Comfort Zone POWR CURVE User manual

Save These Instructions
www.comfortzoneproducts.com
Powr Curve WiFi Series
Features:
• 2-in-1 Fan Design: Stand or Wall-Mountable
(Bracket and Hardware Included)
• 3 Powerful Fan Speeds
• Tri-Curve Plastic Safety Grille
• Adjustable Tilt Head and stand up to 53"
• Timer with Auto-shut off
(Available in Comfort Zone App)
• Wide Area Oscillation
• 120V A.C. / 60 Hz.
Smart Wi Stand Fan
POWR CURVE TECHNOLOGY
with its 6-blade fan design has
30% higher airow for maximum
cooling.
The TRIPLE-ZONE tri-curve grille
eliminates turbulence for a stronger
airow with 20% less noise!*
*Note: Compared to a non-curved fan grille
WALL

2
2
www.comfortzoneproducts.com
INTENDED USE:
This product is intended for indoor residential and ofce use only,
not for industrial or other commercial applications. Use only with
electrical wiring that is in good working order and that meets
applicable codes and ordinances. If you have any questions
whether your wiring is adequate, consult a qualied electrician.
While using your fan, you should follow the IMPORTANT
INSTRUCTIONS listed below. As part of those instructions, we
have used the word “WARNING” to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided, could result
in injury or death.
FCC WARNING:
This equipment may generate or use radio frequency energy.
Changes or modications not expressly approved by the
manufacturer (World and Main, LLC) could void the user's
authority to operate this device.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B Digital Device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
IMPORTANT INSTRUCTIONS:
As with all electrical appliances, basic safety precautions should
always be followed to reduce the risk of electric shock, re, or
injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not
recommended by the manufacturer may cause electrical shock,
re or injury to persons.
• Do not operate the fan with a damaged power cord or after the
fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or
near children, disabled persons or pets and whenever the fan is
left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface
which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth,
non-combustible, level surface.
• Always unplug fan when not in use, when moving from place to
place, when assembling or disassembling parts, and before cleaning.
• The use of attachments, not recommended or sold by the
manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard
(for non-window models).
• Do not operate the fan with blade guards or any safety device
removed.
• Do not insert or allow any object to enter any openings on the
fan. Doing so may cause electric shock and/or re hazard.
Avoid contact with moving parts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
READ & SAVE THESE INSTRUCTIONS
WARNING: SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended
for use in a bathroom, laundry area, or similar locations, or near
sinks, washing machines, swimming pools or other sources of
water. Never locate fan where it may fall into a bathtub or other
water receptacle. Do not use in damp environments such as
ooded basements.
WARNING: HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in
use, to avoid burns, do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near
combustible materials or ammable gases or sources of heat.
Do not use in areas where gasoline, paint or ammable materials
are used or stored. To prevent a possible re, do not block air
intakes or exhaust in any manner. Do not insert or allow foreign
objects to enter any ventilation or exhaust opening as this may
cause an electric shock, re, or damage the fan.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate
electrical system that is up to code. Do not use this product with
any solid-state speed control device.
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended
to t in a polarized outlet only one way. If the plug does not t
fully in the outlet, reverse the plug. If it still does not t, contact a
qualied electrician. DO NOT attempt to defeat this safety feature
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
Do not operate any fan with a damaged cord or plug or after fan
malfunctions, has been dropped or damaged in any manner. Do
not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs
covered under warranty, see warranty statement. For all other
repairs contact World and Main Customer Service by telephone
or mail for information and assistance.
Do not run power cord under carpeting. Do not cover cord with
throw rugs, runners or the like. Arrange cord away from trafc
area where it will not be tripped over. Avoid the use of extension
cords due to risk of re. If an extension cord must be used, the
cord must be minimum 14 AWG and rated not less then 1875
watts. Do not use an extension cord unless the plug can be
completely inserted into its receptacle. Unplug the fan when not
in use. Do not operate fan with its ventilation obstructed.

3
3
www.comfortzoneproducts.com
Clip
PARTS IDENTIFICATION:
Figure 1 Figure 1a
ASSEMBLY INSTRUCTIONS:
FAN HEAD ASSEMBLY:
STEP 1:
Set the back grille on the motor shaft. Make sure that the internal
molded arrow (Fig. 1) points up and the 4 clips t properly. Push
rmly in order to t them tightly (Fig. 1a). Make sure they are
secure.
ASSEMBLY INSTRUCTIONS: (cont.)
STEP 2:
Using a Phillips-head
screwdriver, screw the
3x8mm screw with washer
top (included in the parts
kit) into the cylinder-shaped
housing at the top of the
grille (Fig. 2).
STEP 3:
Set the fan blades on the
shaft of motor body and screw
the blade nut toward the word
“TIGHTEN” as the arrows show
(Fig. 3). NOTE: The blade nut
has a left hand thread. It must
be turned counter-clockwise
to tighten.
STEP 4:
With the center logo upright,
place the front and back grilles
together by aligning the 12
clips, pushing rmly until a
"click" sound is heard
(Fig. 4a, 4b).
STEP 5:
• Take the M3mm nut
(from the parts kit) and place
it on the hex socket at the
bottom of the rear grille
(Fig. 5).
• Next, take the M3x20mm
screw (from the parts kit)
and place it on the socket at
the bottom of the front grille
grille (Fig. 5a).
• Secure the screw to the
nut to ensure the rm grip
of both grilles using a
Phillips-head screwdriver.
Figure 2
Figure 3
Figure 4a Figure 4b
1. Front Grille
2. Rear Grille
3. Grille Clips
4. ST 3x8mm Screw
with washer top:
(secures rear grille
to motor cover)
5. M3x20 Screw
and M3 Nut
(secure grilles'
interlock)
6. Fan Blades
7. Blades Nut
8. Motor Shaft
9. Motor Body
10. Operation/Speed
Control Panel
11. Fan-to-Pole Fixing
Knob
12. Telescopic Pole
13. Height Fixing Ring
14. Telescopic Tube
15. Fan Base
16. Counterweight
17. Washer
18. L-Screw
19. Wall Fan Support Bracket
Nut Screw
Figure 5
Figure 5a
18
2
3
8
9
10
11
15
16 17
4
5
19
7
6
12
13
14
5
1
3

4
4
www.comfortzoneproducts.com
Figure 3
Stand
Mounted
Wall
Mounted
Figure 1
WALL
ASSEMBLY INSTRUCTIONS: (cont.) ASSEMBLY INSTRUCTIONS: (cont.)
BASE ASSEMBLY:
STEP 1:
Unscrew the L-screw from the
telescopic tube washer and
set the tube inside the base’s
round hole (Fig. 1).
STEP 2:
Place the counterweight
at the bottom of the base.
Set the washer under the
counterweight so that the
dome piece touches the
counterweight (Fig. 2).
STEP 3:
Screw the L-screw clockwise
into the washer, holding the
telescopic tube until it is tight
into the base (Fig. 3).
MOUNTING THE FAN ON
THE BASE:
STEP 1:
• Loosen the height xing
ring (A) located on the
telescopic tube by turning
it counterclockwise and
lift the telescopic pole from
the pedestal body until it
reaches the desired height.
• Screw the ring (A) clockwise
until it is tight enough to
secure the telescopic pole
height.
STEP 2:
Unscrew the xing knob (B)
and t the telescopic pole
inside the motor body. Make
sure the pole is inserted fully
to reach the bottom of
the engine body base and
screw the xing knob
clockwise until it is tight.
WALL MOUNT ASSEMBLY:
This fan comes with a wall
mounting option.
NOTE: It is not recommended
to install the fan support
bracket on prefabricated walls
or unstable walls. The fan
should be level when mounted
and at least one of the two
mounting screw locations
should be a wall stud.
STEP 1:
• Using a 1/4" drill bit, drill
two horizontally aligned
holes in the wall with
1.5" separation between
them.
•Push a 1/4" plastic anchor
(included) in each hole.
• Insert a 1/4" x 1" screw
(included) in each anchor
and screw it into the anchor
body no more than 0.78"
deep (Fig. 1).
STEP 2:
Set the previously assembled
motor body with the fan head
onto the wall fan support
bracket (Fig. 2) and tighten
it from behind with the xing
knob (Fig. 2a).
STEP 3:
Mount the bracket with fan
on the previously set two wall
screws (Fig. 3) and make sure
it is set properly (Fig. 3a).
Check to be sure the fan is
secure to the wall.
Figure 3a
Figure 2
Figure 2a
Figure 3
NOTE: The pedestal extension
pole may be recessed inside
the larger pole of pedestal
body.
A
B
Figure 1
Figure 2

5
5
www.comfortzoneproducts.com
USAGE:
FAN OPERATION: Always operate the fan on a stable
surface. Do not set on a rug, over furniture, on an uneven
oor or on a fabric surface. Always follow all instructions and
recommendations listed in this manual.
FAN LOCATION: Place the fan in the area of the room that
will provide proper fan cooling. Do not set your fan closer than
4 inches from any surface such as the wall, curtains or any
furniture which could block the air ow.
FAN CONNECTION: Make sure the fan is in the OFF position on
the control panel before plugging in. Plug the fan directly into
120 volt A.C., 60Hz wall outlet. Be sure plug ts tightly into the
outlet. A loose connection may cause overheating and damage
to the plug or fan. NOTE: To prevent overloading a circuit, do not
plug the fan into a circuit that is servicing other electrical needs.
TURNING FAN ON/OFF:
FAN FUNCTION WITHOUT THE WIFI CONNECTION
ON/SPEED SELECTION: Turn the fan on by pushing the
ON/OFF/SPEED button on the control panel. It will start the fan
on LOW speed. Push the ON/OFF/SPEED button again and the
fan will be on MED speed. Push the ON/ OFF/SPEED button a
third time and the fan will be on HIGH speed. To turn the fan off,
push the ON/OFF/SPEED button a fourth time.
NOTE: A green light will turn on and change its intensity
depending on the selected speed level.
Do not use the fan when the back cover is no more than 10cm
away from any object which may interfere with its air ow, such
as furniture, curtains or walls.
OSCILLATION: When the fan is ON, push the ON/OFF/SPEED
button for 2 seconds and the oscillation mode will be activated.
Press the button again for 2 seconds the oscillation function will
be OFF. The fan’s head angle will move on oscillation mode when
the function is working.
WIFI FUNCTION:
NOTE: Before set-up, please ensure your device is connected
to 2.4 GHz WiFi. The App does not support 5GHz WiFi
connections.
1. INSTALLING THE APP: The Comfort Zone App is compatible
with both iOS and Android operating systems.
Go to either the App Store or Google Play to download the
App (App name: CCC Comfort Zone). Once installed on
your Smart device, check to make sure that your WiFi and
Bluetooth features are enabled and follow the in-app
instructions to set-up the App and link it to your device.
After the fan is paired to the App, you can control the fan
with the App.
2. You can now use your fan with the Comfort Zone App or
through the control panel.
Below is the list of functions you will be able to operate through
the App:
1. On and Off
2. Change Fan Speeds
3. Oscillation
4. Schedule Fan to Turn On or Off Automatically using the timer
5. Use with Voice Assistants
Amazon Alexa:
• POWER:
– Alexa, turn <device_name> ON (or OFF)
• FAN SPEED:
– Alexa, set <device_name> fan speed to ONE (or TWO
or THREE)
– Alexa, turn <device_name> fan speed UP (or DOWN)
• OSCILLATION:
– Alexa, turn <device_name> horizontal swing ON (of OFF)
Google Assistant:
• POWER:
– Ok Google, turn <device_name> ON (or OFF)
– Ok Google, is <device_name> ON?
• FAN SPEED:
– Ok Google, set <device_name> to LOW (or MEDIUM
or HIGH)
– Ok Google, set <device_name> speed to ONE (or TWO
or THREE)
– Ok Google, what speed is <device_name>?
For further information on how to use our App go to the tutorials
directly in the App.
Control Panel
ON/OFF
SPEED
Light
Indicator

6
6
www.comfortzoneproducts.com
LIMITED WARRANTY
This unit is guaranteed to the original retail purchaser against
defects in quality or workmanship for a period of one year
from the date of original purchase. If this unit fails because
of a manufacturing defect within 30 days of purchase, return
the unit, with your receipt, to the retailer. After 30 days, but
within the warranty period, if the unit was purchased within the
continental United States, return it, freight prepaid, to World
and Main for repair or replacement. If the unit was purchased
outside the continental United States, return the unit to the place
of purchase. This warranty does not cover damage caused
by misuse, abuse, overheating or alteration. Repairs made
by anyone other than World and Main are not covered in this
warranty. World and Main will not be held liable for any losses
due to neglectful operation. All implied warranties, including
the warranties of merchantability and of tness of purpose, if
applicable, are hereby limited in duration to the period of one
year from the date of original retail purchase. Some states do
not allow limitations on how long an implied warranty lasts,
so the above limitations may not apply to you. Incidental or
consequential damages arising from a breach of either express
or implied warranties are hereby disclaimed and excluded. Some
states do not allow the exclusion of limitation of incidental or
consequential damages, so this limitation or exclusion may not
apply to you. Upon the expiration of this warranty all such liability
will terminate. No other warranties are expressed or implied.
This warranty gives you specic legal rights, and you may also
have other rights which vary from state to state. No informal
dispute settlement mechanisms are available. This limited
warranty is given in lieu of all other warranties.
Manufactured for:
World and Main (Cranbury), LLC
324A Half Acre Rd.
Cranbury, NJ 08512 USA
800-221-6895
www.comfortzoneproducts.com
Rev. 3/2022
CARE AND MAINTENANCE:
CLEANING: CAUTION – Before cleaning the fan be sure to
disconnect power cord from the plug. Clean the grille surface
with a clean damp cloth. Do not use harsh chemical or
abrasive cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES
IN WATER. Allow fan to dry completely before use. Periodic grille
cleaning with a vacuum will prevent dust build up. The motor is
sealed and does not require any interior maintenance, cleaning
or lubrication.
MAINTENANCE: The internal motor bearings are permanently
lubricated at the factory and do not require any additional
lubrication.
REPAIR: DO NOT USE THE FAN IF IT HAS MALFUNCTIONED
OR BECOME DAMAGED IN ANY WAY.
STORAGE: Keep original carton for storage of the heater.
Coil and tie the power cord to avoid damage during storage.
NOTE: Some models come with a plug where you can replace
a fuse. If your model has this, please read and follow the below
instructions to replace the fuse.
This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the
user servicing instructions (follow product marking for proper
fuse rating) and check the product. If the replacement fuse
blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for
examination and/or repair.
FUSE REPLACEMENT:
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
2. Open fuse cover by sliding open fuse access cover on top
of attachment plug towards blades (see Fig. 2).
3. Remove fuse carefully. Use a small tool to pry the end of the
fuse from holder cavity. Be careful not to break glass window.
4. Replace fuse. WARNING: Risk of re. Replace fuse only with
identical 2.5 or 5.0 Amp, 125 Volt fuse (3.6 mm x 10 mm). Be
sure fuse is properly seated within its cavity.
5. Close fuse cover by sliding it back to its original closed
position.
Slide Cover to Open
Figure 1 Figure 3Figure 2
Slide Cover to Open
