Classeq D 400 Instruction manual

Turning the dishwasher on Loading the dishwasher
Open the door to load the items. Before loading, ensure debris
is rinsed from the items. Once complete, close the door.
See the User Manual for loading information.
Push the On/Off button, the button will flash amber to indicate
pre-heating and water filling of the machine. You can continue
to prepare the machine whilst this process occurs.
21
Selecting a wash programme
4
5
Dishwasher starts cycle
Once the required temperature and water cycle is complete, the amber
indicator will illuminate green and your program will start.
3
D400 D500
G350 G400 G500
Undercounter Dishwasher/Glasswasher
Quick User Guide
Confirming your selection
Your machine has one possible program time that is pre-set
to offer the best possible results. These times are as follows:
• Dishwasher – 3min
• Glasswasher – 2min
Your machine has a heat interlock to ensure that the rinse is in
accordance with environmental health requirements. A recovery
time may be experienced between cycles to get back to this
interlock temperature indicated by the flashing amber heating
indicator. For full information on operating temperatures and the
interlock, please refer to the latest version of the Engineers
Manual on the Classeq website for full information regarding
temperatures and interlock settings.
Cycle indicator will illuminate blue to show a program selection
has been made.

Loading the glasswasher
6
Daily draining and cleaning
The machine must be drained down at the end of each
working day.
See the User Manual for draining instructions.
The interior of the machine should be cleaned after each
service when the machine is drained down.
• Remove and clean the top and bottom Rinse and Wash Arms (1).
• Remove and clean the Primary Filters (2).
• Remove and clean the Secondary Filters (3).
• Clean the interior of the Wash Tank with a sponge (4) and/or
brush for all apertures and outlets (5).
• Clean around the Door Hinge.
• Use a trigger spray bottle with a jet nozzle to spray the ball in
the anti-syphon device with clean water (pumped drain
machines only) (6).
• If required apply food grade grease to the Door Ball Catch.
• Leave the door open over night to let the machine air dry.
Ensure all arms and filters are refitted to the machine before
turning it on.
7
Open the door to load the glasses.
Glasses should be placed in the Open Basket open end down.
Always try to fill the Basket - to prevent glasses clinking against
each other during a wash cycle.
With tall glasses always check carefully that they fit in the
glasswasher when stood upright in the Open Basket.
D400 D500
G350 G400 G500
Undercounter Dishwasher/Glasswasher
Quick User Guide
1 2
3 4
5 6
Document Number 30012267 Rev C
