CODEMAKER Comfortzone User manual

Comfortzone
Installation Guide

Welcome to Comfortzone
We value your privacy! To know more about
our Privacy Policy, visit
hps://codemaker.ie/PrivacyPolicy
If you have any questions about Comfortzone
products.
Please visit hps://codemaker.ie/support
or contact Support by
Email: [e-mail]
2

Contents
What’s in the box........................................
1. Room Thermostat...................................
2. Tank Thermostat....................................
3. Control...................................................
Installation Guide.......................................
1. Installing Room Thermostat....................
2. Installing Tank Thermostat.....................
3. Installing Control....................................
Account Setup.............................................
Who we are...................................................
Safety & Regulatory Guide.........................
Warranty.......................................................
4
5
6
7
8
8
10
11
15
16
17
21
3

This section describes the contents of the
Comfortzone box purchased. Please refer
to the page of the device that you
purchased as follows:
What’s in the box?
1. Room Thermostat
2. Tank Thermostat
3. Control
go to page 5
go to page 6
go to page 7
4

a. Room Thermostat
b. USB cable
c. Power adapter
d. Instruction manual
What’s in the box?
1. Comfortzone Room Thermostat contains:
1a 1b
1c 1d
5

a. Tank Thermostat
b. Heat resistant USB cable
c. Power adapter
d. Adhesive mounts
e. Zip tie
f. Instruction manual
What’s in the box?
2. Comfortzone Tank Thermostat contains:
2a 2b 2c
2d 2e 2f
6

a. Control case cover
b. Control backplate
c. Printed circuit board (PCB)
d. 2 Screws
e. Instruction manual
What’s in the box?
3. Comfortzone Control contains:
3a 3b 3c
3d 3e
7

•Check that you have an active Wi-Fi
connection.
•Switch on your smartphone or tablet’s
Bluetooth seing.
•Position the Room Thermostat near a power
socket and away from any heat sources such
as a radiator or direct sunlight.
Installing Room Thermostat
Before geing started
8

1. Position Room
Thermostat on
any flat surface
away from direct
heat sources.
2. Fit the USB
Cable to your
Room Thermostat
and connect to a
power socket.
3. Proceed to
download the
Comfortzone App
on your smart
phone or tablet
from Google Play
or App Store and
begin setup of
your device.
Installing Room Thermostat
9

Installing Tank Thermostat
The Tank Thermostat is typically installed and aached to
your hot water tank/cylinder. It is set up using Bluetooth
and connects wirelessly to your home Wi-Fi network. The
Tank Thermostat is aached directly to the cylinder while
the sensor facing the cylinder wall. The adhesive mounts
and cables hold the Thermostat firmly for accurate
temperature reading.
If you’re installing a cylinder thermostat
for the first time, cut- away a small piece
of cylinder insulation about 3cm in
diameter to allow your Tank Thermostat
sensor to face the surface of your hot
water cylinder.
Loop one cable tie through one hook of
the Thermostat case and then through
one adhesive mount before tying loosely.
With the sensor positioned over the
opening in the tank insulation, aach
adhesive mount to the cylinder. Repeat
for each cable tie.
Connect heat resistant
USB-C cable to Tank
Thermostat
1
2
3
Steps:
10

Installing Control
Comfortzone smart heating control supports
up to 4 heating zones including hot water.
The Control device should be installed by an
approved installer such as a registered
electrician (RECI) or a registered gas installer
(RGI). Please contact Codemaker Support if
you would like to book an appointment with
an approved installer.
Number of Zones
The installation steps depend on how many
heating zones your home currently has. For a
single heating zone, you can usually just
replace your existing boiler clock timer with
Comfortzone Control. For a home with
multiple heating zones, your electrician or
approved installer will advise you on how to
install your Control.
11

You will need:
1. A single-gang electrical back box.
2. A small flat-head Screwdriver.
3. Comfortzone Control.
Warning: Risk of Electric Shock. Disconnect
all power sources before installation.
Turn off the power supply to your
existing clock timer at your consumer
unit (fuse board). Confirm that the
power supply is properly
disconnected.
Remove your old clock timer or
Control device. Check that you have
a single-gang electrical back box
behind your old timer device to
aach your Control to. If not, fit an
electrical backbox to your wall. An
electrical back box can be purchased
from your local electrical wholesaler.
The Earth wire should be
properly grounded by
connecting it to the earth
terminal in the back box if
one exists (important when
using metal back boxes).
1
2
3
Steps:
12

Position the Control backplate over
the cables and screw the backplate
onto the electrical back box using the
screws provided.
Insert the printed circuit board (PCB)
into the backplate.
Aach the live and neutral
cables to terminal block 1 of
the PCB as indicated.
4
5
6
Aach each zone's switched
live cable to each terminal
block as indicated. Aach
the common cable (COM) to
the other side of the terminal
block.
7
13

Turn on the mains power supply
Setup your device using the
Comfortzone app from the Google
Play Store or from Apple's App Store.
8
9
14

Download the free Comfortzone app for free
on your phone or tablet from Google Play or
Apple store and begin setup of your device.
Account Set-Up
Before geing started
15

Codemaker Limited is a smart heating
technology Company based in Dublin.
Comfortzone is the brand name for our
new smart heating devices which use Wi-Fi
and Bluetooth for setup.
Our devices are Comfortzone Room
Thermostat, Tank Thermostat, and Control.
Our main goal is to allow our Customers to
Save Energy and Save Money!
The Old Station House,
15A Main Street, Blackrock, Co.
Dublin, A94 T8P8,
Ireland
Who we are
16

Safety & Regulatory Guide
for Comfortzone
This booklet provides important safety,
regulatory and warranty information that you
should read before using your Comfortzone
device.
Basic Safety: To avoid damaging your device,
accessories or any connected devices and to
reduce the risk of personal injury, discomfort,
property damage or other potential hazards,
follow the precautions below:
•Handle your Comfortzone device with care.
You may damage the device if you
disassemble, drop, bend, burn, crush or
puncture your device. Using a damaged
device may cause overheating or injury. Don’t
expose your device to liquids, which can
cause a short circuit and overheating. If your
Comfortzone device gets wet, do not aempt
to dry it using an external heat source.
Comfortzone device is designed to operate in
a dry, indoor environment.
WARNING: HEALTH AND
SAFETY INFORMATION
17

•Comfortzone device and its power adapter
are designed to work best in ambient
temperatures between 0° to 35° C and should
be stored between ambient temperatures of
-20° and 60° C. Do not expose the
Comfortzone device to temperatures above
60° C as this may damage the product,
overheat the product, or pose a risk of fire.
• Make sure that the power adapter and
device are well ventilated when in use. Using
damaged cables or power adapters, or using
them when moisture is present, can cause
fire, electric shock, injury, or damage to the
device or other property. Make sure that the
power adapter is plugged into a socket near
your device and is easily accessible. This
product is intended for use with a certified
Limited Power Source (LPS) per IEC 60950-1
and Power Source Class 1 (PS1 per IEC
62368-1 rated: 5 Volts DC, maximum 1 Amp.
•Only power your device with the included
power adapter and cable, or compatible
accessories. Failure to use compatible
accessories can cause fire, electric shock,
injury or damage to the device and the
accessories. Compatible accessories are
available at www.codemaker.ie
18

Service & Support
For online help and support, visit
codemaker.ie/support
Manufacturer address: Codemaker Limited,
The Old Station House, 15A Main Street,
Blackrock, Co. Dublin, A94 T8P8, Ireland.
EU Compliance Notice
Hereby, Codemaker Ltd declares that radio
equipment type: [INSERT DEVICE TYPE] is in
compliance with Directive 2014/53/EU (Radio
Equipment Directive). The full declaration of
conformity may be found at
www.codemaker.ie/declarationofconformity
Restrictions and Requirements under
Directive 2014/53/EU
Product Wireless Information
The devices operate in the following
frequency band within the EU:
2402–2480MHz: Wi-Fi (max. 19.9 dBm), BLE
(max 2.7 dBm).
19

Waste Electrical and Electronic
Equipment (WEEE) Directive
The WEEE symbol above means that
according to local laws and regulations your
product should be disposed of separately
from household waste. When this product
reaches its end of life, take it to a collection
point designated by local authorities for safe
disposal or recycling. The separate collection
Codemaker Ltd. All rights reserved. Comfortzone and
related marks and logos are trademarks of Codemaker Ltd.
