Supermicro SUPERSERVER 6015V-T User manual

SUPER
SUPERSERVER 6015V-T
SUPERSERVER 6015V-TLP
USER’S MANUAL
Revision 1.0c
®

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2007 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America
Manual Revision 1.0c
Release Date: August 7, 2007
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
SUPER MICRO COMPUTER reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and documenta-
tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any
medium or machine without prior written consent.
IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE
OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING
OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for
all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the SuperServer 6015V-
T/6015V-TLP. Installation and maintenance should be performed by experienced
technicians only.
The SuperServer 6015V-T/6015V-TLP is a dual processor 1U rackmount server
based on the SC811TQ-520/SC811TQ-280 server chassis and the Super X7DVL-
E/X7DVL-i serverboard. The X7DVL-E/X7DVL-i supports dual Intel®Xeon®
5100/5000 series processors. Please refer to our web site for updates on supported
processors. Note: the low power configuration of the 6015V-TLP means it supports
5300 or 5100 low-voltage series processors only.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the Super X7DVL-E/X7DVL-i
serverboard and the SC811TQ-520/SC811TQ-280 chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer 6015V-
T/6015V-TLP into a rack and check out the server configuration prior to powering
up the system. If your server was ordered without the processor and memory
components, this chapter will refer you to the appropriate sections of the manual
for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
iii
Preface

SUPERSERVER 6015V-T/6015V-TLP User's Manual
iv
Chapter 4: System Safety
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 6015V-T/6015V-TLP.
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X7DVL-E/X7DVL-i serverboard,
including the locations and functions of connectors, headers and jumpers. Refer
to this chapter when adding or removing processors or main memory and when
reconfiguring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC811TQ-520/SC811TQ-280 1U
rackmount server chassis. You should follow the procedures given in this chapter
when installing, removing or reconfiguring Serial ATA or peripheral drives and when
replacing system power supply units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS POST Messages
Appendix B: BIOS POST Codes
Appendix C: Intel HostRAID Setup Guidelines
Appendix D: Software Installation
Appendix E: System Specifications

v
Preface
Notes

vi
Table of Contents
Preface
About This Manual ...................................................................................................... iii
Manual Organization ................................................................................................... iii
Chapter 1: Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Serverboard Features ..................................................................................... 1-2
1-3 Server Chassis Features ................................................................................ 1-5
1-4 Contacting Supermicro ................................................................................... 1-6
Chapter 2: Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System ................................................................................... 2-1
2-3 Preparing for Setup ........................................................................................ 2-1
Choosing a Setup Location ...................................................................... 2-2
Rack Precautions ..................................................................................... 2-2
Server Precautions ................................................................................... 2-2
Rack Mounting Considerations ................................................................. 2-3
2-4 Installing the System into a Rack ................................................................... 2-4
2-5 Checking the Serverboard Setup ................................................................... 2-8
2-6 Checking the Drive Bay Setup ..................................................................... 2-10
Chapter 3: System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons .................................................................................... 3-1
Reset ........................................................................................................ 3-1
Power ....................................................................................................... 3-1
3-3 Control Panel LEDs ........................................................................................ 3-2
Overheat/Fan Fail ................................................................................... 3-2
NIC2 ......................................................................................................... 3-2
NIC1 ......................................................................................................... 3-2
HDD .......................................................................................................... 3-2
Power ....................................................................................................... 3-3
3-4 Serial ATA Drive Carrier LEDs ........................................................................ 3-3
Chapter 4: System Safety
4-1 Electrical Safety Precautions .......................................................................... 4-1
4-2 General Safety Precautions ........................................................................... 4-2
SUPERSERVER 6015V-T/6015V-TLP User's Manual

4-3 ESD Precautions ............................................................................................ 4-3
4-4 Operating Precautions .................................................................................... 4-4
Chapter 5: Advanced Serverboard Setup
5-1 Handling the Serverboard .............................................................................. 5-1
5-2 Processor and Heatsink Installation ............................................................... 5-2
5-3 Connecting Cables ......................................................................................... 5-5
Connecting Data Cables .......................................................................... 5-5
Connecting Power Cables ....................................................................... 5-5
Connecting the Control Panel .................................................................. 5-6
5-4 I/O Ports ......................................................................................................... 5-7
5-5 Installing Memory ........................................................................................... 5-7
5-6 Adding PCI Cards ........................................................................................... 5-8
5-7 Serverboard Details ........................................................................................ 5-9
X7DVL-E Layout ...................................................................................... 5-9
X7DVL-i Layout ...................................................................................... 5-10
X7DVL-E/X7DVL-i Quick Reference ...................................................... 5-11
5-8 Connector Definitions ................................................................................... 5-12
ATX Power Connector ........................................................................... 5-12
Processor Power Connector .................................................................. 5-12
NMI Button ............................................................................................. 5-12
Power LED ............................................................................................. 5-12
HDD LED ............................................................................................... 5-13
NIC1 LED ............................................................................................... 5-13
NIC2 LED ................................................................................................ 5-13
Overheat/Fan Fail LED .......................................................................... 5-13
Power Fail LED ...................................................................................... 5-13
Reset Button .......................................................................................... 5-14
Power Button .......................................................................................... 5-14
Universal Serial Bus (USB0/1) ............................................................... 5-14
Chassis Intrusion .................................................................................... 5-14
Serial Ports ............................................................................................. 5-15
Fan Headers .......................................................................................... 5-15
LAN1/2 Ethernet Ports ........................................................................... 5-15
ATX PS/2 Keyboard and PS/2 Mouse Ports ......................................... 5-15
Extra USB Headers ................................................................................. 5-16
Alarm Reset ........................................................................................... 5-16
SGPIO .................................................................................................... 5-16
Wake-on-LAN ......................................................................................... 5-17
vii
Table of Contents

viii
Wake-on-Ring ......................................................................................... 5-17
Power SMB Connector .......................................................................... 5-17
SMB ........................................................................................................ 5-17
5-9 Jumper Settings ............................................................................................ 5-18
Explanation of Jumpers ......................................................................... 5-18
CMOS Clear ........................................................................................... 5-18
VGA Enable/Disable ............................................................................... 5-18
LAN1/2 Enable/Disable .......................................................................... 5-19
PCI Slots to SMB ................................................................................... 5-19
Power Force On Enable/Disable ........................................................... 5-19
PWR Supply Failure Detect ................................................................... 5-19
Watch Dog Enable/Disable .................................................................... 5-20
Power LED/Speaker ............................................................................... 5-20
5-10 Onboard Indicators ....................................................................................... 5-20
LAN1/LAN2 LEDs .................................................................................. 5-20
Onboard Power LED .............................................................................. 5-21
POST Code LED Indicators ................................................................... 5-21
System Status LED ................................................................................ 5-21
5-11 Parallel Port, Floppy, IDE and SATA Drive Connections ............................. 5-22
Parallel Port ............................................................................................ 5-22
Floppy Connector ................................................................................... 5-23
IDE Connector ........................................................................................ 5-24
SATA Ports ............................................................................................. 5-24
Chapter 6: Advanced Chassis Setup
6-1 Static-Sensitive Devices ................................................................................. 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 System Fans ................................................................................................... 6-3
System Fan Failure .................................................................................. 6-3
Replacing System Cooling Fans .............................................................. 6-3
6-4 Drive Bay Installation/Removal ...................................................................... 6-4
Accessing the Drive Bays ........................................................................ 6-4
Serial ATA Drive Installation ..................................................................... 6-4
DVD-ROM Drive Installation .................................................................... 6-6
6-5 Power Supply ................................................................................................. 6-7
Power Supply Failure ............................................................................... 6-7
Replacing the Power Supply .................................................................... 6-7
SUPERSERVER 6015V-T/6015V-TLP User's Manual

Chapter 7: BIOS
7-1 Introduction ..................................................................................................... 7-1
7-2 Running Setup ................................................................................................ 7-2
7-3 Main BIOS Setup ............................................................................................ 7-2
7-4 Advanced Setup ............................................................................................. 7-7
7-5 Security Settings ........................................................................................... 7-24
7-6 Boot Setup .................................................................................................... 7-25
7-7 Exit Options .................................................................................................. 7-26
Appendices
Appendix A: BIOS POST Messages
Appendix B: BIOS POST Codes
Appendix C: Intel HostRAID Setup Guidelines
Appendix D: Software Installation
Appendix E: System Specifications
Table of Contents
ix

Notes
SUPERSERVER 6015V-T/6015V-TLP User's Manual
x

Chapter 1
Introduction
1-1 Overview
The Supermicro SuperServer 6015V-T/6015V-TLP is a dual processor, 1U rack-
mount server designed with cutting-edge technology. The 6015V-T/6015V-TLP is
comprised of two main subsystems: the SC811TQ-520/SC811TQ-280 1U chassis
and the X7DVL-E/X7DVL-i serverboard. Please refer to our web site for information
on operating systems that have been certified for use with the 6015V-T/6015V-
TLP.
In addition to the serverboard and chassis, various hardware components may have
been included with the 6015V-T/6015V-TLP, as listed below.
 One (1) slim DVD-ROM drive (DVM-PNSC-824(B))
 Two (2) 10-cm blower fans (FAN-0059)
 Serial ATA (SATA) Accessories:
One (1) SATA backplane (CSE-SAS-810TQ)
Two (2) SATA cables (CBL-0061)
One (1) SATA LED cable (CBL-0157L)
Two (2) SATA drive carriers [MCP-220-00003-02(01)]
 One (1) 64-bit PCI-X riser card (CSE-RR1U-X)
 6015V-TLP only: One (1) PCI-E x8 riser card (CSE-RR1U-EL)
 Rackmount hardware with screws (CSE-PT8):
Two (2) rack rail assemblies
Six (6) brackets for mounting the rack rails in a rack/telco rack
 One (1) CD containing drivers and utilities
 SuperServer 6015V-T/6015V-TLP User's Manual
Note: "B" indicates black.
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 6015V-T/6015V-TLP User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 6015V-T/6015V-TLP lies the X7DVL-E/X7DVL-i, a
dual processor serverboard based upon Intel's 5000V chipset. Below are the main
features of the X7DVL-E/X7DVL-i.
Processor
The X7DVL-E/X7DVL-i has two LGA 771-pin sockets to support two Dual-Core
Intel Xeon 5100/5000 series processors. Please refer to the support section of
our web site for a complete listing of supported processors (http://www.supermicro.
com/support/). Note: Although the X7DVL-i supports 5000 series processors, the
low power configuration of the 6015V-TLP server only allows it to support 5300 and
5100 low-voltage series processors.
Memory
The X7DVL-E/X7DVL-i has six (6) 240-pin DIMM sockets that can support up to
16 GB of ECC FBD (Fully Buffered DIMM) DDR2-667/533 SDRAM. The X7DVL-
E/X7DVL-i's dual-channel memory bus requires modules to be populated in pairs.
All memory modules must be the same size and speed.
Serial ATA
A Serial ATA controller is incorporated into the ESB2 (South Bridge) portion of the
5000V chipset to provide a six-port 3 Gb/s SATA subsystem, which is RAID 0, 1,
10 and RAID 5 supported. The SATA drives are hot-swappable units.
Note: The operating system you use must have RAID support to enable the hot-
swap capability and RAID function of the Serial ATA drives.
PCI Expansion Slots
The X7DVL-E has one x8 PCI-Express slot, one x4 PCI-Express x4 slot, two 64-bit
133/100 MHz PCI-X slots and two 32-bit PCI slots. The X7DVL-i has one x8 PCI-
Express slot, two 64-bit 133/100 MHz PCI-X slots and one 32-bit PCI slot. One
riser card is included with the system to support a single add-on card in a 64-bit
133 MHz PCI slot. (The 6015V-TLP also includes an optional riser card to support
one PCI-Exress x8 add-on card. See Chapter 5 for details.)

Chapter 1: Introduction
1-3
Ethernet Ports
An Ethernet controller is integrated into the ESB2 to support two Gigabit LAN
(Ethernet) ports.
Onboard Controllers/Ports
An onboard IDE controller supports one floppy drive and up to two Ultra ATA 100
hard drives or ATAPI devices. Onboard I/O backpanel ports include one COM port,
two USB ports, PS/2 mouse and keyboard ports, a graphics (monitor) port and two
Gigabit LAN (NIC) ports.
Other Features
Other onboard features that promote system health include voltage monitors, a
chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors, virus protection and BIOS rescue.

1-4
SUPERSERVER 6015V-T/6015V-TLP User's Manual
Figure 1-1 . Intel 5000V Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
USB 2.0
3Gb/S
KUMERAN
PORTS PORT
PORT PORT
PORT
PORT
#0
MCH
(BLACKFORD-VS)
PROCESSOR#2
ESB2
PCI-33MHz
GILGAL
GB LAN FWH
RJ45
RJ45
LPC
COM2
COM1
SIO
W83627
FDD
PCI-Ex4
PCI-X 133
PARALLEL
PORT
IDE
ATA 100
KB
MS
VRM
ISL6306
#2,3
#4 #3
#1,2
#0
VRM
ISL6306
PROCESSOR#1
1067/1333MT/S
1067/1333MT/S
PCI-X SLOT
J12
#6
#2
#2
PCI-Ex8
PCI-X SLOT
J13
#5
J10
#3
PCI-EXP_X8_SLOT
J9
#4
PCI-EXP_X4_IN_X8 SLOT
PCI32_SLOT
J6
#1
HF
USB
#0
#1
#2
#3
#4
PCIE X8
PCIE X4
FBD CHNL0
FBD CHNL1
#1 #1
#0
#0
FBD DIMM
FBD DIMM
SATA
#0
#1
#2
#3
#4
#5
#5
PCI32_SLOT
J11
#2
VGA
ES1000
VGA
CONN
SIMLC IPMI
(5000V)

Chapter 1: Introduction
1-5
1-3 Server Chassis Features
The SuperServer 6015V-T/6015V-TLP is built on the SC811TQ-520/SC811TQ-280
1U rackmount server chassis. The following is a general outline of the main features
of the SC811TQ-520/SC811TQ-280 chassis.
System Power
In the SuperServer 6015V-T, the SC811TQ-520 chassis (6015V-T) includes a single
520W power supply and in the 6015V-TLP, the SC811TQ-280 chassis includes a
single 280W power supply.
Serial ATA Subsystem
For the 6015V-T/6015V-TLP, the SC811TQ-520/SC811TQ-280 chassis was de-
signed to support two Serial ATA hard drives. The Serial ATA drives are hot-swap-
pable units. ATA/100 IDE drives can be alternately supported. Note: The operating
system you use must have RAID support to enable the hot-swap capability of the
Serial ATA drives.
Control Panel
The control panel on the SC811TQ-520/SC811TQ-280 provides important system
monitoring and control information. LEDs indicate power on, network activity, hard
disk drive activity and system overheat conditions. The control panel also includes
a main power button and a system reset button.
Rear I/O Panel
The SC811TQ-520/SC811TQ-280 is a 1U rackmount chassis. Its I/O panel provides
one expansion card slot, one COM port (another is internal), two USB ports, PS/2
mouse and keyboard ports, a graphics port and two Gb Ethernet ports.
Cooling System
The SC811TQ-520/SC811TQ-280 chassis has an innovative cooling design that
features two 10-cm blower system cooling fans. The blower fans plug into a chas-
sis fan header on the serverboard. A fan speed control setting in BIOS allows fan
speed to be determined by system temperature [the recommended setting is 3-pin
(Server)].

1-6
SUPERSERVER 6015V-T/6015V-TLP User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
