Code 3 CD5051 Series User manual

Page 1 of 8
CD5051 Series Directional LEDs
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
Installation and Operation Instructions
Size 5.4” W x 0.6” H x 1.0” D
Weight 0.14 lbs
Input Voltage 12-24 VDC
Current at 12.8 VDC 0.8 Amps
Power at 12.8 VDC 9.1 Watts
Flash Rate See ash pattern charts
Temperature Range -30°C (-22ºF) to 50°C (122ºF)
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator’s responsibility to be sure they can proceed safely before entering an
intersection, drive against trafc, respond at a high rate of speed, or walk on or around trafc lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specications:

Page 2 of 8
Installation and Mounting:
Carefully remove the unit from its packaging. Examine the unit for
transit damage. If damage is found, return the product to your local
dealer for warranty replacement. Do not use damaged or broken
parts. Determine a mounting location with the least amount of
curvature as possible. Also, ensure there is a clear line of sight for
oncoming trafc.
Wiring Instructions:
CAUTION!
When drilling into any vehicle surface, make sure that the
area is free from any electrical wires, fuel lines, vehicle
upholstery, etc. that could be damaged.
Surface Mounting:
Mark and drill two 3.4 mm holes 3.543” or 90 mm apart. Drill a hole
for the wire exit as needed. Secure in place with the gasket and
supplied hardware as shown in FIGURE 1.
FIGURE 1
MOUNTING SURFACE
L Bracket Mounting:
Mark and drill two 2.9 mm holes 3.937” or 100 mm apart. Drill a hole
for the wire exit as needed. Secure in place with the L brackets, gas-
kets and supplied hardware as shown in FIGURE 2.
FIGURE 2
MOUNTING SURFACE
Offset Mounting:
Mark and drill two 2.9 mm holes 5.827” or 148 mm apart. Drill a hole
for the wire exit as needed. Secure in place with the offset brackets,
gaskets and supplied hardware as shown in FIGURE 3.
FIGURE 3
MOUNTING SURFACE
The CD5051 Series of directional LED light heads are self ash-
ing. All wiring should be stranded and a minimum of 22 AWG. The
positive line must have an in-line 3 Amp slow-blow fuse for each
directional as shown in FIGURE 4. Isolate the yellow and blue wires
when not in use.
IMPORTANT! This unit is a safety device and it must be connected
to its own separate, fused power point to assure its continued
operation should any other electrical accessory fail.
FIGURE 4
Note: On dual color units only, apply (+) power to the blue
wire for dimming.
YELLOW -
(SYNC)
+ -
BLACK - GROUND
BLUE -
FLASH PATTERN
SELECT (MOMENTARY
TO GROUND)
RED - POSITIVE
SWITCH
(USER SUPPLIED)
IN-LINE FUSE
(USER SUPPLIED)
WHITE -
POSITIVE
(DUAL COLOR
ONLY)
SWITCH
(USER SUPPLIED)

Page 3 of 8
Flash Pattern Selection:
The CD5051 series directionals can be congured to ash the following patterns by momentarily applying ground to the blue wire. Holding
the blue wire to the ground wire for 2-3 seconds will toggle the unit to the previous pattern. The unit must be powered through the power and
ground wires to allow pattern selection. The blue wire may be wired to momentarily switch. *Applies to Amber, Red, Blue and White. **Ap-
plies to Amber and Blue.
Synchronization:
The CD5051 series directional is capable of syncing with other compatible Code 3 products by following the steps below:
1. Set the desired ash pattern on each unit individually. It is also strongly recommended that the same style of ash pattern be used on all
units to produce the most effective warning pattern. NOTE: Phases A and B for each style of ash pattern in the table denote the relative
timing between units connected in a synchronizing installation. To operate simultaneously, each unit must be set to the same phase (A +
A or B + B); to operate alternately, units must be set to have the opposite phase (A + B or B + A).
2. Connect the yellow sync wires together and check that the units are ashing in a synchronized manner as expected. If a pattern on
one unit appears incorrect, the blue pattern select wire can be used to cycle forward or backward on that individual unit until the correct
pattern is selected. NOTE: This will only change the pattern in the one unit and will not affect the other units connected to the yellow
sync wire.
CD5051X SINGLE COLOR FLASH PATTERN CHART
Pattern Description Phase FPM SAE J595* CA Title 13**
1 Single Flash A 75 Class 1 Class B
2 Single Flash B 75 Class 1 Class B
3 Single Flash A 120 Class 1
4 Single Flash B120 Class 1
5 Double Flash A 75 Class 1 Class B
6 Double Flash B 75 Class 1 Blass B
7Double Flash A 120 Class 1
8 Double Flash B120 Class 1
9-Default Quad Flash A 75 Class 1 Class B
10 Quad Flash B 75 Class 1 Class B
11 Quad Flash A 150 Class 1
12 Quad Flash B150 Class 1
13 Triple Flash A 75 Class 1 Class B
14 Triple Flash B 75 Class 1 Class B
15 Quint Flash A 150 Class 1
16 Quint Flash B150 Class 1
17 Steady Burn
18 Single Flash - Modulation

Page 4 of 8
Red Wire White Wire Red & White
Wires
1 - Default 1 Single Flash - Color 1 A 75 Class 1 Class B
22 Single Flash - Color 1 B 75 Class 1 Class B
3 Single Flash - Alternating Color 1 & 2 A 150
4 Single Flash - Alternating Color 1 & 2 B 150 Class 1 Class B
1 - Default 5 Single Flash - Color 2 A 75 Class 1 Class B
26 Single Flash - Color 2 B 75
337 Single Flash - Alternating Color 1 & 2 A 75
448 Single Flash - Alternating Color 1 & 2 B 75
559 Single Flash - Alternating Color 1 & 2 A 150
610 Single Flash - Color 1 A 375
711 Single Flash - Color 1 B 375
12 Single Flash - Alternating Color 1 & 2 A 750
13 Single Flash - Alternating Color 1 & 2 B 750
614 Single Flash - Color 2 A 375
715 Single Flash - Color 2 B 375
8 8 16 Single Flash - Alternating Color 1 & 2 A 375
9 9 17 Single Flash - Alternating Color 1 & 2 B 375
10 10 18 Single Flash - Alternating Color 1 & 2 A750
11 19 Double Flash - Color 1 A 75 Class 1 Class B
12 20 Double Flash - Color 1 B 75 Class 1 Class B
21 Double Flash - Alternating Color 1 & 2 A 150
22 Double Flash - Alternating Color 1 & 2 B 150
11 23 Double Flash - Color 2 A 75 Class 1 Class B
12 24 Double Flash - Color 2 B 75 Class 1 Class B
13 13 25 Double Flash - Alternating Color 1 & 2 A 75
14 14 26 Double Flash - Alternating Color 1 & 2 B 75
15 15 27 Double Flash - Alternating Color 1 & 2 A 150
16 28 Double Flash - Color 1 A 120 Class 1
17 29 Double Flash - Color 1 BClass 1
30 Double Flash - Alternating Color 1 & 2 A
31 Double Flash - Alternating Color 1 & 2 B
16 32 Double Flash - Color 2 AClass 1
17 33 Double Flash - Color 2 BClass 1
18 18 34 Double Flash - Alternating Color 1 & 2 A
19 19 35 Double Flash - Alternating Color 1 & 2 B
20 20 36 Double Flash - Alternating Color 1 & 2 A
CD5051XX DUAL COLOR FLASH PATTERN CHART
Description
attern
Phase FPM SAE J595* CA T13**
P
120
240
240
120
120
120
120
240

Page 5 of 8
Red Wire White Wire
Red & White
Wires
21 37 Triple Flash - Color 1 A 75 Class 1 Class B
22 38 Triple Flash - Color 1 B 75 Class 1 Class B
39 Triple Flash - Alternating Color 1 & 2 A 150
40 Triple Flash - Alternating Color 1 & 2 B 150
21 41 Triple Flash - Color 2 A 75 Class 1 Class B
22 42 Triple Flash - Color 2 B 75 Class 1 Class B
23 23 43 Triple Flash - Alternating Color 1 & 2 A 75
24 24 44 Triple Flash - Alternating Color 1 & 2 B 75
25 25 45 Triple Flash - Alternating Color 1 & 2 A 150
26 46 Quad Flash - Color 1 A 75 Class 1 Class B
27 47 Quad Flash - Color 1 B 75 Class 1 Class B
48 Quad Flash - Alternating Color 1 & 2 A 150
49 Quad Flash - Alternating Color 1 & 2 B 150
26 50 Quad Flash - Color 2 A 75 Class 1 Class B
27 51 Quad Flash - Color 2 B 75 Class 1 Class B
28 28 52 - Default Quad Flash - Alternating Color 1 & 2 A 75
29 29 53 Quad Flash - Alternating Color 1 & 2 B 75
30 30 54 Quad Flash - Alternating Color 1 & 2A 150
31 55 Quad Flash - Color 1 A 120 Class 1
32 56 Quad Flash - Color 1 B 120 Class 1
57 Quad Flash - Alternating Color 1 & 2 A 150
58 Quad Flash - Alternating Color 1 & 2 B 150
31 59 Quad Flash - Color 2 A 120 Class 1
32 60 Quad Flash - Color 2 B 120 Class 1
33 33 61 Quad Flash - Alternating Color 1 & 2 A 120
34 34 62 Quad Flash - Alternating Color 1 & 2 B 120
35 35 63 Quad Flash - Alternating Color 1 & 2 A 240
64 Single Flash - Modulation - Alternating Color 1 & 2
65 Double & Quad Flash - Alternating Color 1 & 2
66 Single & Triple Flash - Alternating Color 1 & 2
67 Double, Triple & Quad Flash - Alternating Color 1 & 2
36 68 Steady Burn - Color 1
36 69 Steady Burn - Color 2
CD5051XX DUAL COLOR FLASH PATTERN CHART (Continued)
Pattern
Description Phase FPM SAE J595* CA T13**

Page 6 of 8
Notes:

Page 7 of 8
Notes:

Page 8 of 8
© 2018 Code 3, Inc. all rights reserved.
920-0717-00 Rev. A
10986 North Warson Road
St. Louis, MO 63114
Technical Service
[phone]
[email protected]
www.code3esg.com
An ECCO SAFETY GROUP™ Brand
www.eccosafetygroup.com
Warranty:
Product Returns:
If a product must be returned for repair or replacement*, please contact our factory to obtain a Return Goods Authorization Number (RGA
number) before you ship the product to Code 3®, Inc. Write the RGA number clearly on the package near the mailing label. Be sure you use
sufcient packing materials to avoid damage to the product being returned while in transit.
*Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring
service and/or repair.; nor for the packaging, handling, and shipping: nor for the handling of products returned to sender after the service has been rendered.
Manufacturer Limited Warranty Policy:
Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specications for this product (which are avail-
able from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-
TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE
MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WAR-
RANTY.
Exclusion of Other Warranties:
MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EX-
CLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.
Remedies and Limitation of Liability:
MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY
OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE
REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PROD-
UCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO
THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE.
IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY
DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IM-
PROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT
TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF
ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdic-
tions do not allow the exclusion or limitation of incidental or consequential damages.
