commercial cool CCR77LBB User manual

Page 2

Page 3
CONTENTS
SAFETY INFORMATION
Important Safety Instructions............................................................................................................... 4-5
Refrigerant ......................................................................................................................................................... 5
Grounding Instructions...............................................................................................................................6
Installation Guide ........................................................................................................................................... 7
SET UP & USE
Starting Your New Refrigerator.............................................................................................................8
Parts & Features..............................................................................................................................................9
Operating Instructions.............................................................................................................................. 10
Food Storage....................................................................................................................................................11
Door Reversal Instructions...................................................................................................................12-14
CLEANING & CARE..............................................................................................................................................15
TROUBLESHOOTING & WARRANTY
Before You Call For Service...................................................................................................................... 16
Troubleshooting...............................................................................................................................................17
Limited Warranty ............................................................................................................................................18

Page 4
IMPORTANT SAFETY INSTRUCTIONS
1. Use this appliance only for its intended purpose as described in this use and care
guide.
2. This refrigerator must be properly installed in accordance with the installation
instructions before it is used. See grounding instructions in the installation section.
3. Never unplug your refrigerator by pulling on the power cord. Always grasp the
plug firmly and pull straight out from the outlet.
4. Do not operate any appliance with a damaged cord or plug. Return appliance to
the nearest authorized service facility for examination, repair or adjustment.
5. Unplug your refrigerator before cleaning or before making any repairs. Note: If for
any reason this product requires service, we strongly recommend that a certified
technician performs the service. Component parts shall be replaced with like
components and servicing shall be done by factory authorized service personnel,
so as to minimize the risk of possible ignition due to incorrect parts or improper
service.
6. Do not use any electrical device or any sharp instrument in defrosting your
refrigerator.
DANGER - Risk of fire or explosion. Flammable refrigerant used. DO NOT
use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant
tubing.
7. DANGER – Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take o the doors and leave the shelves in place so that
children may not easily climb inside.
8. After your refrigerator is in operation, do not touch the cold surfaces in the freezer
compartment, particularly when hands are damp or wet. Skin may adhere to these
extremely cold surfaces.
NOTE: If the refrigerator/freezer has been placed in a horizontal or tilted position
for any period of time, wait 24 hours before plugging the unit in.
SAFETY INFORMATION
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of re, electric shock and personal injury :
READ ALL INSTRUCTIONS BEFORE USING THE PRODUCT

Page 5
9. Do not refreeze foods that have been thawed completely. The United States
Department of Agriculture in Home and Garden Bulletin No.69 reads: “…You may
safely refreeze frozen foods that have thawed if they still contain ice crystals or if
they are still cold-below 40˚F.
“…Thawed ground meats, poultry, or fish that have any o-odor or o-color
should not be refrozen and should not be eaten. Thawed ice cream should be
discarded. If the odor or color of any food is poor or questionable, discard it. The
food may be dangerous to eat… Even partial thawing and re-freezing reduce the
eating quality of foods, particularly fruits, vegetables, and prepared foods. The
eating quality of red meats is aected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of its eating quality as you
can.”
10. This refrigerator should not be recessed or built-in in an enclosed cabinet. It is
designed for freestanding installation only.
11. Do not operate your refrigerator in the presence of explosive fumes.
12. WARNING - Risk of fire. Component parts shall be replaced with like components
and servicing shall be done by factory service personnel, so as to minimize the
risk of possible ignition due to incorrect parts/improper service.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
SAFETY INFORMATION
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take o the doors. Leave the shelves in place
so that children may not easily climb inside.
REFRIGERANT
GAS WARNINGS
DANGER - Risk of fire or explosion. Flammable refrigerant used. DO NOT use
mechanical devices to defrost refrigerator. DO NOT puncture refrigerant tubing.
DANGER - Risk of fire or explosion. Flammable refrigerant used. To be repaired
only by trained service personnel. DO NOT puncture refrigerant tubing.
CAUTION - Risk of fire or explosion. Flammable refrigerant used. Consult repair
manual/owner’s guide before attempting to service this product. All safety
precautions must be followed.
CAUTION - Risk of fire or explosion. Dispose of property in accordance with
federal or local regulations. Flammable refrigerant used.
CAUTION - Risk of fire or explosion due to puncture of refrigerant tubing;
Follow handling instructions carefully. Flammable refrigerant used.

Page 6
GROUNDING INSTRUCTIONS
ELECTRICAL REQUIREMENTS
The electrical requirements are a 115 volt 60 Hz, AC only, 15 amp. It is recommended
that a separate circuit serving only the product be provided. The product is equipped
with a 3-wire cord having a 3-prong grounding plug. It must be plugged into a wall
receptacle that is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces risk of electric shock by providing an escape wire for the electric current. The
cord provided with this appliance is equipped with a grounding wire and a grounding
plug. The plug must be plugged into an outlet that is properly installed and grounded.
Avoid the use of three prong adapters or cutting o the third grounding prong in
order to accommodate a two prong outlet. This is a dangerous practice since it
provides no eective grounding for the refrigerator and may result in shock hazard.
Consult a qualified electrician or serviceman if:
1) The grounding instructions are not completely understood.
2) You are unsure that the appliance is properly grounded.
3) You have any questions about the grounding or electrical instructions.
POWER SUPPLY CORD
1. Avoid the use of an extension cord because of potential safety hazards under
certain conditions. Have a qualified electrician or serviceman install an outlet near
the appliance.
2. If it is absolutely necessary to use longer cord sets or an extension cord, extreme
care must be exercised.
a) Use only a grounding type 3-wire extension cord that has a 3-blade grounding
plug and a 3-slot receptacle that will accept the plug on the appliance.
b) The marked electrical rating of the cord set or extension cord must equal to or
greater than the electrical rating of the appliance. The longer cord should be
arranged so that it will not drape over the counter top or table top where it can
be pulled on by children or tripped over unintentionally.
NOTE: Neither W Appliance nor the dealer can accept any liability for damage to
the product or personal injury resulting from failure to observe the electrical
connection procedures.
WARNING
Improper use of the grounding plug can result
in a risk of electric shock.
SAFETY INFORMATION

Page 7
SAFETY INFORMATION
INSTALLATION GUIDE
1. Unpack your refrigerator by removing all packaging materials like carton, base,
foams, adhesive tape, etc.
2. Remove all accessories, internal packaging material used to hold shelves, ice tray,
etc. in place.
3. Clean the remains of all adhesive tape used and remove all printed material
supplied.
4. Install the refrigerator in a convenient location away from extreme heat and
cold. Allow sucient clearance between the refrigerator and side wall so the
door(s) will open without obstruction. Refrigerator is not designed for recessed
installation.
5. The floor on which the refrigerator should be placed must be flat, hard, solid, and
even. The refrigerator should not be placed on any soft material such as foam,
plastic, etc.
6. To level your refrigerator, use the two leveling legs located on the bottom front
of your refrigerator. Adjust by turning the legs counterclockwise to raise or
clockwise to lower your refrigerator. The door will close easier if the leveling legs
are extended.
7. The following are recommended minimum clearances around the refrigerator for
proper air circulation:
Sides: 3/4” (19mm)
Top: 2” (50mm)
Back: 2” (50mm)
Proper air circulation will help your refrigerator work at maximum eciency.
NOTE: The appliance must be correctly connected to the power supply.
CAUTION
Care should be taken during the handling, moving and use of the freezer to avoid
damaging the refrigerant tubing or increasing the risk of a leak
WARNING
It is important to keep the power cord away from the compressor at the
back of the refrigerator during operation. The compressor can reach a high
temperature and could cause serious damage to the power cord

Page 8
PROTECTION FROM HEAT AND MOISTURE
• Do not install your refrigerator in any location where heavy moisture is present or if
the location is not properly insulated. This refrigerator is not designed to operate in
temperature setting below 50°F.
• Location for the refrigerator should be on a hard surface and away from direct
sunlight and heat source, e.g., radiators, baseboard heaters, cooking appliances, etc.
STARTING YOUR NEW REFRIGERATOR
After cleaning your refrigerator thoroughly. Wipe the outside with a soft dry cloth, the
interior with a clean moist cloth.
1. Insert the power supply cord into the socket.
2. Turn the thermostat dial to an initial setting of “5” for 15-20 minutes.
NOTE: · As the door gets pressed in during shipping, the gasket may have to be
reset. This is done to prevent the cool refrigerated air from escaping. If there
is a gap between the door gasket and the cabinet, set the gasket by gently
pulling it out of the seal gap.
SET UP & USE

Page 10
SET UP & USE
OPERATION INSTRUCTIONS
TEMPERATURE CONTROL
NOTE: • If the refrigerator/freezer has been placed in a horizontal or tilted position for
any period of time wait 24 hours before plugging the unit in.
• The settings on the temperature are 0,1,2,3,4,5. Adjust the temperature
control to the setting that best suits your needs. The setting of “3” should be
appropriate for home use.
• Turning the temperature to “0” position will shut o the cooling cycle, but
does not turn o the electrical power to the unit.
NOTE: · Wait 3-5 minutes before restarting if you unplug the refrigerator. The unit
may fail to operate properly if restarted too quickly.
· If the ambient temperature is too high, the refrigerator may not reach the
desired target temperature.
· Large amounts of food will lower the cooling eciency of the appliance.
· Do not place food on the air outlet. Leave space for airflow.
· If you choose to change the thermostat setting, adjust thermostat control one
increment at a time. Allow several hours for temperature to stabilize between
adjustments.

Page 11
SET UP & USE
FOOD STORAGE
When storing fresh food that is not
prepackaged, be sure to wrap or store
food in airtight and moisture proof
material unless otherwise noted. This will
ensure proper shelf life and prevent the
transfer of odors and tastes.
• Wipe containers before storing to avoid
needless spills.
• Eggs should be stored in an upright
position in their original carton to
maximize shelf life.
• Fruit should be washed and dried, then
stored in sealed plastic bags before
storing in the refrigerator.
• Vegetables with skins should be stored
in plastic bags or containers
• Leafy vegetables should be washed
and drained and then stored in plastic
bags or containers.
• Hot food should be allowed to cool
before storing. This will prevent
unnecessary energy use.
• Fresh seafoods should be used the
same day as purchased
• When storing meats in the fresh food
section, keep the original packaging or
rewrap as necessary.
FREEZER COMPARTMENT
• To release frozen ice cube tray from
the bottom of the compartment, pour
warm water around it. Boiling water
should not be used as it can damaged
the interior cabinet. Metal objects,
such as, screwdrivers or sharp knives
can damage and puncture the cooling
system tubing. Do not wash the ice
cube tray in a dishwasher; only wash in
lukewarm water.
REFRIGERATOR AND
FREEZER INTERIOR SHELF
1. Carefully tilt the shelf up and slide
forward until the shelf has been
completely removed.
2. Slide the shelf back to replace.
REPLACING THE INTERIOR
LIGHT BULB
Before replacing the light bulb, unplug
the refrigerator
1. To remove the light bulb cover, pull it
outward by squeezing the tabs at the
top and bottom of the light bulb cover.
2. Make sure the light bulb is not too hot
to avoid burns before unscrewing the
light bulb.
3. Replace the bulb with a 10 watt
appliance light bulb.
4. Replace the light bulb cover.
WARNING
Before changing the light bulb, set
temperature control to “0” and unplug
the unit from the wall receptacle.

Page 12
DOOR REVERSAL INSTRUCTIONS
CAUTION:
To avoid personal injury to yourself and/or property, we recommend someone assist
you during the door reversal process.
Make sure appliance is disconnected from outlet.
SET UP & USE
1. Use a at head screwdriver to remove
the top hinge cover.
2. Loosen and remove the 3 screws
holding the top hinge in place.
3. Remove the top hinge and carefully remove the door.
4. Remove the hole plugs from the opposite side and insert them in the screw holes
of the 3 removed screws.
5. The door stoppers for the left and right side of the door are dierent, so a door
stopper for the door reversal is included with the unit (located in the plastic bag).
Remove existing door stopper on the bottom of the top door by removing the
screw.
Install the door stopper that came with the unit on the opposite side with the screw.
NOTE: If the door opening will be reversed again in the future, keep the door stopper
in a safe place.

Page 13
6. Remove the 2 screws of the middle hinge.
7. Remove the middle hinge. Lift o the bottom door and gently set it aside.
8. Remove the hole plugs and insert them in the holes of the removed screws.
9. Remove any loose items in the refrigerator and carefully place it on its back.
10. Remove the bottom hinge by removing the leg and the 4 screws. Remove the
hinge pin, nut washer and leg from the front hole of the bracket.
11. Remove the hole plugs, screw and the leveling leg from the opposite side of the
cabinet and install in the holes of the previously removed screws.
SET UP & USE
2 screws
middle
hinge

Page 14
SET UP & USE
12. Turn over the bottom hinge bracket so the flat
edge is facing the outer left side of the unit.
Reinstall the pin, nut and washer into the bracket.
Re-Insert the leg in the front hole of the bracket
and the leg in the middle hole.
13. Align the door to the cabinet and secure it with
the bottom hinge pin and bracket by inserting
the 4 screws into the holes. Tighten the screws.
Make sure the leg is tightened in the front hole of
the bracket.
14. Align the bottom door and the cabinet. Reinstall the bottom door with the lower
hinge bracket. Tighten the screws. Make sure the legs are tightened.
15. Reinstall the middle hinge. Insert the hinge pin on the top of the lower door and
reinstall using the 2 previously removed screws.
16. Insert the top refrigerator door onto the hinge pin of the middle hinge. Reinstall
the top hinge bracket with the 3 previously removed screws.
17. Make sure the top of the door is aligned with the cabinet and provides a tight seal
with the gasket before tightening screws.
Install the top hinge cover by aligning the back of the cover first and pushing
down.
DOOR ALIGNMENT
If either door is not aligned properly and does not provide a tight seal with the
gasket, loosen the screws on the hinges on top of the door. Reposition the door and
retighten all the screws.

Page 15
VACATION AND MOVING
CARE
• When going on vacation, it is best
that you empty all the food from
your refrigerator and freezer. Set the
temperature dial to “0” and unplug
the refrigerator. Clean the unit as per
“Cleaning Method” and leave the
door open to remove any odors.
• When travelling or moving the
refrigerator, always transport the unit
vertically. Moving the unit on its sides
may damage the refrigerator and/or
its compressor.
ENERGY SAVING TIPS
• The refrigerator should be located in
the coolest area of the room, away
from heat-producing appliances
or heating ducts, and out of direct
sunlight.
• Let hot foods cool to room
temperature before placing in
the refrigerator. Overloading the
refrigerator forces the compressor to
run longer and thus increase energy
consumption. Food that refrigerates
slowly may lose quality or spoil.
• Be sure to wrap food properly, and
wipe containers dry before placing in
the refrigerator.
• The shelves should not be lined with
aluminum foil, wax paper, or paper
towels. This will interfere with cold air
circulation, making the refrigerator
less ecient.
• Organize food to reduce door
openings and extended searches.
Remove as many items as needed at
one time, and close the door as soon
as possible.
HOW TO DEFROST
(Refer to Fig A)
• For maximum energy eciency,
defrost freezer section whenever
frost accumulates to a thickness of
1/4” or more on freezer walls. Note
that frost tends to accumulate more
during the summer months.
• To defrost freezer, remove food
and ice cube tray from the freezer
section. Turn temperature control dial
to 0 position. Defrosting may take a
few hours. To speed up defrost time,
keep the door open and place a bowl
of warm water in the freezer.
• During the defrost, water will
accumulate. Use a towel to wipe o
excess dripping water. Do not leave
unattended.
• After defrosting, empty and wipe
down the interior of the freezer. You
may now reset your refrigerator to
the desired temperature and return
food.
NOTE: · In case you want to speed up the
defrosting, you may put a bowl of
warm water (about 122°F) into the
refrigerator.
· Do not heat the evaporator directly
with hot water or hair dryer while
defrosting. Doing so will damage the
freezer compartment.
· Never use a sharp or metallic
instrument to remove frost as it may
damage the refrigerator and puncture
the cooling coils. It will also void the
warranty.
CLEANING AND CARE
Fig. A

Page 16
TROUBLESHOOTING & WARRANTY
BEFORE YOU CALL FOR SERVICE
IF THE UNIT FAILS TO OPERATE:
A) Check to make sure that the unit is plugged in securely. If it is not, remove the
plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to
be operating properly, test the outlet with another appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE PRODUCT YOURSELF.
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
W Appliance Co. Customer Satisfaction Center at
855-855-0294 or [email protected].
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE

Page 17
TROUBLESHOOTING & WARRANTY
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Refrigerator does not
work
A. Refrigerator is not
switched on
B. Unit is not plugged in or
is loose
C. Fuse has blown or is
defective
D. Wall power socket is
defective
A. Turn on the temperature
control dial. It may be in the
OFF, “0” position
B. Plug in the refrigerator
C. Check fuse, replace if
necessary
D. To be corrected by a
qualied electrician
The food is too cold A. Temperature is not
properly adjusted
A. Set the temperature control
dial to a warmer setting
The food is too warm A. Temperature is not
properly adjusted
B. Door was open for an
extended period
C. A large quantity of warm
food was placed in the
refrigerator within the last
24 hours
D. The refrigerator is near a
heat source
A. Set the temperature control
dial to a cooler setting
B. Open the door only as long
as necessary. Check door
gasket for proper seal
C. Set the temperature control
dial to a colder setting
temporarily
D. Please look in the
“Protection From Heat and
Moisture” section
Heavy build-up of frost,
possibly also on the door
seal
NOTE: This is normal
during high humidity
periods. Frequent door
openings will also cause
heavy frost buildup
A. Door seal is not air-tight
(possibly after reversing
the door)
A. Carefully warm the leaking
sections of the door gasket
with a hair dryer (on a cool
setting). At the same time,
shape the warmed door
seal by hand such that it sits
correctly
Popping or cracking
sounds
A. When compressor comes
on
A. This is a normal sound of
coolant owing through
condenser coils
Refrigerator door does not
shut properly
A. The refrigerator door is
not properly aligned
B. Possible blockage from
food containers, shelves,
bins, etc.
A. Re-align the refrigerator
door. Refer to the “Door
Alignment” section
B. Ensure nothing is blocking
the door
Refrigerator has an odor A. Foods not properly
sealed
B. Interior needs cleaning
A. Removed any contaminated
food
B. Please refer to “Cleaning
and Care” section
TROUBLESHOOTING
Troubleshoot your problem by using the chart below. If the refrigerator still does
not work properly, contact W Appliance Co. customer service center or the nearest
authorized service center. Customers must never troubleshoot internal components.

Page 18
TROUBLESHOOTING & WARRANTY
LIMITED WARRANTY
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to W Appliance Co. at 855-855-0294
from the USA or Puerto Rico.
W Appliance Co. warrants to the original purchaser
that the product will be free from defects in material,
parts and workmanship for the period designated for
this product. The warranty commences the day the
product is purchased and covers up to a period of
1 year (12 months) for labor/1 year (12 months) for
parts (manufacturing defects only)/carry in service/
and a total of 2 years (24 months) for compressor
part only. W Appliance Co. agrees that it will, at its
option, replace the defective product with either a
new or remanufactured unit equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply to the
below:
1. If the appearance or exterior of
the product has been damaged or
defaced, altered or modied in design or
construction.
2. If the product original serial number
has been altered or removed or cannot
be readily determined.
3. If there is damaged due to power line
surge, user damage to the AC power
cord or connection to improper voltage
source.
4. If damage is due to general misuse,
accidents or acts of God.
5. If repair attempts are done by
unauthorized service agents, use of
parts other than genuine parts or parts
obtained from persons other than
authorized service companies.
6. On units that have been transferred
from the original owner.
7. On products that have been purchased
as refurbished, like new, second-hand, in
a “As-Is” or “Final Sale” terms.
8. To products used in a commercial or
rental setting.
9. To products used in settings other than
ordinary household use or used other
than in accordance with the provided
instructions.
10. To damages for service calls for
improper installations.
11. To glass parts and other accessory items
that are included with the unit.
12. Transportation and shipping costs
associated with the replacement of the
unit.
13. Food loss for loss due to product
failure or delay in service, repair or
replacement.
14. Service calls to instruct you how to use
your product.
15. Service calls to repair or replace the
house fuse, reset the circuit breaker or
correct the wiring in the house.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; W Appliance Co. SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specic legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
855-855-0294 to create a ticket for exchange/repair.
Please make sure to provide the date of purchase,
model number and a brief description of the problem.
Our customer service representative will contact you
or send detailed return instructions.
W Appliance Co. does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or tness for a
particular purpose other than the purpose identied within this
user’s manual. W Appliance Co. has made every effort to ensure
that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information
in this user’s manual is subject to change without notice and
does not represent a commitment on the part of W Appliance
Co.. W Appliance Co. reserves the right to make improvements
to this user’s manual and/or to the products described in this
user’s manual at any time without notice. If you nd information
in this manual that is incorrect, misleading, or incomplete, please
contact us at 855-855-0294.
W Appliance Co.
1356 Broadway
New York, NY 10018

© 2021 Commercial Cool is a W Appliance Company.
All Rights Reserved.
