CO/Tech PLYL-02-7.2V User manual

Important!
Read the entire instruction manual carefully
and make sure that you fully understand
it before you use the equipment. Keep the
manual for future reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre deg om
at du forstår dem, før du tar produktet i bruk.
Ta vare på anvisningene for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin alat
käyttää laitetta. Säilytä ohjeet myöhempää
tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung durchlesen und
aufbewahren.
ENGLISHSVENSKANORSKSUOMIDEUTSCH
Multitrimmer med skaft
Multitrimmeri
Multitrimmer mit Stiel
Art.no Model
18-4633 PLYL-02-7.2V-UK
31-8253 PLYL-02-7.2V
Upright
Multitrimmer
Ver. 20141126
Original instructions
Bruksanvisning i original
Original bruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung

2

3
ENGLISH
Upright Multitrimmer
Art.no 18-4633 Model PLYL-02-7.2V-UK
31-8253 PLYL-02-7.2V
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. If you have any questions concerning
technical problems please contact our Customer Services.
Contents
Safety ....................................................................................4
General safety instructions for power tools............................................... 4
Specific safety instructions for electric grass shears................................. 6
Specific safety instructions for hedge trimmers..........................................7
General safety instructions for batteries and chargers...............................7
Key to the safety symbols on the multitrimmer ......................................... 8
Buttons and functions............................................................9
Charging the battery............................................................ 10
Assembly ............................................................................. 10
Changing the cutter .................................................................................. 11
Operating instructions......................................................... 12
Pre-start inspection routine......................................................................12
Switching on and off.................................................................................12
Using the extension handle ......................................................................12
Care and maintenance ......................................................... 13
Cutting/trimming......................................................................................13
Troubleshooting guide......................................................... 13
Disposal............................................................................... 14
Specifications ...................................................................... 14
Multitrimmer.............................................................................................14
Battery 7.2 V Li-ion ...................................................................................14
Battery charger.........................................................................................14

4
ENGLISH
Safety
General safety instructions for power tools
Warning: Read all theinstructions. Failure to comply with thefollowing instructions
can lead to electric shocks, fires or serious injury.
SAVE THESE INSTRUCTIONS.
Theterm “power tool” in thefollowing text refers to your handheld mains operated or
battery operated tool.
1) Work area
a) Keep thework area clean and well illuminated. Cluttered and poorly lit areas
invite accidents.
b) Do not use power tools in explosive environments, e.g. near to flammable
liquids, gases or dust. Power tools generate sparks that can easily ignite dust
and fumes.
c) Keep children and bystanders away from thearea where you are using
thepower tool. Distractions can cause you to lose concentration and control of
thetool.
2) Electrical safety
a) Theplug of thepower tool must fit correctly into thewall socket. Never modify
theplug in any way. Never use anadaptor plug together with earthed power tools.
There is less risk of receiving anelectric shock if plugs and sockets which have not
been modified are used.
b) Avoid physical contact with earthed objects such as pipes, radiators, ovens
and refrigerators. There is anincreased risk of receiving anelectric shock if your
body is earthed.
c) Do not expose thepower tool to rain or other wet conditions. Water entering
apower tool will increase therisk of electric shock.
d) Do not abuse themains lead. Never use thelead to carry or drag thepower
tool or to jerk theplug from awall socket. Keep thelead away from heat, oil,
sharp edges and moving parts. Damaged or tangled leads increase therisk of
electric shock.
e) When using power tools outdoors, use anextension lead that is suitable for
this purpose. Theuse of anextension lead designed for outdoor use decreases
therisk of electric shocks.
f) If theuse of thepower tool in awet environment is unavoidable, awall socket
equipped with aportable residual current device (RCD) should be used.
Use of anRCD significantly reduces therisk of electric shock.

5
ENGLISH
3) Personal safety
a) Pay attention to what you are doing and use common sense when using
power tools. Never use power tools if you are tired or under theinfluence of
drugs, alcohol or medication. One moment of inattention while using apower
tool may result in serious injury.
b) Wear protective clothing. Always wear safety glasses. Using protective
clothing such as dust masks, non-slip safety shoes, helmets and ear defenders
reduces therisk of injury.
c) Avoid accidental starts. Make sure that thepower switch is set to OFF before
plugging thepower tool into awall socket, fitting thebattery or picking up/
carrying thepower tool. Never carry apower tool with your finger on thetrigger
and never connect thepower tool to awall socket when theswitch is set to ON,
since it may result in injury.
d) Remove all service tools/keys before switching on thepower tool.
Aservice tool left on arotating part of thepower tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of thepower tool in unexpected situations.
f) Wear suitable clothing. Do not wear loose-fitting clothing or jewellery.
Keep hair, clothes and gloves away from moving parts. Loose-fitting clothes,
jewellery or long hair could become caught in moving parts.
g) If equipment for theextraction and collection of dust is available, make sure
it is connected and used properly. Theuse of such equipment can significantly
reduce dust-related hazards.
4) Use and maintenance of the power tool
a) Do not force thepower tool. Use thecorrect power tool for your application.
Thecorrect power tool will do thejob better and safer if used at therate for which
it was designed.
b) Never use thepower tool if thepower switch does not switch thetool on and off.
Any power tool that cannot be controlled by thepower switch is dangerous and
must be repaired.
c) Unplug thelead from thewall socket before making any adjustments,
changing accessories or storing thepower tool. These precautions reduce
therisk of thepower tool starting unexpectedly.
d) Store power tools that are not being used out of children’s reach. Do not
allow people who are unfamiliar with thetool or its functions to operate it.
Power tools can be dangerous if they fall into thehands of inexperienced users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
broken parts or anything else which might affect theoperation of thepower
tool. If something is damaged, have thepower tool repaired before use.
Many accidents are caused by poorly maintained power tools.

6
ENGLISH
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use thepower tool and any accessories in accordance with these instructions,
taking into account theworking conditions and thework to be performed.
Using thepower tool for apurpose other than that for which it is intended could
result in adangerous situation.
5) The use and maintenance of cordless power tools
a) Charge thebattery using acharger recommended by themanufacturer.
b) Thetool is supplied with abattery provided by themanufacturer. Do not use
any other battery.
c) If handled incorrectly, battery fluid can leak from thebattery. If this fluid
should come into contact with skin; rinse thearea thoroughly with water.
Always contact adoctor if this fluid comes into contact with your eyes.
6) Service
a) Repairs and service should only be performed by qualified tradesmen, and
only with original spare parts. This guarantees that thesafety of thepower tool
is maintained.
Specific safety instructions for electric grass shears
• Thegrass shears must not be used by children and by persons with reduced
physical, sensory or mental capability or lack of experience and knowledge which
could jeopardise their safety. This product should not be used by anyone that has
not read theinstruction manual unless they have been instructed in its use by
someone who will take responsibility for their safety.
• Read through themanual and familiarise yourself with thecontrols for thecorrect
operation of thegrass shears.
• Never let children or adults use thegrass shears without first having read
theinstruction manual.
• Never use thegrass shears very close to anyone, especially children or animals.
• Make sure that you know how to switch thegrass shears off.
• Familiarise yourself with your surroundings and be prepared for any dangers
should they arise.
• Always inspect thegrass shears before use. Thecutter should be repaired if it has
struck aforeign object and there are signs of wear or damage.
• Only use thegrass shears when there is sufficient daylight or artificial light for
good vision.
• Keep hands and feet away out of thecutting zone.
• Make sure to always stand in asafe position when using thegrass shears.
• Thegrass shears must not be left unattended where children can access them,
they have abuilt-in battery which enables them to be switched on if both buttons
are pressed in.

7
ENGLISH
• Thegrass shears have abuilt-in battery, think carefully about how to hold
theshears safely when cleaning them, inspecting them or removing clogged
material from theblades.
• Switch thegrass shears off immediately if thecutter has come into contact with
aforeign object or if theshears begin to vibrate abnormally.
• Consider thedamage theblades could do to your hands and feet if they were to
come into contact.
• Always ensure that theventilation openings are kept clear from debris.
Specific safety instructions for hedge trimmers
• Thehedge trimmer must not be used by children or by persons with reduced
physical, sensory or mental capability or lack of experience and knowledge which
could jeopardise their safety.
• Keep all parts of your body away from thecutting blades. Do not remove cut
material or hold material to be cut when theblades are moving.
• One moment of carelessness can result in serious personal injury.
• Never allow children to play with theproduct.
• Turn off thehedge trimmer and carry it by thehandle when moving it short
distances. Always have theblade guard in place when storing or transporting
thehedge trimmer. Correct use of thehedge trimmer will reduce thelikelihood of
personal injury caused by thecutting blades.
• Make sure that there are no foreign objects like fencing wire, etc. in thehedge/
bush that you wish to trim.
• Theblades will continue to move for afew seconds after thepower has been
turned off.
• Note: Do not touch thecutting blades while they are moving.
• Always switch off thehedge trimmer and have theblade guard mounted in place
whenever moving or transporting it.
General safety instructions for batteries and chargers
a) Prevent unintentional starting of themultitrimmer by handling it carefully. Make sure
that thesafety lock button and thepower switch are not both pressed in whilst
carrying it.
b) Only use theincluded battery charger or acharger recommended by
themanufacturer. Thebattery charger is only designed to charge certain types of
batteries. If acharger designed for another type of battery is used therisk for fire or
explosion is significantly increased.
c) Battery fluid can leak from thebattery if it is damaged. Avoid physical contact
with this fluid. If this fluid comes into contact with skin; rinse thearea thoroughly
withwater. If thefluid contacts eyes, seek medical attention immediately.
Fluidwhich has leaked from abattery pack can cause skin irritation or burns.

8
ENGLISH
• Never store abattery in direct sunlight or at temperatures above 40°C.
• Only charge thebattery when theambient temperature is between 10°C and 40°C.
• Never expose thebattery or its charger to water.
• Keep thecharger and batteries out of thereach of children.
• Never use thebattery charger or batteries in environments where flammable liquids
or gases are stored.
• Always transport batteries in asafe manner ensuring that they do not come into
contact with each other and never in ametal container.
• Check that thebattery charger and mains lead are whole and undamaged before use.
• Charge thebattery completely if it is not to be used for anextended period.
• Thebattery must only be charged with acharger that conforms to
EN60335-2-29 standards.
Key to the safety symbols on the multitrimmer
Read theentire instruction manual before using themultitrimmer.
Wear aface mask in dusty environments.
Always wear ear protection.
Always wear eye protection.
Themultitrimmer must not be exposed to rain or wet conditions.
Warning: Thecutting blades will continue to move for ashort while after
themotor has been switched off.

9
ENGLISH
1
2
3
4
5
7
8
11
12
9
10
16 17
18
13
14 15
6
Buttons and functions
1. Grass shears (cutting blades)
2. Hedge trimmer (cutting blades)
3. Blade release button
4. Battery charge status LED
5. Safety lock
6. Power switch
7. Charger socket
8. Extension handle control cable socket
9. Cam ring for thecutting blade drive
cam (10)
10. Cutting blade drive cam
11. Extension handle power switch
connection cable
12. Extension handle length adjustment
locking ring
13. Handle
14. Extension handle power switch
15. Safety lock
16. Charger (9V 1000 mA,
centre-positive connector)
17. Grass shear blade guard
18. Hedge trimmer blade guard

10
ENGLISH
Charging the battery
• Plug theDC connector of themains charger into the9 V charger socket (7).
• Make sure that themains voltage is thesame as that stated on therating plate of
thecharger.
• Plug themains charger (16) into awall socket. Thered LED (4) will light as long as
charging is in progress and go out when thebattery is fully charged.
• Thecharging time is 3–5 hours for adischarged battery. It is normal for thebattery
to get hot while it is being charged.
• If thecharging is unsuccessful, check that thewall socket is live.
• Theservice life of thebattery can be prolonged by ensuring that it is always
charged in time. It needs to be charged as soon as theperformance of
themachine drops.
• Make sure that thebattery never becomes fully discharged. This can shorten
theservice life of thebattery.
• Temperature range for charging and storing thebattery: 0–40ºC.
Note:
• Thelithium-ion battery has abuilt-in electronic deep discharge protection which
prevents partial power from being delivered. Full power is provided at all times
until theelectronic protection engages, turning off thetrimmer and signifying that
thebattery needs to be recharged. Thetool will then switch off automatically.
Do not attempt to continue work after this point as doing so may damage
thebattery. Abattery recharge is now required before any work is resumed.
• Thebattery also has abuilt-in electronic overload protection. If thetool is put under
too much pressure, theelectronics automatically cut thepower and thetool stops.
Release thetrigger and wait afew seconds before switching thetrimmer on again.
• Thelithium-ion battery has no memory which means that it can be charged at any
time regardless of its battery charge level.
• Charge thebattery for at least 6 hours thefirst and second time it is charged.
• For long-term storage thebattery should be fully charged at least every 6 months.
Assembly
Themultitrimmer comes with adetachable extension handle and two
interchangeable cutters: Hedge trimmer and grass shears.
