Command access LLP-UL-M KIT User manual

A. B. C.
D.
D. E.
Kit Includes Tools Required
#2 Phillips head screwdriver
Motor Mount w/ MM4 series Module
2- ALLEN SCREWS
1- 8’ Lead w/ VD Connector
1-Allen Wrench 3/32
1- Push & go connector
A.
B.
C.
D.
E.
Additional
Information
LLP-UL-M KIT
INSERT Instructions
The LLP-UL-M-KIT is a field installable motorized latch pullback kit for the Hager 4500,
LSDA9000 and Lawrence 8000 series.
#20227_E
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002

PTS Video
Click or Scan
Step 1- Press the device push pad to the desired setting. (this can be fully depressed or less than fully
depressed).
Step 2- While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3- Continue to keep pad depressed, the device will beep 6 times, roughly 5 seconds. After the beeps
have stopped, release the pad and now the adjustment is complete. If not to your liking repeat the
three steps. That’s all there is to it.
Setting PTS
2 Beeps
3 Beeps
5 Beeps
6 Beeps
Beeps Explanation Solution
Over Voltage
Under Voltage
Forced Release
Push pad is depressed. Device
is re-adjusting
Over-travel or mechanical obstruction
> 28V unit will shut down. Check voltage & adjust to 24 V.
< 22V unit will shut down. Check voltage & adjust to 24 V.
Device will automatically re-engage within 5 seconds.
Check to make sure the push pad is not stuck or catching
on anything.
If mechanical obstruction, remove & push pad down until beeping stops
to reset. If no obstruction, the pad may have been pushed in too far
during PTS calibration. Recalibrate with the pad slightly out. If problem
persists, verify the magnet is within 1/4” of the sensor at the end of
travel.
Troubleshooting & Diagnostics
4 Beeps Failed Sensor Verify all 3 sensor wires are installed correctly. Replace sensor if problem
persists by contacting CAT tech support.
**Important Info**
Make sure to set PTS before finishing installation
Technical Information
#20227_E
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
mm4s switches
2
on
on
off STANDARD TORQUE
HIGH TORQUE
PTS PROGRAMMING LOCKED
PTS PROGRAMMING on
off
Average Latch Retraction Current: 2 Amp
Average Holding Current: 250 mA
High Torque Mode
Average Latch Retraction Current: 1 Amp
Average Holding Current: 215 mA
Standard Torque Mode
SPECIFICATIONS
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or access control
units in-between power supply & module
1
7 Beeps

3
Ceiling Tile
Legend
Standard Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
Recommended Power Supplies:
All Command Access exit devices & field installable kits have been thoroughly
cycle tested with Command Access power supplies at our factory.
For more information click here or go to our website
Retrofit 2-pin Connector
The new 2-pin connector is used when retrofitting a older Command or
Von Duprin installation so you can plug in to the exisiting connector.
PUSH N’ GO Connector
New Exisitng
Wire release
Wire access
Electrified Exit Device
Installation Example
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002

4
1
Remove head cover.
1. Remove filler plate.
2.
Remove (2) screws securing base rail to housing.
3. Slide off housing, exposing baserail and push pad.
4.
If your device has dogging will remove it, if
your device doesn’t please skip ahead 3 steps.
5.
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
Flip over the push pad and remove (2) phillips screws
securing dogging assembly to baserail.
6.
Installation Instructions

5
1
2
Remove dogging assembly and place aside.
7. Remove (2) screws from back of the push pad.
8.
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
Remove push pad end cap
9. Depress the push pad to extend dogging hole.
Slide motor mount attaching hook into
dogging hole.
10.
Release push pad and line up holes on baserail
with holes on motor mount underneath.
11.
12
Install (2) screws with allen wrench provided
to secure the motor moun to the baserail.
12.
CONTINUED

6
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
1
2
Re-install the push pad end cap with (2) screws.
13. Slide housing back onto baserail being cautious
not to pitch any wires
14.
While sliding housing back on make sure motor bracket
fits between exsiting groves.
15. Confirm motor has seated properly but see if the
bottom bracket is sitting flush on the baserail.
16.
Attach to power and test to confirm
motor is functioning.
17.
1 2
Re-install (2) screws securing base rail to housing.
18.
CONTINUED

7
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
Re-install filler plate being cautious of wires.
19. Re-install the head cover.
20.
Hook up to power. Depress push pad & set PTS adjustment.
21.
CONTINUED
Setting PTS
Step 1- Select your preferred torque mode (ships in standard torque) Press the device push pad to the
desired setting. (Recommend to fully depress and release 5%, giving the device room for
changing door conditions.)
Step 2- While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3- Continue to keep pad depressed, the device will beep 6 times. After the beeps have stopped,
release the pad and now the adjustment is complete. If not to your liking repeat the three
steps.
mm4s switches
2
on
on
off STANDARD TORQUE
HIGH TORQUE
PTS PROGRAMMING LOCKED
PTS PROGRAMMING on
off
1
