Classeq D 400 Instruction manual

Turning the dishwasher on
Loading the dishwasher
Push the ‘ON’ button, the button will flash amber to indicate
pre-heating and water filling of the machine. You can continue
to prepare the machine whilst this process occurs.
Open the door to load the items. Before loading, ensure debris
is rinsed from the items. Once complete, close the door.
See the User Manual for loading information.
2
1
Selecting a wash program (optional)
If you do not require the default
program then choose your
desired program using the
SELECT button until the display
shows the program you require.
4Confirming your selection
Cycle indicator will illuminate blue to show a program selection
has been made.
5
Dishwasher starts cycle
Once the temperature and water cycle is complete, the amber
START button will illuminate green and your program will start.
3
D400 D400DUO D400DUOWS D500 D500DUO D500DUOWS
G350 G400 G400DUO G400DUOWS G500 G500DUO G500DUOWS
Undercounter Dishwasher/Glasswasher
Quick User Guide
2 Mins
*
3 Mins
1.5 Mins
2 Mins
5 Mins
*
*Default program
Caution
Only use this Quick User Guide after the
Dishwasher has been fully commissioned.
See Section 5 in the User Manual.

Low Salt Warning
6
Daily Cleaning
The interior of the machine should be cleaned after each
service when the machine is drained down.
• Remove and clean the top and bottom Rinse and Wash Arms. (5)
• Remove and clean the primary filters. (6)
• Remove and clean the secondary filters. (7)
• Clean the interior of the Wash Tank with a sponge (8) and/or
brush for all apertures and outlets. (9)
• Clean around the door hinge.
• Use a trigger spray bottle with a jet nozzle to spray the ball in
the anti-syphon device (pumped drain machines only). (10)
• If required apply food grade grease to the Door Ball Catch.
Ensure all arms and filters are refitted to the machine before
turning it on.
7
The following icon indicates your machine is low on salt.
The salt should be replenished as soon as possible to
avoid limescale from building up in your machine.
To refill the Salt Reservoir follow the instructions below:
1. Open the door to the machine.
2. Remove the right hand basket ramp. (1)
3. Remove the Salt Reservoir Cap at the back right hand corner of
the Wash Chamber. (2 and 3)
4. Using the Salt Funnel supplied fill the Reservoir with granulated
salt. (4)
5. Wipe away any excess or spilt salt from the Chamber and the
Reservoir opening.
6. Refit the Cap to the Reservoir, ensure that the Cap is fitted flat
and secure.
7. Drain down the machine to remove the salt water.
Document Number 30014478 Rev A 050319
D400 D400DUO D400DUOWS D500 D500DUO D500DUOWS
G350 G400 G400DUO G400DUOWS G500 G500DUO G500DUOWS
Undercounter Dishwasher/Glasswasher
Quick User Guide
56
1
10
8
2
6
7
5
9
2
2
34
Before first use, when filling with salt, ensure the Salt
Reservoir has been filled with fresh water. See Section 5
Commissioning in the User Manual.
