Colorlight SF6 User manual

S6F HD Sender

Content
1. Introduction.................................................................................................. 1
2. Interface Description ................................................................................... 2
3. Hardware Connection.................................................................................. 3
4. LEDVISION Installation and Preliminary Configuration ............................... 4
4.1 Computer Configuration .................................................................... 4
4.2 LEDVISION Installation..................................................................... 4
4.3 Graphic Card Settings....................................................................... 6
5. Parameter Configuration ............................................................................. 9
5.1 Detect Sender and Receiving Card................................................... 9
5.2 LED Screen Setting .........................................................................11
5.2.1 Sending Device Setting ........................................................12
5.2.2 Screen Parameters Setting...................................................14
5.2.3 Connection Parameters Setting............................................15

www.colorlightinside.com
1
1. Introduction
S6F is a HD sender with powerful video signal receiving capacity, it
supports DVI and HDMI signal input and loop output, in which max input
resolution is 1920*1200 pixels. Meanwhile, 6 gigabit Ethernet outputs and 3
fiber outputs support the LED screen of 4096 pixels in maximum width or 2560
pixels in maximum height.
S6F adopts dual USB2.0 interfaces for high-speed configuration and easy
cascading, and the operation is simple and convenient. Also, it equips a series
of versatile functions, which have many advantages in applications of
manufacture and engineering.

www.colorlightinside.com
2
2. Interface Description
NO.
Interface
Functions
Remarks
1
Power Switch
On/off
2
Power Supply
AC power supply interface
(AC100～240V)
3
100M Ethernet
Network Control (communicate with
PC, or access network
4
USB_OUT
USB output, cascading with next
sender
5
USB_IN
USB input, which connects with PC
to configure parameters
6
Audio
Audio input, input audio signal and
transmit to the multifunction card
7
Fiber Output
3 single-mode LC fiber outputs
8
Gigabit
Ethernet
RJ45, 6 Gigabit Ethernet outputs,
connect to receiving cards
6 Gigabit Ethernet
outputs support
screen arbitrary
splicing
9
HDMI
HDMI input with loop
10
DVI
DVI input with loop

www.colorlightinside.com
3
3. Hardware Connection
1) Power Supply (PCI):
AC 100～240V
2) Video Signal Input (DVI/HDMI):
Connect PC with S6F through proper DVI/HDMI cable.
3) Screen Configuration (USB):
Use a standard USB A/B cable to connect S6F with PC for S6F
configuration.
4) Ethernet Cable (RJ45):
Connect S6F sender with the receiving card via Ethernet cable for
controlling receiving card and the screen. (Note: The Ethernet cable must be
CAT5E or CAT6)

www.colorlightinside.com
4
4. LEDVISION Installation and Preliminary
Configuration
4.1 Computer Configuration
⚫CPU Frequency >= 2.0GHz;
⚫Host Memory >= 1GB;
⚫Graphic card with DVI/HDMI interface: Memory >= 512MB;
⚫The resolution of PC’s graphic card should be equal to or larger than the
actual LED display’s.
Computer configuration can be adjusted according to the actual situation.
Adjustment mainly aims at total pixels of LED display, the complexity of playing
contents and whether playing HD video or not.
4.2 LEDVISION Installation
Please download the installation package of the LEDVISION software
from Colorlight’s official website www.colorlightinside.com, and complete the
installation according to the diagrams shown below.
① Run the software package, and select [English] for installer language.
Click [OK] to move on.
Note: Run LEDVISION version 5.0 or higher while using S6F.

www.colorlightinside.com
5
② After selecting a language, an installation wizard like below will appear,
click [Next];
Then choose installation location, click [Browse] to change default target
location, then click [Next] after completing;

www.colorlightinside.com
6
Choose components according to your own computer status, click [Install]
to complete;
After the installation is complete you are ready to use LEDVISION.
4.3 Graphic Card Settings
Set up the working mode of the computer graphic card after completing
hardware connection and powering S6F on, you can select Duplicate Mode
and Extend Mode according to the different requirements.
⚫Duplicate Mode: That the contents displayed on LED screen are
consistent with computer, that is to say, copy the computer contents onto
LED screen, as pic below.
PC Screen LED Screen

www.colorlightinside.com
7
⚫Extend Mode: That the contents displayed on LED screen are
inconsistent with computer, that is, to extend a display image from the
right side of PC screen, which is consistent with LED screen’s, we also
call it “Background Playing”, as pic below.
PC Screen LED Screen
For different computers, there are different ways to change the mode.
Take WIN7/8 system + NVIDIA graphics card as an example, please read the
following setting ways.
⚫Method1: Hold down the WIN and P keys at the same time, and select the
mode as you want in the pop-up window.

www.colorlightinside.com
8
⚫Method2: Right-click and select “Screen resolution” to enter the page of
“Modify the display appearance”.
Note: As for other kinds of graphic cards, if there is no corresponding window,
please refer to the user manual of the graphic card.

www.colorlightinside.com
9
5. Parameter Configuration
Please make sure the correctness of the hardware connection before
setting, use LEDVISION to detect sender and all receiving cards.
5.1 Detect Sender and Receiving Card
1. Run LEDVISION, click [Control] – [Screen Control] to enter the
Screen Control window.

www.colorlightinside.com
10
2. [Select Sending Device] for [Sender], click [Detect Senders] in
[Sender Settings]. Please check the hardware connection or the installation
of relevant driver if cannot detect senders.
Select network port and click [Detect Receiver Cards] respectively, the
software will automatically acquire the receiver card quantity of each network
port of the sender. Please check corresponding cable if the numbers of
receiver card are inconsistent with actual status.

www.colorlightinside.com
11
5.2 LED Screen Setting
Click [LED Screen Settings] to enter the LED Screen Setting interface,
and set up “Sending Device”, “Screen Parameters”, “Connection
Parameters”.

www.colorlightinside.com
12
5.2.1 Sending Device Setting
Configure on the relevant parameters of the sender in Sending Device.
Input Signal Information: Display the sender info that auto acquired via
the software, which only provided for reference, and did not support personally
set up.
Sender Resolution: Generally, sender resolution must be consistent with
the graphic card’s.
Advanced Parameter: Prepare for professionals for special applications
settings, no operation allowed for non-professionals.
Advanced Parameter includes the parameters listed below:
Sync Method: Default “Auto”.
Maximum Transmission Unit (MTU): Default “Standard”, and consult
with the technician if you need to apply to “Long”.
Output Mode: Default “Network”, and consult with the technician if you

www.colorlightinside.com
13
need to apply to “Optical Fiber”.
Frame Output: Default “Every Frame”, and consult with the technician if
you need to apply to “Every Other Frame”.
Zero Frame Delay: Default unchecked, and should be enabled by
technician under special status.
Better Graylevel on Low Brightness: Default unchecked, and should be
enable by technician under special status.
Working Mode: Default “Normal”, and consult with the technician if you
need to apply to “Loop Backup”.
IP Set: Set up IP address, select “Automatically obtain an IP address”,
then the sender would auto obtain the IP address; or it would manual set up IP
Address, Subnet Mask and Default Gateway.
Port Area: Set up the control area of each net port of S6F (X, Y, Width,
Height).
Timing Brightness Adjust: Enable Timing Brightness Adjust, set up time
periods and corresponding brightness.

www.colorlightinside.com
14
5.2.2 Screen Parameters Setting
Observe the display screen with single cabinet as an unit, and if all
cabinets themselves could display normally {it is normal circumstance even the
picture between cabinets is not continuous}, please ignore this step and
directly go to the next step.
Otherwise, configuration must be done as follows:
Click [Load], choose the correct parameter file.
Click [Send], to send the loading parameters to the receiving cards. At the
moment, each cabinet should display normally (it is normal circumstance even
the picture between cabinets is not continuous), then click [Save to Receiver]
to save the parameters to the receiving cards.
If each cabinet cannot display normally, you can conduct via the Basic
Setting (Module Information, Box Setting, Performance Setting) or
Intelligent Setting, and you can also contact with the LED screen engineers.

www.colorlightinside.com
15
5.2.3 Connection Parameters Setting
Users don’t need to set up the control area of each net port respectively,
but to the connection relationship between the receiving cards under the
network port loading via each sender, and the software will auto calculate and
set up the port control area according to the connection relationship.
Detailed setting steps as follows:
① Set up the quantity of receiving card
Set how many receiver (receiving card) that one port manages in Row
Count and Col Count (6*9 as an example) according to the actual loading of
LED display, you will see LED display mapping area from the right side
(Viewing from the front of LED display).

www.colorlightinside.com
16
② Receiving Card Parameters Setting
Select the target sender and the net port from the left side, then select
the corresponding cabinets within net port actual control area and set the
connection lines in the mapping area.
There are two methods to set up:
◆Use mouse to select one by one:
In the mapping area, select the first receiving card based on the actual
connection of the net port (view from the front), and then set up the actual
loading width and height of the target receiving card in the right side (128*128
as an example).
Click the receiver (receiving card) one by one, according to actual
connecting line, until the last one for this network port loads.
◆Connection Pattern:
Aiming at the LED screen with standard connection lines, firstly set up the
receiving card information according to the actual loading width and height

www.colorlightinside.com
17
(128*128 as an example).
Select the connection line you want from the right side, then cover the
corresponding area of net port loading in mapping area, finally complete
setting.
Note: As the cabinets have multiple and different specification (that is the
inconsistent capacity of the receiving card), you can select the different one to
adjust separately after completing setting.

www.colorlightinside.com
18
③ Send & Save to Receiving Card
After setting up all the receiving card parameters and connection lines
respectively, click [Send] to send the correct parameter to the receiving card,
and the screen should display normally at this time.
Then click [Save to Receiver] to save parameters to corresponding
receiving card after confirming.
