Coleman 5007 Series User manual
If you smell gas:
1. Do not attempt to
light appliance.
2. Extinguish any
open flame.
3. Disconnect from
fuel supply.
FOR YOUR
SAFETY
Do not store or
use gasoline or
other liquids with
flammable vapors in
the vicinity of this or
any other appliance.
FOR YOUR
SAFETY
DANGER indicates an imminently
hazardous situation which, if not
avoided, will result in death or
serious injury.
DANGER
WARNING indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
WARNING
CAUTION indicates a potentially
hazardous situation which, if
not avoided, may result in minor
or moderate personal injury, or
property damage.
CAUTION
CARBON MONOXIDE
HAZARD
•This appliance can
produce carbon
monoxide which has
no odor.
•Using it in an
enclosed space can
kill you.
•Never use this
appliance in an
enclosed space
such as a camper,
tent, car or home.
DANGER
This manual contains important
information about the assembly, operation
and maintenance of this outdoor propane
appliance. General safety information is
presented on this page and is also located
throughout these instructions. Particular
attention should be paid to information
accompanied by the safety alert symbol
“ DANGER”, “ WARNING”,
“ CAUTION”.
Keep this manual for future reference and
to educate new users of this product. This
manual should be read in conjunction with
the labeling on the product.
Safety precautions are essential
when any mechanical or propane fueled
equipment is involved. These precautions
are necessary when using, storing, and
servicing. Using this equipment with the
respect and caution demanded will reduce
the possibilities of personal injury or
property damage.
The following symbols shown
below are used extensively throughout
these instructions. Always heed these
precautions, as they are essential when
using any mechanical or propane
fueled equipment.
CALIFORNIA PROPOSITION 65:
WARNING: This fuel, and by products
of combustion of this fuel, contain
chemicals known to the state of
California to cause cancer, birth defects,
or other reproductive harm.
• Failure to comply with the
precautions and instructions
provided with this appliance can
result in death, serious bodily
injury and property loss or damage
from hazards of fire, explosion,
burn, asphyxiation, and/or carbon
monoxide poisoning.
• Only persons who can understand
and follow the instructions should
use or service this appliance.
• If you need assistance or information
such as an instruction manual
or labels, contact The Coleman
Company, Inc.
DANGER
• This product is fueled by propane
gas. Propane gas is invisible,
odorless, and flammable. An odorant
is normally added to help detect
leaks and can be described as a
“rotten egg” smell. The odorant can
fade over time so leaking gas is not
always detectable by smell alone.
• Propane gas is heavier than air and
leaking propane will sink to the
lowest level possible. It can ignite by
ignition sources including matches,
lighters, sparks or open flames of
any kind many feet away from the
original leak. Use only propane gas
set up for vapor withdrawal.
• Propane gas should be stored
or used in compliance with local
ordinances and codes or with ANSI/
NFPA 58. Turn off propane when not
in use.
WARNING
EXPLOSION - FIRE HAZARD
• Never store propane near high heat,
open flames, pilot lights, direct
sunlight, other ignition sources or
where temperatures exceed
120 ºF (49 °C).
• Propane is heavier than air and can
accumulate in low places. If you
smell gas, leave the
area immediately.
• Never install or remove propane tank
while outdoor appliance is lighted,
near flame, pilot lights, other ignition
sources or while outdoor appliance is
hot to touch.
• During lighting and operation,
this product can be a source of
ignition. Never use the appliance in
spaces that contain or may contain
volatile or airborne combustibles, or
products such as gasoline, solvents,
paint thinner, dust particles or
unknown chemicals.
• Minimum clearances from
combustible materials: 12 inches
from the sides and 48 inches from
the top.
• Provide adequate clearances around
air openings into the
combustion chamber.
DANGER
CARBON MONOXIDE HAZARD
• This appliance is a combustion
appliance. All combustion appliances
produce carbon monoxide (CO)
during the combustion process.
This product is designed to produce
extremely minute, non-hazardous
amounts of CO if used and
maintained in accordance with all
warnings and instructions. Do not
block air flow into or out of
the appliance.
• Carbon Monoxide (CO) poisoning
produces flu-like symptoms, watery
eyes, headaches, dizziness, fatigue
and possibly death. You can’t see it
and you can’t smell it. It’s an invisible
killer. If these symptoms are present
during operation of this product get
fresh air immediately!
• For outdoor use only.
• Never use inside house, camper,
tent, vehicle or other unventilated
or enclosed areas. This appliance
consumes air (oxygen) and
produces carbon monoxide
(CO). Do not use in unventilated
or enclosed areas to avoid
endangering your life.
DANGER
SERVICE SAFETY
• Keep all connections and fittings
clean. Inspect propane cylinder and
appliance propane connections for
damage before attaching.
• During set up, check all connections
and fittings for leaks using soapy
water. Never use a flame. Bubbles
indicate a leak. Check that the
connection is not cross-threaded
and that it is tight. Perform another
leak check. If there is still a leak,
remove the cylinder and contact
Coleman for service or repairs.
• Use as a cooking appliance only.
Never alter in any way or use with
any device or part not expressly
approved by Coleman.
CAUTION
BURN HAZARD
• Never leave appliance unattended
when hot or in use.
• Keep out of reach of children.
WARNING
CARBON MONOXIDE HAZARD
• For outdoor use only.
• Never use inside house, camper,
tent, vehicle or other unventilated
or enclosed areas. This appliance
consumes air (oxygen) and produces
carbon monoxide (CO). Do not use
in unventilated or enclosed areas to
avoid endangering your life.
DANGER
Technical
Characteristics
To Set Up
Not for home or
recreational vehicle use.
We cannot foresee every use which
may be made of our products. Check
with your local fire safety authority
if you have questions about use.
Other standards govern the use of fuel
gases and heat producing products
for specific uses. Your local authorities
can advise you about these.
• Never refill disposable cylinders.
• Use the preset regulator that came
with the appliance. Do not attempt
to adjust.
• Use only Coleman®accessories
or parts. During appliance set-up,
check all fittings for leaks using
soapy water. Never use a flame.
• Do not place this coffeemaker on
or near a hot gas stove or electric
burner or in a heated oven.
• Place the appliance on a hard, flat
level surface to avoid interruption of
airflow underneath the coffeemaker.
• Scalding may occur if the carafe lid
is removed during brewing cycles.
WARNING
NOTE: Use Coleman®16.4 oz.
disposable propane cylinders. The
LP-gas cylinder(s) used with appliances
must be constructed and marked in
accordance with the specications for
LP-gas cylinders of the U.S. Department
of Transportation or Transport Canada,
CAN/CSA B339.
Turn off regulator valve by pressing it
down and rotating clockwise. (Fig. 2)
Clean the outside of the coffeemaker
with a damp cloth. Rinse the reservoir,
lter holder & carafe thoroughly.
Remove components from carton.
(Fig. 1)
1. Reservoir & Lid
2. Filter Holder
3. Carafe
4. Regulator
Input: 4,500 BTU/h
Category: Pressure regulated propane
Fuel: 16.4 oz. disposable propane cylinders
Regulator: 5007 must be used
Fig. 2
Fig. 1
123
4
To Brew Coffee
To avoid risk of personal injury or
damage to property as a result of
overflow, be sure the carafe is squarely
centered under the filter basket during
the brew cycle. Brewed coffee and
grounds, both in the filter basket
and carafe, are very hot. Handle with
care to avoid scalding. If filter basket
overflows, or if it fails to drain into
carafe during brewing cycle, do not
open or handle filter basket. Turn
burner off and wait for contents to cool
before handling.
WARNING
Screw regulator
into the
connector at
the rear side of
the coffeemaker
hand tight.
(Fig. 3)
Remove plastic
cap from top of
propane bottle
and screw
propane bottle
into regulator
hand tight.
(Fig. 4)
Propane cylinder
correctly installed.
(Fig. 5)
Never operate
coffeemaker with
propane cylinder
in an inverted
position. (Fig. 6)
Pull out lter
holder, and insert
an 8-12 basket
style lter. (Fig. 7)
Add desired
amount of coffee.
Shake lightly to
level the coffee.
Align the brim of
lter holder with
the slot and slide
in. (Fig. 8)
Note: Be sure
lter is centered
before inserting
the lter holder.
SERVICE SAFETY
• Keep all connections and fittings
clean. Inspect propane cylinder and
appliance propane connections for
damage before attaching.
• During set up, check all connections
and fittings for leaks using soapy
water. Bubbles indicate a leak. Never
use a flame.
CAUTION
Fill the carafe with water to the
desired capacity as marked. Maximum
capacity of the
coffeemaker is 10
cups.
Open the
reservoir lid and
pour the desired
amount of water
from the carafe
into the reservoir.
(Fig. 9) Maximum
capacity of the
coffeemaker is 10
cups.
Note: Check
water level
in reservoir
regularly, burning
appliance without
water may cause
re hazard and
burn hazard.
Use only potable drinking water. Never
use water from a lake or stream that has
not been puried. Do not run any other
liquid through the coffeemaker unit.
Before making the rst pot of coffee,
operate the coffeemaker once using only
water and a paper lter. This will remove
any dust or residues that remain in the
system from the manufacturing process.
Leak Check
• Perform leak test outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the outdoor appliance
until connection has been leak tested
and does not leak.
WARNING
Fig. 3
Fig. 4
Fig. 5
Fig. 7
Fig. 6
Fig. 8
Slot
Fig. 10
Fig. 9
To Light
EXPLOSION - FIRE HAZARD
• Propane is heavier than air and can
accumulate in low places. If you
smell gas, leave the
area immediately.
• Always attach or detach propane
source outdoors; never while
appliance is lighted, near flame, pilot
lights, other ignition sources or while
appliance is hot to touch.
• This appliance is very hot during use
and can ignite flammables too close
to the burners. Keep flammables at
least 12 inches from the sides and 48
inches from the top of the appliance.
Keep gasoline and other flammable
liquids and vapors well away
from appliance.
• The appliance must not be exposed
to flammable vapors or liquids
during lighting.
DANGER
BURN HAZARD
• Never leave appliance unattended
when hot or in use.
• Keep out of reach of children.
WARNING
Standard Ignition
Set on sturdy, at surface. For outdoor
use only.
Insert lighted
match through
the Match
Hole and hold
match near
burner and
open regulator
valve to
“HIGH”. (Fig. 11)
If the appliance is hot, use proper
protective equipment.
To Turn Off
Place the empty carafe onto the
warming plate. (Fig. 10) Be sure the
carafe is centered on the warming
plate and is pressed against the
Pause ‘N Serve lever to allow coffee
to ow into the carafe.
Once coffee stops owing, the brewing
cycle is complete. Turn burner off and
serve coffee.
INSTASTART™
Electronic Ignition
Set on sturdy, at surface. For outdoor
use only.
Turn
regulator
valve to
“HIGH”
press igniter
button
repeatedly
until burner
lights.
(Fig. 12)
Note: If igniter fails to light appliance,
follow “Standard Ignition” instructions. If
the appliance is wet the igniter may
not spark.
Visually check burner has lit.
A good ame should be blue with
minimal yellow tip. Some yellow tips
on ames are acceptable as long as
no carbon or soot deposits appear.
(Fig. 13)
Fig. 11
Igniter
Fig. 12
Yellow Blue
Holes in Burner
Blue
Yellow
Good Bad
Fig. 13
Turn off
regulator
valve
(Fig. 14)
Disconnect
propane
cylinder after
nishing
brewing.
Note: If the burner ame is accidentally
extinguished, turn off the regulator valve
and wait 5 minutes before relighting
the appliance.
Fig. 14
To Clean
Make sure
appliance is cool.
Move appliance
away from ame
(including pilot
lights) and other
ignition sources.
Remove propane
cylinder from
regulator and
replace protective
cap on cylinder.
(Fig. 15)
Remove regulator
from appliance.
(Fig. 16)
Clean the
appliance
with mild dish
detergent after
each use, and dry
all parts before storing.
We suggest cleaning your Coleman
coffeemaker at the following intervals:
•40brewcycleswithhardwater•80
brew cycles with soft water
1. Place a paper lter into the brew
basket & install in coffeemaker.
2. Fill carafe to the 10 cup mark with
undiluted white household vinegar and
pour into water reservoir.
3. Place the empty carafe on the
warming plate.
4. Light coffeemaker and allow about
4-5 cups of vinegar to pass through
coffeemaker. Turn off and let
coffeemaker stand 30 minutes.
5. After 30 minutes, pour vinegar back
into reservoir & place empty carafe on
warming plate.
6. Light coffeemaker & let all of the
vinegar run through the coffeemaker.
7. Dispose of the vinegar and paper lter.
8. To ush all traces of vinegar, ll
reservoir with water and cycle water
through coffeemaker.
9. Dispose of water and repeat steps
8 & 9.
To Store
Carafe Use & Care
EXPLOSION - FIRE HAZARD
• Never store propane near high heat,
open flames, pilot lights, direct
sunlight, other ignition sources or
where temperatures exceed 120 ºF
(49 °C).
• The cylinder must be disconnected
when the appliance is in storage.
DANGER
Note: Do not
use solvents or
abrasives, metal
utensils or hard
brushes to clean
the coffeemaker.
The regulator can
be located at the
rear side of the
coffeemaker by
locking the regulator tube into to clips.
(Fig. 17)
Place the coffeemaker and regulator in
a plastic bag, and seal it with a rubber
band. Store the coffeemaker in a cool
and dry place, away from pets and
children. Dry all parts before storing.
Reference repair parts list for
replacement carafe.
Never place carafe directly onto a
burner surface.
Never use carafe on a kitchen range,
oven or in a microwave.
Never set a hot carafe on a wet or
cold surface.
Do not use a cracked carafe or one
with a loose or weakened handle.
Do not clean carafe with cleansers,
steel wool pads or other abrasive
materials. Instead use a mild, non-
abrasive detergent.
Avoid sharp blows, scratches and
rough handling.
Discard carafe immediately if it is ever
boiled dry.
Fig. 16
Fig. 15
Fig. 17
Trouble Shooting
PROBLEM POSSIBLE CAUSE SOLUTION
THE COFFEE IS NOT
BREWING
The water reservoir is
empty.
Open reservoir lid and check
water level.
The lter basket is not
properly inserted.
Insert lter basket correctly.
The carafe is not placed
all the way in on the
warming plate.
Place carafe correctly on the
warming plate.
Burner is not on “HIGH”. Turn regulator valve to “HIGH”.
THE COFFEEMAKER
ONLY BREWS WATER
There are no coffee
grounds in the lter
basket.
Add desired amount of coffee
to the lter basket. Make sure
a lter has been inserted.
THE COFFEEMAKER
BREWS SLOWLY
The coffeemaker needs
cleaning.
Clean coffeemaker as
described in the “To Clean”
section.
Outside conditions are
too windy.
Move coffeemaker to an
outside area that is less windy.
Burner is not on “HIGH”. Turn regulator valve to “HIGH”.
THE FILTER BASKET
OVERFLOWS
The lter basket is not
properly inserted.
Insert lter basket correctly.
The carafe is not placed
all the way in on the
warming plate.
Place carafe correctly on the
warming plate.
Too many coffee
grounds were placed in
the lter.
Remove lter, discard
grounds. Replace paper lter
and begin brew process
again.
THE GROUNDS ARE
IN THE COFFEE
The lter is not properly
seated in the basket.
Seat lter properly within lter
basket.
The lter collapsed. Remove lter, discard
grounds. Replace paper
lter and begin brew process
again.
Things You Should Know
1. It is unsafe and illegal in some places to store or use propane cylinders of greater than
1.14 kg (2.5 lbs.) water capacity (approximately 1 lb. propane) in occupied enclosures.
2. The usual storage areas for camping and picnic equipment are the basement, attic,
or garage. To avoid the accumulation of dust, cobwebs, etc., that is common in these
3. If not completely satised with the performance of this product, please call one of
the numbers listed on the cover of this manual.
Parts List
Accessories (sold separately)
No. Part Number Description
1 5010000810 Hinged Cover (Black)
2 5010000809 Regulator Assy.
3 5010000870 Glass Carafe
2000008032 Stainless Steel Carafe
4 5010000808 Filter Basket (Black)
5010000807 Filter Basket (Red)
No. Part Number Description
5 2000020972 Carry Case
1
2
3
4
5
Discover other camp kitchen on our website.
Table of contents
Other Coleman Coffee Maker manuals
