2!
FXx Standard / FXx Deluxe / FXR / FR1000
Owner’s Manual
•This manual should be considered a permanent part of the motorcycle
and should remain if it is resold.
•This manual contains the latest product information available before
printing. Cleveland CycleWerks reserves the right to make changes at
any time without notice and without incurring any obligation.
•No part of this publication may be reproduced without written
permission.
© 2009-2015 Cleveland CycleWerks
REV.1!01/2015

!
3!
Please write the serial numbers of your motorcycle in the boxes below
Chassis (VIN) Number
Engine Number
Dealer
Color Codes
Cleveland CycleWerks reserves the right to modify any equipment, technical specifications,
colors, materials, services offered and rendered, and the like so as to adapt them to local
conditions without previous announcement and without giving reasons, or to cancel any of the
above items without substituting them with others. It shall be acceptable to stop manufacturing a
certain model without prior notice. In the event of such modifications, please ask your local
Cleveland CycleWerks dealer for information.
IMPORTANT
PLEASE READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE GOING
ON YOUR FIRST RIDE. IT CONTAINS A GREAT DEAL OF INFORMATION AND
ADVICE, WHICH WILL HELP YOU USE AND HANDLE YOUR BIKE PROPERLY.
!
!
!
CONSUMER INFORMATION FOR UNITED STATES
Tampering with noise & emissions control systems is prohibited
Owners are warned that the law prohibits:
A. The removal or rendering inoperative by any person other than for purposes of
maintenance, repair or replacement, of any device or element of design incorporated
into any new vehicle for the purpose of noise and/or emissions control prior to its
sale or delivery to the ultimate purchaser or while it is in use; and
B. The use of the vehicle after such devise or element of design has been removed or
rendered inoperative by any person.
!
!
!
!
!
!
Body
Frame
Swing Arm

!
4!
:IMPORTANT WARRANTY INFORMATION:
YOUR WARRANTY IS OFFERED AND SERVICED DIRECTLY BY THE IMPORTER / DISTRIBUTOR
WITHIN EACH COUNTRY. CLEVELAND CYCLEWERKS DOES NOT SERVICE OR EXTEND A
WARRANTY DIRECTLY TO CUSTOMERS, YOU MUST GO THROUGH YOUR DISTRIBUTOR.
WARRANTY PROCESS: CUSTOMER > CONTACT DEALER FIRST > DEALER CONTACT
DISTRIBUTOR.
This document does not express, extend, or imply that Cleveland CycleWerks is directly or indirectly
offering a warranty for the product in your country. All warranties have to go through the distributor in each
respective country.
Cleveland CycleWerks Distributor / Importer of Record, warrants that this product is free of defects in
material and workmanship.
PLEASE REFERENCE YOUR WARRANTY AND SERVICE BOOKLET FOR
MORE INFORMATION & EMISSIONS WARRANTY
TO RECIEVE SERVICE: Contact your nearest Cleveland CycleWerks service center and/or
dealer. The cost of transportation of the product to and from the service center and/or
dealer must be paid by the owner.
No service center and/or dealer is authorized to modify this warranty.
RI00IJ1Z$

!
5!
IMPORTANT WARRANTY INFORMATION
INTRODUCTION
IMPORTANT SAFETY INFORMATION
SAFETY INFORMATION FOR PARENTS
SAFETY LABEL INFORMATION
COMPONENT LOCATIONS
SERIAL NUMBER LOCATIONS
HANDLE BAR LEVER CONTROLS
FUEL FILL CAP
OPERATING CONTROLS
KEY IGNITION SWITCH
FUEL PET-COCK
BEFORE RIDING
PROTECTIVE GEAR & APPAREL
IS THE MOTORCYCLE READY TO RIDE
PRE-RIDE INSPECTION
BASIC OPERATION & RIDING
BREAK-IN PERIOD
SAFE RIDE PRECAUTIONS
ENGINE STARTING PROCEDURE
FLOODED ENGINE
STOPPING THE ENGINE
SHIFTING GEARS
BRAKING TECHNIQUE
PARKING & POST RIDE INSPECTION
MAINTAINING YOUR MOTORYCLE
IMPORTANT SAFETY PRECAUTIONS
MAINTENANCE SCHEDULE
BASIC MAINTENANCE PRECEDURES
FUEL, GASOLINE
REFUELING & INSPECTION
ENGINE OIL
CHECKING & ADDING OIL
CHANGING OIL & FILTER
CHANGING AIR FILTER
THROTTLE SYSTEM
ENGINE IDLE SPEED
CLUTCH SYSTEM
SPARK PLUG
BRAKING SYSTEM
BRAKE LEVER ADJUSTMENT
BRAKE FLUID CHECK
ADDING BRAKE FLUID
BRAKE PADS
BRAKE SYSTEM BLEEDING
SUSPENSION SYSTEM
FRONT SUSPENSION INSPECTION
FRONT SUSPENSION ADJUSTMENT
REAR SUSPENSION INSPECTION
REAR SUSPENSION ADJUSTMENT
RIMS & TIRES
TIRE AIR PRESSURE
TIRE INSPECTION
TIRE REPLACEMENT
NEW TIRE BREAK-IN PERIOD
DRIVE CHAIN SYSTEM
DRIVE CHAIN INSPECTION
DRIVE SPROCKET INSPECTION
CHAIN ROLLER INSPECTION
CHAIN SLIDER INSPECTION
CHAIN ADJUSTMENT
CHAIN LUBRICATION
CHAIN REMOVAL & REPLACEMENT
TROUBLESHOOTING
DEALING WITH THE UNEXPECTED
SPECIFICATIONS
WIRING SCHEMATICS
MAINTENANCE RECORDS
NOTES
51 -55
56 -57
58 –60
61
62
63-64
47 -50
47
48
48
49
49
49
50
45 -47
45
46
46
47
41 -44
41
41
42
43, 44
04
06
10 -13
13
14
15 – 16, 18 -20
17
18
19
20
19
19
21
21
22
22
23 - 24
23
23
24
24
24
25
26
26
27
27
28, 29
30 -50
30
30
31
31
32
33
33
34
35 -36
37
38 -40
38
38
39
39
40
$MKJ1NJ1%$

!
6!
Dear Customer,
Thank you for choosing Cleveland CycleWerks, we know you have many choices of
motorcycles that you could have chosen; your show of confidence in Cleveland is
appreciated. Our designers, engineers and entire staff have placed a considerable
amount of passion and knowledge into the development and manufacturing of vehicle
that you have chosen.
We do our best to provide a trouble free and exceptional product from the factory. We
recommend you to strictly follow the instructionsgiven in this manual, paying close
attention to the break-in period of this motor vehicle.
The instructions contained in this manual will help you make the most of your
motorcycles performance and operational life. This manual provides useful information
on how to take care of your vehicle, and also describes routine maintenance operations.
For any servicing or assistance you might need, please contact our authorized dealer
and/or service centers.
Cleveland CycleWerks makes every attempt possible to verify the accuracy of our user
manuals, we understand mistakes happen, as manuals are written during the
development of the vehicle, specifications and variations do occur between writing the
manual and production, we clearly state this and note that variations may happen
between the manual and production. Every country has a unique set of laws and
statutes, your countries model may vary slightly from the images or descriptions, due to
each individual countries compliance regulations.
The information contained herein is valid at the time of printing. Cleveland CycleWerks
reserves the right to make changes required by the future development of the above
mentioned products. We do our best to verify the accuracy of this manual, but
mistakes do happen, no liability is accepted for mistakes during the drafting of this
manual.
For your safety and reliability of your vehicle, use original CLEVELAND CYCLEWERKS
spare parts ONLY.
