Compac CUBX CBX-CU812 User manual

The CUBX Collection
2 High x 3 Wide Cube Shelf
CBX-CU812
Bring Designer X-Factor To Any Space!
For assembly advice or parts email or call 0800 266 722 [email protected]
Make life simple with the ultra-versatile Cubx collection. Display, store, divide spaces, and more with this
multi-functional range.
Solidly built with a unique interlocking design for rigidity, the Cubx collection has a clever open back panel so
it can be placed against a wall or freestanding as a smart room feature. Cubx stands out from the crowd with
several other smart features – a small removable glide foot makes transportation and cleaning easier, and the
matching felt storage boxes are made to fit neatly into the cavities for simple storage. With a 10 year guarantee
it’s a popular style for good reason, so make a solid choice in Cubx. The felt storage boxes are a generous size,
measuring 350 x 350 x 350mm, and are available in a range of colours.
Congratulations on the purchase of your CUBX unit.
If you have any questions please email [email protected] or call 0800 7 10 10 10.
CBX-CU812 Job Number:

1For assembly advice or parts email or call 0800 266 722 [email protected]
WHERE TO ASSEMBLE YOUR CUBX UNIT
Assemble your CUBX on a clean and smooth surface, free of anything which may damage the finished surfaces. A clean,
carpeted floor is ideal. If assembling on a workbench or table, we suggest you cover it with the carton the unit was
packaged in.
Warning! Never leave hardware parts where children can reach them. Small parts may be a choking hazard!
Do not allow children to climb on the unit as this can cause the unit to tip. Compac Home can take no responsibility for
damage or injury caused by climbing, sitting, or standing on the unit in any way.
TOOLS REQUIRED:
10 YEAR GUARANTEE
The Cubx Collection carries a 10-year guarantee against defective material or workmanship, excluding misuse and normal wear
and tear. Obviously, as this unit is customer-assembled we cannot guarantee cabinet failure or damage from incorrect assembly.
All claims need proof of purchase – to ensure this register your CUBX unit at www.platform10.co.nz/productguarantee.
Follow the assembly instructions carefully and take note of the precautions below.
·Avoid direct sunlight wherever possible.
·Keep cabinet in a dry place.
·Wipe off spilt liquids immediately.
·Avoid placing hot items directly on the surface.
·To clean, wipe with a clean, slightly damp cloth and buff dry with a soft dry cloth - microfibre is ideal.
·Do not allow nail polish, removers, deodorant or other damaging chemicals to come into contact with the surface.
or
CBX-CU812

2
For assembly advice or parts email or call 0800 266 722 [email protected]
PARTS LIST
Please check you have all the necessary parts before beginning to assemble your CUBX unit. If any parts are missing or damaged
please contact the manufacturers directly, either via our website or call 0800 7101010.
QTY PART DIMENSIONS
NOTES
2 Top/Base 1196W x 396D x 25mmH
Top and Base are Interchangeable
2 Ends 755W x 390D x 25mmH LH and RH Ends are Interchangeable
1 Shelf 1140W x 379D x 15mmH
1 Back Panel 370W x 370D x 15mmH
HARDWARE LIST
PART CODE
Connecng Bolts 102649
Large Cams
102511
32mm Woodscrews
102645
Black Plasc Feet
102492
Rafix Fing
102551
Rafix Bolt
102555
Large Hex Head Screws
108170
QUANTITY IMAGE
12
12
5
5
4
4
8
Allen Key 1
122020
PART NO
02
01
03
04
2 Center Panel 755W x 379D x 15mmH 05
CBX-CU812
1196 mm
396 mm
390 mm
755 mm
379 mm
755 mm
370 mm
370 mm
1140 mm
379 mm
0102
03
04
05

3
ATTENTION !!
Mnfix s the man connecton materal used n our products.
Before startng assembly, please check the drawngs below.
1 2 3
4
12
6
9 3
2
12
6
9 3
2
For assembly advice or parts email or call 0800 266 722 [email protected]
CBX-CU812

4
PART LIST
For assembly advice or parts email or call 0800 266 722 [email protected]
CBX-CU812
01
01
02
02
03
04
05
05

5For assembly advice or parts email or call 0800 266 722 [email protected]
2
1
CBX-CU812
x2
102649
x2
03
05
05
01

6
For assembly advice or parts email or call 0800 266 722 [email protected]
3
4
CBX-CU812
2x
102511
01
03
03

7For assembly advice or parts email or call 0800 266 722 [email protected]
5
62x
102511
CBX-CU812
01 03
03

8
For assembly advice or parts email or call 0800 266 722 [email protected]
7
CBX-CU812
x4
102649
x2
x8
108170
122020
02
02
02
05
05
01
01
8

9For assembly advice or parts email or call 0800 266 722 [email protected]
8x
102511
102492
102645
x5
9
10 Note the feet can be fixed to any sde to support the unt.
CBX-CU812
05
05
02

10
For assembly advice or parts email or call 0800 266 722 [email protected]
x4
102551
04
11
12
CBX-CU812
x4
102555
02
01

11 For assembly advice or parts email or call 0800 266 722 [email protected]
CONGRATULATIONS, your CUBX unit is now complete.
Thank you for supporting New Zealand made furniture and business.
Register your 10 Year Guarantee online. . www.platform10.co.nz/productguarantee
13
14
CBX-CU812
04
x4
