Cloud CS-S SERIES User manual

CS-S Series Installation Guide V1.1
CS-S Series
Surface Mount Loudspeakers
Installation Guide
CS-S4
CS-S6
4” SURFACE MOUNT LOUDSPEAKER
6.5” SURFACE MOUNT LOUDSPEAKER

CS-S Series Installation Guide V1.12
CAUTION - Installation
Speaker must be installed by qualied speaker technician.
CAUTION - Servicing
Do not perform servicing unless you are qualied to do so. The unit contains no user-serviceable parts. Refer
servicing to qualied personnel.
CAUTION - Tap Switch
Before use check and set tap switch under grille to proper setting for your system.
EXPLODED VIEW
Euro block
Port plug
Baffle
Snap fit Grille
Bracket
Bracket screws
TAP SETTINGS
Ta p CS-S6 CS-S4
100 V 70 V 25 V 100 V 70 V 25 V
1 16 ohm 16 ohm
2X 32W 4W X 20W 2.5W
332W 16W 2W 20W 10W 1.3W
416W 8W 1W 10W 5W 0.6W
58W 4W 0.5W 5W 2.5W 0.3W
64W 2W 0.3W 2.5W 1.3W 0.2W

CS-S Series Installation Guide V1.1 3
INSTALLATION
Step 1
Remove speaker from box.
Step 2
Mount bracket to wall.
Step 3
Locate euroblock in accessory bag and connect signal wire.
For daisy-chaining use “LINK” output to run to next speaker.
Step 4
Remove grille and set tap switch to proper setting.
Tap switch is preset to highest 100 V position.
Step 5
For increased weather resistance in outdoor applications,
press port plug into port on the bafe.
Port plug
Step 6
Insert euroblock into rear of speaker.

CS-S Series Installation Guide V1.14
Step 7
Slide speaker into bracket and tighten bracket screws.
Step 8
Aim speaker and tighten bracket screws.
www.cloud.co.uk www.cloudusa.pro
