Compact Industrial RS-232 Device Server
(RS-232 to Ethernet / Modbus RTU to Modbus TCP Converter)
Part Number: DVS-232-2
Https://www.CommFront.com
Revision: 1.0 www.CommFront.com Page 2 of 4
■ INTRODUCTION
The DVS-232-2 is a compact, rugged, industrial-grade RS-232 device server that supports one
channel bi-directional RS-232 to Ethernet conversion which can be used to transmit serial data
over Ethernet and TCP/IP network. The applications of the DVS-232-2 include acting as an RS-232
to Ethernet converter or a Modbus RTU to Modbus TCP protocol converter; controlling RS-232
serial devices from remote Modbus TCP software or Modbus RTU master via Ethernet network;
making a wide variety of M2M communication applications possible by enabling client access
independent of any operating system or proprietary protocol; extending RS-232 serial
communication distance over Ethernet network; and converting conventional serial data network
into TCP/IP network. The DVS-232-2 was designed for harsh industrial environments and
withstands a wide temperature range of -40ºF to 185ºF (-40ºC to 85ºC) and is equipped with
15kV ESD and 600W surge protection. The unit supports TCP and UDP for both server and client
modes, and it features static IP and DHCP for minimizing configuration errors caused by manual
entries. The DVS-232-2 features auto-negotiation for 10 or 100M data rates, and it also supports
MDI and MDI-X (auto-crossover); no DIP switch or jumper settings are required.
■ FEATURES
Compact, rugged, industrial-grade RS-232 device server
RS-232 to Ethernet converter or Modbus RTU to Modbus TCP protocol converter
Designed for harsh industrial environments (DIN-Rail mounting)
Easy configuration via AT commands (RS-232) or built-in web server
Supports static IP and DHCP; supports TCP, UDP and Httpd Client modes
Supports serial baud rates from 600 bps to 460 Kbps; RFC2217 compliant
Auto-Negotiation for 10/100M data rates; MDI and MDI-X auto-crossover
15kV ESD and 600W surge protection
Operating temperature: -40ºF to 185ºF (-40ºC to 85ºC)
Surface Mount Technology manufactured to RoHS and ISO-9001 standards
Compliance: CE, FCC
5-Year manufacturer’s warranty
■ SPECIFICATIONS
Compatibility: EIA/TIA RS-232C; IEEE802.3
Power Source: 5 to 36 VDC
Power Consumption: Less than 1W
Confi
g
uration: AT commands
(
RS-232
)
or built-in web server
Ethernet Network: 10/100M Auto-Ne
g
otiation; MDI-X auto-crossover
Network Protocols: IPv4; TCP/UDP/HTTP; ARP; ICMP
Network Buffer Size: TX: 6KB; RX: 4KB
IP Settings: Static IP or DHCP
Operating Modes: TCP Server & Client; UDP Server & Client; Httpd Client
Max. Number of Client Connections: 8
Serial Port: 600 bps to 460 Kbps; RFC 2217 compliant
Serial Port Buffer Size: RX: 2KB
Communication Protocols: RS-232C; Modbus RTU; Modbus TCP
Protection: Up to 15kV ESD; 600W Surge Protection
Distances: Ethernet: 328ft (100m); RS-232: 16ft (5m)
Connectors: Ethernet: 1x RJ45; 1x 3-Way Terminal Block (T, R, G);
Power: 1x 2-Way Terminal Block
Dimensions (L x W x H): 4.3x1.1x2.6 in (110x28x65 mm)
Weight: 0.2 lb (90 g)
O
p
eratin
g
Tem
p
erature: -40ºF to 185ºF
(
-40ºC to 85ºC
)
O
p
eratin
g
Humidit
y
: 5% to 95% Non-condensin
g
Compact Industrial RS-232 Device Server
(RS-232 to Ethernet / Modbus RTU to Modbus TCP Converter)
Communications made easy
Part Number: DVS-232-2

Revision: 1.0 www.CommFront.com Page 3 of 4
■ APPLICATIONS
APPLICATION 1: DEVICE SERVER (M2M)
APPLICATION 2: SERIAL OVER ETHERNET
APPLICATION 3: MODBUS GATEWAY / MODBUS PROTOCOL CONVERTER
APPLICATION 4: CONVERTING RS-232 NETWORK INTO TCP/IP
Revision: 1.0 www.CommFront.com Page 4 of 4
■ CONNECTIONS
DVS-232-2 CONNECTION DIAGRAM
■ LED INDICATORS
PWR Indicator
ON: Power supply is on
OFF: Power supply is off
ACT Indicator
Flashing: The unit is in working condition
OFF: The unit is not working
TX Indicator
Flashing: Serial port is transmitting data
OFF: Serial port is idle
RX Indicator
Flashing: Serial port is receiving data
OFF: Serial port is idle
10/100M Indicator
ON: The unit is connected to a
100M network
OFF: The unit is connected to a
10M network or is disconnected
Link/Act Indicator
Flashing: Sending/receiving data
OFF: No network connection
■ FACTORY SETTINGS
IP Settings: Static IP
IP Address: 192.168.1.200
Subnet Mask: 255.255.255.0
Gatewa
y
: 192.168.1.254
COM Port Settings: 115.2Kbps, 8, N, 1
Modbus: Modbus RTU <-> Modbus TCP (OFF)
User Name: admin
Password: superuser
Note: To restore factory settings, press the “reset” button for 5 to 15 seconds.
■ TROUBLESHOOTING
Make sure the power supply (5 to 36 VDC) is connected and turned on.
Check LEDs and make sure connections are correct.
Be sure that the DVS-232-2 and your PC are at the same sub network and the COM port settings
match with each other (see “Factory Settings” table).
Press the “reset” button for 5 to 15 seconds to restore factory settings, if necessary.
Test with CommFront’s Serial-TCP/IP software (the free version can be downloaded from:
https://www.commfront.com/pages/downloads):
1) Set Serial-TCP as a TCP client and connect to device server’s TCP port (act as a TCP server).
2) Send Hex commands to DVS-232-2’s TCP port from the Serial-TCP’s “Packet Sender” tool.
When the command reaches the device server’s TCP port, it will be forwarded to device server’s
COM port and come back to Serial-TCP software’s COM port, thus creating an infinite loop. Click
the “De-activate” button to stop the loop.
