Code Blue CB 1-w Manual

800.205.7186 • www.codeblue.com
CB 1-w
Model: ENTM06, ENTM07
Admin Guide
Installation | Configuration | Support | Maintenance | Use
Solar Tower

page 2 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED
ELECTRI- CIAN MAY BE REQUIRED.
Copyright © Code Blue Corporation. All rights reserved. This guide or software
described herein, in whole or part, shall not be reproduced, translated or reduced to any
machine-readable form without prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS
GUIDE, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY
EXPRESSLY DIS- CLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR ANY PARTICU- LAR PURPOSE WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR SUCH OTHER INFORMA- TION. IN NO EVENT SHALL CODE BLUE
CORPORATION BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT
OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modifications to this guide or the
information contained herein at any time without notice. The software described herein
may also be governed by the terms of a separate user license agreement.
Code Blue® is a registered trademark of Code Blue Corporation. The names of actual
companies and products mentioned herein may be the trademarks of their respective
owners.
NOTICE TO USERS

page 3 of 53
Admin Guide
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
CB 1-w Solar Tower
Table of Contents
Section
Section Title
Page #
2
Introduction
5
CB 1-w Model Photos
5
3
Dimensions
6
4
Safety Information
8
5
Installation Instructions
9
Getting Started
9
Tools Needed
10
Solar Battery & Solar Panel Prep
11
Anchor Bolt Kit Instructions
12
Deck Mount Kit Instructions
13
Base Gasket Instructions
14
Tower Installation
15
Set the Unit
15
Solar Audio Paging Installation
16
Installing Solar Audio Paging Array on NEW Unit
16
Solar Audio Paging Amp Connetcion
18
Solar Audio Paging Amp - Volume Level Adjustment
19
Solar Panel Bracket Installation
20
Solar & Cellular Wiring Installation
21
Solar Panel Installation
22
Cellular Communication Wiring & Antenna Installation
24
Solar Power Installation
27
Speakerphone Installation
32
Pre-Installed Components
32
S-1000 & S-1050 Strobe Operation
33
6
Power Requirements
35
7
Wiring Diagrams
39
Complete Solar Tower Diagram - No Audio Paging System
39

page 4 of 53
Admin Guide
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
CB 1-w Solar Tower
Table of Contents (continued)
Section
Section Title
Page #
Complete Solar Tower Diagram - With Audio Paging System
40
Solar Audio Paging Amplifier Wiring
41
Solar Audio Paging Amplifier Connection to Faceplate
Speakerphone
42
Solar Panel To Breaker Detail
43
Solar Batteries To Breaker Detail
44
110-347V AC Standard Wiring with Multi-Tap Transformer (Power
Brick)
45
8
Locating Unit Serial Numbers
46
9
Troubleshooting
47
11
Maintenance Schedule
49
12
Warranty
51
13
Download Information
52
14
Legal & Regulatory Information
53

page 5 of 53
2 Introduction
Long-life LED area light behind shatterproof
Lexan Lens.
Low power consumption LED faceplate light
Custom cut-out stainless steel plates for
camera and/or card reader openings
Second opening
Solar panel
Thank you for choosing the CB 1-w Solar Tower for your Code Blue application.
The CB 1-w Solar Tower is a unique solution created in partnership with Solis based on the
original Code Blue pedestal units that set the industry standard for rugged construction,
full feature availability and high visibility. The CB 1-w Solar Tower is easily recognized
throughout a full 360-degree area. The user friendly lighted faceplate and the integral area
light ensure rapid location in an open environment. The high output strobe is easily
identifiable by security when activated.
The CB 1-w Solar Tower is an excellent choice for walkways, parks, college and commercial
campus areas, open landscape areas and anywhere a freestanding pedestal unit is required.
Pair with our faceplate speakerphones, which are designed for maximum reliability, vandal
resistance, auxiliary functions, mass notification control, and fault monitoring and reporting
capability. (See IA4100, IP5000, LS1000 and LS2000 guides for more information.)
Our unmatched craftsmanship makes our Help Points® the most rugged on the market,
withstanding the punishment of natural and man-made disasters. With durable construction,
our pedestal units can meet any requirement or purpose. CB 1-w Solar Tower units have a
rugged steel construction, shatterproof Lexan Lens, industrial engineering grade reflective
graphics and weather, UV and graffiti resistant paint. They are illuminated by a high-
powered, 270 lumens/92 candela LED blue beacon/strobe.
Features and accessory options include:
IP and analog phone options
LS2000 - VoIP Handset phone with
volume button and keypad options
LS1000 - VoIP Emercomm®
speakerphone with color IP camera
option, single or double call button
options, and keypad option.
IP5000 - VoIP speakerphone with
single or double call button
options, and keypad option.
IA4100 - Analog speakerphone
with single or double call button
options, and keypad option.
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
This guide contains all of the CB 1-w Solar Tower information, including: options, application, installation and wiring.
CB 1-w Solar Tower
with
Solar Audio
Paging Array
CB 1-w
Solar Tower

page 6 of 53
3 Dimensions
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
CB 1-w

page 7 of 53
3 Dimensions
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Solar Audio Paging Speaker Array
7.86
6.50
13.00
SIDE VIEW
TOP VIEW

page 8 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE
Indicates a situation which, if not avoided, could result in damage to
property.
IMPORTANT
Indicates significant information that is essential for proper product
functionality.
NOTE
Indicates useful information that helps get the most out of a
product.
4 Safety Information
HAZARD LEVELS LEGEND
WARNING
DANGER
Safety Instructions
Code Blue products shall be installed by trained professionals. The installation should
conform to all local codes. In some countries, a certified electrician may be required.
When transporting a Code Blue product, use the original packaging or equivalent to
prevent damage to the product.
Code Blue products shall be used in compliance with local laws and regulations.
Store the Code Blue product in a dry and ventilated environment.
Do not install the product on unstable brackets, surfaces or walls.
Use only applicable tools when installing Code Blue products.
Do not use chemicals, caustic agents, steel wool or aerosol cleaners other than those
tested and recommended by Code Blue.
Use only accessories that comply with technical specifications of the product. These
can be provided by Code Blue or a third party.
Use only spare/replacement parts provided by or recommended by Code Blue.
Transportation
When transporting a Code Blue product, use the original packaging or equivalent to
prevent damage to the product.
WARNING
NOTICE
NOTICE

page 9 of 53
Getting Started
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Important Notes:
EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to
for proper operation of Code Blue communication devices connected to
copper or fiber infrastructures communications cable and electrical cable in
the same conduit is not an acceptable installation and shall not be supported.
Analog phones require a minimum of 23mA for proper operation (26-29mA
recommended).
Each analog speakerphone requires its own phone line or PBX extension.
Multiple units shall not be supported.
Speakerphones require programming before operation. Consult the
speakerphone’s Administrator Guide for instructions.
If you are installing IP speakerphones, please read the appropriate manuals
and consult with your Network Administrator.
Size electrical wiring based on length of run.
5 Installation Instructions

page 10 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Tools Needed
All CB 1-w Units Require:
Ladder to reach the top of the unit.
Drill & Security Bit for removing & inserting security screws on
phone, dome top, & access door.
1-1/8” Socket set & extension
Phillips and flat head screwdrivers
1/2" wrench for solar batteries
Volt/Amp Meter (AC/DC)
Solar Insolation Meter
Angle Finder
Level
Compass/GPS
Electrical Termination Tools(crimper, wire cutter, etc.

page 11 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Solar Battery Prep
If needed, remove all batteries from enclosure.1.
Using a multimeter, verify the voltage of each battery. The battery voltage should
be 12.7 VDC or higher. If the battery voltage is less, charge the battery with a
battery charger. If a battery charger is not available, then the SPP should operate
without load for 24 hours to recharge the batteries.
2.
Refer to page 34 for battery wiring during installation.3.
Solar Panel Prep
Remove the solar panels from the shipping containers.1.
Voltage and current should be verified for each panel before installation. To do
this, temporarily place a solar panel pointing directly at the sun. Using the
multimeter, verify the Voc of the panel. The reading should be +/- 15% of the
manufacturer specification.
2.
Using a spare piece of 10 AWG wire, short the positive and negative terminal of
the solar panel. Read the insolation value using the insolation meter and the DC
current using the ring multimeter. The current reading should be +/- 15% of the Isc.
For example, if the Isc specification is 8 A and the insolation meter is reading 500,
then the multimeter should be reading approximately 4 A.
3.
Perform this procedure for each panel. Remove the shorting wire when completed.

page 12 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
2. PULL WIRING
IMPORTANT:
1. FOUNDATION
Four 24-inch L-shaped anchor bolts and an aligning
template are supplied for anchoring the Code Blue
unit. The bolts should be set into the foundation so
that six inches are left showing above the finished
grade level. The anchor bolts should be aligned, using
the supplied template in such a way that the phone
faceplate on the unit face in the desired direction.
The foundation should be at least 24 inches in
diameter and to the correct depth for the frost line in
your area, with a mini- mum depth of at least three
feet (follow local building codes for foundations).
Electrical and telephone line conduit, with a maximum
combined diameter of four inches, should be run up
through the center of the foundation hole. A minimum
of four inches and a maximum of six inches of conduit
above the finished grade level is required. To ensure
proper grounding, a ½-inch x 8-foot copper rod should
be inserted in the center of the foundation and tied to
the steel pedestal.
A minimum of two feet of wire must be available from
the con- duit for electrical and communications wiring.
Anchor Bolt Kit Instructions
1.1 Run Conduit
1.2 Pour the Foundation
1.3 Set the Anchor Bolts in the Wet Foundation
2.1 Pull Power and Phone Line up through Conduits
• Wire gauge must be selected to meet code for voltage/current required for the product to
operate correctly: Minimum 14 AWG.
• Conduit used must comply to National Electrical Standards as observed locally.
NOTE: Follow all national and local codes governing this installation.
NOTE: Communications wire must be shielded phone line. The
phone line must be pulled into the unit using a separate conduit
from the power. Along with a service loop of wire, as noted by the
NEC standards.

page 13 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
2. PULL WIRING
IMPORTANT:
1. DECK
FOUNDATION
Drill a fifth hole in the center to accommodate the conduit.
To prevent tampering, it is advisable to tack weld the
lower nuts to the threaded rod.
Drill four holes through the deck or floor for the four
3/4” threaded rods. The holes should be aligned, using
the tem- plate provided in such a way that the phone
faceplate on the unit will face in the desired direction.
Position the second plate working from below the deck.
Have another worker hold the upper plate and rods in place
from above the deck.
1.4.1 Place the second plate gasket and then the second
plate over the threaded rods.
1.4.2 Secure the second plate with nuts and washers pro-
vided. If required, readjust the nuts so that six inches of the
rods are above the top of the upper plate.
A minimum of two feet of wire must be available from the
conduit for electrical and communications wiring.
Position the first plate working from above the deck.
1.3.1 Thread a nut and washer on the end of each rod so
that approximately six inches extends beyond the base of
the washer.
1.3.2 Insert each rod through the top side of the plate, plate
gasket, and down through the four holes in the deck.
Electrical and telephone line conduit is run through the deck
and the center openings (two-inch diameter) of the upper and
lower deck plates. A minimum of four inches and a maximum of
six inches of conduit above the upper plate is required.
Deck Mount Kit Instructions
2.2 Conduit
1.1 Drill Deck Holes
1.2 Drill Conduit Hole
1.5 Secure Lower Nuts
1.3 Position Upper Deck Plate
1.4 Position Lower Deck Plate
2.1 Pull Power and Phone Line up through Conduits
NOTE: The top of the plate is the side with the tapered edge.
Wire gauge must be selected to meet code for voltage/current required for the product to
operate correctly: Minimum 14 AWG. Conduit used must comply to National Electrical Standards as
ob- served locally.
NOTE: Communications wire must be shielded phone line. The phone line must be pulled into the unit using
a separate conduit from the power. Along with a service loop of wire, as noted by the NEC standards.
SKIP if installation does not include a Deck Mount Kit

page 14 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
3. SECURE THE UNIT
1. SET THE NUTS AND WASHERS
2. SET UNIT UPRIGHT ON ANCHOR BOLTS
Set the gasket on the bolts and cut a small hole where the
conduit is located.
Stretch the screen tightly around the conduit pipe. Slide the
gasket over the bolts to the base of the unit.
Align the phone plate in the desired direction and lift the
Code Blue unit over the anchor bolts. The unit may be lifted
using the bracket on the inside of the unit.
After the foundation has set, screw one set of nuts, followed
by one set of washers, onto the anchor bolts. Set the nuts so
the lowest washer is about 2½ inches above the concrete at
an even height.
Access the mounting studs through the door on the side
of the unit.
Place the second washer on the anchor bolt and place the nut
on top.
Tighten the mounting nuts onto the anchor bolts. This may be
more convenient if a long socket (extension and universal joint)
is used to tighten the hardware.
Base Gasket Instructions
IMPORTANT: A ½-inch minimum
air gap is required between the
foundation and the unit to
prevent moisture problems.
IMPORTANT: Leveling the
bottom nuts is crucial to leveling
the unit.
A small error will be magnified
after installation.
Fasten
Place the base gasket
Use Access Door to reach mounting studs
Set the Code Blue unit on the anchor bolts:
Screw one set of nuts and washers onto the anchor bolts:
*For an extra-strong seal, a bead of silicone caulk can be put on the gasket from bolt
hole to bolt hole before setting the gasket into place and around the conduit.
Note that the unit weighs approximately 200-400 pounds.
Use appropriate lifting materials and methods to avoid
possible injury and/or damage.
To accomplish this, use a small level and check from front to
back, side to side, & diagonally. These nuts are NOT
adjustable after the unit is in place.
The bottom edge of the Code Blue unit will be 1/2" above
the concrete when in stalled.

page 15 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Tower Installation
IMPORTANT
The following list is provided as a checklist for items required prior to installation or items
that will be required on installation site:
Batteries must be FULLY bench charged before installation.1.
A local cellular dealer must provide a SIM card before unit can place calls.2.
Hand/Powered tools, including torque wrench, truck or mechanical lift for the CB 1
unit.
3.
At least two persons and ladders for attaching support collar, adjusting solar panel,
etc.
4.
FOUNDATION - (see Anchor Bolt Installation Instructions on page 10)
SET THE UNIT -
Screw one set of nuts and washers onto the anchor bolts – After the foundation has
set, screw one set of nuts followed by one set of washers onto the anchor bolts. Set
the nuts so the lowest washer is about 2½ inches above the concrete and at an even
height. To accomplish this, use a small level and check from front to back, side to
side and diagonally. These nuts are NOT adjustable after the unit is in place. The
bottom edge of the Code Blue unit will be ½-inch above the concrete when installed.
IMPORTANT: The leveling of the bottom nuts is crucial to the leveling of the unit. A small
error in the adjustment of these will be magnified after installation.
IMPORTANT: A ½-inch minimum air gap is required between the foundation and the
unit. Moisture problems may result if this condition is not complied with.
Set the Code Blue unit on the anchor bolts – Align the phone plate in the desired
direction and lift the Code Blue unit over the anchor bolts. The unit may be lifted
using the bracket on the inside of the unit. Note that the unit weighs approximately
330 pounds. Use appropriate lifting materials and methods to avoid possible injury
and/or damage.
Secure the Code Blue unit – Access the mounting studs through the door on the side
of the unit. Place the second washer, then nut and tighten the mounting nuts onto
the anchor bolts. This may be more convenient if a long socket, extension and
universal joint is used to tighten the hardware.

Solar Panel
Connection
Wires
Audio Paging
Speaker Connection
Wire
page 16 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
(Continued on next page)
Solar Audio Paging Installation
SKIP if installation does not include Audio Paging Array
Installing Solar Audio Paging Array on NEW Unit
Fish Audio Paging & Solar Panel connection wires - Utilizing the opening in the top
of the tower (location where Solar Panel would typically be attached when
installing without an Audio Paging Array), fish the connection wires through the
opening.
Position & Secure Audio Paging Array on Tower - Place the Solar Audio Paging
Speaker Array on top of the tower unit & ensure the all holes align properly. Using
the provided bolts and washers, securely attach the speaker array to the tower.
Connect Audio Paging Speaker Cables - Using the pre-installed Wago connectors,
connect the Audio Paging Speaker Cable to the cable that was fished up through
the opening on the top of the tower in previous steps.
Speaker Array Wire Connection
Audio Paging Array Connection to Tower
NOTE: Prior to beginning the steps below, remove the 6 bolts &
washers on top of the Solar Audio Paging Array to remove the
top plate. This is necessary to make the connections referenced
in the following steps.

page 17 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Solar Audio Paging Installation (continued)
Re-attach Solar Array Top Plate - Using the 6 bolts & washers that were removed
previously, reattach the top plate of the Audio Paging Speaker Array.
Fish Cables Through Cord Grips - Pass the solar panel power & cellular antenna cables
through the pre-installed cord grips located on the top of the Solar Array Top Plate.
Attach Solar Panel Mounting Bracket - While feeding the solar panel connection cables
through the aluminum solar panel mounting bracket, align the bracket on top of the
Solar Audio Paging Array. Secure it to the unit with the 3 bolts & washers provided.
Solar Audio
Paging Array
Top Plate
Solar Panel
Mounting Bracket
Mount & Connect Solar Panel - See steps beginning on page 20 for proper solar
panel installation.
NOTE: It is highly recommended that when Solar Audio Paging is being installed on a unit, that all
connections between the Audio Paging Array, Solar Panel, & Tower are stored inside the speaker
array housing. This provides easier access and protection when the unit is being serviced.
Cord Grips
IMPORTANT NOTE: The pre-installed cord grips are only hand tightened at the factory, allowing for easy
wiring adjustment during install. When connections are completed on site, the cord grips MUST be fully
tightened in order to prevent water from entering the enclosure.

Figure 1 - Amp Connections Figure 3 - Pre-Installed Speaker/Amp Wire
page 18 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Solar Audio Paging Amp Connection
4 Connections From Amp
Black & Red 2 Conductor Wire w/ Female Wago Connector – Connect to
Amp on 5 Way Manifold
Black Wire w/ 7 Pin Connector – Connect to 7 Pin Input on Phone Board (See
Figure 2 for phone inputs)
Gray 4 Pin RJ 11 Cable- Connect to PAS Audio Input on Phone Board. (See
Figure 2 for phone inputs)
Black & Red 4 Conductor Wire w/ Male Wago Connector - Connect to
Amp/Speaker wire that is pre-installed inside the unit. (See Figure 3 for pre-
installed wire)
Figure 2 - Speakerphone Input Locations
Solar Audio Paging Installation (continued)

page 19 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Solar Audio Paging Amp - Volume Level Adjustment
Locate Volume Adjustment Knob on Paging Amp - See location in below photo
Adjust Volume to Desired Level - By turning the knob clockwise or counter
clockwise, this will increase or decrease the volume level of the Audio Paging
Speaker Array.
Solar Audio Paging Installation (continued)

page 20 of 53
GU-168-E
Code Blue • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Admin Guide
CB 1-w Solar Tower
Solar Panel Bracket Installation
Attach the aluminum solar panel base mount to the tower – Align the solar panel
base gasket over the 3 coordinating holes on the tower. Place the solar panel base
mount on top of the gasket. Install a combination washer (rubber, then metal) on
each of the three 5/8 bolts with Loctite treated threads. Secure the bolts tightly to
ensure proper attachment. See Fig. 1.
NOTE: Completely coat Loctite around the threads. Loctite MUST dry for 24 hours
before being exposed to moisture.
NOTE: Each time the bolts are removed, they must be retreated with the Loctite PST.
NOTE: If installing the optional Solar Audio Paging Array, the following steps take place
on top of speaker array housing after attaching it to the tower by using the previous
instructions, instead of on the top of the CB 1-w tower itself.
CB 1-w Tower
Rubber Washer
Metal Washer
Hex Bolt
Gasket
Solar Panel Base Mount
Apply Loctite to
threads of bolt
Apply Loctite to
threads of nut
Figure 1
Solar Panel Mounting Bracket
Figure 2
