Clean & Co VCC888PL Parts list manual
!
!
!
!
!
!
!
!
!
!
!
!
!
!
CARE & USAGE
WELCOME
Thank you for purchasing Clean & Co. We’re thrilled you have chosen this exclusive,
EVINE Live brand created to ensure you have the best cleaning essentials and state-of-
the-art tools at the ready. Please read on for helpful information, including your warranty
details.
IMPORTANT SAFE GUARDS
READ ALL INSTRUCTIONS BEFORE USING YOUR VACUUM CLEANER.
When using an electrical appliance, basic safety precautions should always be observed,
including the following:
WARNING: To reduce the risk of fire, electrical shock, or injury:
1.!Do not leave appliance when plugged in. Unplug from outlet when not in use.
2.!Do not use outdoors or on wet surfaces.
3.!Do not use as a toy. Close attention is necessary when used by or near children.
4. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
5. Do not use with damaged cord or plug. Do not use vacuum if it has been dropped,
damaged, left outdoors, or dropped in water. Return it to an authorized service center.
6. Do not pull or carry by cord, use cord as a handle, or pull cord around sharp edges or
corners.
7. Do not run appliance over cord. Keep cord away from heated surfaces.
8. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
9. Do not handle plug or appliance with wet hands.
10. The vacuum cleaner is not intended to pick up large and/or sharp objects as they can
obstruct the vacuum.
11. Do not put any object into openings. Do not use with any opening blocked; keep free
of dust, lint, hair and anything that may reduce air flow.
12. Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts.
13. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or
ashes.
14. Turn off the control before unplugging.
15. Use extra care when cleaning on stairs.
16. Do not use to pick up flammable or combustible liquids such as gasoline or use in
areas where they may be present.
17. Keep end of hose, wands and other openings away from your face and body.
18. Do not use the vacuum cleaner without dust cup filter in place.
19. Always unplug this appliance before connecting or disconnecting vacuum hose.
20. Store the vacuum indoors. Put the vacuum away after use to prevent tripping
accidents.
21. Using improper voltage may result in damage to the motor and possible injury to the
user. Correct voltage is listed on the rating label.
22. Use only on dry, indoor surfaces.
23. Do not use for any purpose other than described in this user’s guide.
24. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
25. If the brush or extension tubes are blocked, you should switch off the vacuum
cleaner at once. First clear the blocked substance before you attempt to start the
vacuum cleaner again.
26. Do not operate the vacuum cleaner near heaters, radiators, or cigarettes.
27. Before you start using the vacuum cleaner, please remove large or sharp objects
from the floor in order to prevent damage to the filter.
PARTS IDENTIFICATION
5
6
4
7
3
1
2
12
Dust%Cup%Cover
%%Dust%%Cup%
Release%Button
Dust%Cup%Cover%
for%Air%Exhaust
Plastic%Centering%
Filter%System
Dust%Cup
Dust%Cup%Bottom
Dust Cup%Set
9
8
10
11
1. Main Floor Brush
2. Plastic Telescopic Tube
3. Dust Tank Lock
4. Power Switch
5. Dust Tank
6. Dust Tank Upper Part Release Button
7. Dust Tank Bottom Release Button
8. Multi Crevice Brush
9. 2 in 1 Moppping and Vacuum Floor Brush
10. Multi Brush
11. Storage Bag
12. Sponge and Filter
Ideas for using attachments!
Main Floor Brush: Great for carpet, hardwood, stone, or linoleumfloors.
Multi Crevice Brush: Use in corners of walls, hardwood floors or baseboards.
2-in-1 Mopping and Vacuum Floor Brush: Vacuum and mop at the same time with
detachable cloth. Wet the cloth on the attachment and begin vacuuming to clean up
spills on the floor. Great for tile and hardwood floors! NOTE: Cloth is washing
machine safe.
Multi Brush: Use on upholstery or blinds.
ASSEMBLY
NOTE: Please remove the plug from the power socket before fitting or removing
accessories.
1.!Before turning the unit on, install desired attachment into the body. To use the
extension tubes, install the tube into the body. Note: Insert the tube into the body
in the open position then turn to the lock position. Then attach brush of your
choice. See figure 1 for reference on installation.
FIGURE 1
2.!To remove the dust cup from the body, push the release button of the dust cup
and take out the dust cup from the body. See figure 3 for reference.
FIGURE 3
1、push&here
2、move
3. To install the dust cup on the body, first connect the underside of the dust cup to
the body. Then push the dust cup to close with the body. See figure 4 for
reference.
FIGURE 4
CLEANING
How to clean the Dust Cup.
1. Remove the dust cup from body.
2. Press the dust cup bottom release button, then the dust will fall down
automatically. (Note: The contents of the dust cup will be released, please do this
over a trash can). See figure 5 for reference.
3. If the plastic filter system is still dirty, press the dust cup cover (for air exhaust)
release button. Take the filter assembly out of the dust cup, then clean with a soft
brush or wash with water. (Note: Completely dry parts before use.) See figure 6
for reference.
FIGURE 5 FIGURE 6
Dust%Cup%Bottom
%Release%Button
Push
Filter'Assembly
Plastic'Centering'
Filter'System
How to Change and Clean the Sponge and Filter.
1. Remove the dust cup from body.
2. Rotate the dust cup cover counterclockwise from “close” to “open”, take out the
dust cup cover and take out the sponge and filter set. See figure 7 for reference.
3. Pull up the knob of the filter frame and pull out the sponge filter and filter from the
body. The sponge and filter can be cleaned by using a soft brush or rinsing them
in lukewarm water. Note: Parts should be completely dry before next use. See
figure 7 reference.
4. It is recommended to clean filters when suction begins to weaken.
FIGURE 7
Sponge'and'
Filter
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE REASON
POSSIBLE SOLUTION
HAND VACUUM
WILL NOT OPERATE
1. No power in electrical outlet.
2. Unit needs servicing.
1. Check fuse or breaker.
HAND VACUUM
WILL NOT PICK-UP
OR SUCTION
POWER IS WEAK
1. Dust cup is full.
2. Dust cup filter needs
cleaning.
1. Empty dust cup
2. Remove dust cup filter and check for
object(s) in air duct and remove.
DUST ESCAPING
FROM HAND
VACUUM
1. Dust cup is full.
2. Dust cup filter is not installed
correctly.
3. Puncture hole in the dust cup
filter.
1. Empty dust cup.
2. Review dust cup filter instruction.
3. Replace dust cup filter.
HAND VACUUM
BRUSHES WILL NOT PICK UP
1. Dust cup is full.
1. Empty and clean dust cup container.
LIMITED ONE YEAR WARRANTY
This warranty covers all defects in workmanship or materials in the mechanical
and electrical parts, arising under normal usage and care in this product for a period of
12 months from the date of purchase provided you are able to present a valid proof of
purchase. A valid proof of purchase is a receipt specifying item, date purchased, and
cost of item. A gift receipt showing item and date of purchase is an acceptable proof-of-
purchase. Product is intended for household use only. Any commercial use voids the
warranty.
This warranty covers the original retail purchaser or gift recipient. During the
applicable warranty period within normal household use, we will repair or replace, at our
discretion, any mechanical or electrical part which proves defective, or replace unit with
a comparable model. Shipping and handling costs are not included for warranty
replacements and are the responsibility of the customer.
To obtain service under the terms of this warranty, call our customer care
department at 312-526-3760 (Monday- Friday 10 am- 6:00 pm CST), or send an email
of this page when contacting us.
THIS LIMITED WARRANTY COVER UNITS PURCHASED AND USED WITHIN THE
UNITED STATES AND DOES NOT COVER:
• Damages in transit.
• Damages from improper installation.
• Defects other than manufacturing defects.
• Damages from misuse, abuse, accident, alteration, lack of proper care and
maintenance, or incorrect current or voltage.
• Damage from service by other than authorized dealer or service center.
• Shipping and handling costs.
• This warranty gives you special legal rights and you may also have other rights to
which you are entitled which may vary from state to state.
Manufacturer does not assume responsibility for loss or damage for return
shipment. We recommend that you keep your original packaging should you require
repair service. Before returning product please contact our customer care department
for return authorization. When returning product for repair please include your full name,
return address, and daytime phone number. Also include a brief description of the
problem you are experiencing and a copy of your sales receipt or other proof of
purchase in order to validate warranty status.
MODEL VCC888PL
