Operating Instructions
Before operating the unit, please read this manualthoroughly and retain it for future reference.
Thank you for purchasing our product. If there are any questions, please contact the authorized dealer.
PART ONE –QUICK USER QUIDE
IMPORTANT INFORMATION
Legal Notice
Attention:
To ensure account security, please change the password after your first login. You are recommended to set a strong
password (no less than eightcharacters).
The contents of this document are subject to change without prior notice. Updates will be added to the new version of this
manual. We will readily improve or update the products or procedures described in the manual.
No statement, information, or recommendation in this manual shall constitute formal guarantee of any kind, expressed or
implied. We shall not be held responsible for any technical or typographical errors in this manual.
The product appearance shown in this manual is for reference only and may be different from the actual appearance of your
device.
This manual is a guide for multiple product models and so it is not intended for any specific product.
Due to uncertainties such as physical environment, discrepancy may exist between the actual values and reference values
provided in this manual.
Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
Symbols
Symbol
Description
WARNING
!
Contains important safety instructions and indicates situations that may cause bodily injury.
CAUTION!
User must be careful and improper operations may cause damage or malfunction of product.
NOTE!
Indicates useful or supplemental informationabout the use of product.
Safety Information
WARNING!
Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must read all of
the Safety Instructions supplied with your equipment before installation andoperation.
Warnings:
If the product does not work properly, please contact your dealer. Never attempt to disassemble the camera yourself.
(We will not assume any responsibility for problems caused by unauthorized repair or maintenance.)
This installation should be made by a qualified service person and should conform to all the local codes.
When shipping, the camera should be packed in its originalpackaging.
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period of time, put on the lens cap to protect the sensor from

4
dirt.
Do not aim the camera lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal
damage to the camera.
Maintenance Precautions:
If there is dust on the front glass surface, remove the dust gently using an oil-free brush or a rubber dust blowing
ball.
If there is grease or a dust stain on the front glass surface, clean the glass surface gently from the center outward
using anti-static gloves or an oil-free cloth. If the grease or the stain still cannot be removed, use anti-static
gloves or an oil-free cloth dipped with detergent and clean the glass surface gently until it is removed.
Do not use organic solvents, such as benzene or ethanol when cleaning the front glass surface.
Regulatory Compliance
FCC Part 15
This equipment has been tested and found to comply with the limits for digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
This product complies with Part 15 of the FCC Rules. Operation is subject to the following twoconditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired operation.
LVD/EMC Directive
This product complies with the European Low Voltage Directive 2006/95/EC and EMC Directive
2004/108/EC.
WEEE Directive–2002/96/EC
The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE)
Directive and must be disposed of in a responsible manner.

5
Overview
This user guide is suitable for the following models:
3432-1000
Features
Resolution: 1080P
Optical Zoom: 30X
Day and night automatic conversion function (ICR)
Supports 3D noise reduction
Video Output: IP
H.264 encoding, higher compression efficiency
3 data stream function will satisfy various bandwidth, frame rates and storage requirements in real time
Outdoor Environmental Rating: IP67
Input Power: PoE or 12 Vdc
Supports ONVIF Profile S

6
Camera Diagrams
Camera
1. Sunshield Cover
2. Camera Faceplate
3. Camera Enclosure
Camera Pig-Tail Cable
①
Network Port
②
Power Port
③
Waterproof Head

7
Cable Connection
Mode 1: Power by DC Adapter
Mode 2: Power by POE

8
Installing Your Camera
The following diagrams are for your reference only. See the actual product to mount your camera.
Check Camera Components and Installation Conditions
Before mounting your camera, check the device model number and included contents against the packing list to ensure
components are complete.
Camera Structure
1. Camera Body
2. Pig-Tail Cable
3. Waterproof Connector Kit
Important
Verify the bearing capacity of the mounted position
Verify that the mounted position meets the bearing requirements. Otherwise, you are advised to reinforce the
mounted position for the device weight. For more information, see the product datasheet.
Verify lightning protection and grounding requirements
Ground the terminal properly.
NetworkCableInstallation
①
Network Port
②
Crystal Head
③
Network Cable
④
Silicone Ring
⑤
Paw
⑥
Silica Gel Pad
⑦
Hat
⑧
Power Port
1. Insert the ③Network cable through the waterproof head kit (④/⑤/⑥/⑦).
2. Insert the Crystal head.
3. Insert the crystal into the network port.
4. Tighten the head kits (④/⑤/⑥/⑦).
Cable Requirements
Network Cable
10/100 Mbps Ethernet CAT 5/5E/6 UTP cables are applicable to the ANSI/EIA/TIA-568A/B and ISO/D.
Eight wires in the network cable need to be inserted in parallel into the top of the cable connector. The cable connector
needs to be crimped in position. When the cable connector is in position, ensure that the metal pieces of the cable
connector are parallel to each other and the clamp of the cable connector is intact.

9
Power Cable
Data listed in Table 2-1 is applicable to copper cables that use 12 Vdc power supply. The item Core Diameter indicates
the conductor diameter.
Power Loss on the Cable for Different Lengths and Different Core Diameters
Power Connector: Phoenix Connector Description
1. The anode and the cathode are not distinguished for phoenix connectors of red and black cables.
2. GND: yellow-green color.
Note: GND is used to ground the camera. Ensure that GND is connected to a reliable grounding point.
NOTE!
Disconnect the power from the camera beforemounting.
Accessories such as the wall mount bracket and the pendant mount bracket may be necessary during mounting. For
their model, refer to the accessory list recommended by your dealer.
The wall bearing capacity and the bracket length must meet all onsite mounting requirements. You will need to select a
mount type based the actual environment.
POE Specifications
Standard: 802.3af
Electrical equipment power: less than 15W
Input voltage range: 44V-58V
Requirements: Cat5 or higher cable
Core Diameter (Unit: mm)
Distance (Unit: m)
Power (Unit: W)
0.80
1.00
1.25
2.00
30
28
45
72
183
40
21
34
54
137
50
17
27
43
110
60
-
22
36
91
70
-
19
31
78
80
-
-
27
68
90
-
-
24
61
100
-
-
21
55

10
Mounting the Camera
NOTE!
Tighten all the screws to hold the camera securely.
Wall Mount
1. Install the wall mount bracket.
2. Install the screw to lock the camera tight.
