Classic coffee concepts
INSTALLATION,OPERATION,AND SERVICE MANUAL FOR
MRC3AF AUTOMATIC BREWER WTTH HOT WATER FAUCET
Model MRC3AF
23.43Wx8.43Dx20.87H
1750W,14.58A
Ship Wt approx.26.46LB’s
Decanters Not Included

PLUMBER’S INSTALLATION LNSTRUCTIONS
CAUTION: Power to brewer must be O FF before proceeding with plumbin g installation
1) Attach flow/strainer assembly to back of brewer. Strainer inlet will point down.
2) Flush water line before installing brewer. Brewer should be connected to COLD WATER LLNE for best oper ation
3) Water pressure should be at least 20 lbs For less than a 25 ft run ,use 1/4’ copper tubing and connect to 1/2 or larger
Water line, For longer runs ,use 3/8” copper tubing & connect to 1/2” or larger water line and provide an adapter fitting for
Connection to the brewer.
4) lf installed with saddle valve, the valve should have a minimum of 1/8” port hole for up to 25 ft run, and 5/16” port hole for
over 25 ft runs.
5) Connect incoming water line to the strainer in the back of the brewer. Manufacturer recommends connecting to copper tubing.
INSTALLATION INSTRUCTIONS
WARNING: read and follow installation instructions before plugging or wiring in machine to electrical circuit. Warranty will be
Void if machine is connected to any voltage other than that specified on the name plate.
FILL BREWER TANK WITH WATER BEFORE CONNETING TO POWER SUPPLY
1) place the decanter under brew basket, raise top evaporation cover and pour three decanters of water through the top pour-in
screen. water should come through the brew basket as the third decanter of water drains out of water the pour in basin. lf brewer
does not have a pour in opening remove top cover and pour water directly into receiving pan.
2) Adjust timer to deliver desired amount of water (Timer is located behind front acc ess panel).To brew into a regular 60 oz.
Decanter little adjustment should be needed. Turn timer dial clockwise to increase volume of warier ,and counter clockwise
To decrease volume.
3) Brewer is shipped with thermostat turned on, (full clockwise position).Plug or wire in machine to appropriate voltage
Circuit aw noted in the brewers serial tag. Serial tag is located on rear of brewer.
4） Allow 10 to 15 minutes for water in tank to heat to brewing temperature .(Additional water may drip from brew basket on
Initial expansion of water in the tank). This will not occur thereafter.
5) After water hoax reached brewing temperature (thermostat will click off, heatin g noise will stop and green ready light will be
on.) turn lower war mer switch (warmer models). Or lighted rocker switch (airport brewers) to the on position. Depress brew
start switch and run a cycle of water to remove expanded water from tank. (Bre w cycle may be canceled by turning the
rocker switch back to the OFF position.)
6) Run one cycle to check for the proper temperature setting with an accurate thermometer. Take the temperature of this water
at a point below the brew basket opening, at the start of the brew cycle and when the decanter is half full. Recommended
temperature of the water is approximately 195 F.
7) In higher altitude locations (5000 feet above sea level) the thermostat may have to be adjusted lower to prevent boiling.
8) CAUTION: On faucet models the water faucet will dispense hot water when the handle is depressed. The faucet system is
Independent of the brewing system and can be operated dunning brew c ycle. Once brewer is pressurized operate faucet until
Water flows smoothly.
COFFEE PREPARA TION PROCEDURES
1) Place filter into brew basket.
2) Put the proper amount of coffee into the filter.
3) Slide the brew basket into holder.
4) Place empty decanter on warmer located directly under the brew backer and turn corresponding warmer switch to ON position
5) Pour decanter of water through pour-in screen into pour in basin.
6) Hot water will be delivered through the spray head. This distributes the hot water evenly over the coffee bed within the brew

Basket. The coffee brew will drain fro m the brew basket into the decanter below.
1) The resultant coffee brew should be crystal clear and have the desired properties attainable through excellent extraction.
2) TURN OFF WARMER WHEN NOT IN USE. (Red light indicator warmer is on.)
3) To clean brew basket simply remove from brew rails and dump filter into waste basket. The brewing process, as described
Above, can now be started again.
LIMING
To prevent liming problems in tank fittings remove spray head and insert declaiming spring all the wa y into the tank When
inserted into tank properly, no more than ten inches of the spring should be visible at the spray he ad fitting Saw back and forth five or
six times. This will keep fittings open and clear of lime. In hard water areas this should be done everyday. This process takes
approximately one minute. In all areas the spra y he ad should be cleaned at least once a week, Where bad liming has already o ccurred,
a new complete tank assembly may be installed. The tank may be changed in approximately 5 minutes time.
WARRANTY
Classic Coffee Concepts coffee brewers are watt anted against defects in workmanship or materials, under normal use, for 90
Days from the date of purchase Brewer parts are warranted against defect for 12 months from date of purchase.
Liability in all events is limited to the purchase price paid and liability under the aforesaid warranty is limited to replacing or
repainting any part or Paris which are defective in material or workmanship, and retimed to our factory, shipping cost prepaid, NO
warranty expressed or implied, other than the aforesaid is made or authorized b y Classic Coffee Concepts
Prompt disposition will be made if item proves to be defective, within warranty. Before returning an y item, write or call
Classic Coffee Concepts giving model number, serial number, and date of purchase, and describe the nature of the defe ct.
7
8
9

TROUBLE SHOOTING GUIDE
SYMPTOM
POSSIBLE CAUSE
WATH TO CHECK REMEDY
IRRECULARYIELD 1.Not siphoning properly
2.Timer
3.Fluctuating water pressure
4.Solenoid valve
5.Flow washer
6.Flow control screen
7.Faucet coil is leaking
8.Strainer.
1.Refer to "DRIPPING",Step1.
2..Timer consistency,Time
several brew cycles
3. Water pressure
4..Referto "DRIPPING",Step2.
5.Possible line build up in flow
control.
6.Screenbuilt into flow
control .
7.Refer to "DRIPPING",Step3.
8.Water pressure at output
1..Refer to "DRIPPING",Step1.
2. If times are irregular ,replace
timer
3.If pressure fluctuates 10-20PST
during operation of brew
cycle ,add pressure regulator to
inlet side of brewer .set to lowest
pressure level .
4.Refer to "DRIPPING",Step 2.
5.Replace flow washer and clean
line from the control .
6.Replace or clean scree ,Clean
line from flow control
7.Refer to "DRIPPING",Step3
If pressure is low ,clean or replace
strainer.
DRYCOFFEE
REMAINNG
INBREW BASKET
AFTER BREWING
1.Filters
2. Not siphoning properly
3.Improper loading of the brew
basket
1.Are correct filters being
used .
2..Referto "DRIPPING",Step1.
3.Filter and coffee in brew
basket .
1. Insert correct filter
2.Refer to "DRIPPING",Step1.
3.Filter should be contract in the
brew basket and cottee
Bod should be level
WEAK COFFEE 1.Filters
2. Not siphoning properly
3.Improper loading of the brew
basket .
1.Are correct filters being
used .
2..Referto "DRIPPING",Step1.
3.Filter and coffee in brew
basket .
1. Insert correct filter
2.Refer to "DRIPPING",Step1.
3.Filter should be contract in the
brew basket and cottee
Bod should be level
SOLENOID
CLATTE OR
NOWLING
1.Brewer connected to hot
water line
2.Vibration
3.High water pressure
4.Water hammer .
5.60 cycle vibration
1.Incoming water line
2.If brewer is on a metal stand
or counter ,anther the bottom
pan not copper tubing to the
brewer should touch the
counter .
3.Water pressure on incoming
line
4.Nut on top of morbid
1.Brewer should be connected to
cold water line
2.Adjust as necessary
3. If water pressure is over 90PSL
install a pressure regulator and
adjust to 50 PSL
4.This not the fault of the brewer
and can usually be corrected by
rearing scree plumbing water line
5.Nut should be tight ,Tighter as
required
TROUBLE SHOOTING GUIDE

COLDWARMER
STATION
1.Warner-defective
2.Warmer ON/OFF Switch
3.Bad baroness
1.Voltage at warmer terminals
should be 120volts AC
2.If voltage is not present on
warmer terminals,check
continuity of switch .
3. Check connections between
switch and warmer .
1.If voltage is present on
terminals,but warmer will not
beat ,replace warmer
2.If switch does not make and
break continuity when turned
off ,replace switch
3.All connections should be tight
FAUCET WATER
FLOW TOO FAST
OR TOO SLOW
1.No water
2.Flow too slow or too fast
1.(A)Incoming water line shut
off valve (B) Faucet clogging
(C) Needle valve
2. Needle valve
1.(A)Water shut off valve should
be open (B)Clean or rebuild faucet
(C)Needle valve should be open.
2.Increase flow by ruining needle
valve counter clockwise flow by
turning clockwise

SYMPTOM POSSIBLE CAUSE WHAT TO CHECK
REMEDY
CAN'T START
BREW CYCLE
1.No water
2.NO power
3.ON/OFF switch
4.Brew star switch
5.Time or timer harness
6.Solenoid valve
1.Incoming water line&water
shut off
2.Fuse or circuit breaker
Power cord and plug
connections. 3.Swatch
continuity (Normally open)
4.Swatch continuity
(Normally closed)
5.Wire leads to solenoid and
black 3-pin connector
6.(A)Voltage at solenoid valve
terminals.Start a brew cycle
and check for 120 volts AC.
(B)If voltage is present at
terminals chock for water at
line pressure on the inlet side
of solenoid valve.
1.Be sure water shut off is open.
2.Replace or rest circuit protector
3.If ON/OFF switch does not
make and break contact,replace
ON/OFF switch.
4.Make sure these connections are
tight ,If so ,and all also checks out
ok ,replace timer .
5.(A)If voltage is not present at
terminal,refer to steps 2 through
(B)If voltage is present at terminal
and water at line pressure is
present on the inter side of the
solenoid,but not present on the
outgoing side ,replace solenoid.
NO HOT WATER 1.Tank heater
2.Hi-limit thermostat or main
thermosla
1.Check the voltage at the
tank beater terminals.Voltage
should be as implicated on the
octal tug (on real of brewer)
2..Check the voltage between
the white wire on the tank and
the meaning terminal (blue
wire) on the hi-limit
thermostat ,then the outgoing
terminal(black wire) on the
hi-limit thermostat.
1.(A)If correct voltage is present at
the tank heater terminal and water
in tank is not being headed replace
the tank better (B)If voltage is not
present at the tan headed terminals
refer step. (C) If interest voltage is
present at the tank heater
terminals,check voltage at outlet.
2.(A)If voltage is present on the
imaging terminal of the hi-limit
thermostat but not on the outgoing
terminal ,replace hi-limit
thermostat.(B)Check voltage
between black and white wire on
the restate,If voltage is not present
check outlet or circuit breaker.
(C) If voltage is not present on the
incoming terminal of the hi-limit
thermostat,replace the main
thermostat.
TROUBLE SHOOTING GUIDE

DRIPPING 1.Not siphoning propertly
2.Solenoid valve not heating
properly
3.Faucet coil is leaking
1.Water should flow freely
from the spearhead .
2.Solenoid valve assembly .
3.Hot water coil.
1.(A)Clean spearhead holes.
(B)Check tightness of spearhead
tube. (C) See "LIMING"page 2.
2.Be sure spring is in place and
any particles are cleaned from
valve scat ,If valve sent is mon of
modulate ,replace solenoid valve
3.Tighten filings or replace coil .
STEAMING OR
SPITTING
AROUND FUNNEL
1. Main thermostat
2. High altitude
1.Thermostat points stuck or
out of calibrator . 2.Located
above 5.000set.
1.(A)Adjust thermostat.
(B)Thermostat should be calibrated
or replaced
2.See"INSTALLATION
INSTRUCTIONS"page 2.
FAUCET
DRIPPING
1. Charged valve seal 1.Valve seat. 1.Dissemble and clean or replace
as required .
WATER KEEPS
RUNNING
1.Solenoid valve
2.Start switch
3.Timer
1.Refer to "DRIPPING"Step1.
2.Remove wire from switch
and check continuity .
3.Solid state timers are not
repairable.If timer will not
shut off replace.
1.Refer to "DRIPPING",Step1.
2.If start switch does not make and
break contact switch should be
replaced. 3.Replace timer.
