Clippasafe Extendable Swing Shut Gate 130 Operator's manual

Extendable
Swing Shut Gate
WIDTH
HEIGHT
Adjustable from 73 to 96 cm
Top of gate to floor 76.5 cm
IMPORTANT - READ AND FOLLOW
THESE INSTRUCTIONS CAREFULLY
AND KEEP FOR FUTURE REFERENCE
This safety barrier conforms to EN 1930:2011 when fitted according to these instructions between
two clean, structurally sound surfaces.
This safety barrier is designed for children up to 24 months.
This safety barrier is for domestic use only.
Manual closure system.
Suitable for fixing across door openings and at the top and bottom of stairways.
Make sure that you use the correct type of fixings depending on the surface available:
Self-adhesive pads for appropriate surfaces or wood screws for wooden surfaces, multiple usage
dowels and concrete screws for concrete surfaces, multiple usage dowels and cement screws for
cement surfaces and metal screws for metal surfaces.
If the gate has been exposed to an accident, it must not be used again.
Do not allow older children to climb over this gate as this may pose a danger.
Only use original Clippasafe spare parts for this product.
Periodically check the security of the fixings and general condition of each part. Adjust as necessary
referring to these instructions.
WARNING: Read these instructions before installation as incorrect installation can be dangerous.
WARNING: Incorrect fitting or positioning of this safety barrier can be dangerous.
WARNING: Do not use the safety barrier if any components are damaged or missing.
WARNING: The safety barrier must not be fitted across windows.
WARNING: Stop using the barrier if the child is capable of climbing over it.
SPINDLES x 4
WALL CUPS x4
NUTS x 4SPANNER x1
Each 7cm extension
comprises of a vertical bar
and a top and bottom fixing
SELF-ADHESIVE
WALL CUP
PADS x4
GATE7cm
EXTENSIONS
x2
SPRING
WASHER x 4
SPINDLE
CASINGS x4

Pre-Installation
Advice
WARNING - INCORRECT FITTING OR POSITIONING
OF THIS SAFETY BARRIER CAN BE DANGEROUS
If this gate needs to be fitted to a round shaped
newel post, ‘Y’ shaped spindles are available
separately which replace the standard spidles
and wall cups supplied with this gate
Fixing surfaces must be suitable for the
purpose and structurally sound.
LOW PRESSURE MOUNTING WITH
SCREW MOUNTED WALL CUPS
ON BOTH SIDES
LOW PRESSURE MOUNTING WITH
ADHESIVE MOUNTED WALL CUPS
ON BOTH SIDES
EXTENSIONS REQUIRED
GAP
82 - 89cm
89 - 96cm
96 - 100cm
100 - 107cm
107 - 114cm
114 - 118cm
118 - 125cm
125 - 132cm
7cm
1
2
1
1
18cm
1
1
2
1
7+18cm
1
1
2
The surfaces to which the gate fits should
be completely flat and a minimum of
5cm wide.
This product may require the purchase of
appropriate fixing aids suitable for the
surface to which the wall cups are to be
fitted.
WARNING - NEVER USE WITHOUT WALL CUPS.
Without extensions, this gate is suitable for openings between 73cm (28¾in) and 82cm
(32¼in) wide. If gap is wider, see extension guide below. If necessary, fit the extension(s) first,
then follow the installation instructions (Section D).
Two 7cm extensions are included, 18cm extensions are available separately.
WARNING -
GATE MUST BE FITTED
UPRIGHT AS SHOWN
IN ORDER FOR THE
SWING CLOSE
MECHANISM TO
FUNCTION
CORRECTLY.
WARNING - WHEN FITTING ON A
STAIRWAY ALWAYS BLOCK ONE
OPENING DIRECTION SO THAT THE
GATE WILL ONLY OPEN AWAY FROM
THE STAIRS (see installation instructions).

Installation
1.
3.
4.
2.
The distances shown above are for screw fixing only. If using adhesive pads, ensure that the
wall is clean, dry and free from any grease and align the wall cups to the spindles in the gate.
min 12mm
max 60mm
xx
90° 90°
x
x
x4
4
4
37mm
747mm
2x2x or 4x
not
supplied
2x2x or 4x
not
supplied

5.
6.
To close the gate, swing the gate door shut from the open position or close it manually
by holding the handle and closing the gate door until it locks into position.
Always check that the gate is closed and locked before leaving unattended.

7. To block the opening direction of the gate.

Fitting a 7cm Extension
3.
7. If a second 7cm extension is required repeat on the other side of the gate.
5. 6.
1. 2.
4.

Fitting an 18cm Extension - available separately
7. If a second 18cm extension is required repeat on the other side of the gate.
1. 2.
3. 4.
5. 1 6.

1.
Fitting a 7cm & 18cm Extension
Model No.130 - Metal Gate
Model No.132 - Wood Gate
©Clippasafe Ltd 2013 - 130+132/Apr2013
2. 3.
4. 5. 6. 7.
8. 9. 10.
