COMPANION CS-01 User manual

Part No. CS-01
AGA Logo created from high res .jpeg supplied by AGA
PORTABLE GAS OVEN & COOKTOP
INSTRUCTION MANUAL
IMPORTANT
Read these instructions
for use carefully.
Familiarise yourself
with the appliance
before connecting it
to its gas container.
Keep these instructions
for future reference.
CERT: 7171
COM2863_stove_oven_combo_manual_ED2.indd 1 29/07/11 4:24 PM

GENERAL WARNINGS
• This appliance shall only be connected to a POL cylinder certified to AS2469
standards. This appliance is designed for outdoor use only and must be
operated away from any flammable material or surfaces & materials.
• This appliance is to be stored in a dry & well ventilated location free from direct
sunlight. Do not store when still connected to the cylinder. Make sure that the
cylinder is disconnected and is stored in a well ventilated area, free from direct
sunlight, heat and ignition sources. If being stored indoors, ensure that the
location complies with the standard AS/NZS1596.
• This appliance must only be serviced by an authorised service agent, return to
your place of purchase for service & repair.
DANGER!
• During operation all surfaces will be extremely hot and should not be touched
or handled.
• Do not use the appliance if it has a leak, worn, deteriorated or damaged seals.
• Handle with care even after brief use, always pick up using the handle not
the cylinder.
• It may be hazardous to attempt to fit other types of gas containers or cartridges.
• Use only in well ventilated areas.
• Always operate appliance a minimum of 800mm from flammable materials,
walls & ceiling.
• Do not use adaptors or modify appliance to fit other connectors or cylinders.
• Do not use multiple appliances to heat a single utensil.
• Children must be supervised by an adult at all times.
• Never leave appliance unattended when operating.
• Use as a cooking appliance only, is not to be used as heater or modify for any
other reason.
• Avoid boil over & spills on to burners.
CARBON MONOXIDE HAZARD
• This appliance produces carbon monoxide which has no odour.
Using the appliance in enclosed spaces, for example; caravan,
car, boat or mobile home could cause DEATH.
IMPORTANT
• Keep away from children at all times.
• Surfaces of the appliance will become hot during operation please take care
when handling or moving the appliance.
• Appliance is to be used on a stable, level, flat non-flammable surface, the
appliance should be protected from direct drafts and in a well ventilated place.
• Only cooking vessels with a maximum diameter of 220mm are to be used with
this appliance.
• Take care that the primary air intakes, located on the burner tube of this
appliance are not obstructed, or that air flow is restricted by placing items or
other appliances close to or adjacent to the inlets.
• If you smell gas immediately turn the gas off at the cylinder and move the
appliance & cylinder to a well ventilated area outside, keeping well away from
sources of heat such as naked flames & pilot lights.
• Do not attempt to move or relocate the appliance when it is operating,
extinguish the burner & allow to cool, disengage the gas cylinder then
move the appliance.
CHECKING FOR GAS LEAKS
• Check that all connections are tight and that the gas cylinder connection has
been tightened before you turn the cylinder gas valve on.
• NEVER check for leaks with a flame or pilot light.
• Using soapy water coat all connections, if bubbles appear turn the cylinder gas
control off and retighten the connection before re-testing.
• Inspect the appliance regularly for signs of wear, leaks or incorrect operation.
If symptoms such as flaring of the burners, issues with lighting, damages to
hoses or connections or leaks from seals or gas controls are identified do not
attempt to repair, return to your authorised stockist for service & maintenance.
• To check if gas remains in the cylinder, disconnect from the appliance and hold
the cylinder in a vertical position then shake from side to side, if there is a
sound or feel of liquid movement inside the cylinder contains gas.
• When changing gas cylinders ensure this is conducted outside in a well
ventilated location free from people, animals & ignition sources such as naked
flames, pilot lights & electrical equipment with heaters or elements.
SAFETY INSTRUCTIONS
This appliance must only be
used in an above ground open air
situation with natural ventilation,
without stagnant areas, where
gas leakage is rapidly dispersed
by wind and natural convection.
Any enclosure in which the
appliance is used should comply
with one of the following:
(A) An enclosure with walls on
all sides, but with no
overhead cover.
(B) Within a partial enclosure
that includes an overhead
cover and no more than
two walls.
(C) Within a partial enclosure
that includes an overhead
cover and more than two
walls, the following must
apply:
(1) At least 25% of the total wall
area is completely open.
(2) 30% or more in total of the
remaining wall side, back
and front wall areas is open
and unrestricted.
(3) In the case of balconies,
20% or more of the total wall
area must remain open and
unrestricted.
1
1
1
2
2
COM2863_stove_oven_combo_manual_ED2.indd 2 29/07/11 4:24 PM

CONNECTION
Your stove is designed to connect directly on to a POL gas cylinder using the
specially designed LP Gas hose and regulator supplied with the appliance.
• Check that the Control Knobs
are in the “Off” position (turned
fully clockwise).
• Take the stove connector head
of the hose and attach to the gas
inlet on the appliance, tighten
using a spanner.
• Attach the other end of the hose to the gas cylinder and tighten.
• Turn the cylinder gas valve on in an
anti-clockwise direction for one full
turn and then check the connections
for leaks with soapy water. If a
leak is detected turn the cylinder
gas valve “Off” and retighten all
connections, then retest.
LIGHTING BURNER - STOVE
• Make sure the Control Knob is set to
the “OFF” position.
• Depress and turn the Control Knob
anti-clockwise until a “click” sound
is heard, check that the burner is
now alight if so hold the ignition
knob in for 10 to 15 seconds then release.
• If burner is not alight, return the Control Knob back to the “OFF” position, allow
the excess gas to disperse then repeat ignition process.
ADJUSTING FLAME
• Turn the gas control in an anti-clockwise direction to
achieve a higher flame and in the clockwise direction for a
lower flame or fully clockwise to turn the appliance “OFF”.
LIGHTING BURNER - OVEN
• Open oven door.
• Make sure the Control Knob is set to the “OFF” position.
• Depress and turn the Control Knob anti-clockwise until
a “click” sound is heard, check that the burner is now
alight if so hold the ignition knob in for 10 to 15 seconds
then release.
• If the burner does not stay alight, turn the Control Knob
to the “OFF” position and wait for 5 minutes before
attempting to relight the burner.
ADJUSTING TEMPERATURE
• Turn the Control Knob in an anti-clockwise direction
to achieve a higher temperature and in a clockwise
direction for a lower temperature or fully clockwise
to turn the appliance “OFF”.
• The oven temperature is displayed on the gauge located
on the control panel.
TURNING THE APPLIANCE OFF
If the appliance is no longer to be used and to reduce
the risk of blocked gas jets caused by excess gas being
left in the hose, all remaining gas must be expelled from
the hose assembly.
• With the flame still operating, turn the valve on the
gas cylinder in a clockwise direction until it is “Off”.
Allow the flame to burn down then extinguish once all
remaining gas in the hose has been used.
• Turn the gas controls on the appliance clockwise to the
“Off” position.
CARE INSTRUCTIONS
Using warm soapy water with a mild detergent (do not use bleach) wipe down all
surfaces and areas of the appliance, taking care not to allow water to enter the
burner outlets or aeration holes located in the burner tube.
DO NOT submerge the appliance in a sink or bowl.
DO NOT use abrasive cleaners or bleach.
OPERATING THE APPLIANCE
1. Burner Control/Ignition Knob
2. Oven Control/Ignition Knob
3. Thermometer
4. Burners
5. Cylinder Connection
6. Stove Connection
7. Hose & Regulator
Assembly
8. Windshield
9. Oven
5 6
7
8
9
1
1
3
2
4
4
COM2863_stove_oven_combo_manual_ED2.indd 3 29/07/11 4:24 PM

Distributed by
PRIMUS AUSTRALIA Pty Ltd
Bundoora Victoria 3083
www.primusaustralia.com.au
Spare Part List
1 CS-01-01S Gas Control Knob
2 CS-01-02S Gas Control Left Burner
3 CS-01-03S Gas Control Right Burner
4 CS-01-04S Gas Control Oven
5 CS-01-05S Piezo for Burners
6 CS-01-06S Thermocouple for Burners
7 CS-01-07S Gas Jet for Burners
8 CS-01-08S Stove Trivet
9 CS-01-09S Hose & Regulator Assy
10 CS-01-10S Thermometer Assy
11 CS-01-11S Gas Jet for Oven
12 CS-01-12S Thermocouple for Oven
13 CS-01-13S Piezo for Oven
14 CS-01-14S Burner for Stove
15 CS-01-15S Burner for Oven
16 CS-01-16S Foot for Stove
Code CS-01
Description Portable gas oven & cooktop
Size 540L x 300W x 460Hmm
Weight 15kg
Gas Jet
Burner: 0.675mm
Oven: 0.575mm
Consumption
Inlet Pressure: 2.75kPa
Burner: 5.6Mj/hr
116g/hr
Oven : 3.8Mj/hr
78.5g/hr
A selection of spare parts &
components are available for your
appliance to ensure years of operation
WARRANTY
This appliance is covered against faulty
workmanship and materials for a period of
12 months from the date of original purchase.
The following items are not covered by warranty:
• Blocked jet nipples
Each of these items are a serviceable part
and are readily available from your specialist
outdoor retailer.
TECHNICAL DETAILS & SPARE PARTS
1
2
1
4
1
3
9
6
8
5
14
10
13
15
16
12
11
7
