Comnet MLS II MLSH041 User manual

LBI-38425A
Maintenance Manual
Service Section
MLS II Highband Two-Way
Mobile Radios
MLSH041

LBI-38425A GENERAL INFORMATION
2
NOTICE!
Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs,
alterations or substitution of recommended parts made by the user to this equipment not approved by the manufacturer could void the user's
authority to operate the equipment in addition to the manufacturer's warranty.
NOTICE!
The software contained in this device is copyrighted by Com-Net Ericsson Critical Radio Systems, Inc.
Unpublished rights are reserved under the copyright laws of the United States.
This manual is published by Com-Net Ericsson Critical Radio Systems, Inc., without any warranty. Improvements and
changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to
programs and/or equipment, may be made by Com-Net Ericsson Critical Radio Systems, Inc., at any time and without
notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose,
without the express written permission of Com-Net Ericsson Critical Radio Systems, Inc.
Copyright ©1990-2000, Com-Net Ericsson Critical Radio Systems, Inc. All rights reserved.

TABLE OF CONTENTS LBI-38425A
3
TABLE OF CONTENTS
Page
1 Description................................................................................................................................................4
2 Initial Adjustment....................................................................................................................................4
2.1 Transmitter Adjustment ...................................................................................................................4
2.2 Receiver Adjustment........................................................................................................................4
2.3 Re-Installation..................................................................................................................................4
3 Maintenance.............................................................................................................................................5
3.1 Preventive Maintenance...................................................................................................................5
3.1.1 Connections.......................................................................................................................5
3.1.2 Electrical System...............................................................................................................5
3.1.3 Mechanical Inspection.......................................................................................................5
3.1.4 Antenna..............................................................................................................................5
3.1.5 Alignment..........................................................................................................................5
3.1.6 Frequency Check ............................................................................................................... 5
3.1.7 Disassembly.......................................................................................................................6
3.2 Driver Replacement .........................................................................................................................6
3.2.1 To Remove Driver HC1.....................................................................................................6
3.2.2 To Replace Driver HC1.....................................................................................................6
3.3 PA Transistor Replacement..............................................................................................................6
3.4 Chip Component Replacement.........................................................................................................8
3.4.1 To Remove Chip Components...........................................................................................8
3.4.2 To Replace Chip Components...........................................................................................8
4 Disassembly Procedure............................................................................................................................9
4.1 To Remove the System Control/Synthesizer Board.........................................................................9
4.2 To Remove the Transmitter/Receiver Board....................................................................................9
4.3 To Remove the Front Panel/Control Unit........................................................................................10
5 Alignment and Troubleshooting Procedures.........................................................................................12
5.1 Synthesizer.......................................................................................................................................12
5.1.1 Test Equipment Required ..................................................................................................12
5.1.2 TX VCO & RX VCO Alignment.......................................................................................13
5.1.3 Transmitter Frequency Adjustment....................................................................................14
5.1.4 Receiver Frequency Adjustment........................................................................................15
5.1.5 Modulation Level Adjustment...........................................................................................15
5.1.6 Audio Check......................................................................................................................15
5.1.7 Audio Output Level Adjustment Procedure.......................................................................16
5.1.8 Control Logic Troubleshooting .........................................................................................17
5.2 Transmitter.......................................................................................................................................18
5.2.1 General Description of Adjustment ...................................................................................18
5.2.2 Measuring Instruments.......................................................................................................18
5.2.3 Transmitter Adjustment Procedure....................................................................................20
5.3 Receiver...........................................................................................................................................23
5.3.1 Receiver Alignment ...........................................................................................................23
5.3.2 Alignment Procedure.........................................................................................................24
5.3.3 Fixed Squelch Adjustment.................................................................................................25
5.3.4 Receiver Test Procedures ..................................................................................................25

LBI-38425A DESCRIPTION AND INITIAL ADJUSTMENT
4
1 DESCRIPTION
The service section contains the information necessary for aligning and troubleshooting
the MLS II (MLSH041) two-way FM mobile radio. In addition, information is provided
for removing and replacing chip components, disassembly procedures and module
replacement procedures.
2 INITIAL ADJUSTMENT
The following adjustments should be made by a certified electronics technician after the
radio has been installed as described in the Installation Manual.
2.1 TRANSMITTER ADJUSTMENT
The transmitter has been adjusted at the factory and should require no readjustment.
However, the antenna length should he adjusted for optimum VSWR, and the frequency
and modulation measured and recorded for future reference. For the complete
transmitter alignment, refer to the Alignment Procedure (see Table of Contents).
2.2 RECEIVER ADJUSTMENT
No initial adjustments to the receiver are required. Refer to the Table of Contents for the
complete receiver alignment.
2.3 RE-INSTALLATION
The MLS II series mobile radios are designed to operate in 12-Volt negative ground
vehicles only. If the mobile radio is moved to a different vehicle, always check the
battery polarity of the new vehicle system.

MAINTENANCE LBI-38425A
5
3 MAINTENANCE
3.1 PREVENTIVE MAINTENANCE
To insure high operating efficiency and to prevent mechanical and electrical failures
from interrupting system operations, routine checks should be made of all mechanical
and electrical parts at regular intervals. Preventive maintenance should include the
following checks:
3.1.1 Connections
Ground connections to the voltage source should be periodically checked for tightness,
Loose or poor connections to the power source will cause excessive voltage drops and
faulty operation. When ground connections are not made directly to the battery, the
connection from the battery to vehicle chassis must be checked for low impedance. A
high impedance may cause excessive voltage drops and alternator noise problems.
3.1.2 Electrical System
Check the voltage regulator and alternator or generator periodically to keep the electrical
system within safe and economical operating limits. Over-voltage is indicated when the
battery loses water rapidly. Usage of 1 or 2 ounces of water per cell per week is
acceptable for batteries in continuous operation. A weak battery will often cause
excessive noise or faulty operation.
3.1.3 Mechanical Inspection
Since mobile units are subject to constant shock and vibration, check for loose plugs,
nuts, screws and parts to make sure that nothing is working loose.
3.1.4 Antenna
The antenna, antenna base, and all contacts should be kept clean and free from dirt or
corrosion. If the antenna or its base should become coated or poorly grounded, loss of
radiation and a weak signal will result.
3.1.5 Alignment
The transmitter and receiver meter readings should be checked periodically, and the
alignment “touched up” when necessary. Refer to applicable Alignment Procedure and
Troubleshooting sheet for typical voltage readings.
3.1.6 Frequency Check
Check transmitter frequency and deviation. Normally, these checks are made when the
unit is first put into operation, after the first six months and once a year thereafter.

LBI-38425A MAINTENANCE
6
3.1.7 Disassembly
To gain access to the transmitter, receiver, and the system control/synthesizer for
servicing, loosen the four screws securing the cover at the rear of the radio. Then pull
the cover out from under the edge of the front panel and lift the cover off.
3.2 DRIVER REPLACEMENT
3.2.1 To Remove Driver HC1
1. Remove the two screws securing HC1 to the printed wire board.
2. Unsolder the four (4) leads bridging HC1 to the printed board while lifting each lead
as they are unsoldered. SERVICE NOTE: These leads are soft and can be bent very
easily.
3. Gently lift up on the module, taking care not to damage the spacer under the module.
SERVICE NOTE: The module may stick to the printed board.
3.2.2 To Replace Driver HC1
1. Position the module properly, aligning the screw holes and leads with the printed
board. Trim leads if necessary (see Figure 1).
2. Replace the two screws securing the driver to the printed board, using a moderate
torque of 5 inch-pounds.
3. Solder the four leads of driver HC1 to the printed board and ground strap.
Figure 1 - Driver Lead Identification
3.3 PA TRANSISTOR REPLACEMENT
WARNING
The PA transistor contains Beryllium Oxide, a TOXIC substance. If the ceramic or
other encapsulation is opened, crushed, broken or abraded, the escaping dust may be
hazardous if inhaled. Use care when replacing the module.

MAINTENANCE LBI-38425A
7
1. Remove the two retaining screws securing PA transistor TR1 to chassis assembly.
2. Unsolder and remove capacitors. Use a desoldering tool as necessary while lifting
the transistor leads with a small screwdriver or pick. Discard old capacitors.
3. Unsolder the emitter, base, and collector leads of the transistor, and remove it from
the printed board.
4. Remove all excess solder from the board, and clean the holes to allow the new
transistor to be positioned properly and the capacitors to fit into proper locations.
Refer to Figure 2 and trim the new transistor leads (if required) to the lead length of
the removed transistor.
5. Apply silicon grease to the back of the replacement transistor and place the transistor
into the mounting slot.
6. Replace the transistor mounting screws using a moderate torque of 5 inch-pounds.
7. Tack solder the four base leads to the printed board, using minimum solder. Then
solder the emitter and collector leads.
8. Install the capacitors into their proper mounting areas, flush to the board.
9. Solder the capacitor bodies to the printed board by first soldering the outside edge.
Then, holding the iron to the outside edge, touch the solder to the inside edge of the
capacitor. Be careful not to create solder bridges at the front and back edges of the
capacitors.
10. Remove any flux left on the board.
Figure 2 - PA Transistor Lead Identification

LBI-38425A MAINTENANCE
8
3.4 CHIP COMPONENT REPLACEMENT
Replacement of chip capacitors should always be done with a temperature controlled
soldering iron, using a controlled temperature of 700°F (371°C). However, DO NOT
touch black metal film of the resistors or the ceramic body of capacitors with the
soldering iron.
NOTE
The metallized end terminations of the parts may be touched with the soldering iron
without causing damage.
3.4.1 To Remove Chip Components
1. Using two soldering irons, heat each end of the chip at the same time until solder
flows and then remove and discard the chip.
2. Remove excess solder with a vacuum solder extractor.
3. Carefully remove the epoxy adhesive and excess flux to prevent damage to the
printed board.
3.4.2 To Replace Chip Components
1. Using as little solder as possible, “tin” one end of the component and one of the pads
on the printed wiring board.
2. Place the “tinned” end of the component on the “tinned” pad on the board and
simultaneously touch the component and the pad with a well “tinned” soldering iron
while pressing the component down on the board.
3. Place the “tinned” soldering iron on the other end of the component and the pad
simultaneously. Apply solder to the top of the end of the component until the solder
starts to flow. Use as little solder as possible while getting a good joint.
4. After the component has cooled, remove all flux from the component and printed
wiring board area with alcohol.
h
The CMOS integrated Circuit devices used in this equipment can be destroyed by static
discharges. Before handling one of these devices, the serviceman should discharge
himself by touching the case of a bench test instrument that has a 3-prong power cord
connected to an outlet with a known good earth ground. When soldering or desoldering
a CMOS device, the soldering iron should also have a 3-prong power cord connected to
an outlet with a known good earth ground. A battery-operated soldering iron may be
used in place of the regular soldering iron.

DISASSEMBLY PROCEDURE LBI-38425A
9
4 DISASSEMBLY PROCEDURE
4.1 TO REMOVE THE SYSTEM CONTROL/SYNTHESIZER BOARD
1. Remove the two (2) screws !securing the top cover (refer to Figure 3). Remove the
top cover. Then disconnect the interconnecting cables.
2. Remove the eight (8) screws "securing the Synthesizer shield. Remove the shield.
3. Remove the three (3) screws #securing the board.
4. Remove the screws $securing regulator and carefully lift up and remove the board.
Figure 3 – Disassembly Procedure (Top View)

LBI-38425A DISASSEMBLY PROCEDURE
10
4.2 TO REMOVE THE TRANSMITTER/RECEIVER BOARD
1. Remove the screws !and %securing the top cover and the bottom cover (refer to
Figures 3 & 4).
2. Disconnect the interconnecting cables and then remove the seven (7) screws &
securing the shield to the board.
3. Disconnect the interconnecting cable. Remove the four (4) screws 'securing the
antenna shield.
4. Remove the two (2) screws (connecting the power supply cable to the board and
turn the cable stopper mounted on the rear of the frame assembly 90 degrees. Lift up
the cable stopper and remove the power supply cable.
5. Remove the two (2) screws )securing power module HC1. Remove the screws *
securing the power transistor TR1.
6. Remove the two (2) screws +securing the board. Carefully lift up and remove the
board.
4.3 TO REMOVE THE FRONT PANEL/CONTROL UNIT
1. Remove the four (4) screws ,securing the front panel to the frame assembly (refer
to Figure 5).
2. Carefully disconnect the speaker cable from the connector on the Control/
Synthesizer board.
3. Separate the front panel from the frame assembly.
4. Carefully disconnect the ribbon cable connecting the Front Panel/Control unit to the
Control/Synthesizer Board at -.
5. Remove the two (2) screws located at ..
6. While pushing the lock tabs at /remove the Control Panel towards the front.

DISASSEMBLY PROCEDURE LBI-38425A
11
Figure 4 – Disassembly Procedure (Bottom View)
Figure 5 – Disassembly Procedure (Front Panel)

LBI-38425A ALIGNMENT AND TROUBLESHOOTING PROCEDURES
12
5 ALIGNMENT AND TROUBLESHOOTING
PROCEDURES
Radio maintenance is facilitated by using the Troubleshooting Procedures and servicing
techniques unique to this radio. The Troubleshooting Procedures are designed to lead
the serviceman rapidly to the defective component or circuit.
Troubleshooting procedures are provided for most major problems that might arise in the
System Control/Synthesizer Board, the Transmitter, and the Receiver.
5.1 SYNTHESIZER
The Alignment and Troubleshooting procedures for Synthesizer Circuitry on System
Control/Synthesizer Board CMC-552 are as follows:
5.1.1 Test Equipment Required
•Audio Oscillator
•Deviation Monitor
•Oscilloscope
•Frequency Counter
•RF Wattmeter (50 ohms, 100 W)
•VTVM
•Digital Voltmeter
•Power Supply, 13.6 VDC regulated
Measuring System
J701-4
J1
J701-3
P1
RC-5429B
Audio
Oscillator
Power Supply
13.6 Vdc
Radio Coupler
(50Ω)
Deviation
Monitor Oscilloscope
Frequency
Counter
RF wattmeter

ALIGNMENT AND TROUBLESHOOTING PROCEDURES LBI-38425A
13
5.1.2 TX VCO & RX VCO Alignment
STEP METERING POINT TUNING CONTROL METER READING PROCEDURE
1 TP201 Control
Voltage
Monitor
CV202 4.0 VDC
7.0 VDC
In case that highest transmit
frequency is < 156.8 MHz.
Select lowest frequency transmit
channel. With 50 ohm load on the
antenna connector J1, key the
radio. Monitor TP201 with digital
voltmeter and tune CV202 for 4.0
VDC ±0.1 V. Unkey the radio.
In case that highest transmit
frequency is 156.8 MHz. Select
highest frequency transmit
channel. With 50 ohm load on the
antenna connector J1, key the
radio. Monitor TP201 with a
digital voltmeter and tune CV202
for 7.0 VDC ±0.1 V. Unkey the
radio.
2 TP201 CV201 7.0 VDC Select the highest frequency
receive channel. Monitor TP201
with digital voltmeter and tune
CV201 for 7.0 VDC ±0.1 V.
3 TP201 3.5-7.5 VDC Select lowest frequency channel.
Voltage should be between 3.5 –
7.5 VDC transmit and receive for
lowest and highest frequency
channels.
4 J201 +2 to +8 dBm RX/EX injection level should be
between +2 and +8 dBm.
NOTE: Refer to Figure 6 for location of tuning and adjustment controls.

LBI-38425A ALIGNMENT AND TROUBLESHOOTING PROCEDURES
14
5.1.3 Transmitter Frequency Adjustment
STEP METERING POINT TUNING CONTROL METER READING PROCEDURE
NOTE
This step assumes the frequency
is measured when the
transmitter is first keyed. If
delayed, the rapidly rising
ambient temperature must be
taken into consideration. The
Oscillator frequency should be
set at 25°C ambient
temperature.
1 J201 (or J1) FREQ TRIM
Control on
TCXO
(XU201)
Channel
Operating
Frequency
Press the PTT switch while
monitoring RX/EX injection
frequency at J201. Adjust FREQ
TRIM Control on TCXO
(XU201) for the assigned channel
frequency ±0.5 PPM.
Figure 6 – Synthesizer Adjustment

ALIGNMENT AND TROUBLESHOOTING PROCEDURES LBI-38425A
15
5.1.4 Receiver Frequency Adjustment
1. No receiver frequency adjustment is required.
2. With proper alignment of EX injection frequency, RX injection frequency will
automatically be correct.
5.1.5 Modulation Level Adjustment
Procedure for synthesizer Transmit Deviation
1. Select the highest frequency channel.
2. Rotate CG DEV ADJUST, RV202 fully counterclockwise.
3. Connect the audio oscillator and apply a 1 kHz tone at 850 mVrms to MIC HI, J701-
4. Connect the deviation monitor to the antenna connector, J1 through a 30 dB
decoupler. Key the radio. Set DEV ADJUST, RV201 for ±3.75 kHz deviation.
4. Set RV202 fully clockwise. Remove P602 from position 1-2 and set aside. Apply a
400 Hz tone to J602-2 and with the radio keyed, vary its amplitude until the
Deviation Monitor reads 2 kHz. Note the level.
5. Change the audio oscillator frequency for a 10 Hz tone at the same level and set
LOOP MOD ADJUST RV203 for a deviation of 2 kHz. Unkey the radio.
6. Disconnect the audio oscillator and replace P602 in position 1-2.
7. Select a frequency with Tone Channel Guard.
8. Key the radio and set CG DEVIATION ADJUST RV202 for a deviation reading of
±0.75 kHz.
NOTE
If channel guard is not used on any frequency channel, CG DEV ADJUST, RV201,
may be set for ± 4.5 kHz deviation instead of ±3.75 kHz.
5.1.6 Audio Check
Audio Sensitivity
1. Connect audio oscillator output to MIC HI, J701-4. Adjust output for 1 kHz at 1
Vrms.
2. Reduce oscillator output until deviation monitor indication falls to ±3.0 kHz for
radios without Channel Guard or to ± 2.25 kHz for radios with Channel Guard.
Oscillator output voltage should be less than 120 millivolts.

LBI-38425A ALIGNMENT AND TROUBLESHOOTING PROCEDURES
16
5.1.7 Audio Output Level Adjustment Procedure
STEP METERING POINT TUNING CONTROL METER READING PROCEDURE
1 J701-1 RV601 See
Procedure Set the signal generator to the receiver frequency with ±3 kHz
deviation and 1 kHz modulation.
Set the RF signal level to 1000
microvolts. Move P551 from
J551-1, 2 to J551-2, 3 on the
Transmitter/Receiver Board.
Connect RF signal generator to J1.
Terminate J701-1, 6 with a 4 ohm,
6-watt resistor, connect the audio
level meter and the distortion
analyzer input across the resistor.
Set the volume to the maximum
point. Press DOWN button two
times. Adjust RV601 for 4-watt
output (4 Vrms, using the
distortion analyzer as voltmeter).
Return P551 to J551-1, 2.

ALIGNMENT AND TROUBLESHOOTING PROCEDURES LBI-38425A
17
NO
OPERATION
DC
VOLTAGE
IC701- 38
~ 5V?
CHECK
IC609
IC701-4
HIGH?
5.1.8 Control Logic Troubleshooting
RC-5432B
CHECK
IC608
REPLACE
X701
CHECK
IC704-IC708
CHECK
IC701,
IC702,
IC703
PSEN
(IC701-26)
RUNNING?
XTAL
X701
OK?
YES YES
YES
YES
NO
NO
NO
NO

LBI-38425A ALIGNMENT AND TROUBLESHOOTING PROCEDURES
18
5.2 TRANSMITTER
Alignment and troubleshooting procedures for Transmitter circuitry on the
Transmitter/Receiver board CMN-233 are as follows:
5.2.1 General Description of Adjustment
This manual is prepared for adjustments and confirmations of the Exciter/PA section and
covers the following items:
5.2.2 Measuring Instruments
•AVR (DC Power Supply DC 0-20V, 20A)
•Power Meter (usable at the value above 80 W)
•Directional Coupler
•Signal Generator
•Spectrum Analyzer
•Attenuator (30 dB, above 80 W)
•Tester
STOP
START
Confirming the Voltage
Confirming the APC Section
Adjustment and Setting of the Transmitting Output
Initial Setting
1
2
3
4
DC power ON
SG, PTT ON

ALIGNMENT AND TROUBLESHOOTING PROCEDURES LBI-38425A
19
ADJUSTMENT SYSTEM
AVR
POWER
SUPPLY
RADIO
DIRECTIONAL
COUPLER POWER
METER
SPECTRUM
ANALYZER
ATT SPECTRUM
ANALYZER
30 dB
*
* FOR MEASURING SPURIOUS ONLY.
RC-5434B

LBI-38425A ALIGNMENT AND TROUBLESHOOTING PROCEDURES
20
5.2.3 Transmitter Adjustment Procedure
STEP ITEM TEST POINT TUNING CONTROL PROCEDURE
1 Initial Setting Turn the volume on APC RV1,
RV2 fully counterclockwise
(CCW).
2 Confirming the
voltage
TP4
Disconnect RF cable P101 from
connector J201.
Turn on the power.
Turn on the PTT (ground J701-
2).
Confirm voltage of TR6
collector is 9V at TP4 and that
the relay K1 clicks at this time.
3 Setting APC
off power RV1
RV2
Connect RF cable P101 to J201.
Turn the volume RV1 on APC
fully clockwise (CW).
Next, turn the volume RV2
slowly CW and set an output of
48W ±2W at the center
frequency of each band.
4Confirming
minimum
power
RV1 Turn the volume RV1 on APC
fully CCW and confirm
minimum power of 20W or less.
5Confirming
APC on power RV1 Turn volume RV1 on APC slowly CW and set an output of
44W ±2W at the highest
frequency of each band. 40W or
more for other Frequencies.
