COMPANION CS-02 User manual
Part No. CS-02
PORTABLE GAS OVEN
INSTRUCTION MANUAL
IMPORTANT
Read these instructions
for use carefully.
Familiarise yourself
with the appliance
before connecting it
to its gas container.
Keep these instructions
for future reference.
AS 2658:2008
Cert. GSCS20258
SAI Global
GENERAL WARNINGS
• Thisapplianceshallonlybeusedwiththeregulatorsuppliedwiththeappliance
and can be connected to a non-refillable 468g disposable propane cartridge
certified to DOT-39, UN1075 or using an AGA or SAIGlobal certified LP Gas hose
to POL or 3/8” LH cylinder certified to AS 2469.
• Thisapplianceistobestoredinadryandwellventilatedlocationfreefrom
direct sunlight. Do not store when still connected to the cartridge. Make sure
thatthecartridgeisdisconnectedandisstoredinawellventilatedarea,free
from direct sunlight, heat and ignition sources. If being stored indoors, ensure
that the location complies with the standard AS/NZS1596.
• Thisappliancemustbeinspectedregularlyforcorrectoperationandforany
wear and tear that could result in a gas leak or incorrect operation. If any
symptomsorincorrectoperationareobservedcontactcustomerserviceand
presenttheappliancetoanAuthorisedServiceAgentforrepair.
DANGER!
• Duringoperationallsurfaceswillbeextremelyhotandshouldnotbetouched
or handled.
• Donotusetheapplianceifithasaleak,worn,deterioratedordamagedseals.
• Handlewithcareevenafterbriefuse.
• Itmaybehazardoustoattempttotothertypesofgascontainersorcartridges.
• Useonlyinwellventilatedareas.
• OUTDOOR USE ONLY – The appliance must be used outdoors only and is to
beoperatednocloserthan1000mmfromthesidesand1000mmfromabove
all combustible surfaces, fabrics and flammable materials. Must only be used
onsolidandstablehorizontalsurfacesmadefromnon-combustibleornon-
flammable materials and should be protected from direct drafts and in a well
ventilatedplace.
• Donotuseadaptorsormodifyappliancetototherconnectorsorcylinders.
• Childrenmustbesupervisedbyanadultatalltimes.
• Neverleaveapplianceunattendedwhenoperating.
• Useasacookingapplianceonly,isnottobeusedasheaterormodiedforany
other reason.
• Tobeusedwithpropane(LPGas)only.
CARBON MONOXIDE HAZARD
• Thisapplianceproducescarbonmonoxidewhichhasnoodour.Usingtheappliance
inenclosedspaces,suchascaravan,car,boatormobilehomecouldcauseDEATH.
IMPORTANT
• Keepawayfromchildrenatalltimes.
• Takecaretheopeningsatthesideandrearoftheappliancearenotobstructed,
or that air flow is restricted by placing items or other appliances close to or
adjacenttoopenings.Donotbuildthisapplianceintoacavityorenclosure.
• Thisapplianceisnotdesignedtobeusedindoorsormarineapplicationsandor
in areas that maybe subject to wind, rain or salt air.
• Surfacesoftheappliancewillbecomehotduringoperation,pleasetakecare
whenhandlingormovingtheappliance.
• Applianceistobeusedonastable,level,atnon-ammablesurface,the
applianceshouldbeprotectedfromdirectdraftsandinawellventilatedplace.
• Ifyousmellgas,immediatelyturntheapplianceoffandmovetoawell
ventilatedareaoutside,keepingwellawayfromsourcesofheatsuchasnaked
flames and pilot lights.
• Donotattempttomoveorrelocatetheappliancewhenitisoperating,
extinguishtheburnerandallowtocool,disengagethegascartridgethen
movetheappliance.
• Duringoperationiftheapplianceproducesanunusualsmell,gascanbesmelt
ortheamecanbeseenoutsideofthecoveredburnersectioninthebaseof
theoven,turntheunitoffandlocateinawellventilatedarea.Donotrepairor
removecovers-taketheappliancetoanAuthorisedServiceAgent.
CHECKING FOR GAS LEAKS
• Checkthatallconnectionsaretightandthatthegasconnectionhasbeen
tightened before you turn the appliance on.
• NEVERcheckforleakswithaameorpilotlight.
• Usingsoapywater,coatallconnections,ifbubblesappearturnthegascontrol
off and retighten the connection before re-testing.
• Inspecttheapplianceregularlyforsignsofwear,leaksorincorrectoperation.
If symptoms such as flaring of the burners, issues with lighting, damage to
connections or leaks from seals or gas controls are identified, do not attempt to
repair,returntoyourauthorisedstockistforserviceandmaintenance.
• Tocheckifgasremainsinthecartridge,disconnectfromtheapplianceandhold
inaverticalpositionthenshakefromsidetoside,ifthereisasoundorfeelof
liquidmovementinside,thecartridgecontainsgas.
• Whenchanginggascartridgesensurethisisconductedoutsideinawell
ventilatedlocationfreefrompeople,animalsandignitionsourcessuchas
naked flames, pilot lights and electrical equipment with heaters or elements.
SAFETY INSTRUCTIONS
This appliance must only be used
inanabovegroundopenair
situationwithnaturalventilation,
without stagnant areas, where
gas leakage is rapidly dispersed
bywindandnaturalconvection.
Any enclosure in which the
appliance is used should comply
with one of the following:
(A)Anenclosurewithwallson
all sides, but with no
overheadcover.
(B)Withinapartialenclosure
thatincludesanoverhead
coverandnomorethan
two walls.
1
(C)Withinapartialenclosure
thatincludesanoverhead
coverandmorethantwo
walls, the following must
apply:
(1)Atleast25%ofthetotal
wall area is completely open.
(2)30%ormoreintotalofthe
remaining wall side, back
and front wall areas is open
and unrestricted.
(3)Inthecaseofbalconies,
20%ormoreofthetotal
wall area must remain open
and unrestricted.
CONNECTION
Yourovenisdesignedtoconnectdirectlytoagascartridge
using the specially designed LP gas regulator supplied
with the appliance.
• Checkthatthecontrolknobisinthe“off”position
(turnedfullyclockwise.)
• Taketheregulatorandattachtothegasinletontherear
of the appliance, tighten using fingers.
• Attachgascartridgetoregulator.
• Checkconnectionsforleakswithsoapywater,ifaleakis
detected, retighten all connections and then retest.
LIGHTING OVEN
• Openovendoor.
• MakesuretheControl Knobissettothe“OFF”position.
• DepressandturntheControl Knob anti-clockwise until a
“click”soundisheard,checkthattheburnerisnowalight
if so hold the ignition knob in for 10 to 15 seconds then
release.
• Iftheburnerdoesnotstayalight,turntheControl Knob
tothe“OFF”positionandwaitfor5minutesbefore
attempting to relight the burner.
ADJUSTING TEMPERATURE
• TurntheControl Knob in a clockwise direction
toachieveahighertemperatureandinananti-clockwise
direction for a lower temperature or fully clockwise
toturntheappliance“OFF”.
• Theoventemperatureisdisplayedonthethermometer
located on the control panel.
TURNING THE APPLIANCE OFF
Turnthecontrolknobclockwisetothe“OFF”position.
CARE AND CLEANING INSTRUCTIONS
•Ensurethattheapplianceisnotoperatingandiscooltotouch–
internalandexternalsurfaces.
•Donotremoveanypanelsfromtheappliance.
•InternalSurfaces-Openthedoorandslidethewirerackoutandsoakinwarm
soapywater.Usingsoapywaterwithamilddetergent(donotusebleach)wipe
downallsurfaces–Donotremovetheinternalburnercover.
• ExternalSurfaces-Usingwarm,soapywaterwithamilddetergent(donotuse
bleach),wipedownallsurfacesandareasoftheappliance.
• DONOTsubmerge the appliance in a sink or bowl.
• DONOTuseabrasivecleanersorbleach.
OPERATING THE APPLIANCE
1.Oven Control/Ignition Knob
2. Thermometer
3.Ovendoor
4. Gas Connection
5. Regulator
6.PropaneBOMCartridge(soldseparately)
1
2
3
4
5
6
1
1
2
2
Distributed by
PRIMUS AUSTRALIA Pty Ltd
Bundoora Victoria 3083
www.primusaustralia.com.au
Spare Part List
1CS-02-01S OVENHANDLE
2CS-02-05S GASCONTROLVALVE
3CS-02-06S GASJET
4CS-02-07S PIEZOPIN
5CS-02-08S BURNERASSEMBLY
6CS-02-03S LEGS
7CS-02-11S THERMOMETER
8CS-01-01S CONTROLKNOB
9COMP825-01S REGULATOR
Code CS-02
Description Portablegasoven
Size* 520Lx295Wx280Hmm
Weight* 8kg
*ExcludingRegulatorandGasCartridge
Gas Jet
Oven: 0.56mm
Consumption
Inlet Pressure: 2.75kPa
Oven : 3.8Mj/hr
78.5g/hr
Aselectionofsparepartsandcomponentsareavailable
for your appliance to ensure years of operation:
WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if goods fail to be of acceptable
quality and the failure does not amount to a major failure.
For warranty and technical
support please visit
www.primusaustralia.com.au
or call 1300 555 197
TECHNICAL DETAILS & SPARE PARTS
6
9
1
8
2
3
4
5
7
