Installation Instructions
For Ground Light GL007 with Frosted Glass.
To be installed by qualified electrician or suitably competent person.
Installation of this fitting must be carried out in accordance with IEE regulations.
If in doubt consult a qualified electrician.
NOTE: This product must be earthed.
INSTALLATION:
1. Mains electrical power should be disconnected during installation.
2. Excavate/form location hole for Ground Light large enough and deep enough to fit the
plastic sleeve, and a suitable waterproof connector.
3. Install suitable 3 core wiring from mains supply to location of Ground Light.
4. Fit the Ground Light sleeve into the hole.
5. Connect the ground light to the mains supply (including earth) using a suitable waterproof
connector.
6. Fit the ground light into the sleeve, ensuring it locates in the square recesses.
7. Backfill the hole to secure the unit.
GL007 Frosted - IP67.
For further technical assistance, contact our technical department on 01604 495151
CWI 8045 V1

INSTALLATION
Ground light
1) Remove groundlight from
Plastic sleeve.
Plastic Sleeve
2) Excavate ground hole deep
enough to take plastic sleeve
4) Connect ground light to power
supply by using suitable ip rated mains
connector
5) Place ground light into plastic
sleeve. Ensure that connector and
cable are positioned under recess
in ground light housing
6) Back fill soil around ground
light ensuring it remains level
(Ensure to excavate deep hole to one
side of base of hole to house the excess
cable and connector)
(When installing asymmetric ground
lights ensure that square recesses in
plastic sleeve are point the same
direction as the direction of the beam
of light)
CWI 8027 V2
