Compact Electric CDMR-62 User manual

DIGITAL LINE MONITORING RELAY
CDMR-62
3X100V / 57V AC
User Manual
1100 Wien, DOERENKAMPGASSE 7
PHONE: + 43 / 1 / 815-12-71-0 or ++ 43 / 1 / 815-51-74-0
FAX.: + 43 / 1 / 813-64-21-21
homepage: http://www.compactelectric.at
CDMR62e_man_A1.doc
Technical data ...................................................... 2-3
Connection assignments (Fig.1) ......................... 3
Parameterizing the CDMR-62 and information
about the monitoring functions …………..………. 4-5
Change of setup values ....................................... 5
Allocation of the message relays to the switch
stages and inversing the message function……. 6
Combination lock................................................... 6
Real-time clock .....................................................7
Event log .................................................................... 7
Blockage time and blocking relay............................... 7
External blockade input ............................................. 7
Self monitoring ........................................................... 7
PC Parameterizing software ...................................... 8
Menu structure (Fig.3) ................................................10
Front display and keyboard (Fig.4) ............................ 11
Parameter list with setup ranges and
setup values (Tab.1) ................................................. 12-13
com pac t elec t ric
CDMR
Netz 50.00Hz
99.8 98.7 99.3 V
L1 / L1-L2 L2 / L2 -L3 L3 / L3-L1

Grid monitoring relay CDMR-62 / Operating instructions Page 2
CDMR62e_man_A1.doc
Technical data (other values on request)
Measuring circuit:
Rated voltage Un..................... : 3x 100-110V / 57-64VAC
Measuring range ......................... : up to 145V / 82V
Overload resistance .................... : 2 Un (100% ED)
Input resistors ............................. : 500 k(per phase)
Frequency range ......................... : 45 - 65 Hz
Accuracy:
Voltage ..............................: <= 0.2% Un
Frequency ......................... : 0,01 Hz
Phase angle ...................... : +/- 0,5°
Temperature resistance
Voltage ..............................: < 0.01% / °C
Frequency ......................... : no dependency
Phase angle ...................... : +/- 0.006° / °C
Supply voltage:
Absolute Limits …….................... : 70 – 300V AC / 45 – 65 Hz, 19.2 V - 250 V DC (limit values)
(AC/DC Wide range power supply)
Power consumption .................... : 3 VA max.
General information:
"Power On" startup delay............ : 0.3 s (after UHfailure)
Blocking Input B response time : 40ms
Vector surge trip delay............... : 60 – 80 ms
Ambient temperature range : -20 C to +60 C
LCD display contrast ................... : -5 C to +50 C
Contact data (ohm resistive load, see Fig. 2)
Max. switching power ….............. : 2000 VA / 240 W
Max. switch voltage ..................... : 250 V AC / 230 V DC
Max. switch current ..................... : 8 A (250 V AC / 30 V DC)
0.4 A (230 V DC)
Electrical lifetime …..................... : 105switching cycles
Insulation:
Line input - Supply input …………: 2.5 kV
Line input - Relay outputs …...... : 4.0 kV
Safety: ...........................: EN 61010
EMC:
Interference emission : EN 61000-6-2 (Industry)
Interference resistance : EN 61000-6-4 (Industry)
Front installation: Control panel cut-out 92x68mm (WxH) Installation width with rail adapter: 115mm
Mechanical data:
Housing DIN43700 .......... : 96 x 72 x 90 mm
Mounting .......................... : Front panel or DIN Rail 35mm
Material ............................ : Noryl
Flammability .................... : UL94-V0
Protection class ............... : Front IP50 / rear IP30
Terminals ......................... : 2.5 mm², pluggable

Mains monitoring relay CDMR-62 / Operating instructions Page 3
CDMR62e_man_A1.doc
Fig. 1 Terminals and Wiring Diagram
Connection diagram for 4-wire grid: Connection diagram for 3-wire grid:
EMC wiring information: Wire length for connection "B" less then 3 m
Fig. 2: LOAD LIMIT CURVE OF THE OUTPUT CONTACTS
0.5
5
50 500
DC (OHM RESISTIVE LOAD)
A
C (OHM RESISTIVE
LOAD)
L1
L2
L3
L1 L2 L3 N B HP HN
CDMR-62
U H
L1
L2
L3
N
L1 L2 L3 N B HP HN
CDMR-62
U H
CDMR-62
12 22 32 42 5211 21 31 41 5114 24 34 44 54
K1 K2 K3 K4 K5
Measuring-
voltage U
N
Blockade
Serial-
port
Po wer-
supply. U
H
HNHPTGC
R
BN
N
NL3L1 L2
AC: (P) (N)
DC: ( ) ( )
+

Mains monitoring relay CDMR-62 / Operating instructions Page 4
CDMR62e_man_A1.doc
General information:
The CDMR-62 is a digital line monitoring relay on a micro-controller basis with high measuring accuracy and 13 monitor-
ing functions, which are designated by the following abbreviations:
U< ... Undervoltage stage 1 f< ... Undervoltage stage 1 Vk> ...Vector shift
U<< ... Undervoltage stage 2 f<< ... Under frequency stage 2 Asy ... Voltage asymmetry
U<<< Undervoltage stage 3 f> ... Overfrequencies stage 1 Wsy ... Angle asymmetry
U> ... Overvoltage stage 1 f>> ... Overvoltage stage 2 DRE ...Rotational direction
U>> ... Overvoltage stage 2
Relay configuration
See Fig. 3 and Fig. 4 as basic information for configuration through the front control panel, see page 8 for configurations
through serial interface.
1. Information: The standard display with the current line values appears when connect-
ing the auxiliary voltage. Starting with this menu, the arrow keys can be used to browse
through all main menus. Using the ENTER button, one gets from the main menus to the
chain of detailed menus
2. 1st Step: Setting the grid type (3/4-wire grid) in the menu block "General settings".
These settings must be established at the start because different data records are allo-
cated to the 3-wire and 4-wire grid voltage monitoring.
3. 2nd Step: Activation and parameterizing of the required monitoring functions:
Selection of the appropriate main menu (example left U<<). The main and detail menus
always include the abbreviation of the respective switching step in the upper right area.
The output relays, which act on the switching stage (e.g. "K1__4_" with effect on K1 and
K4), are always listed on the second line
4. Information: A switching stage is inactive if no output relay is allocated to it (dis-
play "K_____" in main menu).
Change of the setup values, see page 5.
Settings for 3-wire or 4-wire grid
The star voltages are monitored in the 4-wire grid. The triangular voltages are monitored in the 3-wire grid, the star point
will be created internally. The limit values (U<<< ...U>>, Asy) for the star and triangular voltages are stored independently
from each other. Depending on the selected grid type, only the star or the triangular voltage limits are visible and adjust-
able at the CDMR-62 as well as in the PC parameterizing program.
Connection to a 1-phase grid: Connect voltage to the inputs L1, L2 and L3, grid type = "4-wire".
Voltage monitoring U<<<, U<<, U<, U>, U>>
Voltage measurement (root mean square values, digital harmonic filter) includes the star voltages and the phase-to-
phase voltages. The monitoring is sensitive to individual phases (U< excitation if at least one phase is below the limit
value, U> excitation if at least one phase is above the limit value). The undervoltage triggering can be blocked through
input "B" (see section "External blockade input"). When using the measuring voltage as auxiliary voltage, then the mes-
sage relays for U<, U<< or U<<< must be operated inverted, because otherwise undervoltage cannot be reported if the
auxiliary voltage fails.
Important: At least one undervoltage stage >= 70% must be set for standard grid parallel operation applications
because the frequency and vector shift triggering will be blocked below 70%Un and because otherwise there
would be a voltage range for which no triggering can be performed.
Special function: 2-phase sensitivity for the U< switching stage
This special function can be activated using the parameter "U< Trip Logic" in the menu block "General settings".
U< Trip Logic = OFF: Individual phase sensitivity U< Triggering, if at least one phase
undershoot the limit value.
Line / 50.00Hz
57V 57V 57V
Undervoltage U<<
Stage2 K1__4_ <-
Undervoltage U<
Stage1 K_____ <-

Mains monitoring relay CDMR-62 / Operating instructions Page 5
CDMR62e_man_A1.doc
U< Trip Logic = ON: 2-phases insensitivity, U< triggering is only performed if at least two
phases undershoot the limit value.
Voltage asymmetry Asy
The asymmetry monitoring is triggered if at least one difference between the three star or triangular voltages exceeds
the set limit value (independent of the absolute voltage values, is also triggered, for example, in case of an individual
phase failure).
Phase Angle Asymmetry Psy
Adjustable limit value = deviation from 120°
The angle asymmetry is triggered if one of the three phase angles deviates from 120° by more than the set degree value.
Example: Setting value = 4°, tripping at phase angles <= 116° and >=124°.
The Angel measurement is only possible for 4-wire grids and correct rotating fields. Therefore, the setting menus for Wsy
will not be displayed for 3-wire grid types. The current angles are displayed in the menu "Line: Lxy angle"
(see Fig. 3).
Frequency monitoring f<<, f<, f>, f>>
The frequency monitoring is performed for three phases and it is active as long as at least one phase exceeds 0.7Un.
The frequency triggering will be blocked if all phase voltages are below 0.7Un. The frequency triggering can selec-
tively also be blocked through input "B" (see section "External blockade input").
Vector surge Vs>
Vector surge monitoring is carried out independently in each line. Tripping execution depends on the logic combination
selected in the menue "Vector Surge Vs> \ Trip Logic Vs>": (parameter value = 1 ... 9):
Value Logic Comment
1 "L1 " tripping on Vs> in line L1 (independent of L2 and L3)
2 "L2 " tripping on Vs> in line L2 (independent of L1 and L3)
3 "L3 " tripping on Vs> in line L3 (independent of L2 and L3)
4 "L1,L2,L3" tripping on Vs> in line L1 or L2 or L3 (inclusive "or")
5 "L1+L2 " tripping on Vs> in line L1 and L2 (independent of L3)
6 "L1+L3 " tripping on Vs> in line L1 and L3 (independent of L2)
7 "L2+L3 " tripping on Vs> in line L2 and L3 (independent of L1)
8 "L1+L2+L3" Tripping on Vs> in line L1 and L2 and L3 (within two periods)
9 "OFF " Vs> tripping disabled
The VS> excitation in an individual phase will be blocked if the phase voltage is below 0.7Un.
In addition, the Vs> triggering will be blocked for the set blockade time "t-Blockade Vs" if the auxiliary voltage is switched
on as well as if the measuring voltage will be connected. In addition, Vs> the triggering can be blocked externally (float-
ing contact) through the blockade input "B". After opening the contact, waiting for the blockade time "t-Blockade Vs"
expiration takes place until the monitoring is activated.
The length of the Vs> tripping signal is selectable in the menue "Vector Surge Vs> \ Pulsewidth... Vs>"
Phase sequence SEQ
The phase sequence (L1-L2-L3) is checked once on the rising of all 3 line voltages above 60%Un or in the case of
power-on of the supply voltage. A wrong phase sequence forces the assigned relay(s) to be permanently in the alert
state. The display shows the message: "PHASE SEQUENCE L1-L2-L3 fault!"
Change of setup values
See also Fig. 3 and Fig. 4 Page 10 and 11
1. Select the main menu of the required switching stage (e.g. U<).
(Starting in the grid menu by pressing the "UP/DOWN" arrow buttons simultaneously)
2. Using the "ENTER" button browse through the detail menu of the switching stage until
the required parameter. The switching stage symbol is always located in the upper right
area of the display field. The setup a range is shown in brackets, the set value is displayed
in the right lower area.
Undervoltage U<
Stage1 K_2___<-
Trip Voltage U<
[3– 82] 46.0V

Mains monitoring relay CDMR-62 / Operating instructions Page 6
CDMR62e_man_A1.doc
3. Press the "M/V" button Switches the function of the arrow keys from "Menu scrolling " to
"Value changing"). Now there may be two situations:
Case a): no security code is selected (Code = 000): A "release menue" (see left drawing) is
displayed, "xxx" is a self-incremented change-access counter. Confirm the change-access re-
lease with the ENTER key. (If you entered this menue inadvertently you may escape from the
menue with “UP/DOWN”arrowkeys).
Case b): Change release for an activated combination lock, the first digit flashes.
(If you got to this menu by accident, then please leave it by using the "M/V" button.)
Otherwise, using the "UP/DOWN" button, set the first digit correctly and press ENTER.
The second digit flashes now, adjust it, press ENTER and set the third digit. Complete with
"Enter".
4. Afterwards, the parameter menu will be displayed again and the first digit of the setup value
flashes. The decimal place can now be changed using the "UP/DOWN" arrow keys. (Automat-
ic increment or decrement if button is pressed). The next decimal place flashes after pressing
the ENTER button. After the last decimal place, the new value will be transferred into the
memory by pressing "ENTER" and the value will again be displayed static. (If the change must
be reversed, then the earlier value can be reestablished by pressing the "M/V" button instead
of ENTER).
After completing the change, one can transfer
- to the next menu using the "ENTER" or "DOWN" button,
- to the previous menu using the "UP" button,
- back to the line value display menu (= "Menu reset") pressing "UP" + "DOWN" simultaneously.
Assignment of output relays to individual monitoring functions and negation of output relays
Select the menu "Output-Relay nnn" of the respective switching stage (in accordance with step 1 to step 3 as above).
The switching stage U<< in the left example acts on the relays k1 and K4. The lowercase
letter for k1 shows that this relay is negated. It is energized in the normal state and released
in the tripped state. The "--" characters mark the positions of the (not assigned) relays
K2,K3 and K5.
4. After execution of step 3, the characters "k1" are flashing. The allocation of the U<< triggering with k1 can be deleted
or deactivated using the "UP/DOWN" buttons (in this case, the placeholder "--" is placed instead of "k1").
5. The settings for k1 will be accepted by pressing the "ENTER" button and the change mode will be switched forward to
K2, the placeholder for K2 flashes. Using this method, the positions for all 5 relays will be passed through.
6. After the completion for K5 (using the "ENTER" button), the "M/V" button can be used to start the change mode again
at k1, or a different button can be used to vacate the menu.
Negation of K1 ...K5 function
Select the menue "General Settings \ Negated Relays":
The configuration procedure is equivalent to step 4 - 6 above. An upper case character indi-
cates normal operation, a lower case character indicates negated operation. The relay codes
K1 -K5 are consecutively flashing and may be toggled between upper and lower case charac-
ter by “UP/DOWN” arrowkeys.
Security Code / Change-access release
To prevent unauthorized changing of setting values via the front panel, a three-digit security code can be stored in the
data memory. It has to be entered to get permission to alter parameter values.
If the security code is 000, the security sequence is not active and is replaced by a simple menue with a self-
incremented change-access counter (see step 3 above). The value of this counter may be used as indication of any
access to the change mode. The security code can be modified in the menue "General Settings \ Security code". Subse-
quent changing of the code is possible, but also in this case the active code has to be entered to get the permission for
changing.
Real-time clock
Lock-out Nr.xxx
release? yes<-
Enter Security-
Code....... 000
Trip Voltage U<
[ 3–82] 51.0V
Output-Relay U<<
k1 -- -- K4 --
Negated Relays
k1 K2 K3 K4 K5

Mains monitoring relay CDMR-62 / Operating instructions Page 7
CDMR62e_man_A1.doc
The CDMR-61 is equipped with a real-time clock with a supply-buffer of 60 hours minimum. The time resolution is 1s.
Date and time of the internal clock are displayed in a menue of the "General Settings" chain. The clock settings may be
changed in this menue as well as by the PC program.
Clock setting by menue: see chapter "Change of setting values". The first flashing value is the "day", it may be incre-
mented or decremented with “UP/DOWN” arrowkeys, press ENTER key to step forward to "month" value and repeat
procedure till "seconds" value. After the last entry of the ENTER key flashing of seconds stops and the new date/time
settings are transferred to the realtime clock.
Event History Buffer featuring 100 events capacity
If the relay detects a fault-free line conditions (none of the selected monitoring functions energized) for more than 200ms,
the event trigger logic is activated waiting for the first tripping event. This event is recorded with date and time and the
corresponding line measurement values at the tripping instant. Up to 100 events are stored chronologically. On exceed-
ing this number the oldest event is overwritten.
The content of the history buffer may be displayed on the LCD panel or via the serial interface by a PC program. The
complete information of one event is splitted in two menues. From the menu "Event Monitoring" press the ENTER key to
branch to the:
1. Event menu
Hnn = Event number (H for "History", 00 = newest entry, 99 = oldest entry
U<<< tripping function
To display previous events press M/V key, "Hnn" flashes, now the event number can be scrolled from 00 to 99, the cor-
responding event information is instantly displayed. To check the measured values corresponding to any event,
press M/V key again to stop flashing then step to the 2. Event menue with the “DOWN” arrowkey :
2. Event menu
1. Line: Event number (Hnn) from the first event menu and tripping function,
2. Line: Measured values at the instant of tripping
The entries 00 to 99 can be selected using this menu. The flashing can be stopped – as explained above – for an inter-
esting event and a transfer to the event menu can be performed using the "Arrow up" button, which displays the date and
the time of this event.
Erasing the complete event history buffer:
In the menue "Event Monitoring \ H00-99 Erase" set the parameter value to 1. The erasing procedure takes about 30s.
Don't press any key during this procedure, cause it terminates the procedure in an incomplete state.
Blockage Time and Blocking Relay
Menu "General settings":
These two parameters can be used to adhere to the required brake time between a triggering event and the restart of the
circuit breaker without an external time relay The relay (K1..K5) defined as blocking relay will also be activated during
each triggering and the blockage time will be initiated. If the grid is faultless again, then the blockage time starts to run
and the blocking relay releases only after this time has expired. The blockage time is also effective after the relay power
supply has been connected and the grid is fault free.
External blockade input
Depending on the settings of the parameter “Ext. Blockade U,f" (in menue block "General settings"), the external block-
ade (see Fig.1, Connection "B" and "N" closed through floating contact, triggering time 40 ms) has the following effect:
„Ext.Blockade U,f“ Effect
0 .................... The blockade acts only based on the vector surge trigger "Vs".
1 .................... The blockade acts only on the excitation and triggering of Vs>, U<, U<<, f<, f<<, f>, f>>, Asy.
If the blockade is released and if a line fault is present, tripping is performed after the time
delay programmed for the corresponding monitor function.
2 .................... Blocking of all 13 monitoring functions. If blocking is released and a line fault present, tripping is
performed after the time delay programmed for the corresponding monitoring function.
Self-monitoring
H00: 28-05-2005
U<<< 13:48:16
H00: U<<<
005V 230V 216V

Mains monitoring relay CDMR-62 / Operating instructions Page 8
CDMR62e_man_A1.doc
The relay has a self-monitoring program for error detection in the data memory (checksum er-
rors) which in the error case displays a message "DATA ERROR Parameter No. xxx". If the pa-
rameter "Selfmonitor.->K5" is set, the output relay K5 is changed to the alert state.
The number "xxx" in the display corresponds to the parameter number in the left column of table 1. If two numbers are
listed for one parameter, the first number refers to the corresponding star-type voltage, the second one to the corre-
sponding delta voltage. In the case of a checksum error of this kind, elimination may be successful by entering the pa-
rameter value once again (although the parameter value might be correct).
Parameter numbers 105 to 115 are used for internal scaling. In this case the unit has to be returned to the factory.
The K5 control circuit is designed to perform a watchdog function. If the K5 is configured as negated, it will be de-
energized not only in case of a data error or power supply failure, but also in case of a controller hardware failure.
Additional to self-monitoring the K5 can be assigned to any other monitoring function without restriction.
Use of the measuring voltage as auxiliary voltage
A measuring voltage in the range of 70 – 300 V AC is also permissible as an auxiliary voltage. However, it must be con-
sidered that all message relays transfer into the voltage-less condition in case the measuring voltage fails.
Parameterizing software for laptops
The serial interface offers a comfortable option for the parameterizing of the CDMR relay using a laptop or PC and to
document the set values. A special cable for the connection is available as an accessory.
User interface of the parameterizing program
Parameterizing the relay through a PC:
1. Load the parameter set into the PC: a) directly from the relay (PC menu: "Senden/Empfangen"/"Parameter
empfangen")
or b) from a data carrier with "Datei"/"öffnen" (file extension: ".par")
2. Set the parameter values and transfer to the CDMR ("Senden/Empfangen"/"Parameter senden")
The function of the CDMR is not impaired during the transfer of new parameters.
Exception: a short voltage triggering can occur when changing the grid type (3-wire and 4-wire grid).
Example of the content of the event
memory for the last 10 triggerings.
The triggering time and the meas-
ured values at this time are stored.
DATA ERROR
Parameter No:xxx

Mains monitoring relay CDMR-62 / Operating instructions Page 9
CDMR62e_man_A1.doc
Documentation of the parameter settings:
Saving the parameter set (file extension: .par) with the pull down menu "Datei”/”speichern". A hard copy of the settings
is available with "Datei”/”drucken".
Display current measured values on the PC:
Select "Informationen" menue. The following will be displayed: CDMR characteristic values, measured values and trig-
gers as well as date and time. The “Informationen” menue will be updated in 1 s intervals.
Read the event memory:
Select the menu "Ereignisspeicher", enter the number of events to be listed (starting with the newest) and press
"empfangen". The content of the uploaded list can be saved as a text file.
Installation:
Download ................ : The communication software for the CDMR-62 relay can be downloaded free of charge from
our homepage www.compactelectric.at
Operating system … : Windows XP, Windows Vista and Windows 7
Connection .............. : COM interface (9 pin sub D plug) or COM adapter for USB interface.
COM Interface ……..: Settings for the interface (COM1 ..COM4) in the "Option" menu.

Mains monitoring relay CDMR-62 / Operating instructions Page 10
CDMR62e_man_A1.doc
Fig. 3: CDMR-62 MENUE-DIAGRAM fi le: menu e1e .cd r
Lin e Y/ Y 5 0.0 0Hz
57 V 57 V 5 7V
Undervoltage U<<
Stag e 2 K__ __ < -
Low Voltage U<<<
Stag e3 K__ __ < -
Undervoltage U<
Stufe 1 K____ <-
Ove rvo l tage U >
Stag e1 K_ __ __ < -
Ove rvo l tage U >>
Stag e 2 K__ __ _ <-
Und er fr equ ... f <<
Stag e2 K __ __ _ < -
Underfrequ f<
Stag e 1 K__ 3_ _ <-
Ove rf re qu..... . f>
Stag e 1 K__ _4 _ <-
Ove rf re qu.. f> >
Stufe 2 K___4_ <-
Vect or Su rg e Vs>
... .... ..... .K_____ <-
Phase Asymm Psy
K_____ <-
Asymmetry Asy
K_____ <-
Ph ase Se qu. S EQ
... .... ..... K__ __ _ <-
Hystere sis ... U<<
[ 0- 12] 2.0V
Hysteresis ...U<<<
[ 0- 12] 2.0V
TripVoltage ... U<<
[ 1-82] 40.0V
TripVoltage U<<<
[ 1 - 82] 24. 0V
Trip Delay ... U<<
[0 - 60 0] 0 .10 s
Trip Delay ...U<<<
[0 - 60 0] 0.1 0s
Ret. Delay ... U<<
[0 - 60 0] 0.2 0s
Ret. Delay ...U<<<
[0 - 60 0] 0.2 0s
Output-Re lay U<<
-- -- -- -- --
Outpu tRelayU<<<
-- -- -- -- --
Lin e Y/ 50.00Hz
10 0V 1 00V 1 00V
Li n e: Lx y- An gl e
12 0° 1 20° 120 °
MAIN MENU ES DETAIL-MEN UES
Pu l swidt h . .. Vs >
[ 1- 20] 1s
Trip A ngle ... Vs>
[ 1 -30] 8°
Trip Lo gi c . .. V s>
[1-9 ] L 3 ... 3
Blo ckingTi me Vs>
[ 1 - 20] 1s
Outpu t-Relay Vs>
-- -- -- -- --
Hystere sis ... Psy
[0- 5] 1.0°
Hystere sis ... Asy
[ 0- 12] 2.0V
Trip A ngle .. . Psy
[ 0 -10] 4.0°
Trip Vol tag e Asy
[ 1 -30] 12.0V
Trip De lay ... Psy
[0 - 60 0] 0.1 0s
Trip De lay ... Asy
[0 - 60 0] 0.1 0s
Ret. Delay ... Psy
[0 - 60 0] 0.1 0s
Ret. Delay ... Asy
[0 - 60 0] 0.2 0s
Ou tput- Re lay P sy
-- -- -- -- --
Output-Re lay Asy
-- -- -- -- --
Outpu t-Relay SEQ
-- -- -- -- --
Deta i l- m enu e chai n e quiva le nt to U <<
Deta i l- m enu e chai n e quiva le nt to U <<
Deta i l- m enu e chai n e quiva le nt to U< <
Deta i l- m enu e chai n e quiva le nt to f< <
Deta i l- m enu e chai n e quiva le nt to f< <
Deta i l- m enu e chai n e quiva le nt to f< <
Hystere sis ... f<<
[ 0- 1] 0.05Hz
Trip Frequ ... f<<
[ 4 5 -6 5] 49 .00 Hz
Trip Delay ... f<<
[0.06 - 60] 0.12s
Ret. Delay ... f<<
[0.06 - 60] 0.12s
Ou tpu t-Re lay f <<
-- -- -- -- --
A
A
A
Return to this menu e f rom
an y m en ue by p re ss ing
th e k e ys an d si m ultan eo us ly
Line measuring values
Standard display after power-on
left
key
Ge ne ra l Set ti ngs
... .... ..... ..... .... ... < -
Relais
Informations
Security Code
[ 0- 999] 000
Date: 03-03-2005
Time: 11:2 8:1 6
3- / 4- Wir e M a in s
[ , ] =
Typ e: C DM R-6 2
Un = 100/57V AC
Lo ck- out Ti m e
[ 0 - 99 0] ..... ..... . 0
U< Trip-Logic
[ 0 - 2] (2=Vk) .. 0
Selfmonitor.. ->K5
[ 0 - 1] OFF
Negated Relays
-- -- -- -- --
S er ial - No : 0 000 00
S oft w . J0 902-03
H00: 00-06-2005
U << < 16 :31 .22
H00: U<<<
00 5V 2 28V 2 16V
Tripp i ng no w:
f<
Picked-up Relays
k1 -- K3 -- --
Eve nt Mo nito ring
... .... ..... ..... ..... < -
En er giz ing no w :
f<
H00-H99 Erase
[0 /1] ... ..... .... . 0
LCD-Contrast
[ 0 - 20 ] 11
L an gua ge Se tti ng
[g erm /engl].. .. 1
Ext . Blo ckin g U,f
[ 0 - 2] ..... .... .. 0
Lock-out Relays
-- -- -- -- --

Mains monitoring relay CDMR-62 / Operating instructions Page 11
CDMR62e_man_A1.doc
t
Line / 50.00Hz
100V 103V 101V
L1 / L1- L2 L 2 / L 2-L3 L3 / L3-L 1
t
Undervoltage U<<
Stage2 K1__4_
L1 / L1-L2 L 2 / L2-L3 L3 / L3-L1
1) Standard-Menues:
LINE MEASURING VALUES
2) MAIN MENUES (Example: Undervoltage Stage 2, U<<):
M en ue ID "Line ".
If any trip ping is active
the function symbol is
al te r nat e d isp l aye d.
Relay
configuration:
= star-type
= delta
displayed
line values:
= sta r voltages
=delta voltages
oka y L ED (g reen )
idicat es fa ult- fr ee line system
An y fu ncti on e ner g ize d,
Tri p de la y pr og r essi ng
Any tripping active
"M/V" key:
consecutive switching of displayed values
from to a nd phase angle
Scroll up and down
main menues
Scroll up and down
m ain me nue s
Fig. 4: FRONT- PANEL DESCRIPTION
Press to branch into the
de tai led - me nue ch ai n
of U<<.
The str ing " K1_ _4 __" in dicat es, t ha t K1 an d K4 a r e
assig ne d to U <<. If t here is no nu mb er in the str ing
("K______), the monitoring function is disabled.
Symbol of the monitoring function
t
Trip Voltage U<<
[1 - 82] 45.5V
L1 / L1-L2 L 2 / L2-L3 L3 / L3-L1
3) DETAILED-MENUES (Example: Trip Voltage of Undervoltage Stage 2):
a) n orma l m ode: m enue up / d own scro llin g
b) ch an ge mo de : ( fl ash in g p ar amet er val u e):
i ncr emen t / decr e me nt p ar amet er valu e
a) n ormal mode: step forwa rd to next menue
b) ch ang e m o de: ( fl ashi n g p ar amete r val ue ):
tr an sfer o f th e par amet er valu e t o n on volat ile
data memory, st op flashing
Symbol of the monitoringfunction
Pa ra mete r va lue
Se tting r an ge
"M/V" key:
Toggle key function
be tw ee n "men ue scro llin g" a nd
"parameter increment/decrement"
"ENTER" key
"ENTER" Taste
"M/V" key
(no effect
in this menu)
Return to the standard "L ine ...." menue by simult aneously pressing and keys.
"ENTER" key
sta ti c: ext er na l Bl ocki ng -i n pu t cl ose d
fl ash ing : se lf -mon itor ing al arm

Mains monitoring relay CDMR-62 / Operating instructions Page 12
CDMR62e_man_A1.doc
Tab.1:
Type: CDMR-62 Serial No:
Un: ........... V AC Marking
System: Cabinet:
Date:
Note: The voltage setting ranges in this list are listed in %Un. These values will be displayed at the
CDMR with reference to the respective nominal voltage in volt
Par.
No.
Switch
stage Parameter Setup range Factory
settings
Current settings
at the customer Dim
92, 94 U<<< Trip Voltage [1 - 130%] Un 70% Un V
96 U<<< Trip Delay [0.04 - 600] s 0.10s s
97 U<<< Return Delay [0.04 - 600] s 0.20s s
93, 95 U<<< Hysteresis [0 - 20%] Un 3% (Switch point) V
91 U<<< Output relay K1 ..K5 --
22, 24 U<< Trip Voltage [1 - 130%] Un 70% Un V
26 U<< Trip Delay [0.04 - 600] s 0.1s s
27 U<< Return Delay [0.04 - 600] s 0.1s s
23, 25 U<< Hysteresis [0 - 20%] Un 3% (Switch point) V
21 U<< Output relay K1 ..K5 --
15, 17 U< Trip Voltage [1 - 130%] Un 80% Un V
19 U< Trip Delay [0.04 - 600] s 0.1s s
20 U< Return Delay [0.04 - 600] s 0.1s s
16, 18 U< Hysteresis [0 - 20%] Un 3% (Switch point) V
14 U< Output relay K1 ..K5 --
8, 10 U> Trip Voltage [1 - 130%] Un 110% Un V
12 U> Trip Delay [0.04 - 600] s 0.1s s
13 U> Return Delay [0.04 - 600] s 0.1s s
9, 11 U> Hysteresis [0 - 20%] Un 3% (Switch point) V
7 U> Output relay K1 ..K5 --
1, 3 U>> Trip Voltage [1 - 130%] Un 120% Un V
5 U>> Trip Delay [0.04 - 600] s 0.1s s
6 U>> Return Delay [0.04 - 600] s 0.1s s
2, 4 U>> Hysteresis [0 - 20%] Un 3% (Switch point) V
0 U>> Output relay K1 ..K5 --
50 f<< Trip Voltage [45 -65] Hz 49.00 Hz Hz
54 f<< Trip Delay [0.06 - 60] s 0.12s s
55 f<< Return Delay [0.06 - 60] s 0.12s s
51 f<< Hysteresis [0 – 5.00] Hz 0.05 Hz Hz
50 f<< Output relay K1 ..K5 --

Mains monitoring relay CDMR-62 / Operating instructions Page 13
CDMR62e_man_A1.doc
Par.
No.
Switch
stage
Parameter Setup range Factory
settings
Current settings
at the customer
Dim
43 f< Trip Voltage [45 -65] Hz 49.80 Hz Hz
47 f< Trip Delay [0.06 - 60] s 0.12s s
48 f< Return Delay [0.06 - 60] s 0.12s s
44 f< Hysteresis [0.00 – 5.00] Hz 0.05 Hz Hz
42 f< Output relay K1 ..K5 --
36 f> Trip Voltage [45 -65] Hz 51.00 Hz Hz
40 f> Trip Delay [0.06 - 60] s 0.12s s
41 f> Return Delay [0.06 - 60] s 0.12s s
37 f> Hysteresis [0 – 5.00] Hz 0.05 Hz Hz
35 f> Output relay K1 ..K5 --
29 f>> Trip Voltage [45 -65] Hz 52.00 Hz Hz
33 f>> Trip Delay [0.06 - 60] s 0.12s s
34 f>> Return Delay [0.06 - 60] s 0.12s s
30 f>> Hysteresis [0 – 5.00] Hz 0.05 Hz Hz
28 f>> Output relay K1 ..K5 --
57 Vk> Trip Angle [1- 30] ° 8 ° °
58 Vk> Trip Logic [0 - 9] 8 (L1+L2+L3)
61 Vk> BlockingTime [1 - 20] s 5 s s
62 Vk> Pulswidth [1 - 20] s 1 s s
56 Vk> Output Relay K1 ..K5 --
71, 73 Asy TripVoltage [1 - 50%] Un 20 % Un V
75 Asy Trip Delay [0.04 - 600] s 0.1s s
76 Asy Return Delay [0.04 - 600] s 0.1s s
72, 74 Asy Hysteresis [0 - 20%] Un 10% V
70 Asy Output Relay K1 ..K5 --
99 Wsy Trip Angle [1.0 - 10.0] ° 4° °
103 Wsy Trip Delay [0.04 - 600] s 0.1s s
104 Wsy Return Delay [0.04 - 600] s 0.1s s
100 Wsy Hysteresis [0 - 5.0] ° 1° °
98 Wsy Output Relay K1 ..K5 --
77 SEQ Message relay K1 ..K5 --
79 GEN.: Grid type 3- /4-wire 4-wire
78 Relay inversion K1 ..K5 --
64 Blockage time 0 - 990 s 0 s s
63 Blocking relay K1 ..K5 --
80 Ext. Blockade 0, 1, 2 0
83 U< Trip Logic ON/OFF [0/1] OFF
82 Self monitor. ->K5 ON/OFF [0/1] OFF
123 Combination lock [ 0 - 999 ] 000
Tab. 1 continued
