Clifford GP500 User manual

For the latest vehicle wiring
information and for wiring diagrams
and servicing information on older
Clifford products 24-hour dealer
website:
www.clifforddealer.com
USA Toll Free Technical Support:
800-444-4667
UK Technical Support Free Phone:
800-526708

Standard Features of GP500
Note:ThesystemcurrentdrawofGP500is5mAplusor
minus 0.5mA. Voltage operating range is 9V to 16V.
❑Lifetime Warranty
❑EC 97/24 Approved
❑Weather Resistant
❑Two ACG™ 2 Remote Controls
❑Extended Range
❑Built-In Two-Point Immobilizer™
❑Helmet Theft Protection System
❑Fully Adjustable Dual-LevelPiezo Sensor™
❑Digital Dual-Zone Tilt/Motion Sensor
❑Self-Powered Siren with Key Override
❑Built-In Indicator Light Flasher with On-Board Relay
❑User-Selectable AutoArming™
❑Advanced CMOS Microcomputer
Installation Manual/4991

Standard Features of GP500 (Cont’d)
❑BikeBeacon™ Vehicle Locator System
❑FACT—False Alarm Control and Test
❑Patented SmartPowerUp™ 2
❑Patented Smart AutoTesting™
❑Five-Event TotalRecall™
❑Remote Panic
❑Patented Smart Prior Security Breach Alert
❑Multiple-Vehicle Control
❑Patented Remote Control Code Learning
❑High-Luminescence LED with Automatic
Battery-Saving Mode
❑All Black Wiring
2GP500

System Connections
Control Unit
The GP500 control unit must be installed as far away
as possible from the engine. Under no circumstances
should the unit be installed close to hot or moving
parts.
1.Remove the seat and any side panels necessary to expose the
battery terminals, indicator light wiring and ignition wires.
2.Select a location under the seat to mount the GP500 control
unit. The control unit must be mounted in a flat and level
position with the side bearing the Clifford logo facing upward.
This location must stay dry and allow the use of screws or tie
wraps to securely fasten the control unit to metal. Avoid hot or
moving parts.
3.Mount the GP500 control unit using screws or tie wraps, but do
not permanently affix it until all wiring and testing is complete.
Installation Manual/499 3

LED Status Indicator
Select a prominent location on the motorcycle that is highly visible
from all directions. Discuss placement with the owner.
1.Verify there is adequate space to accommodate the LED, then
drill a 4mm (#21 drill bit) hole and route the wires through it.
2.Mate the BLACK wire connector labeled LED (+) to the LED’s
VIOLET wire as shownin the diagram on page 5.
3. Mate the BLACK wire labeled LED (-) tothe LED’s BLACK
wire as shown in the diagram on page 5.
4. Press the LED into place.
PlainView 2 Coded Programming Switch
1.Discuss placement of the switch with the vehicle owner and
avoid placing the switch where it can be pressed accidentally.
2.Mount the switch on to a clean, dry surface using the supplied
adhesive tape.
3.Mate the switch’s locking connectors to the locking connector from
the control unit.
4GP500

Installation Manual/4995

Indicator Lights
1.Connect a voltmeter lead to ground.
2.Access the indicator light harness near the indicator light switch,
and turn on the left indicator light.
3.Probe the wires. When you probe the correct left indicator light
wire, the voltmeter will read +12V when the indicator lights
illuminate, and 0 volts when they turn off.
4. Turn on the right indicator light and repeat step 3.
5.Connect one of the two BLACK wires labeled Indicator Light
+12Vto the left indicator light circuit and the other wire labeled
Indicator Light +12Vto the right circuit as shown in the
illustration on page 5 .
Starter and Ignition Immobilization Circuits
1.Locate the ignition switch wireloom under the gauges or
key/ignition switch and use a voltmeter to locate the one wire
that carries +12V throughout BOTH the cranking AND
engine running cycles, and 0 volts when the ignition is off.
2. Start the engine, then cut the ignition wire. The engine should
stop running.
3.As shown on page 5, connect the BLACK wire with the Ignition
Input +12 Voltslabel to the key sideof the cut ignition line.
6GP500

4.Connect the BLACK wire with the Ignition Output +12 Volts
label to the coil sideof the cut ignition line.
5.Use a voltmeter to locate the one wire that carries +12V during
the cranking cycle ONLY. Cut this wire, then try to start the
engine. It should not crank.
6. Connect the BLACK wire with the Starter Input+12 Volts label
to the key sideof the cut starter line.
7.Connect the BLACK wire with the Starter Output+12 Volts
label to the starter side of the cut starter line.
NOTE: The starter circuit may carry a very high
current. Be certain that the starter wire connections
are solid. Each immobilization circuit can carry 15
amps.
8.Remove the labels from each of the wires.
Self-Powered Siren with External Key Override
If a thief disconnects power and/or cuts any or all of the wires while
the system is armed, the siren will sound for five minutes and then
reset. If power must be disconnected for servicing, an override key is
provided to turn the siren off. Unlike other back-up battery sirens
Installation Manual/4997

that constantly drain the vehicle battery, Clifford’s design draws
charging current only when the ignition is on (i.e., engine running).
NOTE: The motorcycle must be ridden for eight hours
after the siren has been installed in order to
sufficiently charge the siren’s back-up battery.
1.Select a location for the siren under the seat or behind a side
cover. Keep the siren away from direct exposure to rain and
moisture. Avoid hot or moving parts. Also make sure there is
sufficient clearance for the mounting screws behind the
mounting surface.
2.You must firmly secure the siren using all three sheet metal
screws supplied. Mount the siren away from areas of water ingress
or excessive heat. Point the siren down to avoid moisture.
3.Connect the siren’s BROWN wire to the BLACK wire labeled
Siren Output (-).
4. Connect the siren’s BLUE wire to the BLACK wire labeled
Ignition Output +12V.
5.Connect the RED wire to the 5 amp fuse connected to the
battery positive cable clamp.
6.Connect the BLACK wire to ground.
8GP500

Final Wiring Connections
1.Connect the BLACK wire labeled Constant +12V 5Ato the 5-amp
fuseholder as shown on page 5.
2.Connect the BLACK wire labeled Constant +12V 10Ato the
10-amp fuseholder as shown on page 5.
3. Attach the two fuseholders to the constant +12V source at the
fuse panel, battery or ignition harness.
4.Use ring connectors to attach the two different BLACK wireloom
wires (labeledground) to two different chassis ground points or
one of them directly to the vehicle fuse panel ground. The
ground points must be very clean. A factory bolt that has been
completely cleaned with a wire brush is recommended.
NOTE: Power and test accessories after the basic
system has been tested. Individually fuse all
accessory power connections. Individually fuse all
+12V fuse panel connections.
Installation Manual/4999

SmartPowerUp™ 2
SmartPowerUp 2 ensures that the system powers up in the same state
(disarmed, armed or valet mode) it was last in. When you first power up
the system, it will silently enter its disarmed state.
Remote Control Operation
To transmit either channel 1, 2, or 3: Just press either button I, II,
III, respectively. For instance, to transmit channel 3, press button III.
Refer to the GP500 Owner’s Manual for more information on how to
use the remote controls.
Remote Control Channel Assignments
FunctionPress
button(s)
Arm or disarmI
Silentlyarm or disarmII
10 GP500

FunctionPress
button(s)
Instant AutoArming Bypass (press and hold button for three
seconds while system is disarmed) III
Dual-Level Piezo Sensor Warning Level Bypass (press button
after arming the system). System provides four flashes. III
Dual-Level Piezo Sensor Total Bypass (press and hold button
for three seconds after arming the system). 7 flashes are
provided.
III
Unassigned - This button can be assigned to control ACG-2
systems and accessories on other Clifford-equipped vehicles.I + II
Unassigned - This button can be assigned to control ACG-2
systems and accessories on other Clifford-equipped vehicles.I + III
Digital Tilt/Motion Sensor Warning Zone Bypass (press buttons
after system is armed). 4 flashes are provided. II + III
Digital Tilt/Motion Sensor Total Bypass (press and hold buttons
for three seconds after system is armed). 7 flashes are
provided.
II + III
Installation Manual/49911

FunctionPress
button(s)
Dual-Level Piezo Sensor Adjustment (press and hold buttons
for three seconds while system is disarmed and ignition is
OFF). See Owners Manual for complete instructions.
II + III
FACT—False Alarm Control and Test
The system microprocessor automatically checks for another
activated sensor or trigger before sounding the siren a second time,
thus preventing any further false alarms. If you wish to test FACT,
simply,
1. Arm the system with the remote control.
2.Wait 15 seconds for the Piezo sensor to become active, then
trigger the Dual-Level Piezo Sensor to activate the siren.
3.Do not disarm the system, let the siren complete its cycle.
4.Trigger the sensor again. The alarm should be silent.
5.Trigger the Digital Tilt/Motion Sensor (note that the alarm
should be in an armed state for at least one minute prior to
testing this sensor). The alarm should sound immediately. You
may now disarm.
12 GP500

Five-Event TotalRecall
The system’s nonvolatile memory records the identity of the last five
activated or malfunctioning triggers and sensors:
1.With the ignition off, press and hold the unmarked side of the
PlainView 2 switch.
2. Press remote control button 1 to arm the system, and then again
to disarm.
3.The LED will blink 1–5 times, pause, then blink 1–5 times, etc.
Write down the number of blinks in each cycle.
4.Refer to the chart below. The first number you wrote down was
the most recently activated trigger or sensor. The next number is
the second most recent, and so on up to as many as the last eight
activations.
LED flashesMeaning
1 flashIgnition switch was turned on while the system was
armed
2 flashesActivation of Digital Tilt/Motion Sensor
3 flashesActivation of Dual-Level Piezo Sensor
Installation Manual/49913

LED flashesMeaning
4 flashesActivation of Helmet Theft Protection System
5 flashesNormally Open Auxiliary Input (Optional Accessory such
as a seat trigger or pin switch).
5.If a sensor is often activated, decrease that sensor’s sensitivity (or
reposition the control unit, if necessary). If a certain trigger is
often activated, check the trigger wire for possible shorting.
Programmable Features
1.Refer to the Table of Programmable features below and find the
feature you wish to program. Make note of the number of times
to press the ✱button.
2.Turn the ignition on, or start the engine (skip this step if the
engine is running).
3.Enter the factory preset valet code of “2” by pressing the marked
side twice, then press the unmarked side once. Press and hold
the ✱button ofthe PlainView 2 switch for about 3 seconds until
you hear a siren chirp. Release the button. You are now in Program
mode.
14 GP500

4.Press and release the ✱button of the PlainView 2 switchthe
number of times indicated for the feature you are programming. You
will hear one chirp each time you press the ✱button. Pause. You
will hear a succession of chirps equal to the number of times you
pressed the ✱button. This audibly confirms your selection.
5.Perform the action, if any, in the “Secondary action” column.
6. Pause. You will hear either one or two chirps: Two chirps =
ON, one chirp = OFF(If there is a NOTEfor the selected
feature, perform the actions noted).
7.You may now select another feature or exit program mode:
a.To select a different feature column, go to step 4.
b.To exit program mode, turn the ignition off (you’ll hear
three chirps, the indicator lights flash three times, and the
LED will turn off). The system will automatically exit
program mode after 60 seconds.
If you make an error, just turn off the ignition and start
again.
Installation Manual/49915

Table of Programmable Features
FeatureFactory
SettingNo. of times to
press the
✱button
Second-
ary ActionProgram completion
confirm-
ation
Result
AutoArmingOFF2-1 chirp=OFF
2 chirps=ON
-
Chirps ON3-1 chirp=OFF
2 chirps=ON
-
FACTON4-1 chirp=OFF
2 chirps=ON
-
Siren
Duration30
Seconds5-1 chirp=30
2 chirps=60
3 chirps=90
-
16GP500

FeatureFactory
SettingNo. of times to
press the
✱button
Second-
ary Action Program completion
confirm-
ation
Result
Triggers per
Cycle 3 6 -1 chirp=1
2 chirps=2
3 chirps=3
-
Change PIN
code -7Wait for one chirp,
then enter
new PIN
code. Wait.
3 chirpsEnter new
PIN code
again.
Auto
Program
New Remote
-9Press
button I1 chirpPress button I
again.The
system
provides 2
chirps.
Installation Manual/49917

FeatureFactory
SettingNo. of times to
press the
✱button
Second-
ary ActionProgram completion
confirm-
ation
Result
Program
ACG-2
Remote -
Arm/Disarm
-10Press
button to
be
program-
med
1 chirpPress the
button to
be
programm
ed again.
System
provides 2
chirps.
Program
ACG-2
Remote -
Silent Arm
-11Wait for
one chirp,
then press
button to
be
program-
med
2 chirps-
18GP500
