Comel COMPACTA INOX Guide

IN0432
H O W T O I D E N T I F I F Y T H E U N I T
SERIAL NUMBER........................................
Data, descriptions and drawings in this manual are not binding.
The company reserves the right to make any change if necessary.
001
R E V I S I O N
S E R V I C E A N D U S E I N S T R U C T I O N M A N U A L
M A D E I N I T A L I Y
P l e a s e r e a d c a r e f u l l y
cod. - A00813
TEL. [phone] - 735111
FAX [phone]
P.O. Box 62 P.IVA 0045639 041 8
61045 PERGOLA (PS) - ITALIA
VIA DELL' INDUSTRIA, 40
ZONA INDUSTRIALE SUD
CO.M.E.L. SRL
COSTR. ELETTROMECCANICHE MACCHINE DA STIRO
COMPACTA
INOX

(2)
The unit complies with EEC directive 89/392.
Pag.
I N S T R U C T I O N M A N U A L
Please read carefully the overall instruction manual before
carrying out any operation on the unit, in order to protect
the operator and avoid any damage .
AT TENZ I ONE
TEMP E RATURE
PERICOL O S E
AT TENT I ON
TEMP E RATURE S
DANGERO U S
ATTEN ION
TEMPERATUR
T - HEAT SOURCE-THERE MAY BE
HIGH ES
STOP BEFORE CARRYING OUT ANY OP RATION
ON THE UNIT
TENSION E
EARTH
DO T E ANY FETY DEVICESNO R MOVE SA
DO NOT CARRY OUT ANY OP RATION ON THE UNIT WHEN
IT IS ON
E
LABELS ON THE UNIT
WARNING SIGNS
220/380
(...)
A T T E N T I O N
S A F E T Y W A R N I N G S :
*Before using the unit, please verify that the mains voltage matches what is
indicated on the unit plate.The unit must be plugged into mains and sockets duly
earthed. * If the unit plug and the socket do not match, please have the plug replaced
with a right one by qualified technicians. *The unit is electrically safe under the
condition that it is duly earthed, as provided for by the current electrical safety rules.
The manufacturer cannot be held responsible for any damage arising from the mains
being badly earthed. If in doubt, please contact a qualified technician. * After unpacking the
unit, please make sure that it is untouched. If in doubt, do not operate the unit in any case
and contact a qualified thecnician. *Please make sure that all packaging of the unit (plastic
bags, expanded polystyrene,..) is away from children and carefully disposed of, since it
may be dangerous. * Please do not use adaptors and/or extensions. If needed, only simple
adaptors and extensions complying with the current safety rules must be used. However,
please be careful and do not exceed the power limits marked on the adaptor.
* The manufacturer cannot be held responsible for any damage arising from improper,
wrong and unreasonable use of the unit and from careless service carried out by
unqualified technicians. * Do not touch the unit with damp, wet hands or feet. Do not
immerse the unit into water. * Do not operate the unit in bathrooms or any damp
environment. * Do not pull the electric flex or the whole unit with damp, wet hands or feet.
* Do not let children or the incompetent use the unit, unless under adults’ control. * Do not
leave the unit unattended when it is on, since it may turn dangereous. * Please
make sure that the unit is turned off and disconnected from the power
point before cleaning it out or carrying out any service on it. *Should the unit fail or work badly,
please switch it off and never break it open. If service is needed, please contact service
centres authorised by the manufacturer and ask for original spare parts to be used.
Whether these warnings are disregarded, the safety of the unit may be undermined. * The
user is kindly requested never to replace the electric flex of the unit. When it is
damaged or needs being replaced, please contact service centres authorised by the
manufacturer. *Please always disconnect the unit from the power point when it is not used.

1
2
3
4
5
__IRON MICROSWITCH
__IRON THERMOSTAT
__FILLING TOP
__KNOB TO ADJUST THE STEAM FLOW
__WATER WARNING LIGHT
__STEAM WARNING LIGHT
__BOILER ON/OFF SWITCH
__IRON ON/OFF SWITCH
__PLUG
6
7
8
9
The steam generator Compacta has been designed to iron any kind of fabric in
a professional way by means of a steady steam system.
INSTRUCTIONS
WARNINGS AND SUGGESTIONS
N.B. REGULAR MAINTENANCE OF THE UNIT
a) Screw off the filling top (3) and fill the boiler with no more than 1,4lt of standard
water. Screw on the top mildly.
b) Connect the plug (9) to a 220v, earthed power point.
c) Press the boiler on/off switch (7) to have the boiler come on, press the iron
on/off switch (8) to have the iron come on.
d) Adjust the iron thermostat (2) between linen and cotton position (linen position
is recommended when dry steam is needed, whereas coton position is when
damp steam is needed).
e) Before any ironing, please wait for the steam warning light (6) to belit. Should
the warning light go off while you iron, please go on with your work: the warning
light will come on automatically as soon as the steam has been available again.
f) Press the iron micro switch (1) to have the steam coming out from the iron.
g) Use the knob (4) to adjust the steam flow released from the iron.
- Never overfill the boiler.
- Never screw off the filling top (3) as long as the boiler is under pressure.
- Before screwing off the filling top (3), make sure that no more steam is still inside
the boiler.
- Never leave the unit unattended for long when it is on.
- When the steam is defenitely over, unplug the unit. Please wait for 20 minutes
and screw on the filling top (3) very carefully. Refill the boiler and repeat the
instructions above.
To clean the boiler, please drain it from time to time by reversing the unit and
letting water out by the filling top(3).
(NEVER CARRY OUT THIS OPERATION WHEN THE UNIT IS UNDER
PRESSURE).
REFERENCES
(3)
Pag.
H O W T O O P E R A T E T H E U N I T :
D
I
S
E
G
N
O
I
L
L
U
S
T
R
A
T
I
V
O

SP PA TARE R S
M A N U F A C T U R E R ’ S
If service is needed, please contact service centres authorized
by the manufacturer and ask for original spare parts to be used.
Whether this warning is disregarded, the safety of the unit
may be undermined.

R I C A M B I
COMPACTACOMPACTA 01/08/2017 ITAV-1075
A008C
A0025
A0031
A0037
A0039
A0040
A0041
A0042
A0043
A0051
A0052
A0060
A0072
A0290
A0291
A0292
A0293
A0395*
A0825*
A0826*
A0827*
A0828*
B0034*
B0036*
B0038*
B0058
B0052
G0008
R0034
R0038
C0091-3
C0198-3
C0494-4
C0642-4
Boiler
Thermostat
Iron-resting mat
Handle
Connector
Filling top
Washer
Connector
Washer
On/off switch
Red warning light
Bush
Pressure switch
Aluminium plate
Boiler insulation
Flex with Italian plug
Flex with Schuko plug
Complete steam valve
Plunger
Steam valve coil
Flex support
Green warning light
Heating element
Connector
Complete steam valve
Steam valve core
Steam valve coil
Plunger
Steam valve core
Connector
Inox chassis
Inox front panel
Bottom
Inox base
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
B0058
B0034 / A0827
A0040
A0041
A0039
A0042
B0038 / A0828
A0043
A0037
A0051
B0052
A0052
A0291
A008C
A0290
R0034
C0494-4
A0072
G0008
A0025
A0060
R0038
A0292
A0293
C0091-3
C0198-3
C0642-4
Ref. A0825
Complete black steam valve
(It includes the component parts:
A0826, A0827,A0828 )
* N.B. Please check which type of steam
valve your unit is fitted with, before
ordering its component parts
B0036 / A0826
N.B. The above view is intended as a pure indication.It serves to show all
the component parts of the unit to make any service easier.
DESCRIPTION TYPE LAST CHANGE DATE VIEW REF.
*PIECES PER UNIT (IN THIS VIEW)
Ref. A0395
Complete blue steam valve
(It includes the component parts:
A0826, A0827,A0828 )
* N.B. Please check which type of steam
valve your unit is fitted with, before
ordering its component parts
REF. DESCRIPTION Q**

R I C A M B I
DESCRIPTION
COMPONENT PARTS
721 PAB - GAB IRON
TYPE
LAST CHANGE DATE
VIEW REF.
21/03/2008
IFER-0020
N.B. The above view is a pure indication. It serves to show all
the component parts of the unit to make any service easier .
A0028
A023C
A025A
A028A
D0002
D0004
D0007
D0009
D009A
D0010
D0013
D0018
D0020
D0034
G0001
G0002
G0006
G0007
G0008
G0010
G0011
G0015
G0016
G0017
G0018
G0020
G0021
G0022
R0221
R0709
R0740
Steam hose
Rubber sleeve
Thermostat
Steam hose clamp
Steam hose elbow
Screw
Junction box
Small chromium-plated cover
Big chromium-plated cover
Chromium-plated handle
Cork handle
Thermostat knob
Flex
Micro switch core
Small iron base
Big iron base
Thermal cut-out
Market tag
Heating element
Wire
Wire
Back cap
Spacing cylinder
Screw
Back handle support
Front handle support
Front cap
Micro switch holder
Spacing tag
Blue micro switch button
Washer
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
*PIECES PER UNIT (IN THIS VIEW)
REF. DESCRIPTION Q*
G0008
G0001
G0002
D0002
G0011
D0004
R0221
R0709
D0009
D009A
D0010
G0010
A028A
G0006
A025A
G0007
D0018
D0007
G0015
A023C
D0020
G0016
G0020 G0022
D0034
G0021
G0018
G0017
D0013
R0740
A0028

E L E T T R I C O
DESCRIPTION
WIRING DIAGRAM
COMPACTA
TYPE LAST CHANGE DATE VIEW REF.
12/04/2007 ISE-0261
REF. DESCRIPTION
REC
TEC
MO
EV
PR
REF
TEF
LSA
LSC
MF
INTC
INTF
PE
N
BOILER HEATING ELEMENT
BOILER THERMOSTAT
JUNCTION BOX
STEAM VALVE
PRESSURE SWITCH
IRON HEATING ELEMENT
IRON THERMOSTAT
WATER WARNING LIGHT
BOILER WARNING LIGHT
IRON MICRO SWITCH
BOILER ON/OFF SWITCH
IRON ON/OFF SWITCH
EARTH
NEUTRAL WIRE
TEF
LSA
REF PR
EV
MO
LSC
REC
TEC
INTC
INTF
N220
P
PE
2
1
3
MF
