Climate King HCK-BX9 Manual

1
Climate
King®
User Manual and
Operating
Instructions
INDUSTRIAL
FAN HEATERS
READ INSTRUCTIONS CAREFULLY: Read and follow all
instructions. Keep these instructions in a safe place for future reference. Do
not allow anyone who has not read these instructions to assemble, adjust
or operate the heater.
This product is only suitable for well insulated spaces or occasional
use.
Model: HCK-BX9
1.1 This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children should not play with the appliance. Cleaning and user
maintenance should not be undertaken by children without supervision.
1.2 WARNING: In order to avoid overheating, do not cover the heater.
1.3 Children under 3 years old should be kept away from the appliance unless
continuously supervised.
1.4 Children aged from 3 years and less than 8 years should only switch the
appliance on/off provided that it has been placed or installed in its intended
normal operating position and they are supervised or given instruction concerning
use of the appliance in a safe way and understand the hazards involved. Children
aged from 3 years and less than 8 years should not plug in, adjust and clean the
appliance or perform user maintenance.
1.5 CAUTION-some parts of this product can become very hot and could cause
burns if touched. Particular care must be given where children and vulnerable
people are present.
2. Introduction
2.1 Depending on the power cord fitted there may be limits regarding where this
fan heater can be used. See section 5 for more information. The unit incorporates
a thermostat and a non-self resetting thermal cut-out to control the heating

2
elements. The thermostat detects the air temperature and controls the heat output
of the appliance.The non-self reset thermostat will switch off the heater to
prevent overheating. The fan motor is not controlled by the thermostat. When the
thermostat switches off the heating element the fan can keep running.
2.2 When using the heater for the first time, you may notice a slight emission of
smoke. This is quite normal and it stops after a short time. The heating element is
made of stainless steel and was coated with a protective oil during manufacturing.
The smoke is caused by the residual protective oil when the heater is switched on
for the first time.
Technical specifications
Model
HCK-BX9
Waterproof Class
IPX4
Voltage
400V 3-Phase
Required Power
9000W
Current
13.0A
Required Fuse
16A
Setting
52/4500/9000W
Self-resetting Thermostat
40°C
Product Dimensions (mm)
355x300x490
Net Weight (kg)
9.6
3.1 Housing made of heat-resistant powder coated steel plate.
3.2Supplied with industrial socket installed in the heater. A 3-Phase cable (not
included) of the correct rating fitted with a suitable connector is required to
connect the HCK-BX9 to the power supply.

3
3.3 Coupler/3-Phase cable requirements:
Figure 1
1. Five pin connector 380V/415V 50/60Hz (3P+N+E)
2. Power cord
3. Five pin plug 380V/415V 50/60Hz IPX4 (3P+N+E)
3.4.1 Any separately purchased coupler/cable should match with the appliance
and earthing pin layout. The coupler/cable should be approved for use in the
relevant country. The length of the power cord can be more than 1.8m but less
than 3m. If the power cord is too long and heavy, it could cause the cable to work
loose from the socket in the unit or cause a trip hazard.
3.4.2 When connecting the power cable to the appliance, open the protective lid
in the direction shown below
Figure2
3.5 After use shut down the appliance and remove the plug from the supply
before disconnecting the coupler end of the cable from the unit.
4. Description of Control Panel
HCK-BX9
4.1 Left Dial: Heat setting selector
4.2 Right Dial: Thermostat dial

4
5. Safety
5.1 Before use, please check the marking on the power cord. Depending on the
power cord type this appliance may be used in different ambient conditions
Type
You can use the appliance in
Do not use in
H07RN-F
household, warehouses and
workshops, building sites or
greenhouses
H05RN-F
household, warehouses and
workshops or greenhouses
building sites
H05RR-F
household, warehouses and
workshops
building sites or greenhouses
It is the responsibility of the owner and the operator to read, understand and
comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear
or damage. You must ensure that the risk of electric shock is minimised by the
installation of appropriate safety devices. Appropriate circuit protection should be
incorporated in the main distribution board and/or the individual circuit being used
to connect the appliance. If in doubt consult a qualified electrician before
connecting the appliance to the power supply.
You must also read and understand the following instructions concerning
electrical safety.
5.1.1. The Electricity at Work Act 1989 requires that all portable electrical
appliances, if used on business premises, are tested by a qualified electrician,
using a Portable Appliance Tester (PAT), at least once a year.
5.1.2. The Health & Safety at Work Act 1974 makes owners of electrical
appliances responsible for the safe condition of those appliances and the safety
of the appliance operators. If in any doubt about electrical safety, contact a
qualified electrician.
5.1.3. Ensure that the insulation on all cables and on the appliance is safe before
connecting it to the power supply. See 5.1.1. and 5.1.2. and use a Portable
Appliance Tester.
5.1.4. Ensure that cables are always protected against short circuit and overload.
5.1.5. Regularly inspect power supply cables and plugs for wear or damage and
check all connections to ensure that none are loose.
5.1.6. Important: Ensure that the voltage marked on the appliance matches the
power supply to be used.
5.1.7. DO NOT pull or carry the appliance by the power cable.
5.1.8. DO NOT pull the plug from the socket by the cable.

5
5.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately
have any faulty item repaired or replaced by a qualified electrician.
5.2 When using the electrical appliance basic precautions should always be
followed including:
5.2.1 The fan heater is not suitable for use outdoors in damp weather, in
bathrooms or in other wet or damp environments.
5.2.2 The fan heater can become very hot and should, therefore, be placed at a
safe distance from flammable objects such as furniture, curtains and similar.
5.2.3 Do not cover any part of the fan heater.
5.2.4 The fan heater must not be located immediately below a wall socket.
5.2.5 Do not connect the fan heater using an on/off timer or other equipment
which can automatically switch the device on.
5.2.6 The fan heater must not be placed in rooms where flammable liquids or
gases are used or stored.
5.2.7 If an extension cord is used, it must be as short as possible and always be
fully extended.
5.2.8 You must not connect other appliances to the same mains socket as the fan
heater.
5.2.9 Do not use this fan heater in the immediate surroundings of a bath, a
shower or a swimming pool or any environment where it may come into contact
with water.
5.2.10 If the supply cord is damaged, it must be replaced by the manufacturer,
local service agent or similarly qualified persons in order to avoid a hazard.
5.2.11 Keep children and animals away from the appliance.
5.2.12 Do not place the fan heater on moving vehicles or anywhere it can be
easily tipped over.
5.2.13 If the fan heater is not used for an extended period, unplug the appliance.
Never remove the plug by pulling on the cord.
5.2.14 Keep the heater away from anything that could block the air inlet.
5.2.15 In order to prevent possible electric shock or leakage current, never use
the fan heater with wet hands or operate the appliance when there is water on the
power cord.
5.2. Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities. Contact local government for information regarding
the available disposal options. Improper disposal of electrical waste in landfills or
dumps can result in the release of hazardous substances into the environment.
Always dispose of electrical waste through approved recycling facilities.
5.2.17 This fan heater is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
5.2.18 Do not allow children to play with the appliance

6
6. Operating Instructions
6.1 Position the fan heater so that it stands upright on a firm surface and at a safe
distance from wet environments, sources of water and other liquids, flammable
objects and flammable substances.
6.2 Connect the fan heater to a mains power supply of the correct rating.
6.3 Set the thermostat dial to the MAX setting to set the heater to operate on full
power.
6.4 The fan heater will switch on when the heat level selector dial is set to one of
the power settings. It will take up to 3 minutes for the heater to reach optimum
temperature.
6.5 Once the room reaches the required temperature, turn the thermostat dial
counter-clockwise until the thermostat clicks and the heating element switches off.
Leave the dial in this position to maintain the room temperature. Once the
temperature drops, the heating element will switch on again to maintain
temperature.
6.6 After use and before switching off the heater, turn the thermostat to the MIN
position and turn the fan heat selector switch to the fan position, let the appliance
cool down for two minutes then turn off the heater and remove the plug.
6.7 The HCK-BX9 has an additional thermostat to control the fan motor. If the
internal temperature of the heater is high and it is connected to the power supply
the thermostat can allow the fan to continue to operate independently of the heat
selector dial setting. For example, after operation, when the heater is turned off,
the fan motor may continue to operate to aid the internal cooling of the heater.
7. Cleaning and Maintenance
7.1 Before cleaning the appliance, disconnect it from the power supply and let it
cool down. To keep the outside of the heater case clean, wipe it regularly with a
soft sponge. Where the outside of the case is heavily soiled, wipe it with a sponge
dipped in <50°C water and mild detergent, then dry the heater enclosure with a
clean cloth. Be careful not to let the water enter the appliance or splash water
directly onto the heater. Never use solvent or abrasive cleaners to clean the
heater.
7.2 Clean the cord and plug, dry and pack it in a plastic bag.
7.3 When you store the heater, let it cool down first, keep it dry. Then cover it with
a plastic bag, put in a packing box and store it in a dry, ventilated place.
8. Troubleshooting:
You can solve many common problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before
making a warranty call.

7
Problem
Possible cause
Treatment
The heater does not
operate, even when
it is plugged in and
the heat level
selector switch and
thermostat are
switched on.
The plug is loose, bad
connection
Remove the plug, check the
connection of the plug and
socket. Then connect again.
No power in socket outlet
Move the plug to an
alternative socket with a
known good power supply
The heating
element is glowing
The input voltage is too
high or too low
Use a power supply
according to the rating on the
label
The air inlet grill is blocked
Check the air inlet and
remove any blockage. Keep
the heater away from articles
like curtains, plastic bags,
paper and other items which
can block the air inlet.
The appliance does
not heat up, or only
ventilator worked
The heat selector dial was
not set to a heating setting
Turn the dial to a heat setting
The thermostat operated
Set the thermostat to a higher
temperature and listen to hear
it operating. If there is no click
and the thermostat is not
damaged, the heater will
automatically switch on when
the appliance cools.
The self-resetting cut-out
operated
Turn the heater off and
inspect the blockage of the
inlet or outlet. Disconnect
the plug and wait at least 10
minutes for the protection
system to reset before
attempting to restart the
heater.
The Non-self resetting cut-
out operated
(only for devices fitted with
this function)
Disconnect the power, insert
a suitable size pin/clip/item in
the reset hole on the control
panel, press down on the
reset button.
Abnormal noise
The appliance is not
standing upright
Put the heater on a level
surface

8
Model identifier(s):HCK-BX9
Item
Symbol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local space heaters only
(select one)
Nominal heat
output
Pnom
9
kW
Manual heat charge control with integrated thermostat
[no]
Minimum heat
output (indicative)
Pmin
4.5
kW
Manual heat charge control with room and/or outdoor
temperature feedback
[no]
Maximum
continuous heat
output
Pmax
9
kW
Electronic heat charge control with room and/or
outdoor temperature feedback
[no]
Auxiliary electricity consumption
Fan assisted heat output
[no]
At nominal heat
output
elmax
N/A
kW
Type of heat output/room temperature control (select one)
At minimum heat
output
elmin
N/A
kW
Single stage heat output and no room temperature
control
[no]
In standby mode
elSB
N/A
W
Two or more manual stages, no room temperature
control
[no]
With mechanic thermostat room temperature control
[yes]
With electronic room temperature control
[no]
Electronic room temperature control plus day timer
[no]
Electronic room temperature control plus week timer
[no]
Other control options (multiple selections possible)
Room temperature control, with presence detection
[no]
Room temperature control, with open window detection
[no]
With distance control option
[no]
With adaptive start control
[no]
With working time limitation
[no]
With black bulb sensor
[no]
Contact details:
Remark:
For electric local space heaters, the measured seasonal space heating energy efficiency ηs cannot be worse than the declared
value at the nominal heat output of the unit.

9
Disposal
Environmental Protection
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
SERVICE WARRANTY
Cottage Stores LLP guarantees the product free from defects in materials and
workmanship for a period of twelve months after purchase. Proof of purchase will
be required. Should this unit be operated under conditions other than those rec-
ommended, at voltages other than the voltage indicated on the unit, or any at-
tempts made to undertake unapproved servicing or make modifications to the
unit, then the warranty will be rendered void. The product you buy may sometimes
differ slightly from illustrations. This warranty is in addition to, and does not affect,
your statutory rights. If you have any problems with this product, please in the
first instance call the retailer from whom you purchased it.
Climate King
Cottage Stores LLP
7 Harris Drive
Rugby CV22 6DX
United Kingdom
