Cmp 25506-33 00 series User manual

20"UNBLOCKABLE RING DRAIN

25506-33X-00

All Custom Molded Products main drains are listed and tested in strict accordance to the requirements of

ANSI/APSP - 16 2011, the current standard of reference for the Virginia Graeme Baker Act, and compliant

to the latest Consumer Product Safety Commission (CPSC) requirements.

UL Listed VGB Suction: Compliant to ANSI/APSP-16 2011 & CPSC Requirements

Covered by one or more U.S. patents or pending patent applications. See www.c-m-p.com/patents for details.

TABLE OF CONTENTS

Please read through the entire manual before installing your new unit. Your pool drain tting must be installed and operated as

specied.

A. Safety Instructions & Precautions ......................................................................................... 3

B. Sizing & Specication Reference .......................................................................................... 4

C. Installation & Maintenance Procedures .............................................................................. 5

1. Required for Installation...................................................................................... 5

2. Installation Location ............................................................................................ 5

3. Installation Procedure ......................................................................................... 5

4. Maintenance Procedure..................................................................................... 6

G. Parts List........................................................................................................................................ 8

IMAGES & TABLES IN THESE INSTRUCTIONS

page 4 FLOW RATES

page 4 SPECIFICATIONS

page 4 HEAD LOSS CHART

page 6 INSTALLATION LOCATION

page 6 ALTERNATE PLUMBING

page 7 DIMENSIONS

WARNING When using two or more suction ttings on a common suction line, suctions must be separated by

a minimum of 3 ft or they must be located on two dierent planes (i.e., one on oor and one on the

wall).

WARNING WARNING: DO NOT locate suction outlets on seating areas or on backrests for such seating areas.

NOTICE Attention Installer: This manual contains important information about the installation, operation

and safe use of this product. Before installing this product, read and follow all warning notices and

instructions which are included. This information should be given to the owner and/or operator of

this equipment.

WARNING To reduce the risk of drowning from hair and body entrapment, install suction ttings with a marked

ow rate in gallons per minute that exceeds the ow rate of your system by at least 25%. Always

use multiple suction outlets. If the tting/cover breaks, is damaged, or is missing, shut the system

down immediately. Do not use the system until damaged parts have been replaced.

WARNING Keep hair and clothing a minimum of 12 inches from all suction ttings and drains at all times.

Persons with long hair should secure hair to a minimal length or wear swimming cap. Children

should never be left unattended at any time in a swimming pool, spa, or bathtub. Be sure the

temperature of the water never exceeds the manufacturer’s recommendations.

NOTICE To reduce the risk of injury, installation and service should be done by a qualied Pool Service

Professional, certied electrician or authorized CMP representative.

NOTICE NOTE: In the event that one suction outlet is completely blocked, the remaining suction outlet(s)

serving that system MUST have a ow rating capable of the full ow of the pump(s) for the specic

suction system.

NOTICE Increasing size of the pump may increase ow rate of suction beyond rated safety limits causing

entrapment or death.

CAUTION Hair or body parts blocking the spa or pool suctions may become trapped and held against the

suction tting. Entrapment against the suction ttings can result in drowning or other severe injury.

Never sit on or lean up against suction ttings. Never exceed the maximum allowable ow rate

stated on the suction tting. The suction tting and fasteners should be inspected for damage or

tampering before use. Missing, broken, or cracked suction ttings shall be replaced. Loose suction

ttings shall be reattached or replaced before use of this facility.

SAVE THESE INSTRUCTIONS

A. SAFETY INSTRUCTIONS & PRECAUTIONS

IMPORTANT SAFETY INSTRUCTIONS.

READ AND FOLLOW ALL INSTRUCTIONS

ALWAYS PLUMB AND INSTALL ALL SUCTION FITTINGS ACCORDING TO ALL

BUILDING CODES THAT APPLY IN YOUR AREA.

B. SIZING & SPECIFICATION REFERENCE

TABLE 1: FLOW RATES

MAX FLOW RATE:

2.5" or 2” PLUMBING TWO PORTS: 245.6GPM

ONE PORT: 216GPM (second plugged or used as hydrostatic valve)

FLOW RATE @1.5FPS 216GPM

TABLE 2: SPECIFICATIONS

PIPE SIZE 2.5"SPIGOT / 2"SOCKET

DO NOT adapt suction tting to any pipe size smaller than ASTM 2”

SCH 40 PVC.

OPEN AREA 46.27in2

DRAIN COVER LIFE 7 Years. Replace drain cover and screws every seven years.

UNBLOCKABLE Single or multiple drain use

• Single or multiple drain use

• PVC Sump Body. Use PVC glue to attach plumbing ttings

HEAD LOSS (PA X10�)

FLOW (GPM)

50 100 150 200 250

PRESSURE (HG)

CHART 1: HEAD LOSS CHART

1. REQUIRED FOR INSTALLATION

Your 20” Unblockable Ring Drain includes the following:

• Drain Sump Body

• Drain Suction Cover

• Protective Plaster Installation Cover

• Cover Screws

• 2” NPT Plugs (2)

• Optional/Not Included: Hydrostatic Relief Valve

2. INSTALLATION LOCATION

a. This suction tting is designed for installation on the oor of hot tubs or pools.

b. Do not mount directly under seats.

SAFETY CHECKLIST:

c. Suction tting and fasteners should be observed for damage or tampering before each use.

d. Missing, broken, or cracked suction ttings shall be replaced before use. Loose suction ttings shall be reattached or

replaced before use.

3. INSTALLATION PROCEDURE

PLUMBING:

a. Install sump in the pool/spa oor. Install in the center of the pool/spa OR the deepest point.

b. It is only neccesary to run one main suction line per drain unit

c. There are maximum two ports available:

• OPTION ONE: Plumb with two ports. Connect both ports to one main suction line. Plumbing to ports must be

balanced.

• OPTION TWO: Plumb with one port and plug the second unused port.

• OPTION THREE: Plumb with one port and use the second port as a hydrostatic valve port.

d. Maximum ow rates will vary depending on plumbing option chosen. See Table 1 for details.

FINISHING:

e. IMPORTANT! Leave the protective cover in place until plaster installation is complete.

f. Finish pool with gunite/shotcrete and plaster so that it is completely level with the sump body and cover. Ensure the nish

is completely level. Pool nish should not exceed the top of the sump.

g. Remove the protective cover.

h. Attach cover/grate with the supplied screws.

C. INSTALLATION & MAINTENANCE

Gunite/

Shotcrete

Earth/

Substrate

Plaster/Pool Finish Gunite & Plaster Filled Through Drain Center

IMAGE 1 -INSTALLATION LOCATION

Hydrostatic

Valve

Optional Collection Tube

Threaded Plug

IMAGE 2 -ALTERNATE PLUMBING

2. MAINTENANCE PROCEDURE

a. The cover/grate and screws should be replaced at least every seven (7) years.

b. Inspect pool or spa regularly to ensure that the drain cover/grate is in place and secure.

c. If the cover is found to be broken, cracked, missing, loose or missing screws it must be replaced. Do not use the pool/

facility until a repair or replacement is made.

d. If a drain cover/grate does not pass inspection:

• Close the pool or spa immediately

• Post a closure notice

• Keep the facility closed until a new drain cover and screws are properly installed.

C. INSTALLATION & MAINTENANCE

D. PART DIAGRAMS AND MEASUREMENTS

3-3/16"

2.0"

5-1/2"

17-3/4"

21-3/8"

17-1/2"

1 - 7/ 8 "

IMAGE 3 -DIMENSIONS

G. PARTS LIST

CMP P/N DESCRIPTION

1 25506-330-000 WHITE 20” RING DRAIN COVER

2 25506-330-800 WHITE 20” RING DRAIN BODY

3 25520-050-020 2” PLUGS

–– 25506-334-020 OPTIONAL HYDROSTATIC VALVE

–– –– COVER SCREWS (8)

Parts numbers not listed in product table are only available as part of a complete assembly. See c-m-p.com or pool products catalog for other color options
