Cobra CS9 User manual

230628-7
For use in GB & IE
Gas Salamander
Model CS9
INSTALLATION AND OPERATION MANUAL

The reproduction or copying of any part of this manual by any means whatsoever is strictly forbidden unless authorized
previously in writing by the manufacturer.
In line with policy to continually develop and improve its products, Moffat Ltd. reserves the right to change the
specifications and design without prior notice.
© Copyright Moffat Ltd. August 2011.
MANUFACTURED BY
Moffat Limited
Christchurch
New Zealand
INTERNATIONAL CONTACTS
AUSTRALIA
Moffat Pty Limited
Web: www.moffat.com.au
E.Mail: [e-mail]
Main Office: (tel) [phone]
(fax) [phone]
Service: (tel): 1800 622 216
Spares: (tel): 1800 337 963
Customer Service: (tel): 1800 335 315
(fax): 1800 350 281
CANADA
Serve Canada
Web: www.servecanada.com
E.Mail: [e-mail]
Sales: (tel): 800 551 8795 (Toll Free)
Service: (tel): 800 263 1455 (Toll Free)
NEW ZEALAND
Moffat Limited
Web: www.moffat.co.nz
E.Mail: [email protected].nz
Main Office: (tel): 0800 663328
UNITED KINGDOM
Blue Seal
Web: www.blue-seal.co.uk
E.Mail: [e-mail]
Sales: (tel): [phone]
(fax): [phone]
Spares: (tel): [phone]
(fax): [phone]
Service: (tel): [phone]
(fax): [phone]
UNITED STATES
Moffat
Web: www.moffat.com
Sales: (tel): 800 551 8795 (Toll Free)
(tel): [phone]
(fax): [phone]
Service: (tel): 800 858 4477 (Toll Free)
(tel): [phone]
(fax): [phone]
REST OF WORLD
Moffat Limited
Web: www.moffat.co.nz
E.Mail: [email protected]

1
Contents
CS9 Gas Salamander
Part 1 Introduction ..................................................................................... 2
Part 2 Specifications .................................................................................. 3
Part 3 Installation ........................................................................................ 4
Part 4 Operation ......................................................................................... 7
Part 5 Cleaning and Maintenance........................................................... 9
Part 6 Gas Conversion ............................................................................. 11
Part 7 Replacement Parts List .................................................................. 14

We are confident that you will be delighted with your Cobra Series Salamander, and it will become a most
valued appliance in your commercial kitchen.
To ensure you receive the utmost benefit from your new Cobra Appliance, there are two important things
you can do.
Firstly:
Please read this instruction book carefully and follow the directions given. The time taken will be well
spent.
Secondly:
If you are unsure of any aspect of the installation, instructions or performance of your appliance, contact
your Cobra Series dealer promptly. In many cases a phone call could answer your questions.
CE Only:
These instructions are only valid if the country code appears on the appliance. If the code does not
appear on the appliance, refer to the supplier of this appliance to obtain the technical instructions for
adapting the appliance to the conditions for use in that country.
WARNING:
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS
APPLIANCE.
WARNING:
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE USER SMELLS GAS, ARE TO BE POSTED IN APROMINENT LOCATION. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING THE LOCAL GAS SUPPLIER.
WARNING:
GREAT CARE MUST BE TAKEN BY THE OPERATOR TO USE THE EQUIPMENT SAFELY TO GUARD IT AGAINST RISK OF FIRE.
 THE APPLIANCE MUST NOT BE LEFT ON UNATTENDED.
 ITIS RECOMMENDED THAT AREGULAR INSPECTION IS MADE BY ACOMPETENT SERVICEMAN TO ENSURE CORRECT AND SAFE
OPERATION OF YOUR APPLIANCE IS MAINTAINED.
 DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPOURS OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER
APPLIANCE.
 DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
C AUTION :
This appliance is;
 For professional use and is to be used by qualified persons only.
 Only qualified service persons are to carry out installation, servicing and gas
conversion operations.
 Components having adjustments protected (e.g. paint sealed) by the manufacturer
should not be adjusted by the user / operator.
2
Part 1 Introduction

3
Gas Supply Requirements
- Non - UK Only:
- UK Only:
NOTE: (*)
The burner operating pressure is to be measured at
the manifold test point with both burners operating
at full setting. The operating pressure is ex-factory
set and not to be adjusted, apart from when
converting between gases, if required. Refer to the
‘Gas Conversion Instruction Sheet’ for this appliance
for further details.
Gas Connection
Gas supply connection point is located at the back,
130 mm from right hand side of the appliance, and
entered from beneath the appliance.
Connection is ½ BSP male.
Part 2 Specifications
Model Covered in this Specification -
CS9 Gas Salamander.
General
A commercial heavy duty, wall mounted gas fired
infra-red grilling Salamander for a wide range of
foods. Cobra Salamanders feature independently
controlled heat zones for left and right side of the
cooking area.
Two high speed infrared surface combustion burners
in the ceiling of the cavity are independently
operated with the left and right hand side controls.
Each main burner is provided with flame failure
feature for ease of operation and safety. The main
burners are manually lit with each burner having LO
to HI settings to provide full cooking flexibility.
Rack supports have 4 fixed height positions offering
flat and angled rack positioning.
Cobra Salamanders come standard with a crumb /
drip tray for collection of cooking grease and
crumbs from the cooking operations. The tray is
easily removed (slide out) for cleaning and to
provide easy cleaning access to the rear and sides
of the cooking area.
A Branding Plate is available as an optional
accessory item and provides a deep grooved /
ribbed cooking surface which can be used with this
racking system. Refer to the Replacement Parts List.
The Branding Plates can be fitted onto the standard
wire rack allowing ease of change as required
between menus.
Dimensions
CS9 Gas Salamander.
Natural (G20) Propane (G31)
Heat Input (nett) 8.8 kW 8.8 kW
Gas Rate 0.84 m3/hr 0.63 kg/hr
Supply Pressure 20 mbar 37 mbar
Burner Operating
Pressure 10 mbar 26 mbar
Gas Connection 1/2” BSP Male
Natural Gas LP Gas
(Propane)
Input Rating 31.5 MJ/hr 31.5 MJ/hr
(N.H.G.C.) (29.850 Btu/hr) (29.850 Btu/hr)
Supply Pressure 1.13 - 3.4 kPa 2.75 - 4.5 kPa
(4.5” - 13.5” w.c.) (11” - 18” w.c.)
Burner Operating
Pressure
1.0 kPa (*) 2.55 kPa (*)
(4.0” w.c.) (10.0” w.c.)
Gas Connection ½" BSP Male

4
Location
1. Installation must allow for a sufficient flow of
fresh air for the combustion air supply.
Combustion Air Requirements
Natural Gas 9 m³/hr minimum.
LPG / Propane 9 m³/hr minimum.
2. Installation must include adequate ventilation
means, to prevent dangerous build up of
combustion products.
3. This appliance must be mounted onto a non-
combustible wall or tailored stand, using the rear
wall bracket and spacing screws provided.
4. Combustible walls must not protrude past the
front of the appliance.
5. This appliance must not be mounted on a
combustible surface or metal surface, as
radiated heat will cause these surfaces to
become extremely hot.
6. Caution should be taken as intense heat is
emitted at the bottom front of the appliance.
7. Components having adjustments protected
(e.g. paint sealed) by manufacturer are only to
be adjusted by an qualified service agent. They
are not to be adjusted by the installation person.
8. The unit should be mounted under an extraction
hood in compliance with all local regulations.
In the event that the unit is not mounted under an
extraction hood, the installer must ensure that all
regulations are met and that there is an
unobstructed minimum distance of 750 mm from the
top surface of the unit to the ceiling, which must be
of non-combustible material.
NOTE:
Do not obstruct or block the appliances flue. Never
directly connect a ventilation system to the
appliance flue outlet.
Part 3 Installation
Installation Requirements
NOTE: It is most important that this salamander is
installed correctly and that operation is correct
before use. Installation shall comply with local gas
and health and safety requirements.
Waldorf Salamanders are designed to provide years
of satisfactory service, and correct installation is
essential to achieve the best performance,
efficiency and trouble-free operation.
This appliance must be installed in accordance with
National installation codes and in addition, in
accordance with relevant National / Local codes
covering gas and fire safety.
Australia:
AS 5601 - Gas Installations.
New Zealand:
NZS 5261 - Gas Installation.
United Kingdom:
Gas Safety (Installation and Use) Regulations
1998.
BS6173 - Installation of Catering Appliances.
BS5440 - 1 & 2 Installation Flueing & Ventilation.
Ireland:
IS 820 - Non Domestic Gas Installations.
Installations must be carried out by qualified service
persons only. Failure to install equipment to the
relevant codes and manufacturer’s specifications
shown in this section will void the warranty.
Components having adjustments protected (e.g.
paint sealed) by the manufacturer, are only to be
adjusted by an qualified service agent. They are
not to be adjusted by the installation person.
Unpacking
 Remove all packaging and transit protection
from the appliance including all protective
plastic coating from the exterior stainless steel
panels.
 Check equipment and parts for damage.
Report any damage immediately to the carrier
and distributor.
 Report any deficiencies to the distributor who
supplied the appliance.
 Check that the available gas supply is correct to
that shown on the rating plate located on the
front lower corner of the right hand side panel.
 Check that the following parts have been
supplied with the appliance:-
1 x Salamander Rack.
1 x Trough Tray.
1 x Gas Regulator.
1 x Gas Conversion Kit.
1 x Wall Mounting Bracket, including;
- 2 x 25 mm Black Plastic Spacers.
- 2 x 3/8” Bolts / Nuts.

5
5. Lower the Salamander onto the mounting
bracket.
6. Tighten the black spacers
securely and adjust the
levelling screws / bolts to
ensure that the unit is level.
Gas Connection
NOTE:
ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A
QUALIFIED SERVICE PERSON.
1. Cobra salamanders do not require an electrical
connection, as they function totally on the gas
supply only.
2. It is essential that the gas supply is correct for the
salamander to be installed and that adequate
supply pressure and volume are available. The
following checks should therefore be made
before installation:-
a. Gas Type the appliance has been supplied
for, is shown on a coloured stickers located
above the gas connection and next to the
rating plate. Check that this is correct for the
gas supply the appliance is being installed
for. The gas conversion procedure is detailed
in this manual.
b. Supply Pressure required for this appliance is
shown in the ‘Specifications’ section of this
manual. Check the gas supply to ensure
adequate supply pressure exists.
c. Input Rate of this appliance is stated on the
Rating Plate fitted on the R/H side panel and
in the 'Specifications' section of this manual.
The input rate should be checked against
the available supply line capacity. Particular
note should be taken if the salamander is
being added to an existing installation.
NOTE:
It is important that adequately sized piping runs
directly to the connection joint on the appliance
with as few tees and elbows as possible to give
maximum supply volume.
Part 3 Installation
Clearances
NOTE:
Only non-combustible materials can be used in
close proximity to this appliance.
* We recommend allowing a clearance of 100 mm
on either side of the appliance to allow access
to the side panels for servicing purposes.
** Using the wall mounting accessories provided
with this appliance.
*** Top clearances can be reduced where local fire
protection system is provided, if allowed by the
local regulations.
Wall Mounting (To Non-
Combustible Wall Only)
1. Fix the wall mounting bracket to the wall with six
screws, in such a position that the top of the
bracket is level and at least 945 mm (38”) above
any surface beneath the unit. This will ensure
that the bottom of the Salamander is at least
600 mm (24”) above any surface.
2. Fit the two black plastic spacers to the top rear
corners of the unit. Leave them unscrewed by
approximately 5 mm.
3. Fit the two adjusting screws / bolts into the
nutserts at the bottom rear corners of the unit.
These should protrude approximately 30 mm
from the rear of the Salamander.
4. Lift the Salamander onto the wall bracket, lining
up the black plastic spacers on the salamander
with the mounting notches in the bracket.
Combustible
Surface
Non Combustible
Surface
LH / RH Side 100 mm 25 mm (*)
Rear 50 mm 30 mm
Top Clearance to:
- Extraction Hood 200 mm
- Grease Arresting Filter (**) 400 mm
- Ceiling (***) 750 mm
~ 5 mm
~30 mm


6
Commissioning
The following commissioning checks must be
carried out before the appliance is handed over for
use, to ensure that the unit operates correctly and
the operator(s) understand the correct operating
procedure.
1. Before leaving the new installation;
a. Check the following functions in accordance
with the operating instructions specified in
the ‘Operation’ section of this manual.
 Light the Main Burners.
 Check the Low Fire burner operation.
 Check the High Fire burner operation.
 Check the Racking System operation.
b. Ensure that the operator has been instructed
in the areas of correct lighting, operation,
and shutdown procedure for the appliance.
2. This manual must be kept by the owner for future
reference, and a record of Date of Purchase,
Date of Installation and Serial Number of Unit
recorded and kept with this manual. (These
details can be found on the Rating Plate
attached to the R/H side panel (refer to the ‘Gas
Connection’ section).
NOTE:
If for some reason it is not possible to get the unit to
operate correctly, shut off the gas supply and
contact the supplier of this unit.
Part 3 Installation
3. Fit the gas regulator supplied, into the gas supply
line as close to the appliance as possible.
NOTE:
The gas pressure regulator provided with this
appliance is convertible between Natural Gas and
LPG as per the ‘Gas Conversion Section’ in this
manual.
Ensure the regulator is converted to the correct gas
type that the appliance will operate on.
The regulator outlet pressure is fixed ex-factory for
the gas type that the regulator is converted to and it
is NOT to be adjusted.
The regulator connections are 1/2" BSP female.
The connection to the appliance is 1/2" BSP male.
(Refer to the the ‘Specifications’ section for the
gas supply location dimensions).
NOTE:
A Manual Isolation Valve must be fitted to the
individual appliance supply line.
4. Correctly locate the appliance into its final
operating position and using a spirit level, adjust
the legs so that the unit is level and at the
correct height.
5. Connect the gas supply to the appliance. A
suitable jointing compound which resists the
breakdown action of LPG must be used on
every gas line connection, unless compression
fittings are used.
6. Check all gas connections for leakages using
soapy water or other gas detecting equipment.
7. Check that the gas operating pressure is as
shown in ‘Specifications’ section.
NOTE:
The burner operating pressure is to be measured at
the manifold test point with both burners operating
at full setting. The operating pressure is ex-factory
set and not to be adjusted, apart from when
converting between gases, if required. Refer to the
‘Gas Conversion' instructions for this appliance for
further details.
8. Turn off the mains gas supply and bleed the gas
out of the appliance gas lines.
9. Turn 'On' the gas supply and the appliance.
10. Verify that the operating pressure remains
correct.
WARNING:
DONOT USE ANAKED FLAME TO CHECK FOR GAS LEAKAGES.

7
Lighting the Main Burners
1. Rotate the control knob anti-clockwise to the
position marked HIGH.
2. Manually light the main burner.
- hold the gas control knob depressed for
approx. 10 - 15 secs then release.
3. Once lit the main burner will be burning at full
rate. For a lower heat, push in the gas control
knob and turn fully anti-clockwise to the LOW
position.
4. Also for intermediate heat, position the control
knob between the HIGH and LOW positions.
5. Repeat Items 1 to 4 to light the second main
burner.
Racking System
The Rack System fitted to the Salamander is self-
supporting when withdrawn, to allow easy loading
of food. The installation of the rack is dependent on
the cooking function required.
Part 4 Operation
Operation Guide
1. Cobra Salamanders have been designed to
provide simplicity of operation and 100% safety
protection.
2. Improper operation is therefore almost
impossible, however bad operation practices
can reduce the life of the salamander and
produce a poor quality product. To use this
salamander correctly please read the following
sections carefully:-
 Lighting the Main Burners.
 Racking System.
 Cooking Recommendations.
Description of Controls
The salamander has individual heat controls for the
left and right sides. Select the desired heat level
and allow a few minutes for the elements to heat
up.
 Cobra salamanders provide two
independently controlled heat zones.
 High speed grilling is provided by the two
infrared gas burners in the ceiling of the
grilling compartment.
 The left hand and right hand gas control
knobs operate the left side and right side
burners respectively, independently of each
other.
 Each burner is provided with flame failure
protection.
C AUTION :
 This appliance is for professional use and
is only to be used by qualified persons.
 Only qualified service persons are
allowed to carry out installation,
servicing or gas conversion operations.
 Components having adjustments
protected (e.g. paint sealed) by the
manufacturer should not be adjusted by
the user / operator.
Gas Control Knobs
๐OFF Position.
HIGH Flame.
LOW Flame.
Rack Handles
WARNING:
ALWAYS SET THE GAS CONTROL TO THE 'HIGH' POSITION WHEN
LIGHTING THE MAIN BURNER.
IFTHE MAIN BURNER GOES OUT DURING NORMAL OPERATION
OR FOR ANY REASON, WAIT 3 MINUTES BEFORE ATTEMPTING TO
RE-LIGHT THE MAIN BURNER

8
Part 4 Operation
Cooking Recommendations
1. The Cobra Salamander has been designed to
give a good evenness of heat across the rack
area, so toasting, cheese melting and grilling
should be relatively even wherever food is
placed.
2. The HIGH position is recommended for most
grilling, cheese melting functions and LOW
position for a reduced heat.
3. For cooking food through rather than just
surface browning, rack position three and four
from the top is recommended.
4. With a Branding Plate fitted, the unit is able to
aid the chef in its ability to produce "medium
rare" steaks in the front and "well done" steaks at
the rear - achieved with the sloped Branding
Plate rack position. (Shelf 2 and 3 from the top.).
5. Heating the Branding Plate under the burners
before cooking commences, also allows the
"sealed in flavoured goodness" to be achieved.
WARNING:
TO AVOID THE RISK OF FIRE:-
- DO NOT LEAVE THIS APPLIANCE UN-ATTENDED WHEN IN USE,
AS IT DOES COOK FAST.
- DO NOT USE OR PLACE ANY COMBUSTIBLE MATERIAL WITHIN
600 MM OF THE FRONT COOKING ZONE WHEN THE
APPLIANCE IS IN USE.
- SYSTEMATICALLY CHECK AND CLEAN THE COOKING AREA ,
PARTICULARLY THE GRILL RACK AND DRIP TRAY, BEFORE
LIGHTING THE BURNERS.
MAXIMUM ALLOWABLE LOAD INTO THIS APPLIANCE IS 10 KG
INCLUDING ANY ADDITIONAL ACCESSORIES, IF USED. IT IS NOT
TO BE EXCEEDED.
Should any abnormal operation like;
- ignition problems,
- abnormal burner flame,
- burner control problems,
- partial or full loss of burner flame in normal
operation,
be noticed, the appliance requires IMMEDIATE
service by a qualified service person and shall not
be used until such service is carried out.
IMPORTANT

9
CORRECT LEVEL FOR FRYING MEDIUM WHEN AT
FRYING TEMPERATURE, KEEP TOPPED UP
INDICATES CORRECT FRYING MEDIUM LEVEL
WHEN COLD
Vitreous Enamel Surfaces
 Do not use wire brushes, steel wool or other
abrasive material. Clean the enamelled
surfaces regularly with a good quality domestic
oven cleaner. Remove the rack and side racks
from the Salamander - this allows easy cleaning
of the flat side walls. Leave the crumb / drip tray
in to collect all residue.
Crumb / Drip Tray
 Empty and clean daily.
Periodic Maintenance
NOTE: All maintenance operations should only be
carried out by a qualified service person.
To achieve the best results cleaning must be regular
and thorough and all controls and mechanical
parts should be checked and adjusted periodically
by a qualified service person. If any small faults
occur, have them attended to promptly. Don't wait
until they cause a complete breakdown.
It is recommended that the appliance is serviced
every 6 months.
Part 5 Cleaning and Maintenance
General
 To achieve the best results cleaning must be
regular and thorough. All controls and
mechanical parts should be checked and
adjusted periodically by a qualified service
person. If any small faults occur, have them
attended to promptly.
 Don't wait until they cause a complete
breakdown. It is recommended that the
appliance is serviced every 6 months.
 Clean the salamander regularly. A clean
appliance looks better, will last longer and will
perform better.
Racking
 For ease of cleaning of this unit and the racking
system and to achieve the best results, it is
recommended that the racking is removed
completely from the unit and cleaned
independently. This will allow for a more
thorough cleaning of the Salamander.
 To remove the racking system, carry out the
following instructions.
1. Remove the Crumb / Drip Tray from the
underside of the salamander unit.
2. Remove the Branding Plate from the rack (if
fitted).
3. Slide the rack out of the side racks and
remove from the unit.
4. Remove the left and right hand side racks
from the unit by removing the single securing
screw from each of the side racks.
5. Withdraw the left and right hand side racks
from the unit.
6. Refit the racking in the reverse order once
cleaning has been completed.
Stainless Steel Surfaces
 Clean with detergent. Baked on deposits or
discolouration may require a good quality
stainless steel cleaner or stainless steel wool.
Always apply the cleaner when the Salamander
is cool and rub in the direction of the "grain".
C AUTION :
Always turn off the gas supply at the mains
supply before cleaning.
This appliance is not water proof. Do not
use water jet spray to clean interior or
exterior of this appliance.

10
Part 5 Cleaning and Maintenance
Gas Control Valve Re-Greasing
The gas control valve should be dismantled and
greased every 6 months to ensure the correct
operation of the gas control valve.
To carry out this operation;-
1. Remove the gas control knobs from the gas
tap spindles by pulling the knobs away from
the control panel.
2. Remove the crumb / drip tray from the
appliance.
3. Remove the two screws on the underside of
the control panel, securing the control panel to
the hob.
4. Remove the control panel from the front of the
appliance.
5. Remove the 2 screws holding shaft plate to gas
control body and remove control shaft and
plate. Note orientation of shaft for correct
re-assembly.
6. Using needle nose pliers or similar, pull out gas
control spindle, again noting its orientation.
7. Apply a suitable high temperature gas cock
grease or lubricant such as ROCOL - A.S.P (Anti
scuffing paste) / Dry Moly Paste to the outside
of spindle.
8. Replace spindle and re-assemble the gas
control in reverse order.
9. Refit the control panel to the appliance and
secure with 2 screws.
10. Refit the knobs to the gas control valve
spindles.
Two Screws
Spindle

11
Part 6 Gas Conversion
Gas Conversion Procedure
NOTE:
 These conversions should only be carried out
by qualified persons. All connections must be
checked for leaks before re-commissioning
the appliance.
 For all the following conversion instructions,
the side panels have to be removed (Remove
the two screws at the bottom of each side
panel).
 All conversion details apply to both L/Hand
and R/Hand burners.
 For all relevant gas specifications refer to the
table at the end of this section.
Main Burner Injectors
1. Ensure that the gas supply has been turned 'Off'.
2. Unscrew the main burner injectors (½” A/F).
3. Determine the correct injector sizes for the
corresponding gas type from the rating plate
affixed to the right hand side panel front bottom
corner.
4. Replace with the correct size injectors.
C AUTION :
Ensure that the Unit is isolated from the gas
supply before commencing servicing.
Main Burner
Injector
Low Fire Adjustment
1. Remove the gas control knobs from the front of
the unit.
2. Remove the 2 front control panels by removing
the two screws (per panel) located at the
bottom of each panel.
3. Set the burner low fire adjustment. The low fire
screw on the gas control valve should be
screwed fully in, then unscrewed by the
measurement shown in the ‘Gas Specifications’
table.
NOTE:
The ‘Low Fire Screw’ should be sealed with
coloured paint on completion of the low fire
adjustment.
Commissioning
Before leaving the converted installation;
1. Check all gas connections for leakages using
soapy water or other gas detecting equipment.
2. Check the following functions in accordance
with the operating instructions specified in the
‘Operation’ section of this manual.
 Light the Main Burners.
 Check the Low Fire burner operation.
 Check the High Fire burner operation.
 Ensure all controls operate correctly.
NOTE:
If for some reason it is not possible to get the
appliance to operate correctly, shut off the gas
supply and contact the supplier of this unit.
Low Fire
Adjust-
WARNING:
DONOT USE ANAKED FLAME TO CHECK FOR GAS
LEAKAGES.

12
Part 6 Gas Conversion
Gas Regulator
NOTE:
The regulator supplied is convertible between Natural
Gas and LPG, but it’s outlet pressure is fixed
ex-factory and is NOT to be adjusted.
1. Ensure that the gas supply is turned ‘OFF’ at the
mains.
2. Unscrew the hexagonal cap (23 mm A/F) from the
regulator.
3. Un-clip the plastic pin from the cap, rotate the pin
and re-fit it back into the cap the correct way for
the gas type to be used. (Either ‘LP’ or ‘NAT’
should be visible on the flank of the pin once
re-fitted to the cap).
4. Screw the cap back into the regulator hand tight
only.
Gas Type Identification Label
On completion of the gas conversion, replace the
gas type labels located at:-
- The rear of the unit, above the gas connection.
- Beside the rating plate.
NOTE:
If for some reason it is not possible to get the
appliance to operate correctly, shut off the gas supply
and contact the supplier of this appliance.
NOTE, Pin rotated
for Natural Gas
NOTE, Pin
rotated for LPG

13
Part 6 Gas Conversion
Gas Specifications
- Non UK Only:
- UK Only:
NOTE:
* - The burner operating pressure is to be measured
at the manifold test point with both burners
operating at full setting. The operating pressure
is ex-factory set and not to be adjusted, apart
from when converting between gases, if
required. (Refer to the ‘Gas Conversion’
information for details).
Natural Gas LP Gas (Propane)
Main Burner Injectors Ø 1.85 mm Ø 1.15 mm
Low Fire
Size Ø 1.00 mm Ø 1.00 mm
Adjustment 2 turns out (c.c.w.) ½ turn out (c.c.w.)
Operating Pressure 1.0 kPa (*) 2.55 kPa (*)
Gas Regulator Cap Screw
Supply Pressure 1.13 - 3.4 kPa 2.75 - 4.5 kPa
Natural Gas (G20) Propane (G31)
Main Burner Injectors Ø 1.85 mm Ø 1.15 mm
Low Fire: Size Ø 1.00 mm Ø 1.00 mm
Adjustment 2 turns out (c.c.w.) ½ turn out (c.c.w.)
Burner Operating Pressure 10 mbar (*) 26 mbar
Gas Regulator Cap Screw
Supply Pressure 20 mbar 37 mbar

14
Replacement Parts List
When ordering spare parts, please quote the part number and the description as listed below. If the part
required is not listed below, request the part by description and quote model number and serial number
which is shown on the rating plate.
Controls
019430 Gas Control Valve.
230695 Control Knob.
034115 Main Injector (LPG) 1.15 mm.
034185 Main Injector (Natural Gas) 1.85 mm.
019574 Low Fire Screw (Nat. Gas / LPG) 1.00 mm.
019214K Burner Kit.
026123 Burner Guard.
230671 Thermocouple.
General
026096 Wall Mounting Bracket.
013908 Spacer Foot Assy.
017963 Rack.
026093 Side Rack.
227961 Screw Side Rack.
231546 Crumb / Drip Tray.
Accessories (Optional)
013418 Branding Plate.
Gas Regulator
Gas Conversion Kits
Part 7 Replacement Parts List
IMPORTANT:
Only genuine qualified replacement parts should be used for the servicing and
repair of this appliance. The instructions supplied with the parts should be followed
when replacing components.
For further information and servicing instructions, contact your nearest qualified
service branch (contact details are as shown on the reverse of the front cover of this
manual).
Model
Gas Type to Convert to
Nat. Gas LPG (Propane)
CS9 231551 231552
Gas Type
Gas Regulators
Part No. Description
Nat. Gas
LP Gas / Propane 228533 Regulator (RV47) - 1/2” BSP F/F.
