• Indoor temperature
• Outdoor humidity
• Outdoor temperature / dew point
• Pressure
2. Press + key or MIN/MAX key change the alarm value.
• Hold the + key or MIN/MAX key for 3 second to change the number
in greater steps.
3. Press the ALARM key to turn the alarm on or off
4. When the alarm is enabled for that option, the speaker icon on the LCD will
be displayed next to that option.
5. Press the SET key to confirm the setting and continue to the next option.
6. Press the SNOOZE/LIGHT button on top of the weather station to return to
Normal Mode
THE ALARM
When an outdoor weather alarm has been triggered, it will flash on the LCD
display. The general outdoor alarm icon and high/low alarm icon will flash.

11
CANCELLING THE ALARM WHILE SOUNDING
When an alarm has been activated, it will sound for a maximum of 120
seconds. The LCD display will also flash.
• Press any key to mute the alarm.
If the weather conditions trigger the alarm again within 10 minutes the alarm
will not sound. The LCD will still flash until weather conditions fall below the
trigger value.
The alarm will reset automatically once the current weather condition falls
below the trigger value, or if a new value is entered.
MIN/MAX MODE
1. Press the MIN/MAX key to enter the maximum mode:
• The MAX icon and the maximum recorded values will be displayed.
2. Press MIN/MAX key again to enter the minimum mode.
• The MIN icon and minimum record values will be displayed.
3. Press MIN/MAX key again to return the Normal Mode.
IN THE MAXIMUM/MINIMUM MODE
1. Press the + key to cycle through the following values together with the time
and date at which these values were recorded.
• Indoor humidity maximum
•Indoor temperature maximum
• Outdoor humidity maximum
• Outdoor temperature maximum
• Pressure maximum
2. Press the SET key when the value is flashing to reset the parameter to the
current value.
3. Press the SNOOZE/LIGHT button on top of the weather station to return to
Normal Mode.

12
TROUBLESHOOTING
Problem & cause Remedy
No reception - Distance between
transmitters and receiver too great.
Reduce distance between
transmitter and receiver to receive
signal.
No reception - High shielding
materials between the units (thick
walls, steel, concrete, isolating
aluminum foil etc.)
Find a different location for sensor
and/or receiver.
Interference from other sources (e.g.
wireless radio, headset, speaker, etc.
operating on the same frequency).
Find a different location for the
sensors and/or base station.
Neighbours using electrical devices
operation on the same signal
frequency can also cause
interference with reception.
No reception. Find a new location for the sensors
and/or base station.
Poor contrast LCD or no reception or
low batteries in sensors or receiver.
Change batteries ( check low
battery indicator on the LCD)
Temperature, humidity, or air
pressure is incorrect.
Check/replace batteries.
Adjust relative air pressure to a value
from a reliable source (TV radio,
etc.).

13
SPECIFICATIONS
Outdoor data
Transmission distance in open field : 100 metres maximum
Frequency 433MHz
Temperature range -40°C to + 65°C (show OFL if outside range)
Resolution 0.1 °C
Measuring range rel. humidity 20% - 95%
Humidity accuracy +/- 5% under 0 - 45°C
Measuring interval thermo-hygro sensor 48 sec
Water proof level IPX3
Indoor data
Pressure / temperature 48 sec
Temperature range 0°C to + 60°C (show OFL ifoutside range)
Resolution 0.1°C
Measuring range rel. humidity 1%—99%
Resolution 1%
Measuring range air pressure 919 hPa - 1080 hPa
Resolution 0.1 hPa
Alarm duration 120 sec
Power consumption
Base station 3XAA 1.5V LR6 Alkaline batteries
Remote sensor 2xAAA 1.5V LRO3 Alkaline batteries
Battery life Minimum 12 months for base station
Minimum 24 months for remote sensor

14
DECLARATION OF CONFORMITY

15
