Cocoon HE190041 User manual

QUICK SETUP GUIDE
for more detail, please read the full manual
remove camera
from packaging
Insert microsd card
(Not included)
fully charge using
micro usb cable
attach camera to
desired mount
4K ACTION CAMERA

QUICK SETUP GUIDE
for more detail, please read the full manual
4K ACTION CAMERA
mode
1
2
3
4
5
6
7
8
9 10
11
1. Wi-Fi indicator
Flashes yellow when the Wi-Fi
mode is on. Solid when
connected to a Wi-Fi device
2. OK / shutter button
Take a photo, start/stop video
recording or confirm a selection
3. Up / Wi-Fi button
Move up in a menu
4. Down / microphone button
Move down in a menu
5. Speaker
6. Power / M Button
Turns the action camera on and
off. Switches between modes of
Camera & Video
7. Lens
8. Microphone
9. Micro USB port
10. microSD card slot*
11.
Battery door
12. Capture button
Press to take a photo
13. LED indicator
Indicates that a button has been
pressed
14. Video button
Press to start recording a
video/stop recording
