Comm Box Table S Series User manual

CommBox Interactive
Table User Manual 1.0
Revision: 5

Table of Contents
1 Introduction 3
1.1 Table Assembly Components 3
1.2 Accessories 3
2 Table Assembly Procedure 4
2.1 Step 1 4
2.2 Step 2 5
2.3 Step 3a (for S-Series) 6
2.4 Step 3b (for T-Series) 7
2.5 Step 4 (T-Series Only) 8
3 Computer Installation 9
3.1 Using the Computer Tray 9
3.2 Cabling and Cable Management 10

[phone]
1 Introduction
This assembly manual outlines the procedure to assemble the CommBox Interactive Table
Range. Models include 32S, 42S, 46S, 32T, 42T and 46T.
1.1 Table Assembly Components
Assembled Table Body with Screen and White Cover
4 Legs (2 with CommBox logo)
4 Steel Corner Blocks
1 Beam (T-Series Only)
Screw Pack
20 x M6 x 37mm socket head
20 x M6 washer
20 x M6 spring washer
12 x M4 x 26mm socket head (T-Series Only)
12 x M4 nut (T-Series Only)
24 x M4 washer (T-Series Only)
1.2 Accessories
Two keys
4-Way Power Distribution Unit (PDU) with USB Ports
Cable management velcro ties
Power Supply Unit (PSU) for LED strip
LED dimming controller (optional RF controller available)
2m extension lead with IEC adapter
CommBox Interactive Kiosk accessory kit (USB, HDMI or DVI and remote)

4+61 2 9975 6001
2 Table Assembly Procedure
2.1 Step 1
Unpack the Table body and lay flat on a protective surface to avoid damage to the screen
and cover.
We suggest that you lay the box on its side and slide the table out.Tip:

[phone]
2.2 Step 2
From the accessories Kit, locate the 4 steel corner blocks.
Blocks are shown in red for illustrative purposes only.Note:
Place the blocks flat over the corner section of the frame inside the light strip.

6+61 2 9975 6001
2.3 Step 3a (for S-Series)
Position the 4 legs above the corner blocks and tighten bolts ( ) noting theM6 x 37mm
orientation of the washers.
The assembly of your S-Series table is now complete. Safely stand the table on the legs and
remove the protective film on top.

[phone]
2.4 Step 3b (for T-Series)
Position the 4 legs above the corner blocks.
Tighten bolts to about 70% tension ( ) noting the orientation of the washers. YouM6 x 37mm
will notice that your T-Series table has 900mm legs with a centre welded support block for
beam connection.

8+61 2 9975 6001
2.5 Step 4 (T-Series Only)
Guide the beam into position while adjusting the leg to avoid any damage to the surface.
Ensure that the beam holes line up with the leg block holes and the dressed side of the
beam if facing the top of the table.
Tighten the beam bolts ( ) noting the orientation of the bolt head and washers.M4 x 26mm
Then go back and completely tighten the leg bolts. The assembly of your T-Series table is
now complete. Safely stand the table on the legs and remove the protective film on top.

[phone]
1.
2.
3.
4.
3 Computer Installation
3.1 Using the Computer Tray
The table is designed to fit a compact computer, such as an Intel Nuc.
Using the provided key, open the door below the table.
On the door, there is a computer tray. Remove the tray by removing the six screws.
The tray is full of holes that serve both for cooling, and as mounting holes. Find two
holes that line up with the mounting holes on the base of the computer and screw the
computer to the tray. Be careful to use suitable length screws that do not protrude too
far inside the computer and damage the computer.
Screw the tray, complete with computer, back onto the door.

10 [phone]
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
3.2 Cabling and Cable Management
The table ships with CommBox branded velcro cable ties.
There are plenty of cable management points inside the table to keep things tidy. They are
positioned around the edges inside and along the supporting beams that the touchscreen
rests on. Be sure to leave enough slack in the cables for the door to open fully.
To complete the install, follow these steps:
Connect USB and HDMI cables from the computer to the screen for touch and display
output
Place the supplied PDU inside the table
Connect both the screen and computer power cables to the PDU
Connect the Table light power (should be pre-installed) to the PDU.
Separate the 2m IEC extension and feed the smaller end up through the hole in the
centre of one of the legs where the brace meets it (T-Seried only)
Feed the smaller end of the IEC extension up through the gap at the top of the leg and
connect it inside the table so the connector is not visible.
If needed, feed a network cable through the same route and correct to the computer.
If it recommended to zip tie the power and network cables at the top of leg. Holes are
provided. This will hold them at the back of the leg and prevent damage if the table is
moved.
Connect the power and power the computer and screen.
Adjust the light dimmer to the desired level.
