Climate King HCK-BX5 Manual

1
Model: HCK-BX5
1.1 This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance. Cleaning and user
maintenance should not be undertaken by children without supervision.
1.2 WARNING: In order to avoid overheating, do not cover the heater.
1.3 Children under 3 years old should be kept away from the appliance unless
continuously supervised.
1.4 Children aged from 3 years and less than 8 years should only switch the
appliance on/off provided that it has been placed or installed in its intended normal
operating position and they are supervised or given instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children aged
from 3 years and less than 8 years should not plug in, adjust and clean the
appliance or perform user maintenance.
1.5 CAUTION-some parts of this product can become very hot and could cause
burns if touched. Particular care must be taken where children and vulnerable
people are present.
1.6 Disconnect the heater from the mains power supply before servicing or
performing any cleaning. Servicing and maintenance must only be undertaken by
a qualified electrician or service agent.
2. Introduction
2.1 Depending on the power cord fitted this fan heater may be used in certain
Climate
King®
User Manual and
Operating
Instructions
INDUSTRIAL
FAN
HEATERS
READ INSTRUCTIONS CAREFULLY: Read and follow all
instructions. Keep these instructions in a safe place for future reference. Do
not allow anyone who has not read these instructions to assemble, adjust or
operate the heater.
This product is only suitable for well insulated spaces or occasional
use.

2
locations such as households, warehouses and workshops, building sites or
greenhouses. The heater incorporates a thermostat and a self-resetting thermal
cut-out to control the heating elements. The thermostat detects the air temperature
and controls the heat output of the appliance. The fan motor is not controlled by
the thermostat and it continues working when the thermostat switches off the
heating element. The self-resetting thermal cut-out will switch off the heater to
prevent overheating.
2.2 When using the heater for the first time, you may notice a slight emission of
smoke. This is quite normal and it stops after a short time. The heating element is
made of stainless steel which is coated with a protective oil during manufacturing.
The smoke is caused by the residual protective oil when the heater is switched on
for the first time.
3. Technical specifications
Model
HCK-BX5
Waterproof Class
IPX4
Voltage
400V 3-Phase
Required Power
5000W
Current
7.2A
Required Fuse
10A
Setting
30/2500/5000W
Self-resetting Thermostat
40°C
Product Dimensions (mm)
270*255*400
Net Weight (kg)
5.6
3.1 Housing made of heat-resistant powder coated steel plate.
3.2 Supplied complete with cord and plug (16A 3P+N+E).
4. Description of Control Panel
4.1 Left Dial: Heat setting selector
4.2 Right Dial: Thermostat dial

3
5. Safety
5.1 Before use, please check the marking on the power cord. Depending on the
power cord type this appliance may be used in different ambient conditions
Type
You can use the appliance in
Do not use in
H07RN-F
household, warehouses and
workshops, building sites or
greenhouses
H05RN-F
household, warehouses and
workshops or greenhouses
building sites
H05RR-F
household, warehouses and
workshops
building sites or greenhouses
It is the responsibility of the owner and the operator to read, understand and
comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear
or damage. You must ensure that the risk of electric shock is minimised by the
installation of appropriate safety devices. Appropriate circuit protection should be
incorporated in the main distribution board and/or the individual circuit being used
to connect the appliance. If in doubt consult a qualified electrician before
connecting the appliance to the power supply.
You must also read and understand the following instructions concerning electrical
safety.
5.1.1. The Electricity at Work Act 1989 requires that all portable electrical
appliances, if used on business premises, are tested by a qualified electrician,
using a Portable Appliance Tester (PAT), at least once a year.
5.1.2. The Health & Safety at Work Act 1974 makes owners of electrical
appliances responsible for the safe condition of those appliances and the safety of
the appliance operators. If in any doubt about electrical safety, contact a qualified
electrician.
5.1.3. Ensure that the insulation on all cables and on the appliance is safe before
connecting it to the power supply. See 5.1.1. and 5.1.2. and use a Portable
Appliance Tester.
5.1.4. Ensure that cables are always protected against short circuit and overload.
5.1.5. Regularly inspect power supply cables and plugs for wear or damage and
check all connections to ensure that none are loose.
5.1.6. Important: Ensure that the voltage marked on the appliance matches the
power supply to be used.
5.1.7. DO NOT pull or carry the appliance by the power cable.

4
5.1.8. DO NOT pull the plug from the socket by the cable.
5.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately
have any faulty item repaired or replaced by a qualified electrician.
5.2 When using the electrical appliance basic precautions should always be
followed including:
5.2.1 The fan heater is not suitable for use outdoors in damp weather, in
bathrooms or in other wet or damp environments.
5.2.2 The fan heater can become very hot and should, therefore, be placed at a
safe distance from any flammable objects such as furniture, curtains and similar.
5.2.3 Do not cover any part of the fan heater.
5.2.4 The fan heater must not be located immediately below a wall socket.
5.2.5 Do not connect the fan heater using an on/off timer or other equipment which
can automatically switch the device on.
5.2.6 The fan heater must not be placed in rooms where flammable liquids or
gases are used or stored.
5.2.7 If an extension cord is used, it must be as short as possible and always be
fully extended.
5.2.8 You must not connect other appliances to the same mains socket as the fan
heater.
5.2.9Do not use this fan heater in the immediate surroundings of a bath, a shower
or a swimming pool or other environment where it may come into contact with
water.
5.2.10 If the supply cord is damaged, discontinue use and have it replaced by the
manufacturer, local service agent or similarly qualified persons in order to avoid a
hazard.
5.2.11 Keep children and animals away from the appliance.
5.2.12 Do not place the appliance on moving vehicles or anywhere where it can be
easily tipped over.
5.2.13 If the appliance is not used for an extended period, unplug the appliance.
Never remove the plug by pulling on the cord.
5.2.14 Keep the heater away from anything that could block the air inlet.
5.2.15 In order to prevent possible electric shock or leakage current, never use the
appliance with wet hands or operate the appliance when there is water on the
power cord.
5.2.16 Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities. Contact local government for information regarding
the available disposal options. Improper disposal of electrical waste in landfills or
dumps can result in the release of hazardous substances into the environment.
Always dispose of electrical waste through approved recycling facilities.
5.2.17 This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use

5
of the appliance by a person responsible for their safety.
5.2.18 Do not allow children to play with the appliance.
6. Operating Instructions
6.1 Position the fan heater so that it stands upright on a firm level surface and at a
safe distance from wet environments, sources of water and other liquids or
flammable objects and flammable substances.
6.2 Connect the supplied fan heater plug and cable to a 3-Phase power supply of
the correct rating.
6.3 Set the thermostat dial to the MAX setting to set the heater to operate on full
power.
6.4 The fan heater will switch on when the heat level selector dial is set to one of
the power settings. It will take up to 3 minutes for the heater to reach optimum
temperature.
6.5 Once the room reaches the required temperature, turn the thermostat dial
counter-clockwise until the thermostat clicks and the heating element switches off.
Leave the dial in this position to maintain the room temperature. Once the
temperature drops, the heating element will switch on again to maintain the
temperature
6.6 After use and before switching off the heater, turn the thermostat to the MIN
position and turn the heat selector switch to the fan only position, let the appliance
cool down for two minutes before turning the heater off.
7. Cleaning and Maintenance
7.1 Before cleaning the appliance, disconnect it from the power supply and let it
cool down. To keep the outside of the heater case clean, wipe it regularly with a
soft sponge. Where the outside of the case is heavily soiled, wipe it with a sponge
dipped in <50°C water and mild detergent, then dry the heater enclosure with a
clean cloth. Be careful not to let the water enter the appliance or splash water
directly onto the heater. Never use solvent or abrasive cleaners to clean the
heater.
7.2 Clean the cord and plug, dry and pack it in a plastic bag.
7.3 When you store the heater, let it cool down first. Cover it with a plastic bag, put
in a packing box and store it in a dry, ventilated place.
8. Troubleshooting:
You can solve many common problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before
making a warranty call.

6
Problem
Possible cause
Treatment
The heater does not
operate, even when
it is plugged in and
the heat level
selector switch and
thermostat are
switched on.
The plug is loose, bad
connection
Disconnect the plug, check
the connection of the plug and
socket. Then connect again.
No power from socket outlet
Move the plug to an
alternative socket with a
known working supply.
The heating
element is glowing
The input voltage is too high
or too low
Use a power supply according
to the rating on the label
The air inlet grill is blocked
Check the air inlet and
remove any blockage. Keep
the heater away from articles
like curtains, plastic bags,
paper and other items which
can block the air inlet.
The appliance does
not heat up, or only
the fan runs
The heat selector switch
was not set to a heat setting
Turn the switch to a heat
setting
The thermostat has
operated
Set the thermostat to a higher
temperature and listen to hear
it operating. If there is no click
and the thermostat is not
damaged, the heater will
automatically switch on when
the appliance cools.
The self-resetting cut-out
operated
Turn the heater off and
inspect the of inlet or outlet for
any blockage. Disconnect
the plug and wait at least 10
minutes for the protection
system to reset before
attempting to restart the
heater.
The Non-self resetting
cut-out operated
(only for a device fitted with
this function)
Disconnect the power, insert
a suitable size pin/clip/item in
the reset hole on the control
panel, press down on the
reset button.
Abnormal noise
The appliance is not
standing upright
Put the heater on a level
surface

7
Model identifier(s): HCK-BX5
Item
Symbol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local space heaters only
(select one)
Nominal heat
output
Pnom
5
kW
Manual heat charge control with integrated thermostat
[no]
Minimum heat
output (indicative)
Pmin
2.5
kW
Manual heat charge control with room and/or outdoor
temperature feedback
[no]
Maximum
continuous heat
output
Pmax
5
kW
Electronic heat charge control with room and/or outdoor
temperature feedback
[no]
Auxiliary electricity consumption
Fan assisted heat output
[no]
At nominal heat
output
elmax
N/A
kW
Type of heat output/room temperature control (select one)
At minimum heat
output
elmin
N/A
kW
Single stage heat output and no room temperature
control
[no]
In standby mode
elSB
N/A
W
Two or more manual stages, no room temperature
control
[no]
With mechanic thermostat room temperature control
[yes]
With electronic room temperature control
[no]
Electronic room temperature control plus day timer
[no]
Electronic room temperature control plus week timer
[no]
Other control options (multiple selections possible)
Room temperature control, with presence detection
[no]
Room temperature control, with open window detection
[no]
With distance control option
[no]
With adaptive start control
[no]
With working time limitation
[no]
With black bulb sensor
[no]
Contact details:
Remark:
For electric local space heaters, the measured seasonal space heating energy efficiency ηs cannot be worse than the declared
value at the nominal heat output of the unit.

8
Disposal
Environmental Protection
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
SERVICE WARRANTY
Cottage Stores LLP guarantees the product free from defects in materials and
workmanship for a period of twelve months after purchase. Proof of purchase will
be required. Should this unit be operated under conditions other than those
recommended, at voltages other than the voltage indicated on the unit, or any
attempts made to undertake unapproved servicing or make modifications to the
unit, then the warranty will be rendered void. The product you buy may sometimes
differ slightly from illustrations. This warranty is in addition to, and does not affect,
your statutory rights. If you have any problems with this product, please in the first
instance call the retailer from whom you purchased it.
Climate King
Cottage Stores LLP
7 Harris Drive
Rugby CV22 6DX
United Kingdom
