CS-C Series Installation Guide V2.1
CS-C Series
In-Ceiling Loudspeakers
Installation Guide
CS-C8
CS-C6
CS-C5
CS-C3
8” IN-CEILING LOUDSPEAKER
6.5” IN-CEILING LOUDSPEAKER
5” IN-CEILING LOUDSPEAKER
3” IN-CEILING LOUDSPEAKER
CS-CSUB8
8” IN-CEILING SUBWOOFER
CS-C Series Installation Guide V2.12
CAUTION - Installation
Speaker must be installed by qualied speaker technician.
CAUTION - Servicing
The unit contains no user-serviceable parts. Refer servicing to qualied personnel.
Do not perform servicing unless you are qualied to do so.
CAUTION - Tap Switch
Before use check and set tap switch under grille to proper setting for your system.
EXPLODED VIEW
Cover plate
Euro Block
Back can
Baffle
Dog ear mount
Ceiling Tile Bracket
Fits all models
(ships separate)
Grille
Grille leash
Grille Leash
Screw
Clamp Screw (x4)
Tap Switch
Safety Restraint Tab (x2)
(Restraint not included)
TAP SETTINGS
Ta p CS-CSUB8 CS-C8 CS-C6 CS-C5 CS-C3
100 V 70 V 25 V 100 V 70 V 25 V 100 V 70 V 25 V 100 V 70 V 25 V 100 V 70 V 25 V
1 4 ohm 16 ohm 16 ohm 16 ohm 16 ohm
2X 100W 13W X 64W 8W X 32W 4W X 20W 2.5W X 16W 2W
3100W 50W 7W 64W 32W 4W 32W 16W 2W 20W 10W 1.3W 16W 8W 1W
450W 25W 3W 32W 16W 2W 16W 8W 1W 10W 5W 0.6W 8W 4W 0.5W
525W 13W 1.5W 16W 8W 1W 8W 4W 0.5W 5W 2.5W 0.3W 4W 2W 0.3W
613W 6W 0.8W 8W 4W 0.5W 4W 2W 0.3W 2.5W 1.3W 0.2W 2W 1W 0.2W
CS-C Series Installation Guide V2.1 3
INSTALLATION
Step 1
Remove speaker from box.
Step 2
Mark and cut hole in ceiling or ceiling tile.
Use included hole template.
271mm (10.67”)
CS-C3 = 140mm (5.50”)
Step 3
Locate euroblock in accessory bag and connect signal wire.
For daisy-chaining use “LINK” output to run to next speaker.
Step 4
Remove grille and set tap switch to proper setting and attach
grille leash to bafe. Tap switch is preset to highest 100 V
position.
Step 5 (Ceiling Tile Only)
Place tile bridge on back of ceiling tile. Align holes and insert
speaker in hole. Tighten dog ears. Do not overtighten.
Step 6
Insert euroblock into rear of back can. Attach safety restraint
to rear of back can. Close and secure cover plate.
CS-C Series Installation Guide V2.14
Step 6.1 (CS-C3 only)
Insert euroblock into rear of back can. Attach safety restraint
to side of back can. Close and secure cover plate.
Step 7 (Drywall)
Insert speaker into ceiling opening and tighten dog ear clamps,
do not over tighten.
Step 7.1 (Ceiling Tile Only)
Insert euroblock into rear of back can. Attach safety restraint
to rear of back can. Close and secure cover plate, reattach
grille to speaker. Insert speaker, tile and tile bridge into ceiling.
Step 8
Check tap setting and replace grille.
Step 9
Remove logo tab if desired.
