Cobra CB6 User manual

Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Service Manual
Gas Barbeque
Model CB6

Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
This manual is designed to take a more in depth look at the Cobra Series CB6 Gas Barbeque for the
purpose of making the units more understandable to service people.
There are settings explained in this manual that should never require to be adjusted, but for completeness
and those special cases where these settings are required to change, this manual gives a full explanation
as to how, and what effects will result.
MAKING ALTERATIONS MAY VOID WARRANTIES AND APPROVALS.
IMPORTANT:
WARNING:
ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED OUT BY QUALIFIED PERSONS ONLY.
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE,
INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE
INSTALLING OR SERVICING THIS APPLIANCE.

Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque

Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Contents List
Section Page Number
1. Specifications ............................................................................................ 1
2. Installation ................................................................................................ 3
3. Operation ................................................................................................... 7
3.1 Description of Controls
3.2 Explanation of Control System
4. Maintenance .............................................................................................. 9
Cobra Gas Barbeque Maintenance Schedule
5. Fault Finding ............................................................................................ 10
5.1 Fault Finding Table
5.2 Fault Diagnosis
6. Service Procedures .................................................................................. 12
6.1 Access
6.2 Replacement
6.3 Adjustment / Calibration
7. Accessories .............................................................................................. 18
Gas Conversion Kits
8. Exploded Parts Diagrams ........................................................................ 19
8.1 CB6 Gas Barbeque
9. Service Contacts ...................................................................................... 21
Appendix A: Gas Type Conversion ................................................................. 23
Appendix B: Equipment Design Changes ....................................................... 28
Contents

1
1
Specifications
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Model Number Covered in this Specification
CB6 600 mm Wide 2 Burner Gas Barbeque.
Gas Supply (Non-UK Units)
CB6 132 kg
Unit Weights (Net)
Gas Supply (UK Units)
Injector Sizes
Natural Gas LP Gas / Butane
Input Rating 66.0 MJ/hr 66.0 MJ/hr
(N.H.G.C.) (62,500 Btu/hr) (62,500 Btu/hr)
Supply Pressure 1.13 - 3.40 kPa 2.75 - 4.50 kPa
(4.5” - 13.5” w.c.) (11” - 18” w.c.)
0.95 kPa (*) 2.60 kPa (*)
(3.8” w.c.) (10.0” w.c.)
Gas Connection ½" BSP Male
Burner Operating
Pressure
Town Gas
66.0 MJ/hr
(62,500 Btu/hr)
0.75 - 1.50 kPa
(3" - 6" w.c.)
0.63 kPa (*)
(2.5" w.c.)
Nat Gas
(G20)
Propane
(G31)
Heat Input (nett) Nominal 18.0 kW 18.0 kW
Reduced 6.0 kW 6.4 kW
Gas Rate (nett) Nominal 1.90 m3/hr 1.40 kg/hr
Reduced 0.63 m3/hr 0.50 kg/hr
Supply Pressure 20 mbar 37 mbar
Burner Operating Pressure 10 mbar (*) 26 mbar (*)
Gas Connection ½" BSP Male
Natural Gas (G20) Butane
Main Burners 2.70mm 1.55mm
Pilot Burners 0.45mm 0.30mm
Town Gas
4.50mm
0.75mm
Propane (G31)
1.65mm
0.30mm

2
1
Specifications
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
External Dimensions
CB6 Barbeque 600mm

3
2
Installation
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Installation Requirements
NOTE:
 It is most important that this appliance is installed correctly and that operation is
correct before use. Installation shall comply with local, gas, health and safety
requirements.
 This appliance shall be installed with sufficient ventilation to prevent the occurrence
of unacceptable concentrations of health harmful substances in the room, the
appliance is installed in.
Cobra Series Barbeque are designed to provide years of satisfactory service, and correct installation is
essential to achieve the best performance, efficiency and trouble-free operation.
This appliance must be installed in accordance with National installation codes and in addition, in
accordance with relevant National / Local codes covering gas and fire safety.
Australia: - AS5601 - Gas Installations.
New Zealand: - NZS5261 - Gas Installation.
United Kingdom: - Gas Safety (Installation & Use) Regulations 1998.
- BS6173 - Installation of Catering Appliances.
- BS5440 - 1 & 2 Installation Flueing & Ventilation.
Ireland: - IS 820 - Non - Domestic Gas Installations.
Installations must be carried out by authorised persons only. Failure to install equipment to
the relevant codes and manufacturer’s specifications shown in this section will void the
warranty.
Components having adjustments protected (e.g. paint sealed) by manufacturer are only
allowed to be adjusted by an authorised service agent. They are not to be adjusted by the
installation person.
Unpacking
 Remove all packaging and transit protection from the appliance including all protective plastic
coating from the door outer panel and exterior stainless steel panels.
 Check equipment and parts for damage. Report any damage immediately to the carrier and
distributor.
 Check that the following parts have been supplied with the barbeque:
1 x Gas Regulator.
1 x Gas Type Conversion Kit.
 Report any deficiencies to the distributor who supplied the barbeque.
 Check that the available gas supply is correct to that shown on the rating plate attached inside the
lower cabinet, on the right hand side panel, in the top right hand corner.
Location
1. Installation must allow for a sufficient flow of fresh air for the combustion air supply.
2. This appliance must be installed in a suitably ventilated room to prevent dangerous build up of
combustion products.
Combustion Air Requirements
Natural Gas 18 m³/hr minimum.
LPG / Butane 18 m³/hr minimum.
Town Gas 18 m³/hr minimum.
3. Position the appliance in its approximate working position.
4. All air for burner combustion is supplied from underneath the appliance. The legs must always be
fitted and no obstructions placed on the underside or around the base of the appliance, as
obstructions will cause incorrect operation and / or failure of the appliance.

4
2
Installation
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
5. Components having adjustments protected (e.g. paint sealed) by manufacturer are only to be
adjusted by an qualified service agent. They are not to be adjusted by the installation person.
NOTE: Do not obstruct or block the appliances flue. Never directly connect a ventilation
system to the appliance flue outlet.
Clearances
NOTE: Only non-combustible materials can be used in close proximity to this appliance.
Any gas burning appliance requires adequate clearance and ventilation for optimum and trouble-free
operation. The following minimum installation clearances are to be adhered to:
Assembly
This model is delivered completely assembled. Ensure that the legs, rear rollers are securely attached.
NOTE: This appliance is fitted with adjustable feet / rear rollers to enable the appliance to be
positioned securely and level. This should be carried out on completion of the gas
connection. Refer to the ‘Gas Connection’ section.
Gas Connection
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN AUTHORISED PERSON.
1. Cobra Barbeques do not require an electrical connection, as they function on the gas supply only.
2. It is essential that the gas supply is correct for the barbeque to be installed and that adequate supply
pressure and volume is available. The following checks should therefore be made before installation:
a. The Gas Type the appliance has been supplied for is shown on coloured stickers located above the
gas entry point and next to the rating plate. Check that these are correct for the gas supply the
appliance is being installed for. The gas conversion procedure is detailed in the ‘Gas Conversion and
Specification’ section of this manual.
b. The Supply Pressure required for this appliance is shown in the 'Specifications' Section of this
manual. Check the gas supply to ensure that adequate supply pressure exists.
c. The Input Rate of this appliance is shown on the Rating Plate and in the 'Specifications' section of
this manual. The input rate should be checked against the available supply line capacity. Particular
note should be taken if the Barbeque is being added to an existing installation.
NOTE: It is important that adequately sized piping runs directly to the connection joint on the
appliance with as few tees and elbows as possible to give maximum supply volume.
3. Fit the gas regulator supplied, into the gas supply line as close to the appliance as possible.
The regulator connections are ¾" BSP female.
The connection is ¾" BSP male.
(Refer to the ‘Specifications’ section for the gas supply location dimensions).
NOTE: The gas pressure regulator provided with this appliance is convertible between Natural Gas
and LPG and is already converted ex-factory to the gas type labelled beside the gas
connection point. The regulator outlet pressure is fixed ex-factory and it is NOT to be
adjusted.
Combustible Surface Non Combustible Surface
Left / Right hand side 200mm 0mm
Rear 100mm 0mm

5
2
Installation
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
4. A suitable joining compound which resists the breakdown action of LPG must be used on every gas line
connection, unless compression fittings are used.
NOTE: A manual isolation valve must be fitted to the individual appliance supply line.
5. Correctly locate the appliance into its final operating position and using a spirit level, adjust the legs so
that the unit is level and at the correct height.
6. Connect the gas supply to the appliance.
7. Check gas operating pressure is as shown in 'Specifications' section.
8. Check all gas connections for leakages using soapy water or other gas detecting equipment.
NOTE: The operating pressure to be measured at the
manifold test point and with two burners operating
at the ‘High Flame’ setting.
9. Turn off the mains gas supply and bleed the gas out of the
appliance gas lines.
10. Turn ‘ON' the gas supply and the appliance.
11. Verify the operating pressure remains correct.
WARNING:
CHECK CONNECTIONS FOR LEAKS WITH SOAPY WATER. DO NOT USE A NAKED FLAME.
Manifold
Test Point
Figure 2.

6
2
Installation
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Commissioning
1. Before leaving the new installation;
a. Check the following functions in accordance with the operating instructions specified in the 'Operation'
section of the User Handbook supplied with the appliance.
 Light the Pilot Burner.
 Light the Main Burner.
 Check the Low Fire Burner Operation.
 Check the High Fire Burner Operation.
b. Ensure that the operator has been instructed in the areas of correct lighting, operation, and shutdown
procedure for the appliance.
2. The User Manual must be kept by the owner for future reference and a record of
Date of Purchase ,
Date of Installation and Serial Number of Unit recorded and kept with the manual. (These details
can be found on the rating plate attached to the underside of the R/H side, front hob lower
trim. (Refer to the 'Gas Connection' section).
NOTE: If for some reason it is not possible to get the appliance to operate correctly, contact the
supplier of this appliance.

7
3
Operation
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Safety System
The purpose of the safety system is to shut off the
flow of gas if the pilot flame goes out. It is
comprised of the flame itself, the thermocouple,
and the flame failure gas valve.
The pilot flame is lit by holding in the gas control
knob, which in turn temporarily pushes the plunger
inside the safety valve open and allows gas to flow
through. Once the burner is lit, the thermocouple
will begin to generate millivolts (after about 10 to
30 seconds of being heated) and will energize the
electromagnet inside the gas valve. Once
energized the electromagnet holds the plunger
inside the gas valve in the open position. The
plunger has to have been pushed all the way in for
the electromagnet to be able to hold it in place. If
the burner flame goes out for some reason, the
NOTE: A full user’s operation manual is supplied with the product and can be used for further
referencing of Installation, Operation and Servicing.
Gas Control Knobs
OFF Position
PILOT Burner
HIGH Flame
LOW Flame
Piezo Igniter (with
burner flame viewing
ports).
3.1 Description of Controls
Figure 3.1.
3.2 Explanation of Control
System
thermocouple will cool after about 10 to 30
seconds and stop generating millivolts. The
electromagnet will then de-energize, and the
plunger will snap shut, cutting off the flow of gas.
Detail of each component in the safety system is
explained below.
Thermocouple
The thermocouple is a device that generates
electricity when heat is applied to the tip.
The tip of the thermocouple is located in the pilot
burner flame, and the nut at the other end of the
thermocouple screws into the back of the gas
valve. Inside the copper tubing is a wire which is
joined at the tip but insulated from the rest of the
tubing. These two parts (the copper tubing and
wire) make up the "wiring" for an electrical circuit.
When these two dissimilar metals, wire and tip, are
heated an electrical voltage is produced. This type
of thermocouple generates between 7 and 30
millivolts when heated in the pilot flame.
Figure 3.2a.
Internal
Insulator Nut Conductor Tip

8
3
Operation
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Electromagnetic Flame Failure Gas Valve
The purpose of the safety valve is to shut off the
flow of gas if the pilot flame goes out.
Inside the body of the gas valve is an
electromagnet connected to a spring loaded
plunger. When the electromagnet is energized, it
holds the plunger in, allowing gas to flow through
the valve. When the electromagnet is
de-energized, the plunger snaps to the closed
position, stopping the flow of gas.
Millivolts are provided to the electromagnet by
the thermocouple (not shown) which generates
millivolts when heated. The thermocouple screws
into a fitting at the back of the gas valve to make
an electric connection. By pressing in the gas
control knob, the plunger can be temporarily held
open while lighting.
There are two reasons for this; firstly, gas has to
flow through the safety valve to make it possible
to light the pilot burner, and secondly the plunger
has to be pushed all the way in for the
electromagnet to hold it in. i.e. the
electromagnet is strong enough to hold the
plunger in once there, but is not strong enough
to pull it in by itself.
Sometimes a problem with the flame not staying
lit after releasing the button can be attributed to
not pushing the plunger all the way in.
Figure 3.2b.
Thermocouple
Gas flow
Electromagnet
Plunger
Shaft
Knob
Gas flow Plunger

9
4
Maintenance
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
COBRA GAS BARBEQUE - MAINTENANCE SCHEDULE
Business Name and Address:
Date: Service Report No:
Phone: Fax:
Serial No:
Clients Order No: Serviceman:
Model: Remarks
1 Inspect exterior condition of the unit.
2 Check working gas pressure is correct to figures shown on rating plate. Pressure _____ kPa.
3 Check pilot flames / correct size.
4 Check that all burner ports light. Clear any blockages, if any.
5 Check burner aeration shutters are adjusted to achieve correct flame.
6a Inspect the thermocouples.
6b Replace the thermocouples (every 12 months).
7 Check injectors are clean and free from blockages.
8 Re-grease gas cocks.
9 Check for tightness of gas connections.
10 Check for gas leaks.
11 Check the piezo ignition of both pilots functions correctly.
Service Comments:
Additional work / repairs required:
Customers approval:
Name (print): Title:
Customers signature: Date:
Suggestion: Photocopy this form and keep on file for continued use.
NOTE: A full user’s operation manual is supplied with the product and can be used for further
referencing of Installation, Operation and Servicing.

10
5
Fault Finding
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Fault Possible Cause Remedy
Pilot won’t light. Gas pressure incorrect.
Pilot injector blocked / incorrect
size.
Piezo ignitor faulty.
(Refer Fault Diagnosis 5.2.1).
Check gas pressure and adjust if
necessary.
Check injectors and replace if
necessary.
Replace piezo ignitor.
(Refer Section 6.2.7).
Pilot drops out when knob
released.
Releasing knob before
thermocouple is heated.
Faulty thermocouple.
(Refer Fault Diagnosis 5.2.2).
Pilot injector blocked / incorrect
size.
Gas valve magnet faulty.
(Refer Fault Diagnosis 5.2.2).
Hold control in for longer, see if
pilot will stay alight.
Replace thermocouple.
(Refer Section 6.2.1).
Check injectors and replace if
necessary.
Replace gas valve magnet.
(Refer Section 6.2.10).
Pilot goes out when main burners
come on.
Incorrect gas pressure.
Faulty thermocouple.
(Refer Fault Diagnosis 5.2.2).
Faulty gas control valve.
Check supply / adjust pressure.
Replace the thermocouple.
(Refer Section 6.2.1).
Replace the gas control valve.
(Refer Section 6.2.9).
Main burners will not light. Wrong size or blocked injectors.
Faulty gas control valve.
Incorrect supply pressure.
Replace / clean injectors.
(Refer Section 6.2.6).
Replace the gas control valve.
(Refer Section 6.2.9).
Check supply correct pressure.
Burner goes out while in use. Incorrect or fluctuating gas
pressure.
Small pilot flame—pilot injector
blocked or incorrect size.
Main injector blocked / incorrect
size.
Check gas pressure and adjust if
necessary.
Check pilot injectors and replace if
necessary.
(Refer Section 6.2.2).
Check main injectors and replace if
necessary.
(Refer Section 6.2.6).
Burner flame incorrect colour
(yellow).
Burner aeration incorrectly set. Adjust the burner aeration.
Gas control valve stiff to operate. Gas control valve requires re-
greasing.
Re-grease the gas control valve.
(Refer Section 6.3.1).
5.1 Fault Finding Table
C AUTION :
All installation and service repair work must be carried out by qualified
persons only.

11
5
Fault Finding
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
5.2 Fault Diagnosis
5.2.2 Pilot Drops Out when Gas
Knob Released
Pilot Flame Too Small
If pilot can be lit but the flame is too small to
impinge on the thermocouple, then check the gas
pressure. If pressure is correct, remove the pilot
injector from pilot burner and check for blockages
and / or correct size.
5.2.1 Pilot will not Light
Short in High Tension Lead
If repeated sparking of the piezo shows
intermittent sparking at the electrode, then the
lead should be traced to find area of short. This
can normally be visually seen as the spark arcs.
If the lead is shorting the best solution is to
replace it, as the electrical insulation strength of
the lead may have deteriorated.
If the spark arc can be seen at the electrode
insulator at the pilot burner instead of at the
electrode tip, then the insulator probably has a
fracture and should be replaced.
Piezo Ignitor Faulty
If no spark at all can be generated, remove piezo
ignitor and hold close to cabinet body, depress
piezo ignitor and if a spark cannot be generated
to cabinet body the piezo ignitor is faulty and
should be replaced.
NOTE:
If piezo ignition fails, the pilots can be
manually lit in the interim until the piezo
circuit is repaired. A standard taper torch
or matches / lighter can be used for manual
back-up ignition.
Thermocouple Faulty
Check thermocouple connection to gas control is
firm (loose connections will cause resistance in
millivolt circuit and result in pilot outage).
If connection is OK, then disconnect the
thermocouple from the gas control valve, light
the pilot, and whilst holding the control knob in,
measure voltage between the thermocouple and
earth (e.g. the body of the gas control valve).
This should read approximately 30mV. If this
reading is less than 10mV then the thermocouple
is faulty - replace.
Gas Valve Electromagnet Faulty
If thermocouple millivoltage is above 10mV and
the pilot still will not hold then the gas magnet is
faulty - replace.

6
Service Procedures
12
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Section Page Number
6.1 Access ...................................................................................................... 13
6.1.1 Control Panel............................................................................................................ 13
6.2 Replacement............................................................................................ 13
6.2.1 Thermocouple .......................................................................................................... 13
6.2.2 Pilot Injector............................................................................................................. 14
6.2.3 Spark Electrode ........................................................................................................ 14
6.2.4 Pilot Burner .............................................................................................................. 14
6.2.5 Main Burners ............................................................................................................ 15
6.2.6 Main Burner Injectors................................................................................................ 15
6.2.7 Piezo Ignitor............................................................................................................. 15
6.2.8 H.T Lead .................................................................................................................. 15
6.2.9 Gas Control Valve ..................................................................................................... 16
6.2.10 Gas Control Magnet................................................................................................... 16
6.3 Adjustment / Calibration ........................................................................ 17
6.3.1 Gas Control Valve Re-Greasing................................................................................... 17
6.3.2 Low Fire Rate Adjustment.......................................................................................... 17
WARNING:
 ENSURE THAT THE GAS SUPPLY IS SWITCHED 'OFF' BEFORE COMMENCING SERVICING.
 ALWAYS CHECK / TEST FOR GAS LEAKS ON COMPLETION OF SERVICING REPAIRS ON THE GAS SYSTEM.
C AUTION :
All installation and service repair work must be carried out by qualified
persons only.

6
Service Procedures
13
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Figure 6.2.1a
6.2 Replacement
6.2.1 Thermocouple
Figure 6.1.1
6.1.1 Control Panel
6.1 Access
1) Remove control knobs by pulling firmly away
from control panel.
2) Remove 2 cap screws securing control panel
to barbecue.
3) Panel can now be removed from unit.
4) H.T. leads may be required to be
disconnected if control panel is to be removed
away from the BBQ.
1) Remove the control panel (refer 6.1.1).
2) Undo the thermocouple from the pilot
assembly.
3) Undo the thermocouple from the gas control
valve. The thermocouple can now be
removed.
4) Replace and re-assemble in reverse order.
Figure 6.2.1b
Thermocouple
Connection
Thermocouple
Screws

6
Service Procedures
14
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Figure 6.2.4a
6.2.4 Pilot Burner
6.2.2 Pilot Injector
1) Remove the control panel (refer 6.1.1).
2) Remove pilot supply tube from pilot burner.
3) Remove injector and clean or replace as
required.
NOTE: Ensure that correct size injector is
re-fitted to the unit (refer to
the Specifications section).
Figure 6.2.2
1) Remove the control panel (refer 6.1.1).
2) Remove thermocouple, piezo, and pilot supply
tube and injector from the pilot burner.
3) Remove the two screws securing the pilot
burner to the barbecue.
Figure 6.2.4b
Thermocouple
Gas Pilot Line
H.T Piezo Lead
Two Screws
Pilot Injector
6.2.3 Spark Electrode
1) Remove the control panel (refer 6.1.1).
2) Remove HT lead from spark electrode.
3) Remove spark electrode from pilot burner.
4) Replace and reassemble in reverse order.
NOTE: Inspect spark electrode to make
sure that ceramic is not cracked or
damaged before installing.
Spark Electrode
Figure 6.2.3
4) Replace the pilot burner and re-assemble in
reverse order.

6
Service Procedures
15
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
Figure 6.2.6
6.2.6 Main Burner Injectors
1) Remove the control panel (refer 6.1.1).
2) Remove burner (refer 6.2.5).
3) Unscrew the burner injector.
4) Clean or replace as required.
NOTE: Ensure that the correct size injector
is re-fitted to the unit (refer to the
‘Specifications’ section).
Figure 6.2.5
6.2.7 Piezo Ignitor6.2.5 Main Burner
1) Remove the control panel (refer 6.1.1).
2) Remove the HT lead from the piezo ignitor by
pulling firmly away.
3) Unscrew the nut securing the piezo ignitor to
the control panel.
Figure 6.2.7
4) Replace and re-assemble in reverse order.
1) Remove the top grate and radiant castings
relevant to the burner to be removed.
2) Slide the burner out from its supports.
3) Replace and re-assemble in reverse order.
Main Burner
6.2.8 H.T Lead
1) Remove the control panel (refer 6.1.1) and
remove the HT lead from the piezo ignitor.
2) Remove the HT lead from the piezo electrode,
replace and re-assemble in reverse order.
Figure 6.2.8
Piezo Ignitor
Piezo Ignitor, HT Lead
and Piezo Electrode
Main Injector

6
Service Procedures
16
Revision 2
© Moffat Ltd, August 2012
Cobra Series Gas Barbeque
6.2.9 Gas Control Valve
1) Remove the control panel (refer 6.1.1).
2) Undo the pilot supply, main supply and
disconnect the thermocouple from gas control
valve.
3) Undo the compression nut securing gas
control to the manifold assembly.
4) Remove the gas control valve.
5) On suitable work surface, remove rear nut
from gas control.
6) Extract the gas control magnet.
7) Replace and re-assemble in reverse order.
Figure 6.2.9
Magnet Rear Nut
6.2.10 Gas Control Magnet
1) Remove the control panel (refer 6.1.1).
2) Undo the pilot supply, main supply and
disconnect the pilot thermocouple from the
gas control valve.
3) Undo the compression nut securing the gas
control valve to the manifold assembly.
4) Replace gas control and re-assemble in
reverse order.
NOTE: Ensure that the correct size injector
is re-fitted to gas control (refer to
the ‘Specifications’ section).
5) Adjust low fire setting (refer 6.3.2).
Figure 6.2.10
Gas Control Valve
Manifold Gas
Connection
Main Burner
Gas Supply
Thermocouple
Connection
Pilot Supply
