Cloud CS-S Series User manual

CS-C Series Installation Guide v2.4
CS-C Series
In-Ceiling Loudspeakers
Installation Guide
CS-C8
CS-C6
CS-C5
CS-C3
CS-C4
8” IN-CEILING LOUDSPEAKER
6.5” IN-CEILING LOUDSPEAKER
5” IN-CEILING LOUDSPEAKER
3” IN-CEILING LOUDSPEAKER
4” IN-CEILING LOUDSPEAKER
CS-CSUB8
8” IN-CEILING SUBWOOFER

CS-C Series Installation Guide v2.42
CAUTION - Installation
Speaker must be installed by qualied speaker technician.
CAUTION - Servicing
The unit contains no user-serviceable parts. Refer servicing to qualied personnel.
Do not perform servicing unless you are qualied to do so.
CAUTION - Tap Switch
Before use check and set tap switch under grille to proper setting for your system.
EXPLODED VIEW
Cover plate
Euro Block
Back can
Bae
Dog ear mount
Ceiling Tile Bracket
(ships separate)
Grille*
Grille leash
Grille Leash
Screw
Clamp Screw (x4)
Tap Switch
Safety Restraint Tab (x2)
(Restraint not included)
*See note on page 4 regarding alternative grille styles.
TAP SETTINGS
Ta p CS-CSUB8 CS-C8 CS-C6 CS-C5 CS-C4* CS-C3
100V 70V 25V 100V 70V 25V 100V 70V 25V 100V 70V 25V 100V 70V 25V 100V 70V 25V
1 4 ohm 16 ohm 16 ohm 16 ohm 16 ohm 16 ohm
2X100W 13W X 64W 8W X 32W 4W X 20W 2.5W X 20 W 2.5 W X 16W 2W
3100W 50W 7W 64W 32W 4W 32W 16W 2W 20W 10W 1.3W 20 W 10 W 1.3 W 16W 8W 1W
450W 25W 3W 32W 16W 2W 16W 8W 1W 10W 5W 0.6W 10 W 5 W 0.7 W 8W 4W 0.5W
525W 13W 1.5W 16W 8W 1W 8W 4W 0.5W 5W 2.5W 0.3W 5 W 2.5 W 0.4 W 4W 2W 0.3W
613W 6W 0.8W 8W 4W 0.5W 4W 2W 0.3W 2.5W 1.3W 0.2W 2.5 W 1.3 W 0.2 W 2W 1W 0.2W
* CS-C4 tap settings only apply to Model CS-C4V. Note Model CS-C4H is low-impedance only (16 ohms).

CS-C Series Installation Guide v2.4 3
INSTALLATION
Step 1
Remove speaker from box.
Step 2
Mark and cut hole in ceiling or ceiling tile.
Use included hole template.
CS-C3: 140 mm (5.50")
CS-C4: 177 mm (6.88")
All other models:
271 mm (10.67")
Step 3
Locate euroblock in accessory bag and connect signal wire.
For daisy-chaining use “LINK” output to run to next speaker.
Step 4
Remove grille and set tap switch to proper setting and attach
grille leash to bafe by placing the large end of the clip over
the snap t post (1) then sliding the clip until small end snaps
into place. Tap switch is preset to highest 100 V position.
1
2
Step 5 (Ceiling Tile Only)
Place tile bridge on back of ceiling tile. Align holes and insert
speaker in hole. Tighten dog ears. Do not overtighten.
(Tile bridge not available for C4.)
Step 6
Insert euroblock into rear of back can. Attach safety restraint
to rear of back can. Close and secure cover plate.

CS-C Series Installation Guide v2.44
Step 6.1 (CS-C3 and CS-C4 only)
Insert euroblock into rear of back can. Attach safety restraint
to side of back can. Close and secure cover plate. Note that
on model CS-C4H only, there is an additional rubber seal with
a pre-cut “X” to allow cable access.
Step 7 (Drywall)
Insert speaker into ceiling opening and tighten dog ear clamps,
do not over tighten.
Step 7.1 (Ceiling Tile Only)
Insert euroblock into rear of back can. Attach safety restraint
to rear of back can. Close and secure cover plate, reattach
grille to speaker. Insert speaker, tile and tile bridge into ceiling.
Step 8
Check tap setting and replace grille.
Step 9
Remove logo tab if desired.
NOTE: ALTERNATIVE GRILLES
All CS-C models are supplied with a circular grille as shown
in the above diagrams.
Optional square grilles are available for all models
except CS-C4:
CS-8SQGRILLW (white) and CS-8SQGRILLB (black)
are compatible with Models CS-C5, CS-C6, CS-C8 and
CS-C8SUB
CS-C3SQGRILLW (white) and CS-C3SQGRILLB (black)
are compatible with Models CS-3C
Optional hexagonal grilles are available for CS-3C only:
CS-C3HEXGRILLW (white) and CS-C3HEXGRILLB (black)
All alternative grilles feature the same system of magnetic
attachment to the speaker as the standard circular grilles,
and therefore there is no difference in installation procedure.
